YOUR HANDBOOK
ON THE INTERNET!

CITROËN lets you view your vehicle's
documentation on line, to see earlier versions
and the latest information, simply and free of
charge.
Connect to http://service.citroen.com:

1 |
Select your language and register,
click on the link in the "Private customer access" zone to consult the
vehicle documentation; a window opens providing access to all of
the handbooks,
select your vehicle, choose the body type then the date of issue of
the handbook,
fi nally, click on the heading of your choice.
2 |
3 |
4 |

MULTIFUNCTION
SCREENSCOMFORT ACCESS VISIBILITY
62 Monochrome screen C
66 Colour screen and map
70 Tr i p c o m p u t e r78 Ventilation
80 Manual air conditioning
82 Dual-zone digital air
conditioning
87 Rear screen demist - defrost
88 Front seats
93 Rear seats
94 Steering wheel adjustment
95 Mirrors100 Remote control key
109 Alarm
112 Doors
114 Boot
115 Electric windows
117 Fuel tank
119 Misfuel prevention (Diesel)122 Lighting controls
123 Daytime running lamps
126 Automatic illumination of
headlamps
127 Welcome lighting
128 Headlamp adjustment
129 Directional lighting
131 Wiper controls
132 Automatic rain sensitive
wipers
136 Courtesy lamps
137 Interior mood lighting
138 Boot lamp
004004005005002002003003

100



Opening



A.
Folding/unfolding the key
(first press this button).


3-button remote
control
When a sensor detects a low level of light,
the remote switching on of the dipped beam
headlamps, the sidelamps and the side spotlamps
makes your approach to the vehicle easier.

Welcome lighting

Complete or selective unlocking of
the vehicle
(rapid flashing of the direction
indicators).
Opening the windows
(hold until the desired position is reached).
Selective unlocking of the boot. Normal locking
(press once; fixed lighting of the
direction indicators).
Closing the windows
(hold until the desired position is reached).

127

In the same way, the passenger compar tment
lighting, such as the cour tesy lamps and the
footwell lamps, comes on.

Panoramic windscreen


Blind



)
To open it, take the blind by its central
grip A
, and pull it rear wards, guiding it to
the desired position.

)
To close it, take the blind by its central
grip A
, and pull it for wards, guiding it to
the desired position.
The sun visor should be in the folded position
before moving the blind.
This includes a panoramic area in tinted glass to increase lighting and vision in the passenger compartment.
Fitted with a blind on each side to improve temperature control and a sun visor to avoid dazzle.


Sun visor

Fitted with a courtesy mirror and a ticket holder.


)
To avoid dazzle from the front, lower the
sun visor.

)
To avoid dazzle from the side, disengage
the sun visor from its central fixing and turn
it towards the side window.
Do not attach to or suspend heavy
objects from the blind and its guide rails.

Instruments and controls




1.
Cruise control/speed limiter controls.

2.
Controls for optional functions.

3.
Steering wheel adjustment control.

4.
Lighting and direction indicator control
stalk.

5.
Instrument panel.

6.
Driver's airbag.
Horn.

7.
Controls for audio and telematic system.

8.
Controls for Bluetooth system or telephone.

9.
Bonnet release.

10.
Door mirror controls.
Electric window controls.

11.
Fusebox.

12 .
Manual headlamp height adjustment
Lower side switch panel.

13.
Fuel filler flap opening switch.
Upper side switch panel.

14 .
Side adjustable air vent.

15.
Front side window demisting vent.

Eco-driving

Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.


Optimise the use of your
gearbox

With a manual gearbox, move off gently,
change up without waiting and drive by
changing up quite soon. If your vehicle has
the system, the gear shift indicator invites you
to change up; it is displayed in the instrument
panel, follow its instructions.

With an automatic or electronic gearbox,
stay in Drive "D"
or Auto "A"
, according to
the type of gearbox, without pressing the
accelerator pedal heavily or suddenly.



Drive smoothly


Maintain a safe distance between vehicles, use
engine braking rather than the brake pedal,
and press the accelerator progressively. These
practices contribute towards a reduction in fuel
consumption and CO
2 emissions and also helps
reduce the background traffic noise.

If your vehicle has cruise control, make use of
the system at speeds above 25 mph (40 km/h)
when the traffic is flowing well.



