Page 21 of 253
43Monitoring
Monochrome screen C
Information displays
Press the button, located at the end of the wiper stalk , to display the various trip computer tabs in succession.
- the current information tab with:
Page 22 of 253
A few definitions…
Range
(miles or km) This indicates the distance which can still be travelled with the fuel remaining in the tank in relation to the average fuel consumption over the last few miles (kilometres) travelled.
Current fuel consumption
(mpg or l/100 km or km/l)
This is the average fuel consumption duringthe last few seconds.
Average fuel consumption
(mpg or l/100 km or km/l) This is the average fuel consumption sincethe last trip computer zero reset.
Average speed
(mph or km/h) This is the average speed calculated since the last trip computer zero reset (ignition on).
Distance travelled
(miles or km) This indicates the distance travelled since the last trip computer zero reset.
Stop & Start time counter
(minutes/seconds or hours/minutes)
If your vehicle is fitted with Stop & Star t, a time counter calculates the time spent in STOP mode during a journey. It resets to zero every time the ignition is
switched on with the key.
This value may vary following a change in the style of driving or the relief, resulting in a significant change inthe current fuel consumption.
If dashes are displayed continuously while driving in place of the digits, contact a CITROËN dealer.
This function is only displayed from 20 mph (30 km/h).
When the range falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is displayed when it exceeds 60 miles (100 km).
Distance remaining to destination
(miles or km) This is the distance remaining to be travelled to the final destination. It can be entered by the user. If the distance is not entered, dashes are displayed in place of the digits.
Page 23 of 253
Monochrome screen A
This displays the following information: - time, - date, - ambient temperature (this flashes if there is a risk of ice), - status of the doors and boot, - audio sources (radio, CD...), - trip computer (refer to the "Instruments and Controls" section). Warning messages (e.g.: "Emission control
system faulty") or information messages (e.g.: "Boot open") may appear temporarily. These can be cleared by pressing the "ESC"button.
Displays on the screen
From the control panel of your Audio system, you can: press the "MENU" button to gain access to the main menu ,
press the " " or " " buttons to scroll through the items on the screen, press the "MODE" button to change
the permanent application (date, audio source...), press the " " or " " buttons to change a setting value, press the "OK" button to confirm, or press the "ESC" button to abandon the
operation in progress.
Controls
Press the "MENU" button to gain access to the main menu , then press the " " or " " buttons to scroll through the various menus: - radio- CD, - vehicle configuration, - options, - display settings, - languages, - units. Press the "OK" button to select the menu required.
Main menu
Page 24 of 253
49Multifunction screens
Radio-CD
With the Audio system switched on, once the "Radio- CD" menu has been selected you can activate or deactivate the functions linked with use of the radio (RDS, REG), or the CD (introscan, shuffle, CD repeat). For more information on the "Radio- CD" application, refer to the Audio system par t of the "Audio and Telematics" section.
V e h i c l e c o n fi g u r a t i o n
Once the "Vehicle Configuration" menu has been selected, you can activate or deactivate the following equipment: - wiper linked with reverse gear (refer to the "Visibility" section), - guide-me-home lighting (refer to the "Visibility" section), - parking sensors (refer to the "Driving" section).
Options
Once the "Options" menu has been selected, you can star t diagnostics of the status of the equipment (active, not active, faulty).
Page 25 of 253
L a n g u a g e s
Once the "Languages" menu has been selected, you can change the language used by the display (Français, Italiano, Nederlands, Portugues, Portugues-Brasil, Deutsch, English, Espanol).
Units
Once the "Units" menu has been selected, you can change the units of the following parameters: - temperature (°C or °F), - fuel consumption (l/100 km, mpg or km/l).
Once the fuel consumption units have been set to mpg, the information in the instrument panel screen on speed and distance will also be in mph and miles. For safety reasons, configuration by the driver of the multifunction screen must only be done when stationary.
D i s p l a y s e t t i n g s
Once the "Display settings" menu has been selected, you can gain access to the following settings: - year, - month, - day, - hour, - minutes, - 12 or 24 hour mode.
Once you have selected a setting, press the " " or " " buttons to change its value.
Press the " " or " " buttons to switch respectively to the previous or next setting. Press the "OK" button to save the change and return to the normal display or press the "ESC" button to cancel.
Page 26 of 253
51Multifunction screens
Monochrome screen C
This displays the following information: - time, - date, - ambient temperature (this flashes if there is a risk of ice), - status of doors and boot, - audio sources (radio, CD, USB por t, jack socket etc.), - trip computer (refer to the "Instruments and controls" section).
