Citroen C5 DAG 2008.5 (RD/TD) / 2.G Owner's Manual

2
33
44
11
55
22
USB PLAYER
USING THE USB PORT
Press LIST briefl y to display the list of Folders/Genres/Artists/Playlists on the USB equipment. Navigate through the list using the left/right and up/down buttons. Confi rm the selection by pressing OK.
The lists available are Artist, Genre and Playlist (as defi ned on the iPod ® ). ®
Selection and Navigation are described in steps 1 to 5 above.
Do not connect a hard disk or USB devices other than audio equipment to the USB port This could damage your in stallation.
CONNECTING AN IPOD ®AN IPOD AN IPOD VIA THE USB PORT ®
Press one of these buttons to gain access to the previous/next track on the classifi cation list currently being played. Press and hold one of the buttons for fast forward or rewind play.
Press one of these buttons to gain access to the previous/next Genre, Folder, Artist or Playlist on the classifi cation list currently being played.
Press and hold LIST to display the different classifi cations. Select by Folder/Artist/Genre/Playlist, press OK to select the classifi cation required, then press OK again to confi rm.
- by Folder: all folders containing audio fi les recognised on the peripheral device, classifi ed in alphabetical order without following the fl ow chart. - by Artist: all of the artist names defi ned in the ID3 Tags, classifi ed in alphabetical order. - by Genre: all of the genres defi ned in the ID3 Tags. - by Playlist: in accordance with the playlists recorded on the USB device.
OK

3
11
22
22
11
Then adjust the volume of your audio equipment.
The auxiliary input, JACK and RCA, permits the connection of portable equipment (MP3 player...).
Connect the portable equipment (MP3 player…) to the JACK socket or to the audio sockets (white and red, RCA type) using a suitable cable (not supplied).
Press the SOURCE button several times in succession and select AUX.
USING THE AUXILIARY INPUT (AUX)
JACK SOCKET OR RCA SOCKET (according to vehicle)
ADJUSTING THE VOLUME OF THE AUXILIARY SOURCE
Do not connect a single piece of equipment to the USB socket and the JACK socket at the same time.
The controls are displayed and managed via the portable equipment.
USB PLAYER

4
11
66
22
77
44
99
55
1010
33
88
Saisir code authentiication01OKDel23456789_
BLUETOOTH FUNCTIONS
For reasons of safety and because they require prolonged attention on the part of the driver, the operations for pairing of the Bluetooth mobile telephone with the Bluetooth system of your audio equipment should only carried out with the vehicle stationary. The ignition must be on.
Activate the telephone's Bluetooth function.
A window is displayed with "Searching...".
Press the MENU button.
In the menu, select: - Bluetooth telephone function - Audio - Bluetooth confi guration - Perform a Bluetooth search
The services offered depend on the network, the SIM card and the compatibility of the Bluetooth equipment used. Consult your telephone's manual and your operator to fi nd out which services are available to you. A list of mobile telephones which offer the best range of services is available from the networ k, contact your dealer. BLUETOOTH TELEPHONE
SCREEN C
(AVAILABLE DEPENDING ON MODEL AND VERSION)
The TELEPHONE menu gives access to the following f unctions in particular: Directory * , Call list, Pairing management.
The fi rst 4 telephones recognised are displayed in this window.
"Pairing of Name_telephone successful" appears on the screen.
The automatic connection authorised is only active after the telephone has been confi gured. The directory and the call list can be accessed after the synchronisation period.
OK
PAIRING A TELEPHONE
The pairing can also be initiated from the telepho ne.
A virtual keypad is displayed on the screen: enter a code with at least 4 digits. Confi rm by pressing OK.
Select the telephone to be connected from the list . Only one telephone can be connected at a time.
A message is displayed on the screen of the telephone chosen: to accept the pairing, enter the same code on the telephone, then confi rm by pressing OK. If pairing fails, the number of attempts is not limited.
* if your telephone hardware is fully compatibl e.

