remote control CITROEN C6 2012 Handbook (in English)

82
III
LOCKING/UNLOCKING
FROM THE INSIDE
A press on the controlA operates
the electric central locking andunlocking, provided all the doorsare closed.
It is still possible to open the doorsfrom the inside.
Note: ControlAis inactive if thevehicle has been locked using theremote control or the key.
The three statuses for locking/unlock-ing the vehicle are signalled by the
warning lamp on the control A:It fl ashes when the vehicle is
locked, engine stopped.
It lights up when the ignition is switched on, vehicle locked.It goes out when the vehicle is unlocked.
ï
ï
ï
ACCESS
ANTI-THEFT PROTECTION
When you start the vehicle, doors
and boot closed, the system
automatically locksthe doorsas soon as you reach a speed of
around 6 mph (10 km/h).Note: If a door has been opened, this will lock again automatically whenthe vehicle reaches approx. 6 mph(10 km/h).
Activation/Deactivation of
the anti-intrusion protection
Give a long press on control Afor central locking until you see a mes-sage displayed.ANTI-THEFT
The boot locks automatically as soon as the vehicle reaches a
speed of around6 mph (10 km/h).Note: The opening of a door or use of the control A unlocks the vehicle.
Your vehicle is fi tted with doors that have frameless windows. When you open the doors, immediately youaction the exterior handle, a micro-descent device on the SIDE WINDOWS lowers the glass slightly.
If this device were not working properly, it could result in thewindows breaking:If there should be a battery failure:
Open the doors gently.Do not close the door abruptly as this risks breaking the window, if possible wait until the battery ispowering the vehicle again.If you are intending to work on the battery, open the windows fi rst.In freezing conditions, ice may form to hinder the operation of the micro-descent device. If the actionon the door handle does not move the window down, it is essential fi rst to free the ice.
ï
--
-ï

84
III
A
B
ACCESS
BOOT
This can be unlocked, vehiclestopped:With either the remote control
or the key.
Using the interior central
unlocking button, or simply byopening a door.
Opening from the outside
Press upwards on the lever A.Note:In any event, as soon as the
vehicle is moving at more than
around 6 mph (10 km/h), the boot is locked.
When the vehicle is stationary, the boot unlocks when a door is opened or if the interior
central locking/unlocking button is pressed.
•
•
•
•
Closing the boot
Use the moulded handle on the
inside of the boot trim to lower the boot.
Press fi rml
y shut.
UNLOCKING IN EMERGENCY
In the event of a problem withunlocking the boot, the lock can bereleased if you fold the rear bench-seat:1.Insert a screwdriver into the
aperture Bin the lock.2.Turn it until the boot is unlocked.
For the Lounge Pack seats, contacta CITROËN dealer or a qualifi edg,
workshop.

93
III
The programmable heating sys-
tem operates independently of theengine.
With the engine off, it is used topreheat the engine cooling systemso as to have an optimum engine
operating temperature on starting.
The programmable heating sys-
tem is started using a long-rangeremote control. It can be startedimmediately or programmed tostart later.
In the event of a malfunction of the programmable heating sys-tem, contact a CITROËN dealer pg gy
or a qualifi ed workshop.
Remote control
The remote control for the program-
mable heating system includes the following buttons and display infor-
mation:1. Menu function scroll buttons.
2. Function symbols: clock,
temperature, operating duration, programmed time, heater operation, heater control.3. Digital display of: time,
temperature, operating
duration, programmed time
or heating level.4. Off button.5. On button.
In
formation displayed in the remote control screen
Display of functions
Press buttons1repeatedly to bringup the functions.
The fi rst press of the ri
ght or leftbutton displays the time.
The left button then
gives access
to the programming time, then theheating level (C1 to C5).
The right button gives access to
the cabin temperature, then the
operating duration of the heater
where the system is to be startedimmediately.
In
formation on the cabin tem-perature is only available with theengine off.
PROGRAMMABLE HEATING

