38M O N I T O R I N G
Total distance recorder
S y s t e m w h i c h m e a s u r e s t h e t o t a l
d i s t a n c e t r a v e l l e d b y t h e v e h i c l e
during its life.
The total and trip distances are dis-
p l a y e d f o r t h i r t y s e c o n d s w h e n t h e
i g n i t i o n i s s w i t c h e d o f f , w h e n t h e
d r i v e r ' s d o o r i s o p e n e d a n d w h e n
the vehicle is locked or unlocked.
Trip distance recorder
S y s t e m w h i c h m e a s u r e s a d i s t a n c e
t r a v e l l e d d u r i n g a d a y o r o t h e r p e -
r i o d s i n c e i t w a s r e s e t t o z e r o b y t h e
driver.
W i t h t h e i g n i t i o n o n , p r e s s t h e
b u t t o n u n t i l z e r o s a p p e a r . Lighting rheostat
S y s t e m f o r m a n u a l a d j u s t m e n t o f
the brightness of the instruments
and controls in relation to the exte-
rior brightness.
Operation
Press button A to decrease the
brightness of the instruments
and controls.
Press button B to increase the
brightness of the instruments
and controls. Deactivation
W h e n t h e l i g h t s a r e o f f , o r i n d a y
m o d e o n v e h i c l e s fi t t e d w i t h d a y t i m e
r u n n i n g l i g h t s , p r e s s i n g t h e b u t t o n s
d o e s n o t h a v e a n y e f f e c t .
Page 22 of 306
II
39
M U L T I F U N C T I O N S C R E E N S
MONOCHROME SCREEN C Main Menu
Press on the button A to view the
Main Menu of the multifunction
screen. This menu gives you access
to the following functions:
Presentation
Radio-CD
(see "Audio and Telematics"
chapter)
Bluetooth ®
system
(see "Audio and Telematics"
chapter)
Controls
1. Time
2. Ambient temperature
3. Date and display zone
When the outside temperature is
between +3 °C and -3 °C, the tem-
p e r a t u r e d i s p l a y fl a s h e s ( i c e r i s k ) .
The ambient temperature displayed
may be greater than the actual tem-
p e r a t u r e , i f t h e v e h i c l e i s p a r k e d i n
bright sunlight.
It is recommended that the driver
should not operate the controls
while the vehicle is in motion. Personalisation -
Configuration
This permits activation/deactivation
of the:
- brightness and contrast of the multifunction screen,
- date and time,
- units of the outside temperature displayed.
A. Access to the "Main Menu"
B. Cancellation of the operation or
return to the previous display
C. Scrolling in the screen menus
C o n fi r m a t i o n a t t h e s t e e r i n g wheel
D. C o n fi r m a t i o n o n t h e a u d i o e q u i p -
ment control panel
Page 23 of 306
II
40
M U L T I F U N C T I O N S C R E E N S
Adjusting the brightness and
contrast
Press on A .
Use C to select the "Brightness -
v i d e o a d j u s t m e n t " m e n u . C o n fi r m
with a press on C on the steering
wheel or D o n t h e a u d i o e q u i p -
ment.
S e l e c t t h e c o n fi g u r a t i o n o f t h e
screen using C . C o n fi r m w i t h a
press on C on the steering wheel
or D o n t h e a u d i o e q u i p m e n t .
Select the brightness setting.
C o n fi r m w i t h a p r e s s o n C on the
steering wheel or D on the audio
e q u i p m e n t .
Select the inverse or normal dis-
play mode using C then validate
with a press on C on the steering
wheel or D o n t h e a u d i o e q u i p -
ment. To adjust the brightness
select "+" or "-" and save your
setting with a press on C .
C o n fi r m w i t h "OK" on the
screen. Adjusting the date and the
time
Press on A .
Use C to select the "Date and
time adjustment" menu, then
c o n fi r m y o u r c h o i c e w i t h a p r e s s
on C on the steering wheel or D
o n t h e a u d i o e q u i p m e n t .
S e l e c t t h e s c r e e n c o n fi g u r a t i o n
using C . C o n fi r m w i t h a p r e s s o n
C on the steering wheel or D on
t h e a u d i o e q u i p m e n t .