5
11
22
11
22
11
22
33
YES
RECEIVING A CALL
An incoming call is announced by a ring and a superimposed display on the multifunction screen.
Select the YES tab on the screen using the buttons and confi rm by pressing OK.
Press TEL or OK on the steering wheel controls to accept the call.
From the Bluetooth telephone function Audio menu, select Manage the telephone call then call, call list or directory.
Press the TEL steering wheel control, or press and hold OK for access to your directory. Or To dial a number, use your telephone's keypad, with the vehicle stationary.
MAKING A CALL
Initiate the pairing between the telephone and the vehicle. This pairing can be initiated from the vehicle's telephone function menu or via the telephone's keypad. See steps 1 to 10 on the previous pages. During the pairing phase, the vehicle must be stationary with the ignition on.
Select the telephone to be connected from the telephone function menu. The audio system connects to a newly paired telephone automatically.
BLUETOOTH AUDIO STREAMING
(AVAILABLE DEPENDING ON MODEL AND VERSION)
Wireless transmission of the telephone's music fi les via the audio equipment. The telephone must be able to manage the appropriate bluetooth profi les (Profi les A2DP/AVRCP).
* In certain cases, playing of the Audio fi les must be initiated from the keypad. ** If the telephone supports the function.
Activate the streaming source by pressing the SOURCE button * . The tracks to be played can be controlled as usual via the buttons on the Radio control panel and the steering wheel controls ** . The contextual information can be displayed on the screen.
BLUETOOTH FUNCTIONS

156
10
C H E C K S HDi 173 -
V6 HDi 240 engines
(with particle filter)

1. Screen wash and headlamp
wash reservoir.

2. Power steering and suspension
fl uid reservoir.

3. Engine coolant reservoir.

4. Engine oil dipstick.

5. Engine oil fi ller cap.

6. Air fi lter.

7. Brake fl uid reservoir.

8. Battery.

9. "+" and "-" terminals for starting
with a slave battery.

The diesel fuel system
being under high pres-
sure:
- Any intervention on the system
is prohibited.
- HDi engines are the result of advanced technology.

Any intervention requires spe-
cial qualifi cations which only a
CITROËN dealer can guarantee.

HDi 173

V6 HDi 240

48
3
C O M F O R T
AUTOMATIC AIR CONDITIONING (DUAL-ZONE)

Dual-zone: this is the differentiated regulation of the temperature and air distri-
bution on the driver's side and the front passenger side.
The driver and his front passenger can each adjust the temperat ure and the
distribution of the air to suit their requirements.
The symbols and messages associated with the automatic air condit ioning con-
trols appear on the multifunction screen. This is the normal sys-
tem operating mode.
In accordance with the
level of comfort chosen,
pressing this control,
confi rmed by the display
of indicator lamp A , permits auto-
matic and simultaneous control of
all of the following functions:
- Air fl ow.
- Temperature in the passenger compartment.
- Air distribution.
- Air conditioning.
- Automatic air recirculation.
It is advisable to leave all of the
vents open. Simply pressing one
of the controls, with the exception
of temperature regulation 1a and

1b , switches the system to manual
mode. Indicator lamp A switches off.
1a-1b. Automatic operation

1a.
Automatic operation on the driver's
side

1b. Automatic operation on the pas-
senger's side

2a. Temperature adjustment on the
driver's side

2b. Temperature adjustment on the
passenger's side

3a. Air distribution adjustment on the
driver's side

3b. Air distribution adjustment on
the passenger's side
4a. Driver's zone display

