Safety
(a) Universal child seat: child seat which can be
installed in all vehicles using the seat belt.
(b) Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on thefront passenger seat. When installed in the 2nd
row, they may prevent use of the other seats.
(c) Consult the legislation in force in your country before installing your child on
this seat.
(d) To install a child seat on a rear seat,
"rear ward facing" or "for ward facing", move
the front seat for ward, then straighten the
backrest to allow enough space for the childseat and the child's legs.
( e ) To install a child seat on a rear seat,"rearward facing" or "forward facing", adjust
the rear seat to the fully back position, with
the backrest upright.
Remove and stow the head restraintbefore installing a child seat on a passenger seat. Refit the head restraint once the child seat has been removed.
U
: seat suitable for the installation of a child seat secured using the seat belt anduniversally approved "rear ward facing" and/or "for ward facing", with the passenger seat
adjusted to the midway longitudinal position.U(R): same as U , with the passenger's seatadjusted to the low position with
11 actions on the height control lever and
in the midwa
y longitudinal position.

250
Safety














Installation of child seats secured using
the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using the seat belt and universally approved (a)in relation to the weight of the child and the seat in the vehicle.
Seat
Weight of the child /indicative age /
Groups 0 (b) and 0+
Bir th to 13 kg
Group 1
From 9 to 18 kg
Group 2
From 15 to 25 kg
Group 3
From 22 to 36 kg

1st
row
Front passenger seat (c)
- fixed
UUUU
- height adjustable
U(R)U(R)U(R)U(R)
2ndrow
Outer rear seats
UUUU
Outer rear seats with
longitudinal adjustment ( d ) ( e) eUUUU
Centre rear seat ( d )
UUUU

3rdrowOuter rear seasUUUU

251
6
Safety
(a) Universal child seat: child seat which can be
installed in all vehicles using the seat belt.
(b) Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on thefront passenger seat or in the 3 rd
row. W hen
installed in the 2 ndrow, they may preventuse of the other seats.
(c) Consult the legislation in force in your
country before installing your child on
this seat.
(d) To install a child seat on a rear seat,
"rear ward facing" or "for ward facing", move
the front seat for ward, then straighten the
backrest to allow enough space for the childseat and the child's legs.
( e ) To install a child seat on a rear seat,"rearward facing" or "forward facing", adjust
the rear seat to the fully back position, with
the backrest upright.

Remove and stow the head restraintbefore installing a child seat on a passenger seat. Refit the head restraint once the child seat has been removed.
U
: seat suitable for the installation of a child seat secured using the seat belt anduniversally approved "rear facing" and/or
"for ward facing", with the passenger seat
adjusted to the midway longitudinal position.U(R): same as U , with the passenger's seatadjusted to the low position with
11 actions on the height control lever and
in the midwa
y longitudinal position.

252
Safety











"ISOFIX" mountings
latest ISOFIX regulations
.
The seats, represented below, are fitted with regulation ISOFIX mountings:
- two r
ings A
, located between the vehicle
seat back and cushion, indicated by a
marking,



- a rin
g B, located under a cover on the back of the top of the seat backrest, referred to as
the TOP TETHER for fixing the upper strap. R Its position is indicated by a marking.
Located on the back o
f the seat backrest, the
top tether is used to secure the upper strap of child seats that have one. This device limits
forward tipping of the child seat, in the event of
a front impact.

The incorrect installation of a child seat in a vehicle compromises the child'sprotection in the event of an accident. Observe strictly the fitting instructions
provided with the child seat.


For information on the possibilities for fitting ISOFIX child seats to your vehicle, refer to the table of seating positions.

The ISOFIX mountings are three rings for each seat:


This ISOFIX mounting system ensures fast, reliable and safe fitting of the child seat in your
vehicle.
The ISOFIX child seats are fitted with twolatches which are secured easily on the two rings A.
Some also have an upper strap (or top tether)which is attached to ring B.
To secure the child seat to the TOP TETHER
:


- r
emove and stow the head restraint beforeinstalling the child seat on this seat (refit it after the child seat has been removed),

- remove the TOP TETHERcover by pulling at its cut-out,


- pass the child seat strap behind the seat
backrest, centred between the holes for the head restraint rods,

- secure the upper strap fixing to the ring B,

- tighten the upper strap.

253
6
Safety













ISOFIX child seats recommended by CITROËN and approved for
your vehicle
"RÖMER Baby- Safe Plus and its Baby- Safe Plus ISOFIX base"(size category: E )

Group 0+: from bir th to 13 kg


Installed "rear ward facing" using an ISOFIX base which is attached to the rings A.The base has a stay, adjustable for height, which sits on the vehicle's floor.
This seat can be secured with a seat belt. In this case, only the shell is used and attached to the
vehicle's seat b
y the three-point seat belt.
Baby P2C Midi and its ISOFIX base (size categories: D, C, A, B,B1 )

Group 1: from 9 to 18 kg


Installed "rear ward facing" using an ISOFIX base which is attached to the rings A
The base has a stay, adjustable for height, which sits on the vehicle's floor.
This child seat can also be used "for ward facing". This seat can not
be secured with a seat belt.
We recommend that you use the seat in the "rear ward facing" position up to the age of 3 years.

