bluetooth Citroen DS5 2016 1.G User Guide

DS5_en_Chap11d_RD5_ed02-2015
As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of
your audio system must be carried out
with the vehicle stationary and the
ignition on.
Visit www.citroen.co.uk for more
information (compatibility, additional
help, ...).
The play modes available are:
-
No

rmal: the tracks are played
in order, depending on the
classification of the selected files.
-
Ra

ndom: the tracks in an album
or folder are played in a random
o r d e r.
- Ra
ndom all: all of the tracks saved
in the media are played in random
o r d e r.
-
Re

peat: the tracks played are only
those from the current album or
f o l d e r. Select "
Multimedia " and confirm.
Select " Media parameters " and
confirm.
Select " Read mode " and confirm.
Select the desired play mode and
confirm OK to save the modifications.
Press MENU.
Press OK
for access to the
contextual menu.
or
Press MENU .
Play mode
Using the telephone
Pairing a telephone
First connection
The services offered depend on the network,
the SIM card and the compatibility of the
Bluetooth telephone used.
Consult your telephone's manual and your
operator to find out which services are
available to you.
Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (refer to the
telephone user guide).

293
DS5_en_Chap11d_RD5_ed02-2015
Pairing can also be initiated from the
telephone by searching for detected
Bluetooth devices.
The directory and the calls list can be
accessed after the synchronisation
period (if the telephone is compatible).
Automatic connection must be
configured in the telephone to allow
the connection each time the vehicle is
started.
A message is displayed on the screen of the
telephone: enter the same code and confirm.
Select "
Bluetooth connection " and
confirm. A virtual keypad is displayed on the
screen: enter a code with at least
4
d
igits and conform with OK.
Select " Search for a device".
Select the telephone to be connected
from the list. Only one telephone can
be connected at a time.
A window is displayed "
Search in progress…".
In some cases, the reference number of the
telephone or the Bluetooth address may appear
instead of the name of the telephone.
If pairing fails, try again; the number of attempts is not limited.
Accept the connection to the telephone.
A message appears in the screen to confirm
successful connection.
Streaming - Playing audio
files via Bluetooth
Pair/connect the telephone then play the files:
see the "Pairing" section.
Audio and Telematics

DS5_en_Chap11d_RD5_ed02-2015
The telephone connection automatically
includes hands free operation and
audio streaming.
The ability of the system to connect
to just one profile depends on the
telephone. Both profiles may connect
by default.Indicates that a device is connected.
Indicates connection of the audio
steaming profile.
Indicates connection of the hands-
free profile.
Press MENU
.
Managing connections
Select "Bluetooth connection " and
confirm.
Select "
con

nections management "
and confirm. The list of paired
telephones is displayed. Then select and confirm:
-
"con

nect telephone
" /
"
dis
connect telephone
":
to connect / disconnect the
telephone or the hands-free
connection only.
-
"con
nect media player
" /
"
dis
connect media player
":
to connect / disconnect only
streaming.
-
"con
nect telephone +
media player " / "
di
sconnect
telephone
+
media player
":
to connect / disconnect the
telephone (hands-free and
streaming).
-
"del

ete connection": to delete
the pairing.
Select a telephone and confirm.

DS5_en_Chap11d_RD5_ed02-2015
(so that the caller cannot hear)
In the contextual menu:
-
se
lect "Micro OFF " to switch off
the microphone.
-
de

select " Micro OFF " to switch
the microphone on. In the contextual menu:
-
se

lect "Telephone mode " to
transfer the call to the telephone.
-
de

select "Telephone mode " to
transfer the call to the vehicle. From the contextual menu, select
"dTM
F tones" and confirm to use
the digital keypad to navigate in the
interactive voice response menu.
From the contextual menu, select
" Switch " and conform to return to a
call left on hold.
Secret - Mutecomb ined mode
(to leave the vehicle without ending the call)
Interactive voice response
con

sultation call
In certain cases, the combined mode has to
activated from the telephone.
If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically (depending on the compatibility of
the telephone).

