engine coolant Citroen DS3 2009.5 1.G Owner's Manual

Petrol - Diesel instrument panels, manual or automatic gearbox
Provided with permanent back-lighting, the instrument panel groups together the vehicle's dials and indic ator and warning lamps.
1. Rev counter. Indicates the speed of rotation of the engine (x 1 000 rpm).
2. Vehicle speed. Indicates the current speed of the moving vehicle (mph or km/h). 3. Engine coolant temperature. Indicates the temperature of the engine coolant liquid (° Celsius).
Dials
7. Lighting rheostat button. Adjusts the level of the instrument and controls illumination and the interior mood
lighting.
4. Display screen.5. Fuel level. Indicates the quantity of fuel remaining in
the tank. 6. Display management button Alternates display between range and trip mileage recorder. Ser vicing information. Resets the selected function to zero (trip distance recorder or ser vice indicator).
For more information, refer to the paragraph relating to the button or function and its associated display.

Warning lampis onCauseAction/Obser vations
Diesel engine pre-heating fixed. The ignition switch is at the 2 nd position (ignition on). Wait until the warning lamp has switched off before starting. The duration for which the warning lamp is on is determined by the climatic conditions.
Parking brake fixed. The parking brake is applied or not properly released. Release the parking brake to switch off the warnin g lamp, keeping your foot on the brake pedal. Obser ve the safety recommendations. For fur ther information on the parking brake, refer t o the "Driving" section.
Engine coolant temperature fixed blue. On star ting the engine, it indicates that the engine is cold. After a few minutes driving, it swiches off to indicate that the engine temperature is normal. In order to protect your engine, avoid driving too hard until the warning lamp has switched off.
Foot on the brake pedal fixed. With an automatic gearbox, you have forgotten to press the brake pedal to come out of the P postion.
With the engine running, before releasing the park ing brake you must press the brake pedal to unlock the th e automatic gear selector lever and come out of the P position.
Automatic wiping fixed. The wiper control is pushed downwards. Automatic front wiping is activated.

Passenger's airbag system fixed. The control switch, located in the glove box, is in the " ON " position. The passenger's front airbag is activated. In this case, do not install a rear-facing child seat.
Turn the control switch to the " OFF " position to deactivate the front passenger's airbag. In this case you can install a rear-facing child seat. The passenger's airbag system is automatically put into ser vice on star ting the vehicle (" ON " position).

Warning lamps
When the engine is running or the vehicle is being driven, the switching on of one of the following warning lamps indicates a fault which requires action on the par t of the driver.
Any fault resulting in the switching on of a warning lamp must be investigated fur ther by reading the associated message on the multifunction screen. If you encounter any problems, do not hesitate to contact a CITROËN dealer.
Warning lampis onCauseAction/Obser vations
STOP fixed, associated with another warning lamp and accompanied by an audible signal.
It is associated with the braking system or the engine coolant temperature.
Stop as soon as it is safe to do so. Park, switch off the ignition and call a CITROËN dealer.
Ser vice
temporarily. A minor fault has occurred for which there is no specific warning lamp. Identify the fault by reading the message shown on t he screen, such as, for example: - the engine oil level, - the screenwash level, - the remote control battery, - saturation of the par ticle emission filter (Diesel). For any other faults, contact a CITROËN dealer.
fixed. A major fault has occurred for which
there is no specific warning lamp.
Identify the fault by reading the message shown on t he
screen and contact a CITROËN dealer.

