Citroen C3 RHD 2013 2.G Owner's Manual

12
Technical data
189
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Petrol weights and towed loads (in kg)
Petrol enginesVTi 95VTi 120
GearboxesElectronicManualAutomatic
Model codes: SC...8FP0/P5FS05FS9


- Unladen wei
ght 1 079
1 075
1 089



- Kerb weight 1 154 1 150
1 164


- Gross vehicle wei
ght (GV W)

1 581
1 579

1 612


-
Gross train weight (GTW)
on a 12 % gradient 2 481
2 479
2 512



- Braked trailer
(within the GTW limit)
on a 12 % gradient 900
900
900



- Braked trailer *
(with load transfer within the
GTW limit) 1 150
1 1501 150



-
Unbraked trailer 570570
570



- Recommended nose weight
4646

46

* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
190
For more information on the operation and use of your LPG vehicle, refer to the specific insert attached to the other vehicle documents.
























LPG engine and gearbox

Model codes:SC...KFT0/GPLKFT0/1GPL
Engine1.4 i
Gearbox

Manual(5-speed)


Cubic capacity (cc)

1 360

Bore x stroke
(mm)75 x 77
Max. power: EU standard
(kW)
*
51.5 / 54
Max. power speed
(rpm) 5 200 / 5 200
Max torque: EU standard
(Nm)
115 / 118

Max. torque speed
(rpm) 3 300 / 3 300

Fuel LPG / Unleaded

Catalytic conver ter

Yes
OIL CAPACITY (in litres)


Engine (with filter replacement) 3.0
*
The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).

12
Technical data
191
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
LPG weights and towed loads (in kg)
Engines1.4 i
GearboxeManual
Model codes:SC...KFT0/GPLKFT0/1GPL


- Unladen wei
ght 1 070



- Kerb wei
ght 1 145


- Gross vehicle wei
ght (GV W)

1 529



- Gross train weight (GTW)

on a 12 % slope 2 329



- Braked trailer
(within GTW limit) on a 12 % slope
1 000



- Braked trailer *
(with load transfer within the
GTW limit)
1 000



-
Unbraked trailer 500



- Recommended nose wei
ght 44

* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
192
*
The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).
























Diesel engines and gearboxes
Model codes: SC...8HR48HP4/PS9HK0
EnginesHDi 70 PEFe-HDi 70 PEFHDi 75
GearboxesManual (5-speed)Electronic(5-speed)


Manual (5-speed)


Cubic capacity (cc)
1 398
1 398

1 560

Bore x stroke
(mm)

73.7 x 8273.7 x 82 75 x 88.3

Max. power: EU standard (kW)
*
50
5055
Max. power engine speed
(rpm) 4 000
4 000 4 000
Max. torque: EU standard
(Nm)160

160

185

Max. torque en
gine speed (rpm) 1 750

1 750
1 500

Fuel
Diesel Diesel
Diesel

Catalytic conver ter Yes
Yes
Yes

Particle emissions filter (PEF) Ye s
Ye s
No

OIL CAPACITIES
(in litres)







Engine (with filter replacement) 3.75
3.75
3.75

.../S
:e-HDi model fitted with Stop & Start.

12
Technical data
193
.../S : e-HDi model fitted with Stop & Start.
* The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).
Model codes:SC...9HJ09HP09HPK/S9HP8/PS9HR8/S
EnginesHDi 90HDi 90 PEFe-HDi 90 PEFe- HDi 115 PEF
Gearboxes

Manual(5-speed)


Manual(5-speed)


Manual(5-speed)


Electronic gearbox system(6-speed)

Manual(6-speed)
Cubic capacity (cc) 1 560
1 560

1 5601 560

Bore x stroke
(mm)
75 x 88.3
75 x 88.3 75 x 88.3
75 x 88.3

Max. power: EU standard (kW)
* 68
6868
84
Max. power engine speed
(rpm)
4 000
4 000
4 000 3 600
Max. torque: EU standard
(Nm)

230

230230

270

Max. torque speed
(rpm)
1 750

1 750

1 750
1 750

Fuel DieselDiesel
Diesel
Diesel

Catalytic converter
Yes

YesYes

Yes

Particle emissions filter (PEF) No
Ye sYe s
Ye s
OIL CAPACITIES (in litres)


Engine (with filter replacement)
3.75
3.753.75
3.75


Diesel engines and gearboxes

Technical data
194
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Diesel weights and towed loads (in kg)
EnginesHDi 70 PEFe-HDi 70 PEFHDi 75
GearboxesManualElectronicManual
Model codes:SC...8HR48HP4/PS9HK0


- Unladen wei
ght
1 070

1 080
1 118



- Kerb weight 1 1451 155 1 193



- Gross vehicle wei
ght (GV W)
1 581
1 610

1 592


-
Gross train weight (GTW)
on a 12 % gradient2 2812 310 2 492



- Braked trailer
(within GTW limit) on 12 % gradient700
700
900



- Braked trailer *
(with load transfer with the
GTW limit) 950
9501 150



- Unbraked trailer
570570
570



- Recommended nose wei
ght
46

46
46
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

12
Technical data
195
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Diesel weights and towed loads (in kg)
EnginesHDi 90HDi 90 PEFe-HDi 90 PEFe- HDi 115 PEF
GearboxesManualManualManualElectronicManual
Model codes:SC...9HJ09HP09HPK/S9HP8/PS9HR8/S



- Unladen weight
1 142
1 080

1 085

1 090

1 090



- Kerb wei
ght 1 217 1 155 1 160
1 165 1 165


- Gross vehicle wei
ght (GV W)
1 6051 6081 625
1 634
1 648



- Gross train weight (GTW)
on a 12 % slope 2 505 2 508
2 5252 534 2 548



- Braked trailer
(within the GTW limit)

on a 12 % slope 900
900
900
900
900



- Braked trailer *
(with transfer of load within
the GTW limit)
1 150

1 150

1 150

1 150

1 150



- Unbraked trailer 570
570
570
570
570



- Recommended nose wei
ght
46
46
46
46
46


* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
196





Dimensions (in mm)

12
Technical data
197

















Identifi cation markings
B. Vehicle identification number on the dashboard.
This number is indicated on a self-adhesive label which is visible through the windscreen. C. Manufacturer's label
.The VIN is indicated on a self-destroying labelaffixed to the left hand centre pillar. It bears the followin
g information:


- the tyre pressures, for unladen and
laden conditions,
- the wheel rim and tyre sizes,

- the brands of tyre recommended by themanufacturer,

- the spare tyre inflation pressure,

- the paint colour code.

Wheels which are fitted with 205/45 R17tyres cannot be fitted with snow chains. For more information, contact a CITROËN dealer or a qualifiedworkshop.
The tyre pressures must be checked when the tyres are cold, at least oncea month.

Low tyre pressures increase fuelconsumption. A.
Vehicle identification number (VIN) under the bonnet. This number is engraved on the bodywork near
the passenger compar tment filter. Various visible markings
for the identification of your vehicle.
D. Tyre/paint label.
This label is affixed to the left hand centre pillar.

Technical data
198