254
Safety













Locations for installing ISOFIX
child seats
In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIXmountings.
In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from Ato G , is indicated on the childseat next to the ISOFIX logo.
Weight of the child/ indicative age
Less than 10 kg(group 0)Up to approx. 6 months
Less than 10 kg(group 0)
Less than 13 kg(group 0+)Up to approx. 1 year
From 9 to 18 kg (group 1)From approx. 1 to 3 years
Type of ISOFIX child seatSleeper cot

*
"rearwards-facing""rearwards-facing""forwards-facing"
ISOFIX size categoryFGCDECDABB1

Front passenger seat Not ISOFIX

Outer rear seats, fixed IL- SU ** IL-SUIL-SUXIUF / IL- SU

Outer rear seats, adjustable longitudinallyIL- SU ** IL-SUIL-SUIUF / IL- SU (1)IUF / IL- SU

Centre rear seat XIL-SUIL-SUIUF / IL-SUIUF / IL-SU
*
Sleeper cots cannot be fitted to the front passenger's
seat.
**
The IS
OFIX sleeper cot, secured to the lower rings of an ISOFIX seat,
occupies the full width of the rear seats.

255
6
Safety
IUF: seat suitable for the installation of an
ISOFIX U niversal seat, " Forwards-facing"secured using the top strap to the top
tether on ISOFIX seats. IL- SU: seat suitable for the installation of anIsofix Semi- Universal seat either:


- "rearwards-facing" fitted with a top belt
or a stay,

- "
forwards-facing" fitted with a stay,

- a sleeper cot fitted with an upper strap
or a sta
y.
Remove and stow the head restraintbefore installing a child seat on a passenger seat. Refit the head restraint
once the child seat has been removed. For advice on securin
g of the top belt, refer to
the "Isofix Mountings" section. X: seat not suitable for the installation of a
child seat or sleeper cot for the weight groupindicated.(1)
: The outer seat in row 2 must be adjusted
to 3 notches back from the fully forward position.

256
Safety














Locations for installing ISOFIX
child seats
mountings.
In the case of universal and semi-universal IS
OFIX child seats, the ISOFIX size category, determined by a letter from Ato G , is indicated on the childseat next to the ISOFIX logo.
* Sleeper cots cannot be fitted to the front passenger'sseat. **

The ISOFIX sleeper cot, secured to the lower rings of an ISOFIX seat,
occupies the full width of the rear seats.
Weight of the child/ indicative age
Less than 10 kg(group 0)Up to approx. 6 months
Less than 10 kg(group 0)
Less than 13 kg(group 0+)Up to approx. 1 year
From 9 to 18 kg (group 1)From approx. 1 to 3 years
Type of ISOFIX child seatSleeper cot*"rearwards-facing""rearwards-facing""forwards-facing"
ISOFIX size categoryFGCDECDABB1


Front passenger seat Not ISOFIX

Outer rear seats, fixed IL- SU ** IL-SUIL-SUIUF / IL- SUIUF / IL- SU

Outer rear seats, adjustable longitudinallyIL- SU ** IL-SUIL-SUIUF / IL- SUIUF / IL- SU


Centre rear seat XIL-SUIL-SUIUF / IL- SUIUF / IL- SU


Rear seat in the 3rdrowNot ISOFIX

257
6
Safety
IUF: seat suitable for the installation of an
ISOFIX U niversal seat, " Forwards-facing"secured using the top strap to the top
tether on ISOFIX seats. IL- SU: seat suitable for the installation of anIsofix Semi- Universal seat either:


- "rearwards-facing" fitted with a top belt
or a stay,

- "
forwards-facing" fitted with a stay,

- a sleeper cot fitted with an upper strap
or a sta
y.
Remove and stow the head restraintbefore installing a child seat on a passenger seat. Refit the head restraint
once the child seat has been removed. For advice on securin
g of the top belt, refer to
the "Isofix Mountings" section. X: seat not suitable for the installation of a
child seat or sleeper cot for the weight groupindicated.(1)
: The outer seat in row 2 must be adjusted
to 3 notches back from the fully forward position.

258
Safety
The incorrect installation of a child seat in a vehicle compromises the child's protection in
the event of an accident.
Remember to fasten the seat belts or the child seat harnesses keeping the slackin relation to the child's body to a minimum
,
even for shor t journeys.
For optimum installation of the "for ward facing" child seat, ensure that the back of the child seat is as close as possible to the backrest of the vehicle's seat, or in contactif possible
The head restraint must be removed beforeinstalling a child seat with a backrest on the passenger seat.
Ensure that the head restraint is stowed or attached securely so that it is not thrownaround the vehicle in the event of sharp braking.
Refit the head restraint as soon as the childseat is removed.












Advice on child seats


Children at the front
The legislation on carrying a child on the front passenger seat is specific to each country. Refer to the legislation in force inyour country.
Deactivate the passenger's airbag when a"rearward facing" child seat is installed on the front seat. Otherwise, the child would riskbeing seriously injured or killed if the airbag were deployed.


As a safety precaution, do not leave: - one or more children alone and
unsupervised in a vehicle, - a child or an animal in a vehicle which is exposed to the sun, with the windowsclosed,
- the keys within reach of children insidethe vehicle.To prevent accidental opening of the doors, use the "Child lock".Take care not to open the rear windows bymore than one third.To protect young children from the rays of the sun, fit side blinds on the rear windows.

Installing a booster cushion

The chest par t of the seat belt must be positioned on the child's shoulder withouttouching the neck.
Ensure that the lap part of the seat belt passes correctly over the child's thighs. CITROËN recommends the use of a booster seat which has a back, fitted with a seat belt guide at shoulder level.
