Page 31 of 189
47
II
T R I P C O M P U T E R
Wheel not detected
The SERVICE w a r n i n g l a m p c o m e s o n a n d a v e h i c l e o u t l i n e i s d i s p l a y e d .
T h e w h e e l ( s ) c o n c e r n e d c a n b e i d e n t i fi e d f r o m t h e v e h i c l e o u t l i n e , o n w h i c h i t ( t h e y ) w i l l b e m i s s i n g . I f y o u h a v e n o t c h a n g e d a w h e e l , s u c h i n f o r m a t i o n i n d i c a t e s t h a t t h e s y s t e m i s m a l f u n c t i o n i n g .
C o n t a c t a C I T R O Ë N d e a l e r t o h a v e t h e f a u l t y s e n s o r ( s ) r e p l a c e d .
Colour screen CNaviDrive colour display
T h e d e fl a t i o n d e t e c t i o n s y s t e m i s a d r i v i n g a i d , b u t w h i c h d o e s n o t a b s o l v e t h e d r i v e r f r o m t h e n e e d t o b e v i g i l a n t a n d responsible.
T h i s s y s t e m d o e s n o t r e m o v e t h e n e e d t o c h e c k t h e t y r e s o n a r e g u l a r b a s i s ( s e e " V e h i c l e i d e n t i fi c a t i o n " ) , t o m a k e s u r e t h a t t h e v e h i c l e i s b e h a v i n g c o r r e c t l y a n d t o a v o i d p r e m a t u r e t y r e w e a r a r i s i n g f r o m d r i v i n g t o o f a s t e t c .
Do not forget to check the pressure in the spare wheel.
Any repair or replacement of a tyre on a wheel that is equipped with a sensor must be carried out by a CITROËN dealer.Any repair or replacement repair or
The system may suffer from temporary interference caused by radio transmissions on neighbouring frequencies.
Page 32 of 189
48
II
S I G N A L L I N G
DIRECTION INDICATORS
Left , d o w n w a r d s .
Right , u p w a r d s .
F o r a c h a n g e o f d i r e c t i o n , m o v e t h e c o n t r o l s t a l k b e y o n d t h e t i g h t s p o t . S t o p s a u t o m a t i c a l l y w i t h t h e r e t u r n o f t h e s t e e r i n g w h e e l .
V i s i b l e a l e r t / h e a d l a m p fl a s h
P u l l t h e c o n t r o l t o w a r d s y o u .
T h e h e a d l a m p fl a s h c a n b e m a d e e v e n w i t h t h e i g n i t i o n s w i t c h e d o f f .
Horn
P r e s s a t t h e c e n t r e o f t h e s t e e r i n g w h e e l .
HAZARD WARNING LAMPS
T h i s o p e r a t e s a l l t h e d i r e c t i o n i n d i - c a t o r s s i m u l t a n e o u s l y .
Only use them to indicate dan-ger , f o r a n e m e r g e n c y s t o p o r f o r d r i v i n g i n a b n o r m a l c o n d i t i o n s .
T h e h a z a r d l a m p s c a n a l s o b e u s e d w i t h t h e i g n i t i o n s w i t c h e d o f f .
SOUND SIGNAL FOR HEADLAMPS LEFT ON
T h i s o p e r a t e s w h e n t h e d r i v e r ' s d o o r i s o p e n e d , i g n i t i o n o f f , t o i n d i - c a t e t h a t t h e v e h i c l e l a m p s a r e s t i l l on.
I t s t o p s w h e n y o u c l o s e t h e d o o r , s w i t c h o f f t h e l a m p s o r s w i t c h o n t h e i g n i t i o n .
T h i s s i g n a l d o e s n o t o p e r a t e i f t h e a u t o m a t i c l i g h t i n g o f h e a d l a m p s o r t h e g u i d e - m e - h o m e l i g h t i n g a r e active.
EMERGENCY OPERATION OF HAZARD WARNING LAMPS
A s u d d e n d e c e l e r a t i o n o f t h e v e h i - c l e c a u s e s t h e h a z a r d l a m p s t o c o m e o n a u t o m a t i c a l l y .
T h e y w i l l c e a s e t o o p e r a t e a u t o - m a t i c a l l y , o r m a n u a l l y i f y o u p r e s s t h e h a z a r d l a m p s b u t t o n o n t h e d a s h b o a r d .
The direction indicators cannot operate if the hazard warning lamps are on.
Page 33 of 189
49
II
A
S I G N A L L I N G
GUIDE-ME-HOME LIGHTING
T h i s f u n c t i o n s w i t c h e s o n y o u r h e a d l a m p s , t o l i g h t y o u r w a y w h e n y o u w i s h t o w a l k f r o m a c a r p a r k , f o r e x a m p l e .
T h i s f u n c t i o n i s a c t i v a t e d : M a n u a l l y b y p u l l i n g t h e control A t o w a r d s y o u , w i t h t h e i g n i t i o n s w i t c h e d o f f .
