Page 121 of 256
C
D
A
BB
III
121
R E A R C E N T R A L S E AT B E LT -
C 4 P i C A S S o A N d G R A N d C 4 P i C A S S o
Routing of the seat belt
(C4 Picasso and C4 Grand
Picasso)
- insert the tongue
C into the
buckle on the right, then insert
the second tongue D into the
buckle on the left.
Before use
For safety reasons, it is essential that the seat belt passes th rough the relay ring.
To prevent any damage to seat belts and in order not to get them jammed, take care to stow
them on the sides of the backrests.
Installation of the seat belt
(C4 Picasso)
1.
open the cover
A.
2. Remove the belt tongues from
their housing.
3. Bring the belt tongues up to
the relay ring
B.
4. insert the attachment then
pass the tongues through the
ring.
5. Reclose the cover
A. Make
sure that the belt is correctly
positioned in the recess in the
cover provided for this pur-
pose. Stowage of the belt tongues
(C4 Picasso) -
operate in reverse order to stow
the belt tongues.
Note : You may opt to leave the
seat belt in the relay ring even if
not using it.
Page 122 of 256
122III
Stowing the tongue of the third-row seat belt
Secure the tongue in the place provided on the rear
pillar trim.
Note :
The third-row passenger seat belts that are not
being used can be stowed in order to free up load-
space and facilitate use of the luggage cover.
Requirements for the third-row passenger seat
belts
Take care to attach the third-row passenger seat belts
on the rings provided for this purpose.
Do not attach the belts on the anchoring points
marked with a red cross (see illustration above).
T H i R d R o W S E AT B E LT S -
G R A N d C 4 P i C A S S o
Before use :
To avoid damaging or jamming the seat belts,
take care to stow them on the sides of the backrests.
Page 125 of 256
III
125
TABLE SUMMARISING CHILD SEATS SECURED BY MEANS OF THE VEHICLE SEAT BELT
in conformity with directive 2000/3, the table tells you to what extent each of the seat positions in your vehicle may
take a child seat that is secured by means of the vehicle seat b elt and approved as « Universal » (child seat that
can be used in any vehicle in conjunction with the vehicle se at belt) as a function of the weight of the child.
Consult « User Precautions », chapter on « Child Safety » at the end of this handbook, in order to ensure
that you are installing your child in conditions of maxi mum safety.
C H i L d R E S T R A i N T S
For seats in groups 1, 2 and 3, check that the child seat is correctly secured on the backrest of the
vehicle seat. If necessary, remove and stow the head re straint.
It is imperative to deactivate the front passenger airbag i f you are installing a « rear-facing » child
seat in the front passenger seat position.
T a k e c a r e t o c o m p l y w i t h t h e fi t t i n g i n s t r u c t i o n s g i v e n i n t h e c h i l d s e a t m a n u f a c t u r e r ’ s u s e r
guide.
To install a large child seat, rear-facing or forward-faci ng, on one of the rear seats, slide the seat
rearwards so that the child seat is not hampered by the fr ont seat.
Seat position
Weight groups established by legislation
< 10 kg and < 13 kg (groups 0 and 0+) 9 – 18 kg
(group 1) 15 – 25 kg
(group 2) 22 – 36 kg
(group 3)
1 st
row* Front passenger U U U U
2 nd
row Lateral U U U U
Central U U U U
3 rd
row** Lateral U U U U
U
: Seat position suitable for the installation (in conjunction with the vehicle seat belt) of a universal rear-facing
child seat and a universal forward-facing child seat.
* :
Before installing your child in the front passenger seat position, refer to the chapter on Child Safety, paragraph on
« Rules for transporting of children in the front p assenger seat position ».
** :
Applies only to the 7 seater model.
