STOP & START
T h e S t o p & S t a r t s y s t e m p u t s t h e e n -
g i n e t e m p o r a r i l y o n s t a n d b y - S T O P
m o d e - d u r i n g s t o p s i n t h e t r a f fi c
( r e d l i g h t s , t r a f fi c j a m s , o r o t h e r . . . ) .
The engine restarts automatically -
S T A R T m o d e - a s s o o n a s y o u w a n t
to move off. The restart takes place
instantly, quickly and silently.
P e r f e c t f o r u r b a n u s e , t h e S t o p &
S t a r t s y s t e m r e d u c e s f u e l c o n s u m p -
t i o n a n d e x h a u s t e m i s s i o n s a s w e l l
as the noise level when stationary.
Operation
- with the 6-speed electronic
gearbox system, at speeds be-
low 4 mph (6 km/h), press the
brake pedal or put the selector
lever in position N .
Going into engine STOP mode
The "ECO" warning lamp
comes on in the instrument
panel and the engine goes
into standby: I f y o u r v e h i c l e i s fi t t e d
with the system, a time
counter calculates the
sum of the periods in
S T O P m o d e d u r i n g a j o u r n e y . I t r e s t s
itself to zero every time the ignition
is switched on with the key.
For your comfort, during parking
m a o e u v r e s , S T O P m o d e i s n o t a v a i l -
able for a few seconds after coming
out of reverse gear.
S T O P m o d e d o e s n o t a f f e c t t h e f u n c -
t i o n a l i t y o f t h e v e h i c l e , s u c h a s f o r e x -
ample, braking, power steering...
Never refuel with the engine
i n S T O P m o d e ; y o u m u s t
switch off the ignition with the key. Special cases: STOP mode
unavailable
In this case, the "ECO"
w a r n i n g l a m p fl a s h e s f o r a
few seconds then goes off.
This operation is perfectly normal.
S T O P m o d e i s n o t i n v o k e d w h e n :
- the driver's door is open,
- the driver's seat belt is not fas-
tened,
- t h e v e h i c l e h a s n o t e x c e e d e d 6 mph (10 km/h) since the last
engine start using the key,
- the electric parking brake is ap- plied or being applied,
- the engine is needed to maintain a comfortable temperature in the
passenger compartment,
- demisting is active,
- some special conditions (bat- tery charge, engine tempera-
ture, braking assistance, ambient
temperature...) where the engine
is needed to assure control of a
system.
Page 162 of 336
IX
141
D R I V I N G
Page 163 of 336
IX
!
!
142
D R I V I N G
In the event of a malfunction with
the system, the "ECO OFF" switch
w a r n i n g l a m p fl a s h e s t h e n c o m e s
on continuously.
Have it checked by a CITROËN
dealer.
I n t h e e v e n t o f a f a u l t i n S T O P m o d e ,
the vehicle may stall. It is then nec-
essary to switch off the ignition and
start the engine again using the
key.
Operating fault
T h e S t o p & S t a r t s y s t e m
makes use of advanced
t e c h n o l o g y . S p e c i a l i s t k n o w l e d g e
is needed for any work on the sys-
tem, which can only be assured by
CITROËN dealers. Before working under the
b o n n e t , d e a c t i v a t e t h e S t o p &
S t a r t s y s t e m t o a v o i d a n y r i s k
of injury resulting from automatic
o p e r a t i o n o f S T A R T m o d e .
Maintenance
This system requires a battery with
a s p e c i a l s p e c i fi c a t i o n a n d t e c h n o l -
ogy (reference numbers available
from CITROËN dealers).
Fitting a battery not listed by
CITROËN introduces the risk of
malfunction of the system.
Page 164 of 336
IX
!
143
D R I V I N G
Mode selection Displays on the instrument panel
automatic mode: gear lever in
position D ,
sequential mode: gear lever in
position M ,
SPORT mode: gear lever in po-
sition D and button A pressed,
SNOW mode: gear lever in posi-
tion D and button B pressed. The position of the gear lever and
the driving mode are displayed on
the instrument panel dial
C .
A position grille associated with the
gear lever allows you to view the
selected position.
For safety:
- position P can be disen-
gaged only if you press
the brake pedal,
- when a door is opened, an au- dible signal is heard if the gear
lever is not in position P ,
- always make sure that the gear lever is in position P before you
leave your vehicle.
I f t h e g e a r b o x i s i n p o s i t i o n P but
the position of the gear lever is dif-
ferent, reposition the gear lever on
P so that you can start the vehicle.
AUTOMATIC GEARBOX
A u t o m a t i c g e a r b o x w h i c h o f f e r s a
choice between the comfort of fully
automatic operation, enhanced by
the sport and snow programmes, or
manual gear changing.
Four driving modes are provided:
- automatic operation for elec-
tronic control of the gears by the
g e a r b o x ,
- the SPORT programme for a
more dynamic driving style,
- the SNOW programme to im-
prove driving when the grip is
poor,
- manual operation for sequen-
tial changing of the gears by the
driver.
Page 165 of 336
IX
!
