82
IV
A C C E S S
Tailgate release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking

 Fold back the rear seats to gain
access to the lock from inside
the boot.

 Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.

 Push the white part, located in-
side the lock, to the left to unlock
the boot.
PANORAMIC GLASS ROOF
System which consists of a pan-
oramic tinted glass surface to in-
crease the light and visibility in the
passenger compartment.
Fitted with an electric blind in sever-
al sections to improve temperature
and noise related comfort.
Opening the roof blind

 Rotate the control B to slide the
roof blind to the position desired
(positions 1 to 9 ). Closing the roof blind

 Rotate the control B to posi-
tion 0 to close the roof blind.

Recommendations
- Pressing the locking button on the remote control for more than
two seconds will close the blind
(practical when, for example,
you leave your vehicle on a sun-
lit carpark).
- On returning to your vehicle, a press on the button B reposi-
tions the blind to the last position
selected.
Anti-pinch
The blind has an anti-pinch function.
At the end of its travel, when the blind
encounters an obstacle on closing, it
stops and moves back slightly.
Following a fault or after a battery
disconnection during the movement
of the blind or after it has stopped,
you have to re-initialise the anti-
pinch function:

 place the blind in the closed
position,

 press button B for approximately
two seconds.

81
A C C E S S
BOOT

 After unlocking the vehicle com-
pletely using the remote control
or the key, with the rear screen
closed, pull on the handle 1 and
raise the tailgate.

 Lower the tailgate using one of
the two handholds 3 , located on
the interior boot trim. -
when the engine is run-
ning
this warning light
comes on, accompanied
by a message on the
multifunction display for
a few seconds,
-
when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning light comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion display for a few seconds.
If the tailgate is not closed correctly:
REAR SCREEN
This opening gives you enhanced
access to your boot, even if you are
parked close to a wall or another
vehicle. Closing

 Lower the rear screen guiding
it with the wiper arm until it is
closed.
If the rear screen is not closed
correctly: - when the engine is run-
ning
, this warning light
comes on, accompanied
by a message on the mul-
tifunction display for a few
seconds,
- when the vehicle is moving
(speed above 6 mph (10 km/h)),
this warning light comes on, ac-
companied by an audible signal
and a message on the multifunc-
tion display for a few seconds.
The boot and the rear screen
cannot both be open at the same
time.
When the rear screen is open,
you
can access the boot by raising the rear
shelf using its tab (C4 Picasso).

 After unlocking the vehicle com-
pletely using the remote control
or the key, with the boot closed,
press the control 2 and raise the
rear screen using the base 4 of
the wiper arm.

 Past the balancing point, allow
the tailgate to lower and close
itself (do not assist it or slow it
down).
Opening
Opening
Closing

82
IV
A C C E S S
Tailgate release
System for mechanical unlocking of
the boot in the event of a battery or
central locking malfunction.
Unlocking

 Fold back the rear seats to gain
access to the lock from inside
the boot.

 Insert a small screwdriver into
hole A of the lock to unlock the
tailgate.

 Push the white part, located in-
side the lock, to the left to unlock
the boot.
PANORAMIC GLASS ROOF
System which consists of a pan-
oramic tinted glass surface to in-
crease the light and visibility in the
passenger compartment.
Fitted with an electric blind in sever-
al sections to improve temperature
and noise related comfort.
Opening the roof blind

 Rotate the control B to slide the
roof blind to the position desired
(positions 1 to 9 ). Closing the roof blind

 Rotate the control B to posi-
tion 0 to close the roof blind.

Recommendations
- Pressing the locking button on the remote control for more than
two seconds will close the blind
(practical when, for example,
you leave your vehicle on a sun-
lit carpark).
- On returning to your vehicle, a press on the button B reposi-
tions the blind to the last position
selected.
Anti-pinch
The blind has an anti-pinch function.
At the end of its travel, when the blind
encounters an obstacle on closing, it
stops and moves back slightly.
Following a fault or after a battery
disconnection during the movement
of the blind or after it has stopped,
you have to re-initialise the anti-
pinch function:

 place the blind in the closed
position,

 press button B for approximately
two seconds.

83
IV
A C C E S S
FUEL TANK

Capacity of the tank: approxi-
mately 60 litres.
Low fuel level
When the minimum level in the tank is reached, this warning
lamp on the instrument panel
comes on, accompanied by
an audible warning and a message
on the multifunction screen.

You have enough fuel left to drive
approximately 50 km (approx.
30 miles).

 Press on the control A , situated
on the control panel on the left
hand side. The fuel fl ap automat-
ically opens up. The petrol or diesel engine of your
vehicle is fi tted with a catalytic con-
verter, a device which helps to re-
duce the level of harmful emissions
in the exhaust gases.

