display Citroen C4 AIRCROSS 2012 1.G Workshop Manual

249
04AUDIO / VIDEO


INFORMATION DISPLAYED IN MUSIC SERVER MODE
The number and the name of the track



A. currently being played are displayed.
The number and the name of the playlist B. currently being played are displayed.
The name of the artist is displayed for theC. playlist currently being played.
The playing time of the track currently D. being played is displayed.
The playing mode currently selected isE. displayed.
Group lists: position of the cursor and total F. number of groups.
Playlists: position of the cursor and total number of playlists.
Track lists: position of the cursor and total number of tracks.
To display the list of groups, the playlist

G. and the list of tracks.
To scroll up or down through the tracks.

H.
Press and hold for fast backwards or forwards playing of a track.
To scroll up or down through the playlists.

I.
Group lists: number and name of the

J. group.
Playlists: number and name of the playlist.
Track lists: number and name of the track.
To display the secondary menu.

K.
Displays the item currently selected.

L.
Move the cursor onto the track currently

M. being played.
ABCD
E
F
G
HIJK
L
M

253
04AUDIO / VIDEO


INFORMATION DISPLAYED IN MP3/WMA CD MODE
The number and the name of the track



A. currently being played are displayed.
The name of the album/folder is displayedB. for the track currently being played.
The name of the artist is displayed for theC. track currently being played.
The playing time of the current track is D. displayed.
The playing mode currently selected isE. displayed.
Position of the cursor and total number of F. folders or tracks on the current level.
To display the list of folders of a higher G. level.
Displays the item currently selected.H.
To scroll up or down through the tracks.I.
Press and hold for fast backwards or forwards playing of a track.
To scroll up or down through the folders.J.
Displays the folder number and the folder K. name. Plus the lists and numbers of
tracks and the name of the fi le (without extension).
To display the secondary menu.L.
Move the cursor onto the track currentlyM. being played.
Displays the type of medium, MP3 or N. WMA.


The
CD button is only active if the player contains a CD.

Press
Open to return the screen to the verticalposition.
ABC
EF
G
IKL
M
N
D
H
J

254
04AUDIO / VIDEO


PLAYING AN MP3/WMA CD (1/2)

Press


Explanation

Result
Press the M
ODE button then CD, if the player already contains a CD.
Movin
g around the folders
Selectin
g a folder

Otherwise, insert a CD in the player, play begins automatically.
You can move b
y one level at a time.
Press on the name o
f a folder and at each press the list of folders of the level below is
displayed.
Press on the folder above to move up and/or select a level.
Press [
Folder] to select the previous folder.
Press [Folder
 ] to select the next folder.
These displays indicate the current level:
CD: level 0, folder below: level, folder below that, level 2, etc ...
Up to 8 levels.

256
04
INFORMATION DISPLAYED IN DVD MODE
AUDIO / VIDEO


The DVD button is only active if the player contains a DVD.
Press
Open to return the screen to the vertical position.
For safet
y reasons, the video is notdisplayed while driving, however the audiocan be played.
To displa
y the picture and watch a DVD, park the vehicle in a safe place.
To play the previously selected zone on

J. the disc.
To display the DVD title menu.

K.
To scroll up or down through the chapters.

L.
Press and hold for fast backwards or forwards play.
To scroll up or down through the titles.

M.
To enter a title or chapter number.

N.
To change the angle.

O.
To change the language of the subtitles.

P.
To change the language.

Q.
To select a chapter or title or specify a

R. number.
This icon is displayed when the operation



A. requested cannot be carried out.
The number of the chapter currently beingB. played is displayed.
The number of the title currently being C. played is displayed.
Symbols display the current status of theD. player.
The playing time is displayed. E.
To resume normal play when play isF. paused or during slow-motion play.
To stop play temporarily.G.
To stop play. Press the screen to accessH. the menu.
For slow-motion play. I.
ABCDE
FGHIJ
KLM
RQPON

257
04AUDIO / VIDEO

Result

Explanation
Selectin
g a chapter Press the M
ODE button then DVD, if the player already contains a DVD.
Otherwise, insert a DVD in the player, the picture is displayedautomatically. Press the screen to access the menus.
While driving, only the soundtrack is played and no picture is displayed.
Press [
 Chapter] to select the previous chapter or return to the beginning of the chapter currently being played.
Press and hold
for fast backwards play.
Press [
Chapter  ] to select the next chapter.
Press and hold
for fast forwards play.
Selectin
g a title
Press [ Title] to select the previous title.
Press [Title ] to select the next title.
Press

PLAYING A DVD

258
05
DISPLAY SCREEN, SOUND, PICTURE
SETTINGS
- Choose to switch off the screen.