299
DS5_en_Chap11d_RD5_ed02-2015
To modify the contacts saved in the
system, press MENU then select
" Telephone " and confirm.
Select "
dire

ctory management "
and confirm.
You can:
-
"con

sult an entr y ",
-
"dele

te an entry ",
-
"dele

te all entries ".
Make a long press on SOUR
cE or
S

R
c fo

r access to the directory
or press OK , and
select "
ca

ll " and confirm.
The system accesses the telephone's
contacts directory, depending on
its compatibility, and while it is
connected by Bluetooth.
With certain telephones connected
by Bluetooth you can send a contact
to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.
Select "
dire

ctory
" to see the list of
contacts.
directory
Audio and Telematics

301
DS5_en_Chap11d_RD5_ed02-2015
Screen menu map(s)
Option A
Option A11
Option B...
Media parameters
ME
dIA
T
ELEPHONE
choice of playback mode
cho

ice of track listing
Option A1
Normal By folders
Random all By genres
Random By artists
Repeat By playlists
3
3
3
3
3
3
3
3
3
1
1
2
1
2
2
Main function
call
Rad io parameters
directory
call

s list
voice

mail box
dial
directory management
T elephone management
Hang up
con

nections management
BLUETOOTH
cON

NE
cTI
ON
Search for a device
delete an entry
dele
te all entries
con
sult an entr y
Telephone status
1
1
1
1
1
2
2
2
2
1
1
2
2
2
2
Screen c
Audio and Telematics

305
DS5_en_Chap11d_RD5_ed02-2015
QUESTIONANSWER SOLUTION
The CD is ejected
automatically or is not
played by the player. The CD is inserted upside down, is unplayable, does not contain
any audio data or contains an audio format which the player cannot
p l ay.
The CD is protected by an anti-pirating protection system which is
not recognised by the audio equipment. -
Ch

eck that the CD is inserted in the player
the right way up.
-
Ch

eck the condition of the CD: the CD
cannot be played if it is too damaged.
-
Ch

eck the content in the case of a recorded
CD: consult the advice in the "Audio" section.
-
Th

e audio equipment's CD player does not
play DVDs.
-
Du

e to their quality level, certain writeable
CDs will not be played by the audio system.
The CD player sound is
p o o r. The CD used is scratched or of poor quality.
Insert good quality CDs and store them in
suitable conditions.
The audio settings (bass, treble, ambience) are unsuitable. Set the treble or bass level to 0, without selecting
an ambience.
I am unable to connect my
Bluetooth telephone. It is possible that Bluetooth is switched off on the telephone or that
the telephone has not been made not visible. -
Ch

eck that your telephone has Bluetooth
switched on.
-
Ch

eck in the telephone's settings that it is
" Visible to all".
The Bluetooth telephone is not compatible with the system. You can check the compatibility of your
telephone on www.citroen.co.uk (services).
The Bluetooth connection
is cut. The battery of the peripheral may not be sufficiently charged. Recharge the battery of the peripheral device.
Audio and Telematics

AB
Accessories .................................................. 23 4
Accessory position ....................................... 101
Ad
ditive, AdBlue
.............................. 29
, 253 -261
Additive, Diesel
.....................................

250, 251
Adjusting headlamps
.................................... 150
A

djusting head restraints
.......................... 72
, 75
Adjusting seats
.......................................... 72

, 73
Adjusting the date
..................................... 39

, 42
Adjusting the height and reach of the steering wheel
........................................ 81
A

djusting the seat belt height
....................... 187
A

djusting the time
............................... 38
, 39, 42
Advice on care and maintenance
............................................... 233
A

dvice on driving
......................................
98, 99
Airbags
....................................................

31, 189
Airbags, curtain
..................................... 191

, 192
Airbags, front......................................... 189, 192
Airbags, lateral
...................................... 191

, 192
Air conditioning, automatic
....................... 90

, 91
Air vents
.......................................................... 89
A

larm
............................................................... 63
An

ti-lock braking system (ABS)
.................... 182
A

nti-pinch
........................................................ 68
Ant

i-theft
....................................................... 10

1
Armrest, front
............................................ 82

, 85
Armrest, rear
............................................. 82

, 86
Ashtray
............................................................ 8

2
Assistance call
......................................

181, 278
Assistance, emergency braking
................... 182
A

udible warning
............................................ 181
A

udio streaming (Bluetooth)
................. 29
1, 293
Audio system
...........................................

