Key Citroen DS3 2009.5 1.G User Guide

- Position 1: Stop - Position 2: Ignition - Position 3: Star ting
Ignition switch Starting the vehicle
 Inser t the key in the ignition switch.
The system recognises the star ting code.  Turn the key fully towards the fascia to position 3 (Star ting) .  When the engine star ts, release the key.
 Immobilise the vehicle.
 Turn the key fully towards you to position 1 (Stop) .  Remove the key from the ignition switch.
Switching the vehicle off
Do not attach any heavy objects to the key as this could weigh down on it when in the ignition switch and cause a fault.
Key reminder
If the key is left in the ignition switch, an audible signal sounds when the driver's door is opened.

85Access
Following disconnection of the vehicle battery,
replacement of the remote control battery or in the event of a remote control malfunction, you can no longer unlock, lock or locate your vehicle.  First of all, use the key in the lock to unlock or lock your vehicle.  Then, reinitialise the remote control. If the problem persists, contact a CITROËN dealer as soon as possible.
Remote control problem
Reinitialisation
 Switch off the ignition.  Turn the key to position 2 (Ignition) .  Press the closed padlock immediately for a few seconds.  Switch off the ignition and remove the key from the ignition switch. The remote control is fully operational again.
Changing the battery
Battery ref.: CR1620/3 volts. This replacement battery is available from CITROËN dealers.
 Maintain pressure on lug A and remove the chrome finisher by sliding it off at 45°.  Unclip the casing by inser ting a coin at the
notch and rotating.  Slide the flat battery out of its location.  Slide the new battery into its location obser ving the original direction.  Clip the casing in place, then the chrome finisher.  Reinitialise the remote control.
If the battery is flat, you are informed by lighting of this warning lamp in the instrument panel, an audible signal and a message on the multifunction screen.
 Unfold the key.  Release the chrome finisher by pressing on
lug A .

Do not throw the remote control batteries away, they contain metals which are harmful to the environment. Take them to an approved collection point.
Lost keys
Visit a CITROËN dealer with the vehicle's V5 registration document and your personal identification documents. The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a replacement key.
Remote control
The high frequency remote control is a sensitive syst em; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it. Do not repeatedly press the buttons of your remote con trol out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised. The remote control does not operate when the key is i n the ignition, even when the ignition is switched off, except for reinitialisation.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more difficult in an emergency. As a safety precaution (with children on board), remove the key from the ignition when you leave the vehicle, even for a shor t time.
Anti-theft protection
Do not make any modifications to the electronic engin e immobiliser system; this could cause malfunctions.
When purchasing a second-hand vehicle
Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your possession are the only ones which can star t the vehicle.

89Access
Triggering of the alarm
This is indicated by sounding of the siren and flashing of the direction indicators for approximately thir ty seconds. After it has been triggered, both types of protection are again operational.
If the alarm is triggered ten times in succession, the eleventh time will result in it becoming inactive. If the indicator lamp on button A flashes rapidly, this indicates that the alarm was triggered during your absence. When the ignition is switched on, this flashing stops immediately. To avoid triggering the alarm when washing your vehicle, lock it using the
key in the driver’s door lock.
Failure of the remote control
 Unlock the vehicle using the key in the driver’s door lock.  Open the door; the alarm is triggered.
 Switch on the ignition; the alarm stops.
Locking the vehicle without
activating the alarm
 Lock or deadlock the vehicle using the key in the driver’s door lock.
Malfunction
When the ignition is switched on, lighting of the indicator lamp on button A for ten seconds indicates a siren fault. Have it checked by a CITROËN dealer.
* According to country.
Automatic activation *
2 minutes after the last door or the boot is closed, the alarm is activated automatically.  To avoid triggering the alarm on entering the vehicle, first press the unlocking button on the remote control.

91Access
In the event of unwanted opening of the window on closing (for example in the presence of frost):  press the switch until it opens completely,  then pull it immediately until it closes,  continue to hold the switch for
approximately one second after the window has closed. The safety anti-pinch function is not active during these operations.
Safety anti-pinch
On the driver's side, the one-touch front electric window has a safety anti-pinch function. When the window rises and meets an obstacle, it stops and par tially lowers again.
Reinitialisation
Always remove the key from the ignition when leaving the vehicle, even for a shor t time. In the event of contact during operation of the windows, reverse the movement of the window. To do this, press the corresponding switch. When the driver operates the passenger electric window switch, they should ensure that no one is preventing correct closing of the window. The driver should ensure that the passenger uses the electric window correctly. Be aware of children when operating the windows.
In the event of a malfunction you have to
reinitialise the operation of the electric windows:  release the switch and pull it again until the window closes completely,  hold the switch for approximately one second after closing,  press the switch to lower the window automatically. The safety anti-pinch function is not active during these operations.

