Airbags
Disarming
The passenger's front air bag alone can be disarmed:
With the ignition switched off, insert the key into the passenger air bag disarming switch,
turn it to the "OFF" position,
then remove the key keeping the s l o t i n t h i s p o s i t i o n .
Front air bags
The front air bags are incorporated in the
centre of the steering wheel for the driver
a n d i n t h e f a s c i a f o r t h e f r o n t p a s s e n g e r .
Front air bag fault
If this warning light comes on, accompanied by an audible signal and a message on the display, consult a CITROËN signal and a message on the signal and a message on the
dealer to have the system c h e c k e d .
Reactivation
In the "OFF" position, the passenger air bag will not be triggered in the e v e n t o f a n i m p a c t .
As soon as the child seat is removed, turn the air bag slot to the "ON"position to re-activate the air bag and thus ensure the safety of your p a s s e n g e r i n t h e e v e n t o f a n i m p a c t .
To ensure the safety of your child, it is essential to disarm the passenger air bag when you install a rear-facing child seat on the front p a s s e n g e r s e a t . O t h e r w i s e , t h e c h i l d would risk being killed or seriously i n j u r e d i f t h e a i r b a g w e r e t o i n fl a t e .
The air bag warning light on the instrument panel is lit throughout the period of d i s a r m i n g .
If the two air bag warning lights are lit continuously, do not install a r e a r - f a c i n g c h i l d s e a t . C o n s u l t a C I T R O Ë N d e a l e r . a r e a r - f a c i n g c h i l d s e a t . C o n s u l t a a r e a r - f a c i n g c h i l d s e a t . C o n s u l t a
Activation
They are deployed simultaneously, unless the passenger's front air bag has been disarmed, in the event of a serious front impact applied to all or part of the front impact zone A in the longitudinal centreline of the vehicle on a horizontal plane directed from the f r o n t t o w a r d s t h e r e a r o f t h e v e h i c l e .
T h e f r o n t a i r b a g i n fl a t e s b e t w e e n the front occupant of the vehicle and the fascia to cushion his forward m o v e m e n t .
Page 172 of 250
SAFETY
175
Airbags
5
The air bags have been designed to
maximise the safety of the occupants
(with the exception of the centre
seats of rows 2 and 3) in the event
of a serious collision; they work in
conjunction with the force limiting seat
b e l t s .
In the event of a serious collision, the
electronic detectors record and analyse
the front and side impacts suffered in
the impact detection zones:
- in the event of a serious impact, t h e a i r b a g s i n fl a t e i n s t a n t l y a n d
protect the occupants of the
v e h i c l e .
Immediately after the impact, the air
b a g s d e fl a t e r a p i d l y , s o t h a t t h e y d o n o t
hinder the visibility of the occupants
n o r t h e i r p o s s i b l e e x i t f r o m t h e v e h i c l e . - in the event of a minor or rear
impact and in certain roll-over
conditions, the air bags will not
be deployed; the seat belt alone
i s s u f fi c i e n t t o p r o v i d e m a x i m u m
p r o t e c t i o n i n t h e s e s i t u a t i o n s .
The seriousness of the collision
depends on the nature of the obstacle
and the speed of the vehicle at the
m o m e n t o f i m p a c t . Air bags only operate when the
ignition is switched on.
T h i s e q u i p m e n t o n l y o p e r a t e s o n c e .
If a second impact occurs (during the
same or a subsequent accident), the
a i r b a g w i l l n o t o p e r a t e .
The triggering of an air bag or air bags
is accompanied by a slight discharge
of harmless smoke and a noise, due
to the activation of the pyrotechnic
c a r t r i d g e i n c o r p o r a t e d i n t h e s y s t e m .
This smoke is not harmful, but
sensitive individuals may experience
s o m e i r r i t a t i o n .
The noise of the detonation may result
in a slight loss of hearing for a short
t i m e .
AIR BAGS
It is imperative that the passenger
air bag is disarmed if a child seat
i s i n s t a l l e d f a c i n g r e a r w a r d s . R e f e r
to the "Children on board" section of
c h a p t e r 5 .
Page 173 of 250
176
Airbags
Good practice
I f y o u r v e h i c l e i s fi t t e d w i t h a f r o n t
passenger air bag, side air bags or
curtain air bags, observe this good
p r a c t i c e .
S i t i n a n o r m a l u p r i g h t p o s i t i o n .
W e a r a c o r r e c t l y a d j u s t e d s e a t b e l t .
D o n o t l e a v e a n y t h i n g b e t w e e n t h e
occupants and the air bags (a child,
p e t , o b j e c t . . . ) . T h i s c o u l d h a m p e r t h e
operation of the air bags or injure the
o c c u p a n t s .
After an accident or if the vehicle has
been stolen or broken into, have the air
b a g s y s t e m s c h e c k e d .
All work on the air bag system is
strictly forbidden unless it is carried out
b y q u a l i fi e d p e r s o n n e l o f t h e C I T R O Ë N
n e t w o r k . Front air bags
D o n o t d r i v e h o l d i n g t h e s t e e r i n g w h e e l
by its spokes or resting your hands on
t h e c e n t r e p a r t o f t h e w h e e l .
Passengers must not place their feet
o n t h e f a s c i a .
Smoke as little as possible as
deployment of the air bags can cause
burns or the risk of injury from a
c i g a r e t t e o r p i p e .
Never remove or pierce the steering
w h e e l o r h i t i t v i o l e n t l y .
Side air bags
O n l y p u t a p p r o v e d c o v e r s o n t h e s e a t s .
T h e s e w i l l n o t h i n d e r i n fl a t i o n o f t h e
s i d e a i r b a g s .
C o n s u l t a C I T R O Ë N d e a l e r .
D o n o t fi x o r g l u e a n y t h i n g t o t h e s e a t
b a c k s . T h i s c o u l d c a u s e i n j u r y t o t h e
chest or arms when the side air bag
i n fl a t e s .
D o n o t s i t w i t h t h e u p p e r p a r t o f t h e
body any nearer to the door than
n e c e s s a r y .
Curtain air bags
D o n o t fi x o r g l u e a n y t h i n g t o t h e r o o f .
This could cause injury to the head
w h e n t h e c u r t a i n a i r b a g i n fl a t e s .
D o n o t r e m o v e t h e g r a b h a n d l e s
installed on the roof, they play a part in
s e c u r i n g t h e c u r t a i n a i r b a g s .
Even if all of the precautions
mentioned are observed, a risk of
injury or of minor burns to the head,
chest or arms when an air bag is
t r i g g e r e d c a n n o t b e r u l e d o u t . I n f a c t ,
t h e b a g i n fl a t e s a l m o s t i n s t a n t l y ( w i t h i n
a f e w m i l l i s e c o n d s ) t h e n d e fl a t e s w i t h i n
the same time discharging the hot gas
v i a o p e n i n g s p r o v i d e d f o r t h i s p u r p o s e .
Page 174 of 250
SAFETY
177
Airbags
5
Side air bags
I f fi t t e d o n y o u r v e h i c l e , t h i s i s a s y s t e m
which protects the driver and front
passenger in the event of a serious
side impact in order to limit the risk of
i n j u r y t o t h e c h e s t .
Each side air bag is incorporated in the
f r o n t s e a t b a c k f r a m e , o n t h e d o o r s i d e . T h e c u r t a i n a i r b a g i n fl a t e s b e t w e e n
the front or rear occupant of the vehicle
a n d t h e w i n d o w s .
Impact detection zones
