Page 227 of 368
9
225
Te c h n i c a l d a t a
*
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
Engines and gearboxes
.../S
: model fitted with the Stop & Start (AS&G) function.
PETROL ENGINES
1.6 litre 115
2.0 litre 150
Model codes
:
BU
...
NKZ7
NKZ7/S
NKZ0
NKZ0/S
AFYR
AFZ7
AFYV
AFZM
AFYT
AFZH
AFYW
AFZP
Tr a n s m i s s i o n m o d e
2WD
2WD
4WD
2WD
4WD
Cubic capacity (cc)
1 590
1 998
Bore x stroke (mm)
75 x 90
86 x 86
Max power * : EU standard (kW)
86
113
Max power engine speed (rpm)
6 000
6 000
Max torque: EU standard (Nm)
15 4
19 9
Max torque engine speed (rpm)
4 000
4 200
Fuel
Unleaded
Unleaded
Catalytic conver ter
Ye s
Ye s
GEARBOXES
Manual
(5-speed)
Manual
(5-speed)
CVT
(6-speed)
OIL CAPACITY (in litres)
Engine (with filter replacement)
4.2
4.3
Page 234 of 368
232
Te c h n i c a l d a t a
*
The maximum power corresponds to the value type-approved on a test bed, under conditions defined in European legislation (Directive 1999/99/EC).
DIESEL ENGINES
1.6 HDi 110
1.8 HDi 150
Model codes :
BU...
9HD8/S
9HDB/S
6HZ8/S
6HZB
6HZB/S
Tr a n s m i s s i o n m o d e
2WD
4WD
2WD
4WD
Cubic capacity (cc)
1 560
1 798
Bore x stroke (mm)
77 x 88.3
83 x 83.1
Max power * : EU standard (kW)
84
11 0
Max power engine speed (rpm)
3 600
4 000
Max torque: EU standard (Nm)
270
300
Max torque engine speed (rpm)
1 750
2 000 to 3 000
Fuel
Diesel
Diesel
Catalytic conver ter
Ye s
Ye s
Particle emission filter (PEF)
Ye s
Ye s
GEARBOXES
Manual
(6-speed)
Manual
(6-speed)
OIL CAPACITY (in litres)
Engine (with filter replacement)
3.75
5.3
Engines and gearboxes
.../S
: model fitted with the Stop & Start (AS&G) function.
Page 339 of 368
.
337 Alphabetical index
ABS and EBFD systems ............................... 148
Accessories .................................................. 210
Accessory socket, 12V .................100, 102, 103
Access to bulbs ............................................. 188
Adjusting headlamps .................................... 139
Adjusting head restraints ................................83
Adjusting seat belt height ............................. 152
Adjusting the steering wheel ..........................89
Airbag, knee ..........................................158, 160
Airbags, curtain ..................................... 159, 160
Airbags, front.........................................156, 160
Airbags, lateral ......................................158, 160
Air conditioning ...............................................22
Air conditioning, automatic ....................... 91, 94
Air conditioning, manual ........................... 91, 92
Air filter ..........................................................222
Air flow ............................................................90
Air intake ............................................ 90, 93, 96
Air vents ..........................................................90
Alarm ............................................................... 75
Anti-lock braking system (ABS) .................... 148
Anti-theft ....................................................... 112
Apple
® player ............................... 283, 308, 330
Armrest, front ..................................84, 100, 103
Armrest, rear ...................................................86
ASC ............................................................... 150
Ashtray, portable ...................................100, 102
Audible warning ............................................ 147
Audio- CD ......................319, 321, 325, 334, 335
Audio streaming
(Bluetooth) ..........................................292, 332
Audio systems ............................... 255, 293, 313
Audio-telematics ...........................................255
Automatic illumination
of headlamps ...................................... 134, 136
Automatic operation of hazard warning
lamps .......................................................... 147Automatic rain sensitive windscreen
wipers ......................................................... 142
Automatic switching off of lighting ................ 136
Auxiliary socket .....................................104, 329
AC
Capacity, fuel tank ........................................ 216
CD MP3 ......................................... 281, 307, 325
Central locking .................................... 62, 66, 74
Changing a bulb .....................................188 -193
Changing a fuse .................................... 194-199
Changing a wheel .................................. 181-186
Changing a wiper blade ................................203
Changing the date ...........................................56
Changing the remote control battery .............. 70
Changing the time .............................. 54, 56, 58
Checking levels ..................................... 219 -221
Checking the engine oil level ........................ 219
Checks ...................................214, 215, 219 -224
Children .................................. 155, 157, 161-176
Child lock ....................................................... 176
Child seats ............................ 161, 162, 166 -175
Cigarette lighter............................................. 102
Closing the boot .............................................. 73
Closing the doors ............................................ 72
Colour screen ....................... 256, 259, 294, 297
Connectors, audio ................ 104, 282, 329, 330
Controls for air conditioning ......................92, 94
Coolant ............................................................46
Coolant level .................................................220
Courtesy lamp, front ..................................... 144
Courtesy lamp, rear ...................................... 144
Cruise control ................................................ 126
Cup holder ..................................................... 100
CVT gearbox ......................................... 115, 223 Battery .................................................. 200, 222
Battery, charging ...........................................202
Battery, remote control ............................. 70, 71
Bluetooth (telephone) ....................243, 292, 310
Bluetooth telephone with voice
recognition .......................................... 243 -254
Bonnet ........................................................... 213
Bonnet stay ................................................... 213
Boot ................................................................. 73
Boot lamp ...................................................... 146
Bottle holder .................................................. 100
Brake discs ....................................................224
Brake lamps .................................................. 192
Brake pads ....................................................224
Brakes ...........................................................224
Braking assistance system ........................... 148
Bulbs (changing, type) ...........................188 -193
Date (setting) ...................................................56
Daytime running lamps .........................136, 190
B
D