144
D R I V I N G
Never select positions P or R
if the vehicle is not stationary.
If, while the vehicle is moving, po-
sition N is engaged inadvertently,
allow the engine to idle before en-
gaging position D or M .
Moving off
To start the engine, the gear
lever must be in position P or N .
Operate the starter.
When the engine is running,
place the gear lever on R , D or
M as required.
Check, in the instrument panel,
the position engaged.
Release the brake pedal and ac-
celerate.
To avoid a possible difference
between the position of the gear
lever and the actual position of
t h e g e a r b o x , a l w a y s e x i t f r o m
position P with the ignition on
and brake pedal applied.
Otherwise, when the ignition is on or
the engine is running:
reposition the gear lever in posi-
tion P ,
put your foot on the brake ped-
al and then select the gear you
want. Park
This position of the gear le-
ver is used to prevent the
vehicle from moving when
you are stationary.
To select position P, move the
gear lever back to the highest
position (towards R ), then push
it forwards and then to the left.
T o e x i t p o s i t i o n P , move the gear
lever to the right and then to the
position you want.
Only engage this position when
the vehicle is completely sta-
tionary. In this position, the front
wheels are locked. Make sure
that the gear lever is correctly
positioned. Reverse gear
Only engage this position
when the vehicle is station-
ary. To prevent snatching,
do not accelerate too soon
after selection.
Neutral Never select position N if
the vehicle is moving.
Page 166 of 336
IX
145
D R I V I N G
Automatic operation
Move the gear lever to position D .
T h e g e a r b o x c o n s t a n t l y s e l e c t s the gear that is best suited to the
following parameters:
- driving style,
- r o a d p r o fi l e
- vehicle load.
T h e g e a r b o x o p e r a t e s w i t h o u t r e q u i r -
ing any intervention on your part.
F o r c e r t a i n m a n o e u v r e s ( f o r e x -
ample overtaking), you can obtain
m a x i m u m a c c e l e r a t i o n b y p r e s s i n g
the accelerator pedal hard down
past the point of resistance, which
then produces an automatic change
down to a lower gear. W h e n b r a k i n g , t h e g e a r b o x m a y
change down automatically in order
to provide effective engine braking.
If you lift your foot off the accelerator
a b r u p t l y , t h e g e a r b o x w i l l n o t e n g a g e
a higher gear.
Manual operation
Position of the gear lever for manual
gear changing.
Move the gear lever to position M .
Push the gear lever towards the
" + " sign to change up a gear.
Pull the gear lever towards the " - "
sign to change down a gear. - If the vehicle stops or reduces
s p e e d ( f o r e x a m p l e w h e n a p -
proaching a stop sign), the gear-
b o x c h a n g e s d o w n a u t o m a t i c a l l y
t o fi r s t g e a r .
- In sequential mode, it is not nec- essary to release the accelerator
during gear changes.
- A request to change gear is ac- cepted only if the engine speed
permits it.
- The SPORT and SNOW modes
do not operate in sequential
mode.
Page 167 of 336
IX
!
146
D R I V I N G
SPORT and SNOW
programmes
SPORT programme "S"
These two special programmes sup-
plement the automatic operation in
very particular conditions of use.
With the gear lever in po-
sition D and the engine
running, press button A . SNOW programme "
"
With the gear lever in position D
and the engine running, press
button B .
T h e g e a r b o x a d a p t s t o d r i v i n g o n
slippery roads.
This programme makes moving off
easier and improves traction in con-
ditions of poor grip.
appears on the instrument
panel.
T h e g e a r b o x a u t o m a t i c a l l y f a v o u r s a
dynamic driving style.
S appears on the instrument panel. Return to automatic operation
At any time, press the button
s e l e c t e d a g a i n t o e x i t f r o m t h e
programme engaged and return
to auto-adaptive mode. A strong snatch may be felt
when selecting
R for reverse
gear.
In the event of a malfunction, the
g e a r b o x i s b l o c k e d i n o n e g e a r ;
d o n o t e x c e e d a s p e e d o f 6 2 m p h
(100 km/h).
Do not turn off the engine while the
gear selector is in position D or R .
Never press the accelerator and
brake pedals simultaneously.
Braking and acceleration should
be done with the right foot only.
Pressing both pedals simultane-
o u s l y m a y d a m a g e t h e g e a r b o x .
Consult a CITROËN dealer.
Page 168 of 336
IX
147
D R I V I N G
FIXED CENTRED CONTROLS STEERING WHEEL
1
Rotation - S c r o l l t h e v a r i o u s p a g e s o f i n f o r m a t i o n o n t h
e i n s t r u m e n t p a n e l
screen.
- Move through the various menus on the instrume nt panel screen.
- Increase/decrease values.
S h o r t p r e s s
- Open the menu on the instrument panel screen (only when stationary).
- S e l e c t a n d c o n fi r m i n f o r m a t i o n .
Long press Trip computer zero reset (if the trip computer page is displayed).
2 S h o r t p r e s s - Cancel the current operation.
- Return to the previous screen on the instrumen
t panel screen.
Long press Return to the initial page on the ins trument panel screen.