Doors
Opening
From outside
 After unlocking the vehicle using the remote control or the key, pull the door handle.
From inside
 Pull the door lever to open the door; this unlocks this vehicle completely.
Closing
When a door is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds,
- when the vehicle is moving (speed higher than 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen for a few seconds.
Version with deadlocking
The interior door controls do not operate when the vehicle is deadlocked.

93Access
System which provides full manual locking or unlocking of the doors from the inside.
Manual centralised control
Locking
 Press button A to lock the vehicle.
The red indicator lamp on the button comes on.
Unlocking
 Press button A again to unlock the vehicle. The red indicator lamp on the button switches off.
If one of the doors is open, central
locking from the inside does not take place.
If the vehicle is locked from the outside, the red indicator lamp flashes and button A is inactive.  In this case, use the remote control or the key to unlock the vehicle.
Automatic centralised
control
System which provides full automatic locking or unlocking of the doors and the boot while driving. You can activate or deactivate this function.
Locking
When the speed exceeds 6 mph (10 km/h), the doors and the boot lock automatically.
Unlocking
 Above 6 mph (10 km/h), press button A to unlock the doors and the boot temporarily.
If one of the doors is open, the automatic central locking does not take place. If the boot is open, the automatic central locking of the doors is active.

Activation
 Press button A for more than two seconds. A confirmation message appears on the multifunction screen, accompanied by an audible signal.
Deactivation
 Press button A again for more than two seconds. A confirmation message appears on the multifunction screen, accompanied by an audible signal.
System which locks or unlocks the doors mechanically in the event of a malfunction of the central locking.
Emergency control
Locking the driver's door
 Inser t the key in the lock, then turn it to the right.
Unlocking the driver's door
 Inser t the key in the lock, then turn it to the left.
Locking the passenger door
 Inser t the key in the lock, located on the edge of the door, then turn it one eighth of a turn .
Unlocking the passenger door
 Pull the interior door opening control.

95Access
Boot
Opening
 After unlocking the vehicle using the remote control or the key, pull the handle and raise the tailgate.
Closing
 Lower the tailgate using the interior grab handle.
If the tailgate is not closed correctly:
- when the engine is running , this warning lamp comes on, accompanied by a message on the multifunction screen for a few seconds,
- when the vehicle is moving (speed above 6 mph (10 km/h)), this warning lamp comes on, accompanied by an audible signal and a message on the multifunction screen for a few seconds.
System for mechanical unlocking of the boot in the event of a battery or central locking malfunction.
Tailgate release
Unlocking
 Fold back the rear benchseat to gain access to the lock from inside the boot.  Inser t a small screwdriver into hole A of the lock to unlock the tailgate.

Fuel tank Fuel tank capacity: approximately 50 litres (petrol) or 48 litres (Diesel).
Low fuel level
Filling
A label affixed to the inside of the flap reminds you of the type of fuel to be used depending on your engine. Additions of fuel must be of at least 5 litres, in order to be taken into account by the fuel gauge.
The key cannot be removed from the lock until the cap is refitted. Opening the filler cap may create a noise a caused by an inrush of air. This vacuum is entirely normal, resulting from the sealing of the fuel system.
To fill the tank in complete safety:  the engine must be switched off, open the fuel filler flap,  inser t the key in the cap, then turn it to the left,
 remove the cap and hook it onto the clip located on the inside of the flap,  fill the tank, but do not continue after the 3rd cut- off of the pump ; this could cause malfunctions.
When you have filled the tank:  put the cap back in place,  turn the key to the right, then remove it from the cap,  close the flap.
When the fuel tank minimum level is reached this warning lamp comes
on on the instrument panel. When it first comes on there remains approximately 5 litres of fuel in the tank. You must refuel as soon as possible to avoid running out of fuel. If you run out of fuel (Diesel), refer also to the "Checks" section.