A

To switch it back on, touch the screen or press any button.
- Choose the settings of the sound in the
B vehicle, if an audio source is selected(FM, CD, ...), for:
- the sound distribution or the volume
B1 such as the front-rear balance, the bass,
the medium, the treble, the volume
adjustment in relation to the vehicle
speed,
- the type of music (with surround option) B2 such as classic, jazz, pop, rock, hip hop,country, normal, ...
- the sound fi eld (with surround option) B3 such as stage, live, hall, normal, ...
- Choose the quality of the picture for: C
- the colour (when playing DVDs), C1
- the intensity of the colours (when playing C2 DVDs),
- the brightness, C3
- the contrast, C4
- the level of black. C5
B1B2
B3
C1C2C3C4C5
ABC

260
05

EQUIPMENT, CONTRAST, TRAFFIC INFORMATION (TP)
SETTINGS
- Choose to adjust or set the parameters of F certain equipment offered in your vehicle(e.g.: unfolding/folding of the mirrors,closing the windows on locking, timingand sensitivity of the automatic lighting,
direction indicators motorway function, ...):
- to scroll up the list, F1
- to scroll down the list, F2
- to reinitialise all of the settings F3 (manufacturer's settings).
Press each setting to select or change the parameters.
- Choose to adjust the contrast of the G display in relation to the ambient light level(day, night or automatic).
- Choose to activate or deactivate the H traffi c information (TP).

HG
F
F1
F2
F3

265
07USB PLAYER
The number and the name of the track


A. currently being played are displayed.
The name of the album/folder is displayedB. for the track currently being played.
The name of the artist is displayed for theC. track currently being played.
The playing time of the current track is D. displayed.
To display the list of folders of higher E. levels.
To display in list mode. F.
To scroll up or down through the tracks.G.
Press and hold for fast backwards or forwards playing of a track.
To scroll up or down through the folders. H.
To display the secondary menu.I.
Move the cursor to the track being played.J.
Display the format of the current fi le: MP3, K. WMA, AAC, WAV.
Displays the type of medium: USB or iPod.

L.
INFORMATION DISPLAYED IN USB OR AUX MODE
or
ABC
D
E
GI
J
K
F
L
H

266
07USB PLAYER
The number and the name of the track


A. currently being played are displayed.
The name of the album/folder is displayedB. for the track currently being played.
The name of the artist is displayed for theC. track currently being played.
The playing time of the current track is D. displayed.
To display/sort each category:E.
The item currently selected and beingF. played is highlighted.
To scroll up or down through the tracks.G.
Press and hold for fast backwards or forwards playing of a track.
To display the secondary menu.H.
Move the cursor onto the track currentlyI. being played.
Displays the type of medium: USB or iPod.

J.
INFORMATION DISPLAYED IN IPOD (OR APPLE® PLAYER) MODE ®
Go to the root
Artists
Albums
Songs
Genres

Pla
ylists
ABC
D
E
GH
I
J
F

267
07
PLAYING A TRACK (1/2)
Press


Explanation

Result
Pr
ess the MODE button then on USB/iPod.
USB PLAYER
Press on a track to play it.
In iPod mode: you can display / sort by category at any time.
In USB or AUX mode: you can press the next folder up at any time, to go up one level/or select a level.
Press [

Track] to select the previous track or return to the beginning of the track currently being played.
Pr
ess and hold for fast backwards. Selectin
g a previous / next track
Press
[Track] to select the next track.
Pr
ess and hold for fast forwards.