For petrol engines, unleaded fuel
is obligatory.
The fi ller neck is narrower, permit-
ting unleaded petrol only.

 Take care to select the pump
that corresponds to the correct
fuel type for your vehicle.

 Introduce the nozzle so as to
push in the metallic gate valve B.

 Make sure that the nozzle is
pushed in as far as possible
before starting to refuel (risk of
blowback).

 Maintain this position throughout
the refuelling operation.

 Push the fuel fl ap to reclose it.
Fuel cut-off switch
Your vehicle is equipped with a
safety device which cuts off the fuel
supply in the event of a collision.
Refuelling

If you are fi lling your tank to the
top, do not persist after the third
cut-off; this could cause your
vehicle to malfunction.

84
IV
A C C E S S

UNLEADED PETROL After switching off the ignition, the
control
A is active for only a few
minutes. If necessary, switch on
the ignition again to reactivate it.

If you have put in fuel that is
wrong for your vehicle, it is es-
sential to have the tank drained
before you start the engine.
Fuel quality
A label affi xed to the inside of the
fuel fl ap indicates the fuels that are
authorised.

DIESEL FUEL
The petrol engines are designed to
run on RON 95.
However, for better vehicle perfor-
mance (petrol engines), we recom-
mend RON 98.

85
V I S I B I L I T Y
V
LIGHTING CONTROLS
System for selection and control of
the various front and rear lights pro-
viding the vehicle's lighting.
Main lighting
The various front and rear lights of
the vehicle are designed to adapt
the driver's visibility progressively in
relation to the climatic conditions:
- side lights, to be seen,
- dipped headlamps to see without dazzling other drivers,
- main beam headlamps to see clearly when the road is clear,
- directional headlamps for improved visibility when cornering.
Additional lighting
Other lights are installed to fulfi l the
requirements of particular driving
conditions:
- a rear fog lamp to be seen from a distance,
- front fog lamps for even better visibility,
- daytime lights to be seen during the day. Programming
Various automatic lighting control
modes are also available according
to the following options:
- guide-me-home lighting,
- automatic lighting,
- directional lighting.
Manual controls
lights off,
automatic switching on of
the lights,
side lights only,
dipped headlamps or
main beam headlamps.

B. lever for inversion of the lights by
pulling: dipped headlamps/main
beam headlamps.
In the lights off and side lights
modes, the driver can switch on
the main beam headlamps directly
("headlamp fl ash") for as long as he
pulls the lever.
Displays
Lighting of the corresponding indi-
cator light on the instrument panel
confi rms the selective switching on
of the lighting selected.
The lighting commands are issued
directly by the driver by means of
the ring
A and the lever B .
A. main lighting mode selection ring,
with:

86
V I S I B I L I T Y
V

C. fog lamps selection ring.
The fog lamps operate with the side
lights and the dipped and main beam
headlamps.
- 1 st turn forwards: lighting of rear foglamp.
- 1 st turn rearwards: extinction of rear foglamp. - 1 st turn forwards: lighting of front
foglamps.
- 2 nd turn forwards: lighting of rear foglamps.
- 1 st turn rearwards: extinction of rear foglamps.
- 2 nd turn rearwards: extinction of front foglamps.
Model with rear foglamp only
Model with front and rear
foglamps In good or rainy weather, both day
and night, the front fog lamps and
the rear fog lamp are prohibited. In
these situations, the power of their
beams may dazzle other drivers.
They should only be used in fog or
snow.
In these weather conditions, it is
your responsibility to switch on the
fog lamps and dipped headlamps
manually as the brightness sensor
may detect suffi cient light.
Do not forget to switch off the front
fog lamps and the rear fog lamp
when they are no longer neces-
sary.
Lights on buzzer
The triggering of an audible signal
when a front door is opened warns
the driver that he has forgotten to
switch off his vehicle's lights, with
the ignition off and in manual lights
mode.
In this case, switching off the lights
stops the audible signal.
With the ignition off, if the dipped
headlamps remain on, they will
switch off automatically after thirty
minutes to prevent discharging of
the battery.

87
V I S I B I L I T Y
V
* According to country.
Daytime lights
System which permits automatic
switching on of the special lights at
the front, so that you can be seen
during the daytime.
On vehicles fi tted with daytime lights,
the corresponding lights come on
when the vehicle is started * .
The instruments and controls (instru-
ment panel, multifunction display, air
conditioning control panel, ...) are not
lit, except on switching to the auto-
matic switching on of the lights mode
or when the lights are switched on
manually.
Programming
Manual guide-me-home
lighting
The temporary maintaining of the
dipped headlamps lighting after the
vehicle's ignition has been switched
off makes the driver's exit easier
when the light is poor.
Switching on

 With the ignition off, "fl ash" the
headlamps using the lights stalk B .