3 S h o r t p r e s s Increase the speed in steps of 1 mph (1 km/h)/stor ing the speed.
Maintained press Increase the speed in steps of 5 mph (5 km/h).
4 S h o r t p r e s s Decrease the speed in steps of 1 mph (1 km/h)/stor ing the speed.
Maintained press Decrease the speed in steps of 5 mph (5 km/h).
5 S h o r t p r e s s S u s p e n d o r r e s u m e c r u i s e c o n t r o l / s p e e d l i m i t e r ( d e
p e n d i n g o n t h e
mode selected).
6 S h o r t p r e s s S e l e c t c r u i s e c o n t r o l o r s p e e d l i m i t e r m o d e ( t h e c
y c l e o n t h i s b u t t o n
will always begin with selection of the speed limit er).
7 S h o r t p r e s s Deactivate cruise control/speed limiter.
8 S h o r t p r e s s - Pick up an incoming call.
- Hang up the current call.
- Open the telephone short-cut menu.
- C o n fi r m o n t h e l i s t a n d t h e t e l e p h o n e m e n u .
Long press Refuse an incoming call.
9 S h o r t p r e s s / L o n g p r e s s Horn.
10 S h o r t p r e s s Activate/deactivate Black Panel mode (night drivin g).
11 S h o r t p r e s s Activate the voice command.
Long press Navigation instruction repeat.
Page 169 of 336
IX
148
D R I V I N G
12
Rotation - R a d i o s o u r c e : S c r o l l t h e p r e - s e t s t a t i o n s .
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S c r o l l t h
e C D s o r
directories.
- On the multifunction screen menus: Movement an d increase/
decrease.
S h o r t p r e s s - O n t h e m u l t i f u n c t i o n s c r e e n m e n u s : c o n fi r m .
- Open the short-cut menus (depending on the mul
tifunction
screen page).
Long press Open the multifunction screen main me nu.
13 S h o r t p r e s s Cancel the current operation and return to the pre
vious page on the
multifunction screen.
When an incoming telephone call is received: Refus e the call.
Long press Return to the initial page on the mul tifunction screen.
14 S h o r t p r e s s Access to the multifunction screen general menu.
15 S h o r t p r e s s / M a i n t a i n e d p r e s s Volume increase.
16 S h o r t p r e s s / M a i n t a i n e d p r e s s Volume decrease.
17 S h o r t p r e s s - First press: mute.
- S e c o n d p r e s s : r e s t o r e s o u n d .
18 S h o r t p r e s s - Radio source: Automatic search of higher freq uencies.
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S e a r c h f o r t h e n e x t t r a c k .
Maintained press - C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : F a s t f o r w a r d p l a y .
19 S h o r t p r e s s - Radio source: Automatic search of lower frequ
encies.
- C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : S e a r c h f o r t h e
previous track.
Maintained press C D / M P 3 C D / C D c h a n g e r / j u k e b o x s o u r c e : F a s t b a c k w a r d s .
20 S h o r t p r e s s - Radio source: display the list of radio stati
ons available.
- CD/MP3 CD and CD changer source: display the l ist of CD
tracks and directories.
- J u k e b o x s o u r c e : d i s p l a y t h e l i s t o f a l b u m s .
Long press Update the list of radio stations.
21 S h o r t p r e s s / L o n g p r e s s Horn.
22 S h o r t p r e s s MODE: selection of the type of information present ed on the multifunction screen.
Page 170 of 336
IX
149
D R I V I N G
SPEED LIMITER
S y s t e m w h i c h p r e v e n t s t h e v e h i -
c l e f r o m e x c e e d i n g t h e s p e e d p r o -
grammed by the driver.
When the limit speed is reached, the
accelerator pedal no longer has any
effect.
The speed limiter is switched
on manually: a speed of at least
2 0 m p h ( a p p r o x . 3 0 k m / h ) m u s t b e
programmed.
The speed limiter can in no way re-
place respect for speed limits or vigi-
lance and responsibility on the part
of the driver.
Steering mounted controls
The speed limiter switches are lo-
cated on the left-hand side of the
steering wheel. Displays on the instrument
panel
The speed limiter information is dis-
played in zone
A of the instrument
panel.
Programming
Press on button 4 to select speed
limiter mode " LIMIT ".
T h e s e l e c t i o n i s c o n fi r m e d b y t h e
display of the function in zone A of
the instrument panel. Activation
Press on button 3 when the de-
s i r e d m a x i m u m s p e e d i s d i s -
played.
The information "ON" then appears
in zone A .
When the function is selected, the
last memorised speed and the infor-
mation "PAUSE" are displayed.
With the engine running, you can
a d j u s t t h e m e m o r i s e d m a x i m u m
speed, displayed in zone A , by
pressing on:
Button 1 to increase the memo-
r i s e d m a x i m u m s p e e d .
Button 2 to decrease the memo-
r i s e d m a x i m u m s p e e d . S u c c e s s i v e p r e s s e s w i l l m o d i f y t h e
m a x i m u m s p e e d i n s t e p s o f 1 m p h
and a continuous press in steps of
5 mph.