Control the use of your
electrical equipment

Before moving off, if the passenger
compartment is too warm, ventilate it by
opening the windows and air vents before
using the air conditioning.
Above 30 mph (50 km/h), close the windows
and leave the air vents open.
Remember to make use of equipment
that can help keep the temperature in the
passenger compar tment down (sun roof and
window blinds...).
Switch off the air conditioning, unless it has
automatic digital regulation, as soon as the
desired temperature is attained.
Switch off the demisting and defrosting
controls, if not automatic.
Switch off the heated seat as soon as
possible.

Vent ilat ion


Air intake

The air circulating in the passenger compar tment
is filtered and originates either from the outside
via the grille located at the base of the windscreen
or from the inside in air recirculation mode.


Air treatment

The incoming air follows various routes
depending on the controls selected by the
driver:


- direct arrival in the passenger compartment
(air int ake),

- passage through a heating circuit (heating),

- passage through a cooling circuit (air
conditioning).



Control panel

The controls of this system are grouped
together on control panel A
on the centre
console.


Air distribution



1.
Windscreen demisting-defrosting vents.

2.
Front side window demisting-defrosting
vents.

3.
Side adjustable air vents.
4.
Central adjustable air vents.

5.
Air outlets to the front footwells.

6.
Air nozzles to the front footwells.

7.
Air outlets to the rear footwells.

Manual air conditioning











The air conditioning system operates with the engine running.


1. Temperature adjustment



)
Turn the dial to select a
position between blue (cold)
and red (hot) so as to adjust
the temperature to your
requirements.



2. Air fl ow adjustment

This dial is used to increase or
decrease the speed of the air
booster fan.

3. Air distribution adjustment

This dial is used to arrange the distribution of
air in the passenger compar tment by combining
several air outlets.

)
If you place the air flow control
in position 0
, the system is
deactivated. However, a slight flow
of air, due to the movement of the
vehicle, can still be felt.


)
Turn the dial from position 1
to position 5
to
obtain a comfor table air flow. Windscreen and side windows.
Windscreen, side windows and
footwells.
Footwells.
Central and side vents.
The air distribution can be
adapted by placing the dial in an
intermediate position.

81Comfort

4. Air intake/Air recirculation

The intake of exterior air prevents the formation
of mist on the windscreen and side windows.


)
Press the button to recirculate
the interior air. The indicator
lamp comes on to confirm this. This function allows hot or cold air to be
delivered selectively and more quickly.


5. Air conditioning On/Off

The air conditioning is designed to
operate effectively in all seasons,
with the windows closed.

Switching on



)
Press the "A /C "
button, the button's
indicator lamp comes on.
The air conditioning does not operate
when the air flow adjustment control 2

is in position " 0
". The recirculation of interior air isolates the
passenger compar tment from exterior odours
and smoke.
Return to exterior air intake as soon as possible
to prevent deterioration of the the air quality
and the formation of mist.

)
Press the button again to permit the intake
of exterior air. The indicator lamp goes off
to confirm this.

It enables you to:


- lower the temperature, in summer,

- increase the effectiveness of the demisting
in winter, above 3 °C.



Switching off



)
Press the "A /C "
button again, the button's
indicator lamp goes off.
Switching off may affect comfor t levels
(humidity, condensation).

Dual-zone digital air conditioning
The air conditioning system operates when the engine is running.


Automatic operation


1. Automatic comfort programme


We recommend the use of one of
the three AUTO modes available:
they provide optimised regulation of
the temperature in the passenger
compartment according to the comfor t value
that you have chosen.
These three modes automatically adjust the
air flow, according to the desired setting, while
also maintaining the desired comfort value.

)
Press the "AU TO "
button repeatedly:


- a first indicator lamp comes on; the
"light" setting mode is selected,

- a second indicator lamp comes on; the
"medium" setting mode is selected,

- a third indicator lamp comes on; the
"intense" mode setting is selected.
When the engine is cold, the air
flow will reach its optimum level
progressively, taking account of the
weather and the desired comfort level
so as to avoid too great a distribution
of cold air.
On entering the vehicle, if the interior
temperature is much colder or warmer
than the comfor t value, there is no
need to change the value displayed in
order to obtain the comfor t required.
The system corrects the difference
in temperature automatically and as
quickly as possible.
This system is designed to operate effectively
in all seasons, with the windows closed.
