81
VI
L A Y O U T
REMOVABLE ASHTRAY
Pull the cover to open the ash-
tray.
T o e m p t y i t , r e m o v e t h e a s h t r a y
by pulling it upwards.
LIGHTER/12 V ACCESSORIES SOCKET
T o u s e t h e l i g h t e r , p r e s s i t i n a n d
wait a few seconds until it pops
out automatically.
To connect a 12 V accessory
( m a x p o w e r : 1 0 0 W a t t s ) , c o n n e c t
a suitable adaptor to the socket
on the centre console.
Operates with the ignition on.
USB BOX
T h i s c o n n e c t i o n b o x , c o n s i s t i n g o f
a J A C K s o c k e t a n d a U S B p o r t , i s
located on the centre console.
It permits the connection of portable
e q u i p m e n t , s u c h a s a d i g i t a l a u d i o
player of the iPod ®
or USB stick type.
I t r e a d s t h e a u d i o fi l e f o r m a t s w h i c h
are transmitted to your audio equip-
ment and played via the vehicle's
speakers.
Y o u c a n m a n a g e t h e s e fi l e s u s i n g
the steering wheel controls or the
audio equipment control panel and
display them on the multifunction
screen.
W h e n i t i s i n u s e , t h e p o r t a b l e e q u i p -
ment charges automatically.
For further details concerning the
u s e o f t h i s e q u i p m e n t , r e f e r t o t h e
"Audio and Telematics" section.
Page 92 of 282
82
VI
L A Y O U T
Storage pockets in the front doors and rear panels
Storage pockets
STORAGE DRAWERS
To open
Press at the centre of the drawer.
T o r e t r i e v e a n o b j e c t , l i f t t h e d r a w e r
up using the aperture provided.
Flap
P r e s s a t t h e c e n t r e o f t h e fl a p .
Page 93 of 282
83
VI
L A Y O U T
Oddments tray on front
central console
Grab handles/Coat hooks
MAT
Removable cover which protects the
c a r p e t a g a i n s t e x t e r i o r d i r t .
Fitting
W h e n fi t t i n g t h e m a t f o r t h e fi r s t t i m e ,
u s e o n l y t h e fi x i n g s p r o v i d e d i n t h e
bag attached.
Removal
To remove the mat on the driver's
s i d e :
move the seat as far back as
p o s s i b l e ,
u n c l i p t h e fi x i n g s ,
remove the mat. Refitting
T o r e fi t t h e m a t o n t h e d r i v e r ' s s i d e :
p o s i t i o n t h e m a t c o r r e c t l y ,
r e fi t t h e fi x i n g s b y p r e s s i n g ,
check that the mat is secured
correctly.
To avoid any risk of jamming of the
p e d a l s :
- only use mats which are suited t o t h e fi x i n g s a l r e a d y p r e s e n t i n
t h e v e h i c l e ; i t i s i m p e r a t i v e t h a t
t h e s e a r e u s e d ,
- n e v e r fi t o n e m a t o n t o p o f another.
Page 94 of 282
84
VI
L A Y O U T
REAR ARMREST
Comfort and storage device for the
rear passengers.
Lower the rear armrest for a
more comfortable position.
Raise the cover to gain access
to its storage compartment.
T h i s h a s a s t o r a g e t r a y , t w o c a n
holders and two pen holders.
LASHING RINGS
Use the 6 lashing rings on the lug-
g a g e c o m p a r t m e n t fl o o r t o s e c u r e
your loads.
You can use suitable load retainers
( h a l f - h e i g h t p a r t i t i o n s , g r i l l e , e t c . )
supplied by the CITROËN network.
It is recommended that the load is
i m m o b i l i s e d b y s e c u r i n g i t fi r m l y u s i n g
t h e l a s h i n g r i n g s o n t h e fl o o r .
Hooked onto the stowing rings by
m e a n s o f r e a r s i d e fi x i n g s , t h i s e n a b l e s
you to secure your luggage.
Luggage retaining net
Page 95 of 282
79
VI
L A Y O U T
SUN VISOR
TOLL CARD/CAR PARK TICKET WINDOWS
The athermic windscreen limits
heating of the passenger compart-
ment by reducing the effects of the
sun's rays (ultra-violet). It consists
o f a r e fl e c t i v e l a y e r , w h i c h a l s o
blocks certain radio-electric signals
( t o l l c a r d p a y m e n t s , . . . ) .
F a c i l i t y f o r a f fi x i n g t o l l c a r d s a n d / o r
car park tickets.
These windows are located on each
side of the base of the interior mirror.
T h e y a r e t w o n o n - r e fl e c t i v e a r e a s o f
the athermic windscreen.
System which protects against sun
from ahead or from the side and
courtesy system with illuminated
mirror.
W i t h t h e i g n i t i o n o n , l i f t t h e fl a p ;
the mirror is illuminated automati-
cally.
T o p r e v e n t d a z z l e f r o m a h e a d , f o l d
the visor downwards.
It can be disengaged from its central
fi x i n g a n d p i v o t e d o v e r t o t h e s i d e
windows if required.
PANORAMIC GLASS ROOF
System which consists of an area of
panoramic tinted glass to increase
the light and visibility in the pas-
s e n g e r c o m p a r t m e n t . I t i s fi t t e d w i t h
2 independent manual blinds to help
maintain a comfortable tempera-
ture.
Opening
Raise the blind's handle and
release.
E a c h b l i n d i s fi t t e d w i t h a r o l l e r w h i c h
stores it once you release it.
Closing
Front blind
Pull the blind rearwards until it
locks in.
Rear blind
Pull the blind forwards until it
locks in.
Page 96 of 282
80
VI
L A Y O U T
ILLUMINATED GLOVE BOX
