Citroen DS4 DAG 2010.5 1.G Owner's Manual

153Fittings
 To connect a 12 V accessory (max power: 120 W), remove the cap and connect an appropriate adaptor.  Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot wall, which can be used to light the boot or as a torch.
For the boot lamp function, refer to the "Visibility - § Boot lamp" section.
Torch
Operation
This torch operates with NiMH type rechargeable bateries.
It has an battery life of approximately 45 minutes and charges while you are driving.
Obser ve the polarities when fitting the rechargeable batteries. Never replace the rechargeable batteries with normal batteries.

Use
 Extract the torch from its location pulling it upwards.
 Press the switch, located on the back, to switch the torch on or off.  Unfold the suppor t, located on the back, to set down and raise the torch; for example, when changing a wheel.
Storing
 Put the torch back in place in its location star ting with the lower par t.
If you have forgotten to switch off the torch, this switches it off automatically.
Storage box
 Raise the boot carpet for access to the storage box. This has areas for the storage a box of spare bulbs, a first aid kit, two warning triangles... It also contains the vehicle tools, the temporary tyre repair kit...
It the torch is not engaged correctly, it may not charge and may not come on when the boot is opened.

153Fittings
 To connect a 12 V accessory (max power: 120 W), remove the cap and connect an appropriate adaptor.  Turn the key to the ignition on position.
12 V accessory socket
This is a removable lamp, fitted in the boot wall, which can be used to light the boot or as a torch.
For the boot lamp function, refer to the "Visibility - § Boot lamp" section.
Torch
Operation
This torch operates with NiMH type rechargeable bateries.
It has an battery life of approximately 45 minutes and charges while you are driving.
Obser ve the polarities when fitting the rechargeable batteries. Never replace the rechargeable batteries with normal batteries.

Use
 Extract the torch from its location pulling it upwards.
 Press the switch, located on the back, to switch the torch on or off.  Unfold the suppor t, located on the back, to set down and raise the torch; for example, when changing a wheel.
Storing
 Put the torch back in place in its location star ting with the lower par t.
If you have forgotten to switch off the torch, this switches it off automatically.
Storage box
 Raise the boot carpet for access to the storage box. This has areas for the storage a box of spare bulbs, a first aid kit, two warning triangles... It also contains the vehicle tools, the temporary tyre repair kit...
It the torch is not engaged correctly, it may not charge and may not come on when the boot is opened.

General points relating to child seats
Although one of CITROËN's main criteria when designing your vehicle, the safety of your children also depends on you.
CITROËN recommends that children should travel in the rear seats of your vehicle: - "rearwards-facing" up to the age of 2, - "forwards-facing" over the age of 2.
For maximum safety, please obser ve the following recommendations: - in accordance with European regulations, all children under the age of 12 or less than one and a half metres tall must travel in approved child seats suited to their weight , on seats fitted with a seat belt or ISOFIX mountings * , - statistically, the safest seats in your vehicle for carr ying children are the rear seats, - a child weighing less than 9 kg must travel in the "rear wards-facing" position both in the front and in the rear.
* The rules for carrying children are specific to each country. Refer to the current legislation in your country.

Child safety
Child seat in the front
"Rearwards-facing"
When a "rear wards-facing" child seat is installed on the front passenger seat , it is essential that the passenger airbag is deactivated. Other wise, the child would risk being seriously injured or killed if the airbag were to inflate .
"Forwards-facing"
When a "for wards-facing" child seat is installed on the front passenger seat , adjust the vehicle's seat to the intermediate longitudinal position with the seat back upright and leave the passenger airbag activated.
Intermediate longitudinal position

Passenger airbag OFF
Child seats recommended by CITROËN CITROËN offers a complete range of recommended child seats which are secured using a Child seats recommended by CITROËN Child sthree point seat belt :
Group 0+: from bir th to 13 kgGroups 1, 2 and 3: from 9 to 36 kg

L1"RÖMER Baby-Safe Plus" Installed in the rear wards-facing position.
L2"KIDDY Life" The use of the restraining cushion is compulsory for carrying young children (from 9 to 18 kg).
Groups 2 and 3: from 15 to 36 kg

L3"RECARO Star t''
L4"KLIPPAN Optima" From the age of 6 years (approximately 22 kg), the booster is used on its own.