96
III
Replacing the battery
The remote control is powered bya 6 V-28L battery cell, which isincluded.
Information appears on the screen
when this battery should be replaced.
Unclip the casing and replace thebattery.
Th
e remote control must then bere-initialised, as described on thispage.
Do not discard old batteries; take
them to an approved recyclingpoint.
Re-initialisation of the remote control
Always switch off the program-mable heating while refuelling inorder to avoid the risk of fi re or explosion.
To avoid the risk of intoxicationor asphyxiation, the program-mable heating should not beused, even for a short time, inan enclosed space such as agarage, or workshop withoutexhaust gas extraction.
Do not park the vehicle over infl ammable materials (drygrass, dead leaves, papers…),as there is a risk of fi re.
The programmable heating sys-tem is supplied by the vehicleísfuel tank. Before using it, ensurethat there is suffi cient fuel in thetank. If the low fuel warning lampis on we strongly recommendthat you do not programme theheating to come on.
PROGRAMMABLE HEATING
If the battery is disconnected or
replaced, the remote control must be re-initialised.
After switchin
g on, within fi veseconds press button4(OFF) for
1 second.
If the o
peration is successful, the "OK" message appears in the
remote control screen.
If not, the
"FAIL"message
appears. Repeat the procedure.
As a secondar
y advantage, use of your programmable heating sys-
tem allows it to be used to pre-heat
t
he passenger compartment.

133
VA
A
FUEL
If you should put in fuel that is not suitable for your vehicle'sengine type, it is imperative to have the tank drained beforeyou start the engine again.
While you are refuelling, theengine must be stopped and the
ignition switched off.
When you are seeking to fi ll your
tank, do not persist after the
third cut-off; that could cause
your vehicle to malfunction.
Fuel must be added in quantitiesof more than 5 litres to be reco-gnised by the fuel gauge.
To open the fl ap, press button A. Undo the cap and attach it to the
tab on the inside of the fl ap.
Opening the cap can trigger a
vacuum. This results in a noise caused by the sealing of the fuel circuit.Note: The fuel fl ap is locked when you lock your vehicle with the remote control.
FUEL QUALITY
A label inside the fi ller fl ap tells you
which type of fuel to use.
Quality of the fuel used for Diesel engines
The Diesel engines are perfectlycompatible with biofuels whichconform to current and futureEuropean standards (Diesel fuel
which complies with standard EN
590 mixed with a biofuel whichcomplies with standard EN 14214)which can be distributed at thepumps (possible incorporation of 0
to 7 % Fatty Acid Methyl Ester).
The use of an
y other type of (bio)fuel (vegetable or animal oils,
domestic fuel oil, etc.) is strictlyprohibited (risk of damage to theengine and fuel circuit).

149
INDEX
12 V battery ............124 → 126 - XIV
A
ABS system..................................74
Access.................................82 → 84
Access to the boot .................84 - 99
Adjusting the front seats........58 - 59
Adjustment of rear seats....97 → 100
Adjustment of the rear view mirrors.................................63 - 64
Advice on driving ............................X
Air conditioning............ 42 - 85 → 92
Air distribution........................89 - 92
Air fi lter.......................................r121
Air fl ow ...................................89 - 92
Air recirculation ñEntry of air from outside.............90
Airbags ........................101 - V → VII
Anti-intrusion alarm................26 - 27
Anti-pinch.............................56 - 118
Anti-theft bolts....................141 - 143
Anti-theft protection......................82
Ashtray........................................11 4
Audio system/NaviDrive ................43, 7.01 - 7.57
Automatic gearbox...............65 → 68
Automatic lighting of headlamps...51
B
Badge reader...............................r11 6
Battery replacement ...................124
Bonnet........................................120
Boot ..............................84 - 99 - 117
Brake fl uid...................................121
B
Brakes.......................................... 74
Braking system ............................XIII
Brightness sensor.........................r37
C
Capacities ................................... 132
Card-holder..................................11 6
Catalytic converter......................rXVII
CD changer.................................r117
Central locking.......................23 - 25
Central unlocking..........................23
Changing a wheel............141 → 143
Changing the remotecontrol battery............................24
Changing bulbs................134 → 138
Changing the vehicle battery......124
Checks........................................ 121
Child restraints.................103 → 105
Child safety ..........................56 - 83 -

