74
IV
A C C E S S
Lost keys
Visit a CITROËN dealer with the ve-
hicle’s V5 registration certifi cate and
your personal identifi cation docu-
ments.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a
replacement key.
Remote control
The high frequency remote control
is a sensitive system; do not operate
it while it is in your pocket as there
is a possibility that it may unlock the
vehicle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle. You
run the risk of stopping it from work-
ing and the remote control would
have to be reprogrammed.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off,
except for reprogramming.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to the
electronic engine immobiliser sys-
tem, this could cause malfunctions.
When purchasing a
second-hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collec-
tion point.

72
IV
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Drive position
Depending on the version of your
vehicle, the orange and red warning
lamps should also come on for a short
time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off
the ignition. Wait ten seconds then
operate the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the
steering. The key can only be re-
moved in position S .

2.
"M": Ignition switched on, the
steering is unlocked (by turning
the key to position M , move the
steering wheel gently if neces-
sary).

3. "D": Starter position.
Never turn the key to this position
when the engine is running.
Key in ignition buzzer
If you forget to remove the key from
the ignition, a buzzer sounds when
the driver's door is opened.
DO NOT RUN THE ENGINE IN AN
ENCLOSED SPACE OR WHERE
THERE IS INSUFFICIENT
VENTILATION.

IT IS ESSENTIAL ALWAYS TO
KEEP THE ENGINE RUNNING
IN ORDER TO RETAIN BRAKING
AND STEERING ASSISTANCE
.

NEVER REMOVE THE IGNITION
KEY BEFORE THE VEHICLE HAS
COME TO A COMPLETE STOP.
STOPPING
Vehicles equipped with
a turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.

73
IV
A C C E S S
Remote control problem
Following disconnection of the ve-
hicle battery, replacement of the re-
mote control battery or in the event
of a remote control malfunction, you
can no longer unlock, lock or locate
your vehicle.

 First of all, use the key in the lock
to unlock or lock your vehicle.

 Then, reinitialise the remote
control.
If the problem persists, contact
a CITROËN dealer as soon as
possible.
Reinitialisation

 Switch off the ignition.

 Turn the key to position 2
(Ignition) .

 Press the closed padlock imme-
diately for a few seconds.

 Switch off the ignition and re-
move the key from the ignition
switch.
The remote control is fully opera-
tional again. Battery ref.: CR0523/3 volts.
This replacement battery is avail-
able from CITROËN dealers.
If the battery is fl at,
you are informed by
lighting of this warning
light, an audible signal
and a message on the
multifunction display.

 Unclip the casing using a coin at
the notch.

 Slide the fl at battery out of its
location.

 Slide the new battery into its
location observing the original
direction.

 Clip the casing.

 Reinitialise the remote control.
Changing the battery

75
IV
A C C E S S
ALARM
System which protects and provides
a deterrent against the theft of your
vehicle. It provides two types of pro-
tection, exterior and interior, as well
as an anti-tamper function.
Exterior protection
The system detects opening of the
vehicle.
The alarm is triggered if anyone tries
to enter the vehicle by forcing a door,
the boot or the bonnet.
Interior protection
The system detects any variation in
the volume in the passenger com-
partment.
The alarm is triggered if anyone
breaks a window or moves inside
the vehicle.
If you wish to leave a pet in the vehi-
cle or a window partially open, deac-
tivate the interior protection.
Anti-tamper function
The system detects the putting out
of service of its components.
The alarm is triggered if anyone
tries to put the wires of the siren, the
central control or the battery out of
service.
Do not make any modifi cations to
the alarm system, this could cause
malfunctions. Locking the vehicle with full
alarm
Activation

 Switch off the ignition and get out
of the vehicle.

 Lock or deadlock the vehicle us-
ing the locking button on the re-
mote control.
The alarm is activated; the indicator
light on button A fl ashes once per
second.
Deactivation

 Unlock the vehicle using the
unlocking button on the remote
control.
The alarm is deactivated; the indica-
tor light on button A switches off. Locking the vehicle with
exterior protection alarm only
Deactivation of the interior
protection

 Switch off the ignition.

 Within ten seconds, press but-
ton A until the indicator light is lit
continuously.

 Get out of the vehicle.