Warning messages (E.g. "Emisions control system faulty") or information messages (E.g.: Automatic headlamps active") may appear temporarily. These can be cleared by pressing the "ESC" button.
Displays on the screen
From your Audio system control panel, you can: press the "MENU" button to gain access to the main menu , press the " " or " " buttons to scroll through the items on the screen, press the "MODE" button to change the permanent application (trip computer, audio source...), press the " " or " " buttons to change a setting value,
press the "OK" button to confirm, or press the "ESC" button to abandon the operation in progress.
Controls
Press the "MENU" button to gain access to the main menu : - audio functions, - the trip computer, - personalisation-configuration, - telephone (hands-free kit). Press the " " or " " buttons to select the menu required, then confirm by pressing the "OK" button.
Main menu
Page 27 of 253
With the Audio system switched on, once this menu has been selected you can activate
or deactivate the functions linked with use of the radio (RDS, REG, RadioText), the CD (introscan, shuffle, CD repeat) or the MP3 player (USB por t /jack socket). For more information on the "Audio functions" application , refer to the Audio system par t of the "Audio and Telematics" section.
"Audio functions"
menu
"Trip computer" menu
Once this menu has been selected, you can consult information concerning the status of the
vehicle (warnings log, status of functions, etc.)
A l e r t l o g
This summarises the active warning messages, displaying them in succession on the multifunction screen.
Status of functions
This summarises the status (active or inactive) of the vehicle's functions.
Enter distance to destination
This allows you to enter an approximate distance until your final destination.
Press the "MENU" button to gain access to the g e n e r a l m e n u.
Press the arrows, then the "OK" button to select the "Trip computer" menu.
In the "Trip computer" menu, select one of the following applications:
Page 28 of 253
53Multifunction screens
"Personalisation-
C o n f i g u r a t i o n " m e n u
Once this menu has been selected, you can gain access to the following functions: - define the vehicle parameters, - display configuration, - choice of language.
D e fi n e t h e v e h i c l e p a r a m e t e r s
Once this menu has been selected, you can activate or deactivate the following equipment: - wiper linked to reverse gear (refer to the "Visibility" section), - guide-me-home lighting - parking sensors (refer to the "Driving" section).
Example: setting of the duration of the guide-
me-home lighting Press the " " or " " buttons, then the "OK" button to select the menu required.
Press the " " or " " buttons, then the "OK" button to select the "Guide-me-home headlamps" line.
Press the " " or " " buttons to set the value required (15, 30 or 60 seconds), then press the "OK" button to confirm.
Press the " " or " " buttons, then the "OK" button to select the "OK" box and confirm or press the "ESC" button to cancel.
Page 29 of 253
D i s p l a y c o n fi g u r a t i o n
Once this menu has been selected, you can gain access to the following settings: - brightness-video setting, - date and time setting, - selection of units.
Once the fuel consumption units have been changed to mpg, the information in the screen relating to speed and distance also changes to mph and miles respectively.
For safety reasons, configuration by the driver of the multifunction screen must only be done when stationary.
C h o i c e o f l a n g u a g e
Once this menu has been selected, you can change the language used by the display (Deutsch, English, Espanol, Français, Italiano, Nederlands, Por tugues, Por tugues-Brasil, Türkçe * ).
* According to country of destination.
With Audio system on, once this menu is selected you can configure your Bluetooth hands-free system (pairing), view the various telephone directories (list of calls, ser vices...) and manage your calls (call, hang up, second call, secret mode...). For more information on the "Telephone" function, refer to the Audio system par t of the "Audio and telematics" section.
"Telephone" Menu
Page 30 of 253
55Multifunction screens
16/9 colour screen (MyWay)
It displays the following information automatically and directly: - time, - date, - altitude, - ambient temperature (the value displayed flashes if there is a risk of ice),
- check of the doors, - warning and vehicle function status messages, displayed temporarily,
- audio functions, - trip computer information (see the "Monitoring" section), - satellite navigation system information.
Displays on the screen
MyWay To select one of the applications, at the control panel: press the dedicated "R ADIO" , "MUSIC" , "NAV" , "TR AFFIC" , "SETUP" or "PHONE" button for access to the corresponding menu, turn the dial to change the selection, press the dial to confirm the selection, or press the "ESC" button to abandon the
current operation and return to the previous display.
Controls
For more information on these applications, refer to the "Audio and Telematics" section or to the specific user guide given to you with the other owner's documents.