Warning lampis onCauseAction/Obser vations
Engine autodiagnosis system
fixed. The emission control system has a
fault.
This lamp should switch off when the engine is star ted.
If it does not switch off, contact a CITROËN dealer urgently.
flashing. The engine management system has a fault. Risk of destruction of the catalytic conver tor. Have it checked by a CITROËN dealer.
Low fuel level fixed. When it first comes on there remains approximately 5 litres of fuel in the tank.
You must refuel as soon as possible to avoid running out of fuel. This warning lamp will come on every time the ignition is switched on, until a sufficient addition of fuel is made. Fuel tank capacity: approximately 50 litres (petrol ) or 48 litres (Diesel). Never continue to drive until you run out of fuel a s this could damage the emission control and injection systems.
Maximum coolant temperature fixed red. The temperature of the cooling system is too high. Stop as soon as it is safe to do so. Wait until the engine has cooled down before topping
up the level, if necessary. If the problem persists, contact a CITROËN dealer.

35Instruments and controls
With the engine running, when the needle is: - in zone A , the temperature is correct,
- in zone B , the temperature is too high; the central STOP warning lamp and the maximum temperature warning lamp 1light up in red, accompanied by an audible signal and a message on the multifunction screen. You must stop as soon as it is safe to do so. Wait a few minutes before switching off the engine. Consult a CITROËN dealer.
Coolant temperature
indicator
After driving for a few minutes, the temperature and pressure in the cooling system increase.
To top up the level:  wait for the engine to cool down,  unscrew the cap by two turns to allow the pressure to drop,  when the pressure has dropped, remove the cap,  top up the level to the "MA X" mark.

167Checks
* According to engine.
Petrol engines
1. Screenwash reser voir. 2. Coolant header tank. 3. Air filter * .
4. Brake fluid reser voir. 5. Battery. 6. Fusebox. 7. Engine oil dipstick. 8. Engine oil filler cap.

* According to engine.
Diesel engines
1. Screenwash reser voir. 2. Coolant header tank. 3. Air filter * .
4. Brake fluid reser voir. 5. Battery. 6. Fusebox. 7. Engine oil dipstick. 8. Engine oil filler cap. 9. Priming pump * .

Changing the coolant
The coolant does not have to be changed.
Fluid specifi cation
The coolant must conform to the manufacturer's recommendations.
Screenwash fluid level
Fluid specifi cation
For optimum cleaning and to avoid freezing, this fluid must not be topped up or replaced with water.
Take care when carrying out checks under the bonnet as some par ts of the engine can be very hot (risk of burns).
Coolant level
Top up the level when necessary.
The coolant level should be close to the "MA X" mark but should never exceed it. When the engine is warm, the temperature of the coolant is regulated by the fan. This can operate with the ignition off. On vehicles which are fitted with a par ticle emission filter, the fan may operate after the vehicle has been switched off, even if the engine is cold.
In addition, as the cooling system is pressurised, wait at least one hour after switching off the engine before carrying out any work. To avoid any risk of scalding, unscrew the cap by two turns to allow the pressure to drop.
When the pressure has dropped, remove the cap and top up the level.

207Practical information
The rear parking sensors will be deactivated automatically if a genuine
CITROËN towbar is used.
Driving advice
Distribution of loads
 Distribute the load in the trailer so that the heaviest items are as close as possible to the axle and the nose weight approaches the maximum permitted without exceeding it. Air density decreases with altitude, thus reducing engine per formance. Above 1 000 metres, the maximum towing load must be reduced by 10 % and so on for every 1 000 metres of altitude. Refer to the "Technical Data" section for details of the weights and towing loads which apply to your vehicle.
Side wind
 Take into account the increased sensitivity to side wind.
Cooling
Towing a trailer on a slope increases the temperature of the coolant. As the fan is electrically controlled, its cooling capacity is not dependent on the engine speed.  To lower the engine speed, reduce your speed. The maximum towing load on a long slope depends on the gradient and the ambient temperature. In all cases, pay attention to the coolant temperature.
Braking
Towing a trailer increases the braking distance.
Tyres
 Check the tyre pressures of the towing vehicle and of the trailer, obser ving the recommended pressures.
Lighting
 Check the electrical lighting and signalling on the trailer.
 If the warning lamp and the STOP warning lamp come on, stop the vehicle and switch off
the engine as soon as possible.