 Lock or deadlock the vehicle using
the locking button on the remote
control.
The exterior protection alarm alone
remains activated; the indicator light
on button A fl ashes once per second.
In order to be taken into account,
this deactivation must be car-
ried out each time the ignition is
switched off.
Reactivation of the interior
protection

 Unlock the vehicle using the
unlocking button on the remote
control.

 Relock the vehicle using the re-
mote control.
The alarm is activated again with
both types of protection; the indicator
light on button A switches off.

76
IV
A C C E S S
Triggering
This is indicated by sounding of the
siren and fl ashing of the direction
indicators for approximately thirty
seconds.
After it has been triggered, the alarm
is again operational.
If the alarm is triggered ten times in
succession, the eleventh time will
result in it becoming inactive. If the indicator light on button A
fl ashes rapidly, this indicates that
the alarm was triggered during
your absence. When the ignition is
switched on, this fl ashing stops im-
mediately.
To avoid triggering the alarm when
washing your vehicle, lock it using
the key.
Do not activate the alarm before
disconnecting the battery, other-
wise the siren will sound. Failure of the remote control

 Unlock the vehicle using the key
in the driver's door lock.

 Open the door; the alarm is
triggered.

 Switch on the ignition; the alarm
stops.
Locking the vehicle without
alarm

 Lock or deadlock the vehicle
using the key in the driver's door
lock.
* According to country.
Malfunction
When the ignition is switched on,
lighting of the indicator light on
button
A for ten seconds indicates
a siren fault.
Have it checked by a CITROËN
dealer. Automatic operation *
Depending on the legislation in force
in your country, one of these cases
may occur:
- 45 seconds after the vehicle is
locked using the remote control,
the alarm is activated, regard-
less of the status of the doors
and boot.
- 2 minutes after the last door or the boot is closed, the alarm is
activated.

 To avoid triggering the alarm
on entering the vehicle, fi rst
press the unlocking button on
the remote control.

77
IV
A C C E S S
ELECTRIC WINDOWS
System intended to open or close a
window manually or automatically.
Fitted with a safety auto-reverse
system and a system for deactiva-
tion in the event of misuse of the
rear controls.

1. Driver's electric window
control.

2. Passenger's electric window
control.

3. Rear right electric window
control.

4. Rear left electric window
control.

5. Deactivation of the rear
electric window and door
controls. One-touch electric windows
There are two options:
-
manual mode

 Press or pull the control gently.
The window stops when the
control is released.
- automatic mode

 Press or pull the control fi rmly.
The window opens or closes
fully when the control is re-
leased.

 Pressing the control again
stops the movement of the
window.
The electric window controls re-
main operational for approximately
45 seconds after the ignition is
switched off or until the vehicle is
locked after a door is opened.
If one of the passenger windows
cannot be operated from the driv-
er's door control pad, carry out the
operation from the control pad of
the passenger door concerned,
and vice versa. Safety auto-reverse
When the window rises and meets
an obstacle, it stops and partially
lowers again.
If the window cannot be closed (for
example, in the presence of ice),
immediately after the movement is
reversed:

 press and hold the control until
the window opens fully,

 then pull the control immediate-
ly and hold it until the window
closes,

 continue to hold the control for
approximately one second after
the window has closed.

The safety auto-reverse function
is not operational during these
operations.

78
IV
A C C E S S
Reinitialisation
If a window does not rise automatical-
ly, its operation must be reinitialised:

 pull the control until the window
stops,

 release the control and pull it
again until the window closes
fully,

 continue to hold the control for
approximately one second after
the window has closed,

 press the control to lower the
window automatically to the low
position,

 when the window has reached
the low position, press the con-
trol again for approximately
one second.

The safety auto-reverse function
is not operational during these
operations. Deactivation of the rear
electric window and door
controls

 For the safety of your children,
press control 5 to deactivate the
rear electric window controls re-
gardless of their position.
Indicator light on, the rear controls
are deactivated.
Indicator light off, the rear controls
are activated. Always remove the key from the
ignition when leaving the vehicle,
even for a short time.
If an obstacle is encountered during
operation of the electric windows,
you must reverse the movement of
the window. To do this, press the
control concerned.
When the driver operates the con-
trols for the passengers' electric
windows, he must ensure that no
one is preventing correct closing of
the windows.
The driver must ensure that the
passengers use the electric win-
dows correctly.
Be aware of children when operating
the windows.
This warning light comes on
temporarily on the instru-
ment panel on deactivation
and each time the ignition is
switched on. This control also deactivates the
interior controls for the rear doors
(refer to the section "Child safety - §
Electric child lock").
Any other status of the indicator light
indicates a malfunction of the elec-
tric child lock. Have it checked by a
CITROËN dealer.