A u t o m a t i c a l l y , p r o v i d e d : T h e a u t o m a t i c l i g h t i n g o f h e a d l a m p s i s a c t i v a t e d . T o a c t i v a t e t h e g u i d e - m e - h o m e l i g h t i n g f u n c t i o n , s e l e c t i n t h e " M a i n m e n u " , t h e n i n " P e r s o n a l i s a t i o n / C o n fi g u r a t i o n " , t h e s u b - m e n u f o r l i g h t i n g a n d s i g n a l l i n g , t h e n a c t i v a t e t h e f u n c t i o n .
S e e " M u l t i f u n c t i o n d i s p l a y s " .Note: It is possible to modify the dura-tion of the guide-me-home lighting (approx. 60, 30 or 15 seconds) in the m e n u " P e r s o n a l i s a t i o n / C o n fi g u r a t i o n " .
Page 34 of 189
50
II
C
S I G N A L L I N G
Front foglamps on
Front foglamps and rear foglamps on
R o t a t e t h e r i n g C f o r w a r d s .
Switching off
F i r s t a c t i o n r e a r w a r d s , r e a r f o g l a m p s o f f .
S e c o n d a c t i o n r e a r w a r d s , f r o n t a n d r e a r f o g l a m p s o f f .Note: the foglamps should be used only in fog or in other conditions of poor visibility.
FRONT AND REAR FOGLAMPS (RING C)
Lighting
W i t h d i p p e d / m a i n b e a m s o n :
R o t a t e t h e r i n g C f o r w a r d s .
DAYTIME-RUNNING LAMPS
T h e s e c o m e o n a u t o m a t i c a l l y w h e n t h e e n g i n e i s r u n n i n g : I f t h e f u n c t i o n i s a c t i v a t e d in the Main Menu. See " M u l t i f u n c t i o n d i s p l a y s " .
P r o v i d e d t h e l i g h t i n g c o n t r o l stalk is on position 0 a n d a l l t h e h e a d l a m p s a r e o f f .
I f t h e d a y t i m e - r u n n i n g l a m p s a r e a c t i v e , t h e s i d e l a m p s w i l l a l s o b e o n ( d e p e n d i n g o n c o u n t r y s p e c i fi - c a t i o n ) .
Page 35 of 189
51
II
FEATURES
W i t h d i p p e d b e a m s o r m a i n b e a m s , t h e Directional headlamps f u n c t i o n t u r n s t h e h e a d l a m p s i n t h e d i r e c t i o n t h e r o a d a h e a d i s t a k i n g .
Y o u r v i s i o n o n b e n d s i s c o n s i d e r a b l y e n h a n c e d .Note: An automatic correction of the beam height enables you not to dazzle other drivers.
X E N O N D U A L F U N C T I O N D I R E C T I O N A L
H E A D L A M P S
Function activatedFunction deactivated
ACTIVATION/DEACTIVATION
A c t i v a t e d b y d e f a u l t , t h i s f u n c t i o n c a n b e a c t i v a t e d / d e a c t i v a t e d i n t h e " M a i n m e n u " o n t h e m u l t i f u n c - t i o n s c r e e n . S e e " M u l t i f u n c t i o n d i s -plays".
The activated/deactivated status is retained w h e n y o u s w i t c h o f f t h e e n g i n e .Note: This function is not active when the vehicle is stationary, moving at very low speed, or in reverse gear.
S h o u l d t h e r e b e a m a l f u n c t i o n t h e " D i p p e d b e a m s " w a r n i n g l a m p fl a s h e s . H a v e t h e s y s t e m c h e c k e d by a CITROËN dealer. S h o u l d t h e r e b e a m a l f u n c t i o n t h e " D i p p e d b e a m s " w a r n i n g l a m p fl a s h e s . H a v e t h e s y s t e m c h e c k e d S h o u l d t h e r e b e a m a l f u n c t i o n t h e " D i p p e d b e a m s " w a r n i n g l a m p fl a s h e s . H a v e t h e s y s t e m c h e c k e d
It is recommended to change both Xenon bulbs at the same time if there is a failure of one of them.
Page 36 of 189
52
II
W I P E R S
CONTROL POSITIONS2: R a p i d w i p e .
1: N o r m a l w i p e .
I: I n t e r m i t t e n t w i p e .0: O f f .
One press downwards:AUTO: A u t o m a t i c w i p e a c t i v a t e d . S i n g l e w i p e .
Page 37 of 189
53
II
CHANGING THE WIPER BLADES
I f y o u h a v e t o replace t h e m , t h e w i p e r b l a d e s h a v e t o b e p a r k e d i n t h e maintenance position . F o r t h i s , s w i t c h o f f t h e i g n i t i o n a n d t h e n w i t h i n o n e m i n u t e m o v e t h e w i p e r c o n t r o l s t a l k . T h e w i p e r s s t a n d u p i n a v e r t i c a l p o s i t i o n .
A f t e r r e p l a c e m e n t , switch on the ignition a n d move the wiper control stalk s o t h a t t h e w i p e r s r e s u m e t h e i r n o r m a l position.Note: t h i s a c t i o n p l a c e s t h e P i l o t e d D e fl e c t o r i n t h e m a i n t e n a n c e p o s i t i o n .