Select the date and the time set-
tings, using B . C o n fi r m w i t h a
press on C on the steering wheel
or D o n t h e a u d i o e q u i p m e n t .
Press C to select the values you
w i s h t o m o d i f y . C o n fi r m y o u r
choice with a press on C on the
steering wheel or D on the audio
e q u i p m e n t .
C o n fi r m w i t h "OK" on the
screen. Choosing the units
Press on A .
Use C to select the "Choice of
u n i t s " m e n u , t h e n c o n fi r m y o u r
choice with a press on C on the
steering wheel or D on the audio
e q u i p m e n t .
Using C , select the unit then val-
idate with a press on C on the
steering wheel or D on the audio
e q u i p m e n t .
C o n fi r m w i t h "OK" on the
screen.
Selection of the type of
information displayed (Mode)
Successive presses on the end of
t h e w i p e r s t a l k o r o n t h e MODE but-
t o n o n t h e a u d i o e q u i p m e n t p e r m i t
selection of the type of informa-
tion presented on the multifunction
screen (date or radio, CD, MP3 CD,
CD changer).
Page 24 of 306
II
41
M U L T I F U N C T I O N S C R E E N S
16/9 COLOUR SCREEN (WITH MY WAY)
Displays on the screen
It displays the following information
automatically and directly:
- time,
- date,
- altitude,
- ambient temperature (the value d i s p l a y e d fl a s h e s i f t h e r e i s a r i s k
of ice),
- audio functions,
- satellite navigation system infor- mation. Controls
From the MyWay control panel, to
select one of the applications:
press the dedicated "RADIO" ,
"MUSIC" , "NAV" , "TRAFFIC" ,
"SETUP" or "PHONE" button
for access to the corresponding
menu,
turn the dial to move the selection,
p r e s s t h e d i a l t o c o n fi r m t h e s e -
lection,
or
press the "ESC" button to aban-
don the current operation and re-
turn to the previous display.
* According to country. For more information on these
applications, refer to the "Audio
E q u i p m e n t " s e c t i o n o r t o t h e s p e -
c i fi c u s e r g u i d e g i v e n t o y o u w i t h
the other owner's documents. "SETUP" menu
Press the "SETUP" button to
gain access to the "SETUP"
menu. This allows you to select
from the following functions:
- "System language",
- "Date & time",
- "Display",
- "Units",
- "System".
System language
This menu allows you to select
the language used by the dis-
play: Deutsch, English, Espanol,
Français, Italiano, Nederlands,
P o l s k i , P o r t u g u e s , T ü r k ç e * .
Page 25 of 306
II
42
M U L T I F U N C T I O N S C R E E N S
Display
This menu allows you to set the
brightness of the screen, the screen
colour scheme and the colour of the
map (day/night or auto mode). Units
This menu allows you to select the
units for temperature (°C or °F) and
d i s t a n c e ( m i l e s o r k i l o m e t r e s ) .
System
This menu allows you to restore the
f a c t o r y c o n fi g u r a t i o n , d i s p l a y t h e
software version and activate scroll-
ing text.
F o r s a f e t y r e a s o n s , c o n fi g u r a t i o n
of the multifunction screen by the
driver must be only done when sta-
tionary.
Date & time
This menu allows you to set the date
and time, the format of the date and
the format of the time.
To set the date and time:
Press the "SETUP" control.
Turn the dial to select "DATE &
TIME" .
P r e s s t h e d i a l t o c o n fi r m .
Turn the dial to select "SET
DATE & TIME" .
P r e s s t h e d i a l t o c o n fi r m .
T u r n t h e d i a l t o s e l e c t a fi e l d :
- C for the day,
- D for the month,
- E for the year,
- F for the time.
P r e s s t h e d i a l t o c o n fi r m .
Turn the dial or use the alphanu-
m e r i c k e y p a d t o s e l e c t t h e d i g i t s
which form the date and time.
P r e s s t h e d i a l t o c o n fi r m e a c h
fi e l d .
Turn the dial to select "DATE
FORMAT" .
C h o o s e t h e f o r m a t r e q u i r e d a n d
p r e s s t h e d i a l t o c o n fi r m .
