steering wheel adjustment Citroen C4 2008.5 1.G Owner's Manual

14
F A M I L I A R I S A T I O N
S I T T I N G C O M F O R T A B L Y

1. Unlock the steering column using
the lever.

2. Lock the steering column with the
lever.

3. Adjust the position of the steering
wheel for height and reach.
Manual adjustment of steering
wheel height and reach

 55 Front seat belt

1. Locking.

 99
Adjustment of front head
restraints
Adjustment of rear head restraints

 52
Height and angle.

A. Low position.

B. High position.
A. Height adjustment (5-door).

B. Storing the seat belt (3-door).

 49

55
III
C O M F O R T
Interior mirror
Adjustable mirror providing a central
rearward view.
Manual model
The mirror is fi tted with a night-time
anti-dazzle device.
Adjustment

 Adjust the mirror so that the
glass is directed correctly in the
"day" position.
Day/night position

 Pull the lever to change to the
"night" anti-dazzle position.

 Push the lever to change to the
normal "day" position.

In order to prevent dazzle, the inte-
rior mirror glass darkens automati-
cally depending on the intensity of
the light from the rear.
It lightens when the light (light beam
of following vehicles, sun...) de-
creases, so guaranteeing optimum
visibility.
Switching on

 Switch on the ignition and press
switch 1 .
The indicator light 2 comes on and
the mirror operates automatically.
Switching off

 Press switch 1 .
The indicator light 2 switches off and
the mirror remains in its lightest state.
In order to guarantee optimum vis-
ibility when manoeuvring the vehi-
cle, the mirror lightens automatically
when reverse gear is engaged.
STEERING WHEEL ADJUSTMENT
The height and reach of the steer-
ing wheel can be adjusted to adapt
the driving position to the size of the
driver.
Adjustment

 First, adjust the driver's seat to
the most suitable position.

 When stationary , pull the con-
trol to unlock the steering wheel.

 Adjust the height and reach.

 Push the control to lock the
steering wheel.
After locking, if you press fi rmly on
the steering wheel, a slight click may
be heard.
As a safety precaution, the mirrors
must be adjusted to reduce the
"blind spot". Automatic day/night model
System which automatically and
progressively changes between day
and night use.
As a safety precaution, it is impera-
tive that these operations are carried
out while the vehicle is stationary.

117
IX
D R I V I N G
*
To comply with legislation in certain coun-
tries, the "Menu" control may be deacti-
vated while the vehicle is in motion.
Multifunction screen controls

A. Selection of the type of informa-
tion to be displayed on the right
of the screen (radio, trip compu-
ter, navigation/guidance…).
For the multifunction screen A, choice of activation/deactivation
of your functions and adjustment
choices.

B. Access to the "Main Menu" * .

C. Validation of the function chosen
or of the value modifi ed.
Pick up/Hang up (see chapter "Audio").

D. Scrolling in the multifunction
screen.

E. Cancellation of the current op-
eration or return to the previous
display. SPEED LIMITER
System which prevents the vehi-
cle from exceeding the speed pro-
grammed by the driver.
Once the limit speed has been
reached, the accelerator pedal no
longer has any effect.
The speed limiter is switched
on manually: a speed of at least
30 km/h (around 20 mph) must be
programmed.
The speed limiter cannot, in any cir-
cumstances, take the place of the
observance of speed limits or of the
vigilance and responsibility of the
driver.
Steering wheel controls
The speed limiter controls are locat-
ed on the left-hand side of the steer-
ing wheel.
Displays on the instrument panel
The programmed information is
grouped together in zone A of the
instrument panel display.
Programming
Rotate the control 1 to the "LIM" po-
sition.
On selection of the function, the pre-
vious memorised speed and the in-
formation "OFF" are displayed :
With the engine running, you can
adjust the memorised maximum
speed, by means of short or long
presses on :

 button 4 to increase the memo-
rised maximum speed,

 button 2 to decrease the memo-
rised maximum speed.
Successive presses will modify the
maximum speed in steps of 1 mph
and a sustained press in steps of
3 mph.

117
IX
D R I V I N G
*
To comply with legislation in certain coun-
tries, the "Menu" control may be deacti-
vated while the vehicle is in motion.
Multifunction screen controls

A. Selection of the type of informa-
tion to be displayed on the right
of the screen (radio, trip compu-
ter, navigation/guidance…).
For the multifunction screen A, choice of activation/deactivation
of your functions and adjustment
choices.

B. Access to the "Main Menu" * .

C. Validation of the function chosen
or of the value modifi ed.
Pick up/Hang up (see chapter "Audio").

D. Scrolling in the multifunction
screen.

E. Cancellation of the current op-
eration or return to the previous
display. SPEED LIMITER
System which prevents the vehi-
cle from exceeding the speed pro-
grammed by the driver.
Once the limit speed has been
reached, the accelerator pedal no
longer has any effect.
The speed limiter is switched
on manually: a speed of at least
30 km/h (around 20 mph) must be
programmed.
The speed limiter cannot, in any cir-
cumstances, take the place of the
observance of speed limits or of the
vigilance and responsibility of the
driver.
Steering wheel controls
The speed limiter controls are locat-
ed on the left-hand side of the steer-
ing wheel.
Displays on the instrument panel
The programmed information is
grouped together in zone A of the
instrument panel display.
Programming
Rotate the control 1 to the "LIM" po-
sition.
On selection of the function, the pre-
vious memorised speed and the in-
formation "OFF" are displayed :
With the engine running, you can
adjust the memorised maximum
speed, by means of short or long
presses on :

 button 4 to increase the memo-
rised maximum speed,

 button 2 to decrease the memo-
rised maximum speed.
Successive presses will modify the
maximum speed in steps of 1 mph
and a sustained press in steps of
3 mph.