WINDSCREEN WASH
T o o p e r a t e t h e w i n d s c r e e n w a s h , p u l l t h e w i p e r s t a l k t o w a r d s y o u .
T h e s c r e e n w a s h i s a c c o m p a n i e d b y a t i m e d w i p e o f t h e w i n d s c r e e n , t h e h e a d l a m p w a s h a l s o a c t i v a t e s i f t h e d i p p e d b e a m s a r e o n .
T h e d i s p l a y o f a m e s s a g e i n d i c a t e s t h a t t h e r e i s o n l y a p p r o x . o n e l i t r e o f s c r e e n w a s h fl u i d r e m a i n i n g .
I n f r e e z i n g c o n d i t i o n s , a l w a y s c h e c k t h a t t h e w i p e r b l a d e s a r e f r e e t o operate.
R e m o v e a n y a c c u m u l a t i o n o f s n o w a t t h e b a s e o f t h e w i n d s c r e e n .
Page 38 of 189
54
II
A
W I N D O W S
After a battery disconnection or if there has been a malfunction , you have to reinitialise the anti- p i n c h f u n c t i o n f o r e a c h w i n d o w : L o w e r t h e w i n d o w f u l l y u s i n g t h e c o n t r o l , t h e n c l o s e . I t w i l l r i s e o n l y a f e w c e n t i m e t r e s . P r e s s r e p e a t e d l y o n t h e c o n t r o l u n t i l t h e w i n d o w i s f u l l y c l o s e d .
K e e p t h e c o n t r o l p r e s s e d f o r a t l e a s t a f e w s e c o n d s a f t e r t h e w i n d o w h a s f u l l y c l o s e d .
WARNING
D u r i n g t h i s o p e r a t i o n , t h e a n t i - p i n c h p r o t e c t i o n d o e s n o t w o r k .
Page 39 of 189
55
II
S T E E R I N G C O L U M N A D J U S T M E N T –
S E A T B E L T H E I G H T A D J U S T M E N T
MANUAL ADJUSTMENT OF THE STEERING WHEEL FOR HEIGHT AND REACH
W h i l e t h e v e h i c l e i s s t a t i o n a r y , u n l o c k t h e s t e e r i n g w h e e l b y p u s h - i n g t h e l e v e r f o r w a r d .
A d j u s t t h e h e i g h t a n d t h e r e a c h o f t h e s t e e r i n g w h e e l , t h e n l o c k t h e p o s i t i o n b y p u l l i n g t h e l e v e r u p w a r d s .
ELECTRICAL ADJUSTMENT OF THE STEERING WHEEL FOR HEIGHT OR REACH
W h i l e t h e v e h i c l e i s s t a t i o n a r y , a d j u s t t h e h e i g h t o r t h e r e a c h o f t h e s t e e r i n g w h e e l b y m o v i n g t h e c o n t r o l : f o r w a r d o r r e a r w a r d t o a d j u s t the reach u p o r d o w n t o a d j u s t t h e h e i g h t .
T h e s t e e r i n g w h e e l a d j u s t m e n t i s m e m o r i s e d w i t h t h e d r i v i n g p o s i - t i o n ( S e e " M e m o r i s a t i o n " ) .
Page 40 of 189
56
II
1
3
2
F R O N T S E A T S
ADJUSTMENT OF THE BACKREST ANGLE
Action the control 1 a n d a d j u s t t h e a n g l e o f t h e b a c k r e s t .
I t i s p o s s i b l e t o t i l t t h e b a c k r e s t 4 5 ° f o r w a r d s u n t i l i t l o c k s . T o u n l o c k i t , press control 1.
ADJUSTMENTS TO THE HEIGHT AND ANGLE OF THE HEAD RESTRAINT
T o r a i s e i t , p u l l u p w a r d s .
T o l o w e r i t , p r e s s o n t h e c o n t r o l 2 t o u n l o c k i t , a n d s i m u l t a n e o u s l y o n t h e h e a d r e s t r a i n t i t s e l f .
T o a d j u s t t h e a n g l e o f t h e h e a d r e s t r a i n t , t i l t i t f o r w a r d s o r r e a r w a r d s a t t h e b o t t o m .
T o r a i s e i t , p r e s s c o n t r o l 2 t o u n l o c k i t , t h e n p u l l i t u p w a r d s .
CONTROLS FOR THE HEATED SEATS
T h e f r o n t s e a t s c a n b e h e a t e d i n d e p e n d e n t l y o f e a c h o t h e r . O n t h e c o n t r o l s f o r t h e h e a t e d s e a t s 3 l o c a t e d o n t h e o u t e r s i d e o f t h e s e a t s , r o t a t e t h e k n o b t o s e l e c t a n y o f t h r e e h e a t i n t e n s i t i e s :
0: O f f .
1: S l i g h t h e a t .
2: M e d i u m h e a t .
3: M a x i m u m h e a t .
Note: The heated seats only operate when the engine is running.
SEAT HEIGHT AND SLIDE ADJUSTMENTS
S e e f o l l o w i n g p a g e .
