glove box Citroen DS4 2011 1.G Owner's Manual

15Familiarisation
Instruments and controls




1.
Steering lock and ignition.

2.
Steering mounted control paddles for the
6 -speed electronic gearbox system.

3.
Wiper/screenwash/trip computer
control stalk.

4.
Speaker (tweeter).

5.
Windscreen demisting vent.

6.
Sunshine sensor.

7.
Passenger's airbag.

8.
Glove box /Audio/video sockets/
Passenger's airbag deactivation switch.

9.
Heated seat control.

10.
Lumbar massage control.

11.
Electric parking brake.

12 .
Gear lever, 6 -speed electronic gearbox
system.

13.
Large multifunctional storage unit.

Passenger safety



1.
Open the glove box.

2.
Inser t the key.

3.
Select the position:
"OFF"
(deactivation), with "rear facing"
child seat,
"ON"
(activation), with front passenger or
"for wards facing" child seat.

4.
Remove the key keeping the switch in the
new position.


Passenger's front airbag


184



A.
Front left seat belt not fastened/unfastened
warning lamp.

B.
Front right seat belt not fastened/
unfastened warning lamp.

C.
Rear right seat belt unfastened warning
lamp.

D.
Rear centre seat belt unfastened warning
lamp.

E.
Rear left seat belt unfastened warning
lamp.

F.
Passenger's front airbag deactivated
warning lamp.

G.
Passenger's front airbag activated warning
lamp.


Seat belts and passenger's
front airbag

179, 18 5

Lighting dimmer


fixed. The lighting dimmer is making an
adjustment. You can adjust the level of illumination of the
instruments between 1 and 16.



Passenger's
airbag system
fixed in the seat belt
and passenger's front
airbag warning lamps
display.
The control switch, located in the glove
box, has been placed in the "ON"
position.
The passenger's front airbag is activated.
In this case, do not install a "rear facing"
child seat. Move the control switch to the "OFF"
position
to deactivate the passenger's front airbag.
In this case, you can install a "rear facing" child seat.





Automatic wiping


fixed. The wiper control is pushed
downwards. Automatic front wiping is activated.
To deactivate automatic wiping, operate the control
stalk downwards or put the stalk into another position.

Warning lamp



is on



Cause



Action/Observations





Stop & Start


fixed. When the vehicle stops (red lights,
traffic jams, ...) the Stop & Star t
system has put the engine into STOP
mode. The warning lamp goes off and the engine restar ts
automatically in START mode, as soon as you want
to move off.

flashes for a few
seconds, then goes
off. STOP mode is temporarily
unavailable.
or
START mode is invoked
automatically. Refer to "Driving - § Stop & Start" for special cases
with STOP mode and START mode.


Parking space
sensors


fixed. The parking space sensors function
is selected. To star t measurement, operate the direction indicator
on the side of the space to be measured, and do not
exceed 12 mph (20 km/h). A message is displayed
once the measurement has been completed.

51Monitoring




Passenger's
airbag system


fixed in the instrument
panel and/or seat belt
and front passenger's
airbag warning lamps
display. The control switch, located in the
glove box, is set to the OFF
position.
The passenger's front airbag is
deactivated. Set the control to the "ON"
position to activate
the passenger's front airbag.
In this case, do not fit a child seat in the rear-facing
position.

Warning lamp



is on



Cause



Action/Observations






ESP/ASR


fixed. The button, located at the bottom
left of the dashboard, is pressed. Its
indicator lamp is on.
The ESP/ASR is deactivated.
ESP: electronic stability programme.
ASR: anti-slip regulation. Press the button to activate the ESP/ASR. Its indicator
lamp goes off.
The ESP/ASR system is activated automatically when
the vehicle is star ted.
If deactivated, the system is reactivated automatically
from around 30 mph (50 km/h).










Deactivation indicator lamps

If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally.
This is may be accompanied by an audible signal and a message on the multifunction screen.

