Page 28 of 338
29
I
I N S T R U M E N T S a n d C O N T R O L S
Lighting is associated
with the display of an-
other warning lamp :
Service If this comes on, it in-
dicates the occurrence
of a problem in one
of the systems which
d o e s n o t h a v e a s p e c i fi c w a r n i n g
lamp.
In order to identify it, consult the mes-
sage on the multifunction screen.
The warning lamp only comes on
temporarily in the case of the follow-
ing minor faults:
- incorrect closing of the doors, boot, rear screen and bonnet,
- fl a t r e m o t e c o n t r o l b a t t e r y ,
- incorrect tyre pressure,
- the end of saturation of the parti- c l e e m i s s i o n fi l t e r ( D i e s e l ) .
In the case of major faults, the warning lamp remains on until the operating
f a u l t i s r e c t i fi e d , c o n t a c t a C I T R O Ë N
dealer as soon as possible. Braking
If this comes on, it indicates
the occurrence of a fault in
one of the braking systems:
- s i g n i fi c a n t d r o p i n t h e l e v e l i n t h e circuit,
- electronic brake force distribution (EBFD) faulty (simultaneous light-
ing of the ABS warning lamp),
stop the vehicle immediately and as
safely as possible.
Consult a CITROËN dealer.
Application/Release of the
automatic electric parking brake
If this warning lamp comes
o n p e r m a n e n t l y , i t i s c o n fi r m -
ing that the parking brake is
applied.
I f i t fl a s h e s , i t i s i n d i c a t i n g a n a p -
plication or release fault. Contact
a CITROËN dealer urgently (see
section "Driving - § Electric parking
brake"). Automatic electric parking brake
fault
This warning lamp comes
on if there is a malfunction in
the automatic electric park-
ing brake.
Deactivation of the automatic
functions of the automatic
electric parking brake
This comes on if the "auto-
matic application" and "auto-
matic release" functions
when you switch off the
engine are deactivated * or
faulty.
Dynamic stability control
(ESP/ASR) The ESP/ASR system is put
into service automatically
when the vehicle is started.
Unless the system has been
deactivated, if this warning lamp
and the indicator lamp on the button
come on continuously, this indicates
the occurrence of a fault in the ESP/
ASR system or in the hill start assist
system.
Engine autodiagnostics system
If this comes on, it indicates
the occurrence of a fault in
the engine management
system.
I f i t fl a s h e s , i t i n d i c a t e s t h e o c -
currence of a fault in the emission
control system.
Central alert
- punctured wheel,
- braking,
- coolant temperature,
stop the vehicle immediately and as
safely as possible.
Consult a CITROËN dealer.
Anti-lock braking system (ABS) If this comes on, it indicates
the occurrence of a fault in
the anti-lock braking system.
However, this does not
prevent operation of the vehicle's
assisted braking.
* According to country.
Page 30 of 338
31
I
I N S T R U M E N T S a n d C O N T R O L S
Service indicator
System which informs the driver
when the next service is due, in ac-
cordance with the manufacturer's
servicing schedule.
The point at which the service is
due is calculated from the last indi-
cator zero reset. It is determined by
two parameters:
- the distance travelled,
- the time elapsed since the last service. 5 seconds after the ignition is switched
on,
the spanner is switched off ; the
distance recorder resumes its normal
operation. The display then indicates
the total and trip distances.
Less than 620 miles (1 000 km)
remain before the next service is
due
Examples
: 400 miles (900 km) re-
main before the next service is due.
For 5 seconds after the ignition is
switched on, the display indicates: Service overdue
For 5 seconds after the ignition is
switched on,
t h e s p a n n e r fl a s h e s
to indicate that the service must be
carried out as soon as possible.
Example: the service is overdue by
300 miles/km.
For 5 seconds after the ignition is
switched on, the display indicates:
5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation. The
spanner remains on to indicate that
a service must be carried out soon. 5 seconds after the ignition is
switched on, the distance recorder
resumes its normal operation.
The
spanner remains lit .
More than 620 miles (1 000 km)
remain before the next service
is due
For 5 seconds after the ignition is
switched on, the spanner symbol-
ising the service operations comes
on. The distance recorder display
line indicates the distance remaining
before the next service is due.
Example: 4 800 miles/km remain
before the next service is due.
For 5 seconds after the ignition is
switched on, the display indicates:
The distance remaining may be
weighted by the time factor, depend-
ing on the driver's driving habits.
Therefore, the spanner may also
come on if you have exceeded the
two year service interval.
Page 31 of 338
32
I
I N S T R U M E N T S a n d C O N T R O L S
Service indicator zero reset Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the distance
recorder display begins a count-
down,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essential
that the level is topped up to prevent
damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL
--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 32 of 338
32
I
I N S T R U M E N T S a n d C O N T R O L S
Service indicator zero reset Engine oil level indicator
After each service, the service indi-
cator must be reset to zero.