Turn the dial to select "TIME
FORMAT" .
C h o o s e t h e f o r m a t r e q u i r e d a n d
p r e s s t h e d i a l t o c o n fi r m .
Page 26 of 306
II
43
M U L T I F U N C T I O N S C R E E N S
16/9 HIGH DEFINITION COLOUR SCREEN (WITH NAVIDRIVE 3D)
Displays on the screen
It displays the following information
automatically and directly:
- time,
- date,
- altitude,
- ambient temperature (the value d i s p l a y e d fl a s h e s i f t h e r e i s a r i s k
of ice),
- audio functions,
- t e l e p h o n e a n d a d d r e s s b o o k i n - formation,
- satellite navigation system infor- mation. Controls
From the NaviDrive 3D control pan-
el, to select one of the applications:
press the dedicated "RADIO" ,
"MEDIA" , "NAV" , "TRAFFIC" ,
"ADDR BOOK" or "SETUP"
button for access to the corre-
sponding menu,
turn the dial to move the selection,
p r e s s t h e d i a l t o c o n fi r m t h e s e -
lection,
or
press the "ESC" button to aban-
don the current operation and
return to the previous display. For more information on these
applications, refer to the "Audio
E q u i p m e n t " s e c t i o n o r t o t h e s p e -
c i fi c u s e r g u i d e g i v e n t o y o u w i t h
the other owner's documents.
Page 27 of 306
II
44
M U L T I F U N C T I O N S C R E E N S * According to country.
"SETUP" menu
Press the "SETUP" button to gain
access to the "SETUP" menu.
This allows you to select from
the following functions:
- "Languages and Speech",
- "Date & Time",
- "Display",
- "Units",
- "System".
Language & Speech
This menu allows you to:
- select the language used by the display (Deutsch, English,
Espanol, Français, Italiano,
N e d e r l a n d s , P o l s k i , P o r t u g u e s ,
T ü r k ç e * ) ,
- select the voice recognition pa- rameters (activation/deactiva-
tion, advice on use, personal
voice programming, etc.),
- set the volume of the voice syn- thesiser. Date & Time
This menu allows you to set the date
and time, the format of the date and
the format of the time (refer to the
" A u d i o E q u i p m e n t " s e c t i o n o r t o t h e
s p e c i fi c u s e r g u i d e g i v e n t o y o u w i t h
the other owner's documents).
Display
This menu allows you to set the
brightness of the screen, the screen
colour scheme and the colour of the
map (day/night or auto mode).
Units
This menu allows you to select the
units: temperature (°C or °F) and
d i s t a n c e ( k m o r m i l e s ) .
System
This menu allows you to restore the
f a c t o r y c o n fi g u r a t i o n , d i s p l a y t h e
software version and activate scroll-
ing text.
F o r s a f e t y r e a s o n s , c o n fi g u r a t i o n
of the multifunction screen by the
driver must only be done when
stationary.
Page 28 of 306
III
45
C O M F O R T
VENTILATION
A. Sunshine sensor.
B. Soft air diffusion grille.
The soft air diffusion grille locat- ed in the centre of the dashboard
provides optimum distribution of
the air for the front seats.
This system eliminates unpleas- ant air currents while maintaining
an optimum temperature in the
passenger compartment.
To open the soft air diffusion grille, turn the wheel upwards.
To close the soft air diffusion grille, turn the wheel fully down-
wards.
In very hot weather, to obtain more satisfactory central and
side ventilation, it is advisable to
close the diffused air grille.
C. Cooled glove box.
D. Rear passenger vents.
Page 29 of 306
III
46
C O M F O R T
Air conditioning
We recommend use of the automatic
regulation of the air conditioning.
It permits automatic and optimised
control of all of the following func-
t i o n s : a i r fl o w , t e m p e r a t u r e i n t h e
passenger compartment and air
distribution, by means of various
sensors (ambient temperature, sun-
shine). This eliminates any need for
you to change your settings other
than the temperature value dis-
played.
Take care not to cover the sun-
shine sensor A .