4b. Passenger's zone display

5. Air fl ow adjustment

6. Activation/deactivation of the air
conditioning

7.
Air recirculation – intake of exterior
air

8. Rear demisting - defrosting

9. Front demisting - defrosting

49
3
C O M F O R T

 Turn control 2a to change the
temperature on the driver's side
and control 2b to change the
temperature on the passenger's
side: to the right to increase the
temperature or to the left to re-
duce it.
The setting required is displayed.
The value indicated on the display
corresponds to a level of comfort
and not to a temperature in degrees
Celsius or Fahrenheit, depending
on the screen confi guration.
A setting around the value 21 usually
makes it possible to obtain optimum
comfort. However, depending on your
requirements, a setting between 18
and 24 is usual.
On entering the vehicle, the interior
temperature may be much colder
(or warmer) than is comfortable.
There is no need to change the
temperature displayed in order to
quickly obtain the level of comfort
required.
The automatic regulation of the air
conditioning will use its maximum
performance settings to correct the
temperature difference as quickly
as possible.
2a-2b. Temperature adjustment Control via the manual
controls

 Press one of the controls, with
the exception of temperature
regulation 2a and 2b . The indi-
cator lamps A on the "AUTO"
controls switch off.
It is possible to adjust one or more
functions manually while leaving the
other functions in automatic mode.
Switching to manual mode may re-
sult in discomfort (temperature, hu-
midity, odour, condensation) and
may not provide optimum comfort.
To return to "AUTO" mode, press
controls 1a and 1b . The indicator
lamps A come on. 3a-3b. Air distribution adjustment

 Press control

3a to change
the distribu-
tion of the air
fl ow on the
driver's side.

 Press control 3b to change the
distribution of the air fl ow on the
passenger's side.
The indicator lamps corresponding
to the distribution chosen come on:
- Windscreen and front side win- dows.
- Front ventilation (central and side vents and air diffusion grille
if open) and rear ventilation.
- Front and rear footwells.
Simultaneous display of the distribu-
tion of air to the windscreen and side
windows and of front and rear venti-
lation is not possible.

50
3
C O M F O R T
5. Air fl ow adjustment
 Press the control:
- to increase the air fl ow,
-
to reduce the air fl ow.
The air fl ow level is indicat-
ed by the progressive light-
ing of the fan blade indicator lamps.

Reducing the fl ow to minimum
switches the air conditioning OFF.
To prevent condensation and dete-
rioration of the quality of the air in
the passenger compartment, ensure
that an adequate fl ow of air is main-
tained.
6. Air conditioning
The air conditioning will
only operate when the
engine is running. The air
blower control (air fl ow ad-
justment) must be active in
order to obtain air conditioning.

 Press control 6 . The indicator
lamp comes on.
In order to be effective, the air
conditioning must be used with the
windows closed. 7. Air recirculation - intake of
exterior air
Automatic air intake
mode
It is activated by default
in automatic comfort
regulation.
Automatic mode is activated with
reverse gear or operation of the
screenwash.
This function permits recircula-
tion of the air and isolation the
passenger compartment from
exterior fumes and odours. It is
inactive when the ambient tem-
perature is below +5°C to avoid
the risk of misting inside the ve-
hicle.

Closing the air intake

 Press control 7 to
close the exterior air
intake.
It must be cancelled as soon as pos-
sible to permit renewal of the air in
the passenger compartment and
demisting.

Intake of exterior air

 Press control 7 once
to open the exterior air
intake.
While retaining the other settings,
this position allows the driver to iso-
late the passenger compartment at
any time from unpleasant exterior
odours and fumes.

98
6
F I T T I N G S
BOOT FITTINGS (SALOON)

1. Battery for vehicles with V6 HDi
engine.

2. Boot fl oor (spare wheel stor-
age).

3. Boot lamp.

4. Location for 6 CD changer. Luggage securing rings

 Use the 4 securing rings on
the boot fl oor to secure your
luggage.
For safety reasons in the event of
sharp braking, you are advised to
place heavy objects as far forward
in the boot as possible.

164
11
P R A C T I C A L I N F O R M A T I O N
CHANGING A WHEEL
Access to the tools
The tools are to be found in a protec-
tive holder inside the spare wheel.

 Pull back the retaining strap for
access. List of tools

1. Wheelbrace

2. Jack

3. Tool for the removal/refi tting of
bolt protectors
4. Centring guide

5. Towing eye

6. Moveable chock (depending on
equipment)
