ISOFIX child seats recommended by CITROËN and approved for
your vehicle
Follow the instructions for fitting child seats con tained in the seat manufacturer's installation guide .
FAIR Bimbofix ISOFIX (size category: C or A )
Group 0/1: up to 18 kg
Can be installed facing for ward or rear ward using an ISOFIX base which
is attached to the rings A and includes a stay which extends down to the
floor of the vehicle.
Can be installed facing for ward, attached to the s eat using a three-point
seat belt.
6 seat body angle positions.
(size category B1 )
Group 1: from 9 to 18 kg
Is installed in the for ward-facing position. Is attached to the rings A and the upper ring B ,
referred to as the Top Tether, using an upper strap.
Three seat body angles: sitting, reclining, lying d own.
Can be installed facing for ward, attached to the s eat using a three-point
seat belt.
164
Child safety
Your vehicle has been approved in accordance with the new ISOFIX regulation . The seats, represented below, are fitted with regulation ISOFIX mountings:
"ISOFIX" mountings
There are three rings for each seat: - two rings A , located between the vehicle seat back and cushion, indicated by a label,
- a ring B , behind the seat, referred to as the Top Tether for fixing the upper strap. ther
This ISOFIX mounting system provides fast, reliable and safe fitting of the child seat in your vehicle.
The incorrect installation of a child seat
in a vehicle compromises the child's protection in the event of an accident.
For information regarding the ISOFIX child seats which can be installed in your vehicle, refer to the table showing the locations for
installing ISOFIX child seats.
When fitting an ISOFIX child seat to the left hand rear seat, before fitting the seat, first move the centre rear seat belt towards the middle of the vehicle, so as to avoid the seat inter fering with the operation of the seat belt.
The ISOFIX child seats are fitted with two latches which are secured on the two rings A . Some seats also have an upper strap , known as the Top Tether, which is attached to ring B . To attach this strap, raise the vehicle seat's head restraint then pass the hook between its rods. Then fix the hook on ring B and tighten the upper strap.
163
or