The procedure for resetting to zero
is as follows:
switch off the ignition,
press and hold the trip distance
recorder zero reset button,
switch on the ignition; the distance
recorder display begins a count-
down,
when the display indicates "=0" ,
release the button; the spanner
disappears. System which informs the driver
whether the engine oil level is cor-
rect or not.
This information is displayed for a
few seconds when the ignition is
switched on, after the service infor-
mation.
The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.
Oil level correct
Oil level low
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL" , accompanied by an audible
signal and a message on the multi-
function screen.
I f t h e l o w o i l l e v e l i s c o n fi r m e d b y a
check using the dipstick, it is essential
that the level is topped up to prevent
damage to the engine. Oil level gauge fault
T h i s i s i n d i c a t e d b y t h e fl a s h i n g o f
"OIL
--" . Contact a CITROËN dealer.
Dipstick
Refer to the "Checks" section to lo-
c a t e t h e d i p s t i c k a n d t h e o i l fi l l e r c a p
on your engine. There are 2 marks on
the dipstick:
- A = max; never ex-
ceed this level,
- B = min; top up the
l e v e l v i a t h e o i l fi l l e r
cap, using the type
of oil suited to your
engine.
Following this operation, if you wish
to disconnect the battery, lock the
v e h i c l e a n d w a i t a t l e a s t fi v e m i n u t e s
for the zero reset to be taken into ac-
count.
Page 34 of 338
34
II
M U L T I F U N C T I O N S C R E E N S
MULTIFUNCTION SCREEN A
Presentation
1. Time
2. Date and display zone
3. Ambient temperature
When the ambient temperature is
between +3 °C and -3 °C, the tem-
p e r a t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
T h e d i s p l a y o f c e r t a i n t y p e s o f i n -
f o r m a t i o n i s s o m e t i m e s b y s c r o l l i n g
a n d s o m e t i m e s b y a l t e r n a t i o n .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a t i o n
to be displayed in zone 2 ( d a t e ,
r a d i o - C D a n d t r i p r e c o r d e r )
B or F. W i t h i n t h e m e n u s , c h o i c e
o f a c t i v a t i o n / d e a c t i v a t i o n o f
f u n c t i o n s a n d s e l e c t i o n o f
adjustments By pressing on the button
A , then
using button B , y o u h a v e a c c e s s t o
t h e f o l l o w i n g f u n c t i o n s :
Page 36 of 338
36
II
M U L T I F U N C T I O N S C R E E N S
MULTIFUNCTION SCREEN C M a i n M e n u
Presentation
Radio-CD
( s e e " A u d i o a n d
T e l e m a t i c s " )
T r i p c o m p u t e r
T h i s p e r m i t s :
B l u e t o o t h
®
h a n d s - f r e e k i t
( s e e " A u d i o " a n d
T e l e m a t i c s )
Controls
1. Time
2. Ambient temperature
3. Date and display zone
When the ambient temperature is be-
tween +3 °C and -3 °C, the tempera-
t u r e d i s p l a y fl a s h e s ( r i s k o f i c e ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t m a n i p u l a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n .
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n Press on the button
A to view the
" M a i n M e n u " o f t h e m u l t i f u n c t i o n
s c r e e n . T h i s m e n u g i v e s y o u a c c e s s
t o t h e f o l l o w i n g f u n c t i o n s :
- e n t e r i n g t h e d i s t a n c e t o y o u r destination,
- a c c e s s t o t h e l o g o f a l e r t s ( r e c a l l o f a l e r t s s i g n a l l e d p r e v i o u s l y ) ,
- a c c e s s t o t h e s t a t u s o f f u n c t i o n s , s u c h a s t h e a c t i v a t i o n / d e a c t i v a -
t i o n o f a u t o m a t i c h e a d l a m p s ,
a u t o m a t i c w i n d s c r e e n w i p e r s ,
E S P . . .
Page 40 of 338
40
II
M U L T I F U N C T I O N S C R E E N S
NAVIDRIVE MULTIFUNCTION COLOUR SCREEN
Presentation
1. Ambient temperature
2. D i r e c t o r y
3. Date
4. Telephone
5. Time
When the ambient temperature is be-
tween +3 °C and -3 °C, the tempera-
t u r e d i s p l a y fl a s h e s ( r i s k o f i c e ) .
The ambient temperature displayed
m a y b e g r e a t e r t h a n t h e a c t u a l t e m -
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
b r i g h t s u n l i g h t .