103 → 105 - VIII → IX
Child seats.....103 → 105 - VIII → IX
Cigar-lighter.................................r113
Cold weather shield....................140
Colour screen C..................39 → 42
Controls at the steering wheel........8
Coolant temperature.....................46
Cruise control ........................69 - 70
Cup-holders .................................111
D
Dashboard.................................8 - 9
Date ................................39 - 41 - 43
D
Daytime-running lamps.................52
Deactivation of passenger’s airbag.......................................101
Deadlocking...........................23 - 25
Diesel particulate fi lter system ......81
Diesel preheating..........................29
Dimensions........................146 - 147
Dipped beams ..............................51
Direction indicators .......................50
Driverís fl oor mat.........................113
Driverís oddments tray ................ 111
Driverís seat beltfastening sensor...r61
Driving.................................18 → 20
Driving position............................... II
Driving positions....................37 - 60
Dust/pollen fi lter............................r86
E
Eco-driving............................... 21-22
Economy mode.............................28
Ejecting the key............................24
Electric exterior rear viewmirrors.................................63 - 64
Electric parking brake ............75 - 76
Electric steering column adjustment..................................57
Electric windows control...............56
Electrical accessories ................XVIII
Electronic immobiliser...................25
Electronic stability programme(ESP)..........................................73
Engine coolant ............ 46 - 121 - 123

151
INDEX
P
Pavement lighting........................110
Personalisation/Confi guration .....................40 → 42
Power steering oil.......................121
Programmable heating........93 → 96
R
Radiator – coolant fl uid...............123
Radio .....................................39 - 43
Rain detector................................r54
Rear automatic air conditioning ....92
Rear blind....................................116
Rear demisting - deicing...............90
Rear foglamps ..............................52
Rear seats .............................97 - 99
Rear storage................................11 2
Recycling andthe environment.......................XXIII
Refi tting a wheel.........................143
Remote control ......................23 - 24
Remote control key.......................23
Removing a wheel......................143
Replacing a fuse.........................127
Replacing bulbs...............134 → 137
Reset to zero ................................35
Rev counter..................................r35
Roof bars....................................139
Running-in.................................XVIII
S
Screen wash fl uid .......................136
Seat belt height adjustment..........57
S
Seat belts.......................61 - III → IV
Seat pockets................................11 2
Sidelamps .....................................51
Signalling.............................50 → 52
Snow chains .................145 - X - XIX
Snow-guards..............................140
Soft diffusion system .............85 - 89
Spare wheel................................141
Speed limiter............................71-72
Speed-sensitive rear spoiler (defl ector)...................................77
Sport mode.................................106
Spotlamps...................................109
Starter...........................................r48
Starting.........................................28
Starting the engine.......................29
Starting the engine withan assisting battery.................. 126
Steering column adjustment.........57
Steering lock................................. 28
Sun roof.......................................f118
Sun visor......................................116
Suspension oil ............................136
Suspension with electronicallycontrolled springing and
damping....................................106
System of emergency brakingassistance .................................. 74
T
Temperature adjustment..............87
Time ................................39 - 41 - 43
T
Tools...........................................141
Towbar........................................r138
Towing – Lifting...........................144
Trip computer........r39, 40 - 44 → 49
Turbochargers ..............................29
Tyre defl ation detection .......47 → 49
Tyre maintenance.........................XV
Tyre pressures...........141 - 148 - XV
Tyres...................................141-XV
U
Under the bonnet ........................122
Unlockingin emergency.......................76 - 84
User Precautions .............................I
V
Vehicle identifi cation...................148
Ventilated storage under the central armrest...........85
Ventilation ..................................... 14
Visibilit
y......................................... 13
Visible alert...................................50
W
Washing the vehicle.....................54
Wh
eel for
temporary use..........................143
Windscreen wash.........................55
Winter precautions.......................XIX
Wiper blades.................................55
Wipers ...................................54 - 55