 A second "headlamp fl ash"
switches the function off again.
Switching off
The manual guide-me-home lighting
switches off automatically after a set
time.
The manual guide-me-home lighting
is also available by pressing the lights
button on the remote control (refer to
the section "Accesses - § Remote
control key"). Automatic lighting
The side lights and dipped head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external
light is detected or in certain cases of
activation of the windscreen wipers.
As soon as the brightness returns
to a suffi cient level or after the wind-
screen wipers are switched off, the
lights are switched off automatically.
Activation

 Turn ring A to the "AUTO" posi-
tion. The automatic lighting is
accompanied by a message on
the multifunction display.
Deactivation

 Turn ring A to a position other
than "AUTO" . Deactivation is
accompanied by a message on
the multifunction display.
In countries in which
this function is not
imposed by regula-
tions, you can activate
or deactivate it via the
multifunction display
confi guration menu.
In countries in which it is imposed by
regulations:
- by default, this function is acti- vated,
- the side lights and the number plate lights are also switched on.

88
V I S I B I L I T Y
V
Linked with the automatic
"Guide-me-home" lighting
Association with the automatic lighting
provides the "guide-me-home" lighting
with the following additional options:
- selection of the duration of main-taining of the lighting for 15, 30
or 60 seconds in the vehicle
parameters on the multifunc-
tion display confi guration menu
(in the case of the monochrome
screen A, the duration is fi xed),
- automatic activation of "guide- me-home" lighting when auto-
matic lighting is in operation.
Operating fault
In the event of a malfunction of the
brightness sensor, the lights come
on, a message appears on the mul-
tifunction display, accompanied by
an audible signal.
Consult a CITROËN dealer. In fog or snow, the brightness
sensor may detect suffi cient light.
Therefore, the lights will not come
on automatically.
Do not cover the brightness sensor,
linked with the rain sensor and
located in the centre of the wind-
screen behind the interior mirror; the
associated functions would no longer
be controlled. EXTERIOR SIDE LIGHTERS
These illuminate:
- the zones facing the driver’s and passenger’s doors,
- the zones forward of the door mir- rors and rearward of the front doors.
Switching on
The side lighters come on:
- when you unlock the vehicle or press on the lighting button on
the remote control,
- when you remove the key from the ignition,
- when you open a door,
- when you use the remote control.
Switching off
They are timed to go out automatically.
MANUAL ADJUSTMENT OF THE HEADLAMPS
To avoid dazzling other road users,
the height of the halogen bulb head-
lamps must be adjusted according
to the load in the vehicle. To do this,
turn the control, located below the
fascia to the left of the driver, to the
appropriate position:

0. 1 or 2 people in the front seats.

-. 3 people.

1. 4 to 7 people.

-. Intermediate setting.

2. 4 to 7 people + maximum autho-
rised loads.

-. Intermediate setting.

3.
Driver + maximum authorised loads.
Initial setting is position "0" .

89
V I S I B I L I T Y
V
AUTOMATIC ADJUSTMENT OF THE DIRECTIONAL HEADLAMPS
In order to avoid causing a nuisance
to other road users, this system cor-
rects the height of the xenon head-
lamps beam automatically and when
stationary, in relation to the load in
the vehicle. If a malfunction occurs,
this warning light is dis-
played on the instrument
panel, accompanied by
an audible signal and a
message on the multi-
function display.
The system then places your head-
lamps in the lowest position.
Do not touch the xenon headlamps.
Consult a CITROËN dealer.
DIRECTIONAL LIGHTING
When the dipped or main beam
headlamps are on, this function
enables the light beam to follow the
direction of the road.
The use of this function, coupled
with the xenon headlamps only,
considerably improves the quality of
your lighting when cornering.

with directional lighting

without directional lighting Programming
The function is activated
or deactivated via the
multifunction display
confi guration menu.
Operating fault If a malfunction occurs, this
warning light fl ashes on the
instrument panel, accompa-
nied by a message on the
multifunction display.
Consult a CITROËN dealer.
When stationary or moving at very
low speed or when reverse gear is
engaged, the function is inactive.
The status of the function remains
in the memory when the ignition is
switched off.
On vehicles fi tted with daytime run-
ning lights, the function is activated
if the lights stalk is in the "AUTO"
or "Dipped/main beam headlamps"
position. In position "0" , the func-
tion is not activated.