I t i s r e c o m m e n d e d t h a t t h e d r i v e r
s h o u l d n o t o p e r a t e t h e c o n t r o l s
w h i l e t h e v e h i c l e i s i n m o t i o n . Controls
M a i n M e n u
T r a f fi c I n f o r m a t i o n
N a v i g a t i o n / G u i d a n c e
Map
A u d i o F u n c t i o n s
T e l e m a t i c s
C o n fi g u r a t i o n ,
for adjusting various parame-
t e r s ( d a t e , t i m e , u n i t s )
Video
V e h i c l e D i a g n o s t i c s
A. A c c e s s t o t h e " M a i n M e n u "
B. S c r o l l i n g i n t h e s c r e e n m e n u s
C. S e l e c t i o n a n d c o n fi r m a t i o n i n t h e
m e n u s o f t h e f u n c t i o n c h o s e n o r
t h e v a l u e m o d i fi e d
D. C a n c e l l a t i o n o f t h e o p e r a t i o n o r
return to the previous display
E. S e l e c t i o n o f t h e t y p e o f i n f o r m a -
tion to be displayed permanently
( d a t e , r a d i o - C D , t r i p c o m p u t e r )
o n t h e r i g h t o f t h e s c r e e n Press on the button
A to view the
" M a i n M e n u " o f t h e m u l t i f u n c t i o n
s c r e e n .
T h i s m e n u g i v e s y o u a c c e s s t o t h e
f o l l o w i n g f u n c t i o n s ( s e e " N a v i D r i v e
I n s t r u c t i o n s " ) :
Page 41 of 338
41
II
M U L T I F U N C T I O N S C R E E N S
TRIP COMPUTER
S y s t e m w h i c h p r o v i d e s c u r r e n t i n f o r -
m a t i o n c o n c e r n i n g t h e t r i p t r a v e l l e d
( r a n g e , f u e l c o n s u m p t i o n . . . ) .
M o n o c h r o m e s c r e e n A Data displays
P r e s s t h e c o n t r o l f o r m o r e t h a n
t w o s e c o n d s t o r e s e t t o z e r o t h e
d i s t a n c e t r a v e l l e d , t h e a v e r a g e
f u e l c o n s u m p t i o n a n d t h e a v e r -
a g e s p e e d .
Zero reset
T h e t r i p c o m p u t e r p r o v i d e s t h e f o l -
l o w i n g i n f o r m a t i o n : - range,
- c u r r e n t f u e l c o n s u m p t i o n ,
- d i s t a n c e t r a v e l l e d ,
- a v e r a g e f u e l c o n s u m p t i o n ,
- a v e r a g e s p e e d .
The next press then returns you
t o t h e n o r m a l d i s p l a y .
P r e s s t h e b u t t o n , l o c a t e d a t t h e
end of the wiper
s t a l k , to display
t h e v a r i o u s i t e m s o f t r i p c o m p u -
t e r d a t a i n s u c c e s s i o n .
Page 42 of 338
42
II
M U L T I F U N C T I O N S C R E E N S
TRIP COMPUTER
S y s t e m w h i c h p r o v i d e s c u r r e n t i n f o r -
m a t i o n c o n c e r n i n g t h e r o u t e t r a v e l l e d
( r a n g e , c o n s u m p t i o n , … ) .
M o n o c h r o m e s c r e e n C
N a v i D r i v e c o l o u r s c r e e n D i s p l a y o f i n f o r m a t i o n
Trip zero reset
P r e s s t h e b u t t o n , l o c a t e d a t t h e
end of the wiper
s t a l k , to display
t h e v a r i o u s t r i p c o m p u t e r i n f o r -
m a t i o n g r o u p s i n s u c c e s s i o n :
- t h e c u r r e n t i n f o r m a t i o n g r o u p w i t h :
Page 46 of 338
46
III
C O M F O R T
Air conditioning
To ensure that your system operates
correctly, it is recommended to have
it checked regularly.
Water arising from condensation
in the air conditioning drains away
through a hole provided for this pur-
pose. A pool of water may thus form
under the vehicle when stationary.
To keep the air conditioning com-
pressor well sealed, it is essential to
operate the air conditioning at least
once in every month.
Regardless of the season, the air
conditioning is useful, since it re-
moves humidity and condensation.
To be effective, the air conditioning
should only be used with the win-
dows closed.
If after a lengthy stop in bright sun-
light the interior temperature is exces-
sive, air the passenger compartment
by opening the windows for a few
moments, then close them again.
The air conditioning operates by using
power from the engine. This results in
a slight increase in fuel consumption.
Dust filter/Odour filter
(active carbon)
T h e r e i s a fi l t e r f o r e x c l u d i n g o d o u r s
and dust.
T h i s fi l t e r h a s t o b e c h a n g e d i n a c -
cordance with the vehicle's servic-
ing schedule (see "Maintenance and
Warranty Guide").
Air circulation
A i r v e n t s o n t h e fl o o r u n d e r n e a t h t h e
front seats provide enhanced heat-
ing for the rear seat positions; take
care not to obstruct them.
Air vents
The air vents to the face have grilles
and thumbwheels to adjust the air
fl o w a n d d i r e c t i o n ( u p - d o w n , r i g h t -
left).
The automatic regulation of the air
conditioning, inside the cabin, uses
a number of sensors (sunlight sen-
sor, outside temperature sensor...)
that relieve you of the need to make
frequent adjustments outside the
displayed temperature.
Be careful not to obstruct the sun-
light sensor, located on the dash-
board behind the instrument panel.
Sensors