Interior fi ttings



1.
Sun visor


(see "Familiarisation - § Panoramic
windscreen")

2.
Ticket/card holder


3.
Illuminated

glove box


(see details on a following page)

4.
Door

pockets


5.
USB port/Auxiliary socket


(see details on a following page)

6.
Cigar lighter/12 V accessor y socket


(see details on following pages)

7.
Por table ashtray


(see details on following pages)

8.
Centre armrest with storage


(see details on a following page)

143Fittings











Illuminated glove
box

It has dedicated locations for storing a water
bottle, the vehicle's handbook pack...
Its lid has locations for storing a pen, a pair of
glasses, tokens, maps, a cup...


)
To open the glove box, raise the handle.
It is lit when the lid is opened.
It houses the front passenger airbag
deactivation switch A
.
If the vehicle is fitted with air conditioning, it
provides access to the ventilation nozzle B
,
distributing the same conditioned air as the
vents in the passenger compartment.






Portable ashtray




)
Pull the cover to open the ashtray.

)
To empty it, remove the ashtray by pulling it
upwards.
To avoid any problem of inter ference
or risk of over turning, do not place the
ashtray near the gear lever.

Front airbags

System which protects the driver and front
passenger in the event of a serious front impact
in order to limit the risk of injury to the head and
thorax.
The driver's airbag is fitted in the centre of the
steering wheel; the front passenger's airbag is
fitted in the dashboard above the glove box.
Deployment

The airbags are deployed simultaneously,
unless the passenger's front airbag is
deactivated, in the event of a serious front
impact to all or par t of the front impact zone A
,
in the longitudinal centreline of the vehicle on a
horizontal plane and directed from the front to
the rear of the vehicle.
The front airbag inflates between the thorax
and head of the front occupant of the vehicle
and the steering wheel, driver's side, and the
dashboard, passenger's side to cushion their
for ward movement.

249Practical information














Changing a wheel
Procedure for changing a faulty wheel for the spare wheel using the tools provided with the vehicle.
The tools are installed in the boot under the
floor.
To gain access to them:


)
open the boot,

)
raise the floor,

)
secure it by hooking its cord on the hook
on the rear shelf suppor t,

)
with a standard size spare wheel, unclip
and remove the box in the middle of the
wheel containing the tools,
or

)
with a "space-saver" spare wheel; lift the
wheel at the rear towards you for access
to the storage box containing the tools.


Access to the tools


List of tools

All of these tools are specific to your vehicle.
Do not use them for other purposes.

Wheel with trim


When removing the wheel
, detach the
trim first using the wheelbrace 1
pulling
at the valve passage hole.

When refitting the wheel
, refit the trim
star ting by placing its notch facing the
valve and press around its edge with
the palm of your hand.


3.
"Bolt cover" tool.
For removing the bolt protectors (covers)
on alloy wheels.

4.
Socket for the security bolts (located in the
glove box).
For adapting the wheelbrace to the special
"security" bolts.


1.
Wheelbrace.
For removing the wheel trim and the wheel
fixing bolts.

2.
Jack with integral handle.
For raising the vehicle.

Fusebox 1



Fuse N°



Rating


Functions



F8



3 A

Alarm siren, alarm ECU.


F13



10 A

Cigarette lighter.


F14



10 A

12 V socket in boot.


F16



3 A

Lighting for the large multifunctional storage unit, rear map
reading lamps, glove box illumination.


F17



3 A

Sun visor illumination, front map reading lamps.


F28



15 A

Audio system, radio (after-market).


F30



20 A

Rear wiper.


F32



10 A

Hi-Fi amplifier.

Fusebox 2



Fuse N°



Rating


Functions



F36



15 A

Rear 12 V socket.


F37



-

Not used.


F38



-

Not used.


F39



-

Not used.


F40



25 A

230 V/50 Hz socket.

Fuse tables

381Visual search
Interior


Boot f it tings 15 3 -15 6


- rear parcel shelf

- hooks

- 12 V socket

- torch

- lashing eyes

- storage compartment


Rear seats 93 -94
Rear armrest /Ski flap 152
ISOFIX mountings 166 -168

Child seats 160 -165
Front seats 88-92
Seat belts 179 -182
Airbags 183 -18 8

Glove box 143
Deactivating the passenger's airbag 185
Interior fittings 142-152


- auxiliary socket /USB port

- cigarette lighter/12 V socket

- portable ashtray

- front armrest

- 230 V/50 Hz socket

- mats

Panoramic windscreen 12


- blind

- sun visor