L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings. The child is restrained by the seat belt.

Passenger airbag OFF
Child seats recommended by CITROËN CITROËN offers a complete range of recommended child seats which are secured using a Child seats recommended by CITROËN Child sthree point seat belt :
Group 0+: from bir th to 13 kgGroups 1, 2 and 3: from 9 to 36 kg

L1"RÖMER Baby-Safe Plus" Installed in the rear wards-facing position.
L2"KIDDY Life" The use of the restraining cushion is compulsory for carrying young children (from 9 to 18 kg).
Groups 2 and 3: from 15 to 36 kg

L3"RECARO Star t''
L4"KLIPPAN Optima" From the age of 6 years (approximately 22 kg), the booster is used on its own.

L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings. The child is restrained by the seat belt.

161Child safety
Locations for child seats secured using the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using the seat belt and universally approved (a) in relation to the weight of the child and the seat in the vehicle.
Seat
Weight of the child/ indicative age
Less than 13 kg (groups 0 (b) and 0+) Up to ≈ 1 year
From 9 to 18 kg (group 1) From 1 to ≈ 3 years
From 15 to 25 kg(group 2) From 3 to ≈ 6 years
From 22 to 36 kg (group 3) From 6 to ≈ 10 years
Front passenger seat (c)
- fixed U(R1)U(R1)U(R1)U(R1)
- height adjustable U(R2)U(R2)U(R2)U(R2)
Outer rear seats UUUU
Centre rear seat XXXX
(a) Universal child seat: child seat which can be i nstalled in all vehicles using the seat belt. (b) Group 0: from bir th to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat. (c) Consult the legislation in force in your country before installing your child on this seat. U : seat suitable for the installation of a child seat secured using the seat belt and universally approv ed "rear facing" and/or "for ward facing". U(R1) : identical to U , with the vehicle's seat backrest inclined fully for wards. U(R2) : identical to U , with the vehicle's seat adjusted to the highest p osition. X : seating position not suitable for installing a child seat for the weight group indicated.

Advice on child seats
The incorrect installation of a child seat in a vehicle compromises the child's protection in the event of an accident. Remember to fasten the seat belts or the child seat harnesses keeping the slack relative to the child's body to a minimum, even for shor t journeys. When installing a child seat using the seat belt, ensure that the seat belt is tightened correctly on the child seat and that it secures the child seat firmly on the seat of your vehicle. Move the seat for wards if necessary. For optimum installation of the "for wards-facing" child seat, ensure that the back of the child seat is in contact with the back of the vehicle's seat and that the head restraint does not cause any discomfor t. If the head restraint has to be removed, ensure that it is stored or attached securely to prevent it from being thrown around the vehicle in the event of sharp braking.
Children under the age of 10 must not travel in the "for wards-facing" position on the front passenger seat, unless the rear seats are already occupied by other children, cannot be used or are absent. Deactivate the passenger airbag when a "rear wards-facing" child seat is installed on the front seat. Other wise, the child would risk being seriously injured or killed if the airbag were to inflate.
Installing a booster seat
The chest par t of the seat belt must be positioned on the child's shoulder without touching the neck.
Ensure that the lap par t of the seat belt passes correctly over the child's thighs. CITROËN recommends the use of a booster seat which has a back, fitted with a seat belt guide at shoulder level.
As a safety precaution, do not leave: - a child or children alone and unsuper vised in a vehicle, - a child or an animal in a vehicle which is exposed to the sun, with the windows closed, - the keys within reach of children inside the vehicle. To prevent accidental opening of the doors
and rear windows, use the "Child lock". Take care not to open the rear windows by more than one third. To protect young children from the rays of the sun, fit side blinds on the rear windows.