79
A C C E S S
DOORS
Opening
From outside When the selective unlocking is ac-
tivated, the fi rst press of the remote
control unlocking button permits
unlocking of the driver’s door only.
 Pull the front door control to
open the door; this unlocks this
vehicle completely.

 Pull the rear door control to open
the door; this unlocks the door
concerned only.
With the selective unlocking acti-
vated:
- the driver’s door control un- locks the driver’s door only.
- the other door controls unlock the other doors and the boot.
The interior door controls do not
operate when the vehicle is dead-
locked. Manual centralised control
System which provides full manual
locking or unlocking of the doors
and boot from the inside.
Locking

 Press button A to lock the vehicle.
The red indicator light on the button
comes on.
If one of the doors is open, the cen-
tral locking from the inside does not
take place.
If the boot or the rear screen is
open, the central locking from the
inside is active for the doors, to
permit the transportation of long
objects.

 After unlocking the vehicle com-
pletely using the remote control
or the key, pull the door handle. From inside

80
IV
A C C E S S
Unlocking

 Press button A again to unlock
the vehicle.
The red indicator light on the button
switches off.
If the vehicle is locked or dead-
locked from the outside, the red
indicator light fl ashes and button A
is inactive.

 In this case, use the remote
control or the key to unlock the
vehicle.
Automatic centralised control
System which provides full automatic
locking or unlocking of the doors,
boot and rear screen while driving.
You can activate or deactivate this
function.
Locking
When the speed exceeds 6 mph
(10 km/h), the doors, the boot and
the rear screen lock automatically. Unlocking

 Above 6 mph (10 km/h), press
button A to unlock the doors, the
boot and the rear screen tempo-
rarily.
Activation

 Press button A for more than
two seconds.
A confi rmation message appears on
the multifunction display.
Deactivation

 Press button A again for more
than two seconds.
A confi rmation message appears on
the multifunction display. Emergency control
System which locks or unlocks the
doors mechanically in the event of
a malfunction of the battery or of the
central locking.
Locking the driver’s door

 Insert the key in the lock, then
turn it to the right.
Unlocking the driver’s door

 Insert the key in the lock, then
turn it to the left.
Locking the front and rear
passenger doors

 Insert the key in the lock, located
on the edge of the door, then turn
it one eighth of a turn .
Unlocking the front and rear
passenger doors

 Pull the interior door opening
control.
If one of the doors or the boot or
rear screen is open, the automatic
central locking does not take place.

81
A C C E S S
BOOT

 After unlocking the vehicle com-
pletely using the remote control
or the key, with the rear screen
closed, pull on the handle 1 and
raise the tailgate.

 Lower the tailgate using one of
the two handholds 3 , located on
the interior boot trim. -

when the engine is running
this warning light comes on,
accompanied by a message
on the multifunction display
for a few seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning light comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion display for a few seconds.
If the tailgate is not closed correctly:
REAR SCREEN
This opening gives you enhanced
access to your boot, even if you are
parked close to a wall or another
vehicle. Closing

 Lower the rear screen guiding
it with the wiper arm until it is
closed.
If the rear screen is not closed
correctly: - when the engine is run-
ning
, this warning light
comes on, accompanied
by a message on the
multifunction display for a
few seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning light comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion display for a few seconds.
The boot and the rear screen
cannot both be open at the same
time.
When the rear screen is open,
you can access the boot by rais-
ing the rear shelf using its tab
(C4 Picasso).

 After unlocking the vehicle com-
pletely using the remote control
or the key, with the boot closed,
press the control 2 and raise the
rear screen using the base 4 of
the wiper arm.

 Past the balancing point, allow
the tailgate to lower and close
itself (do not assist it or slow it
down).
Opening
Opening
Closing