If you select the automatic mode (by
pressing the "AUTO" control) and leave
all of the vents open, optimum comfort
will be maintained and humidity and
condensation will be removed regard-
less of the exterior climatic conditions.
The temperature in the passenger
compartment can only be lower than
the ambient temperature if the air
conditioning is on.
HEATING, VENTILATION AND AIR CONDITIONING RECOMMENDATIONS
In order to be effective, the air con-
ditioning must be used with the win-
dows closed. If the vehicle has been
parked in the sun for a long period
and the interior temperature is very
h i g h , fi r s t v e n t i l a t e t h e p a s s e n g e r
compartment with the windows
open for a few minutes, then close
the windows.
To keep the air conditioning system
in good working order it is essential
that it is operated at least once a
month.
The air conditioning uses engine power
during its operation. As a result, the fuel
consumption of the vehicle increases.
In certain cases of particularly ardu-
ous use (e.g. towing the maximum
load on a steep gradient in high
temperatures), switching off the air
conditioning saves engine power
and improves the towing capacity.
Air inlet
Check that the exterior grille for the
air inlet, at the bottom of the wind-
screen, is clean and free of dead
leaves, snow, etc.
When washing the vehicle using a
high pressure nozzle, avoid spraying
at the air inlet. Air circulation
Maximum comfort is obtained by
means of a good distribution of air in
the passenger compartment, both in
the front and in the rear.
To obtain a uniform distribution of
air, take care not to block the ex-
terior air intake grille located at the
base of the windscreen, the vents,
the air outlets under the front seats
and the air extractor located behind
t h e fl a p s i n t h e b o o t .
T h e f r o n t a n d r e a r v e n t s a r e fi t t e d
with thumbwheels to adjust the air
fl o w a n d d i r e c t i o n . W e r e c o m m e n d
that you leave all of the vents open.
Dust filter/Odour filter
(active carbon)
T h e r e i s a fi l t e r f o r e x c l u d i n g o d o u r s
and dust.
T h i s fi l t e r m u s t b e c h a n g e d i n l i n e
with the vehicle's servicing schedule
(see: "Maintenance and Warranty
Guide").
Page 30 of 306
III
47
C O M F O R T
DIGITAL AIR CONDITIONING (MONO-ZONE)
This is the normal sys-
tem operating mode.
In accordance with the
level of comfort cho-
sen, pressing this con-
t r o l , c o n fi r m e d b y t h e
switching on of indicator lamp A , per-
mits automatic and simultaneous con-
trol of all of the following functions:
- A i r fl o w .
- Temperature in the passenger compartment.
- Air distribution.
- Air intake.
- Air conditioning.
1. Automatic operation
It is advisable to leave all of the
vents open.
Simply pressing one of the controls,
with the exception of control
2 , switches
the system to manual mode.
Indicator lamp A switches off. 2. Temperature adjustment
Turn control 2 to
change the tempera-
ture:
- Clockwise to increase the temperature.
- Anticlockwise to reduce the tem- perature.
The setting required is displayed.
The value indicated on the display
corresponds to a level of comfort
and not to a temperature in degrees
Celsius or Fahrenheit, depending on
t h e s c r e e n c o n fi g u r a t i o n .
A setting around the value 21 usu-
ally makes it possible to obtain opti-
mum comfort. However, depending
on your requirements, a setting be-
tween 18 and 24 is usual.
On entering the vehicle, the interior
temperature may be much colder (or
warmer) than is comfortable. There is
no need to change the temperature
displayed in order to obtain rapidly
the level of comfort required.
The automatic regulation of the air
conditioning will use its maximum
performance settings to correct the
temperature difference as quickly as
possible.
Mono-zone: this is the overall regu-
lation of the temperature, distribu-
t i o n a n d fl o w o f a i r i n t h e p a s s e n g e r
compartment.
The symbols and messages associ-
ated with the digital air conditioning
controls appear on the multifunction
screen.
1. Automatic operation
2. Temperature adjustment
3. Air distribution adjustment
4. Activation/deactivation of the air
conditioning
5. A i r fl o w a d j u s t m e n t
6. Front demisting - defrosting
7. Rear demisting - defrosting
8. Air recirculation - intake of exte-
rior air
9. Screen