39, 281
Automatic headlamps
............................. 20

, 147Battery ............................................
223 -227, 251
Battery, charging ........................................... 2
25
Battery, remote control
............................. 59

, 60
Black panel ...................................................... 38
Blind spot sensors
........................................ 123
Bl

ueHDi
.........................................
246, 253 -261
Bluetooth (hands-free)
.................................. 292
Boo

t
.................................................................62
B

oot (opening)
.................................................53
B

rake discs
....................................................252
B

rake lamps
..................................................2

16
Brake warning lamp
........................................ 27
B

raking assistance system
...........................182
B

raking, dynamic emergency
...............103

, 107
Bulbs (changing)
.................................... 21

1-218
Capacity, fuel tank
........................................ 23

9
Cap, fuel filler
................................................ 239
CD .................................................................

287
CD, MP3
................................................ 28

8, 289
Central locking
.......................................... 53

, 55
Changing a bulb
..................................... 211

-218
Changing a fuse
..................................... 21

9-222
Changing a wheel
.................................. 20

2-209
Changing a wiper blade
........................ 15

6, 228
Changing the remote control battery
.............. 59
Ch

ecking the engine oil level
.................. 36
, 247
Checking the levels
................................ 24

7-25 0
Checking tyre pressures (using the kit)
........ 201
C

hecks
..................................
244, 245, 251, 252
Checks, routine
..................................... 25

1, 252Date (setting)
.............................................

39, 42
Daytime running lamps
..................14

5, 211, 212
Deactivating ESC
.......................................... 18 4
D

eactivating the passenger airbag
...............19 0
D

eadlocking
....................................................56
D

emisting, defrosting
......................................95
Dem

isting, defrosting
the mirrors
..............................................

80, 95
cd
Child lock ............................................... 169, 176
Children .................................. 160 -176, 188, 190
Child seats
............................................ 1

6 2-18 8
Child seats, conventional
...................... 168

, 169
Child seats, ISOFIX
............................... 170

-173
Cigarette lighter............................................... 83
C
IT

ROËN
Lo
calised
Emergency Call
.......................................... 278
C

leaning (advice)
.......................................... 233
Cl

ock
............................................................... 38
C

losing the boot
.............................................. 62
C

losing the doors
......................................
53, 55
Configuration, vehicle
............................... 39

, 45
Control, emergency boot release
................... 62
Co

ntrol, emergency door
................................ 57
Co

ntrol, heated seats
...................................... 76
Co

ntrol stalk, lighting
............................ 142

, 148
Control stalk, wipers
.............................. 153

-155
Courtesy lamps
............................................. 157
C

ruise control
........................................ 12
8, 133
Cup holder
....................................................... 8

2

1 Audio and Telematics









7-inch touch screen tablet


GPS satellite navigation - Multimedia audio - Bluetooth ®
telephone


Contents
First steps 2
Steering mounted controls 4
Menus 5
Navigation 6
Navigation - Guidance 14
Tr a ffi c 18
Radio Media 20
Radio 26
DAB (Digital Audio Broadcasting) radio 28
Media 30
Settings 34
Connected services 42
Internet browser 43
MirrorLink
TM 46
CarPlay® 50
Te l e p h o n e 5 4
Frequently asked questions 62

The system is protected in such a way that it will only operate in
your vehicle.
As a safety measure, the driver should only carry out operations
which require prolonged attention while the vehicle is stationary.
The display of the energy economy mode message signals
that the electrical equipment currently operating is going into
standby.
Refer to the energy economy mode section of your vehicle's
handbook.

3 Audio and Telematics


With the engine running, press to
mute the sound.
With the ignition off, press to switch
the system on.

Volume adjustment (each source
is independent, including traffic
announcements (TA) and navigation
instructions).
Select the audio source (depending on
version):


- FM / DAB / AM * stations.

- USB memory stick.

- CD player (located in front panel).

- Smartphone via MirrorLink
TM
or CarPlay ®
.

- Telephone connected by Bluetooth * and
using Bluetooth * audio streaming.

- Media player connected to the auxiliary
socket ( jack, cable not supplied).

- Jukebox * , after first copying audio files to
the internal memory of the system.



AM and DAB are not available on
Hybrid4 vehicles.


*
Depending on equipment.

Short-cuts: using the virtual buttons in the
upper band of the touch screen tablet, it is
possible to go directly to the selection of audio
source, the list of stations (or titles, depending
on the source).
The screen is of the "resistive" type, it
is necessary to press firmly, par ticularly
for "flick" gestures (scrolling through a
list, moving the map...). A simple wipe
will not be enough. Pressing with more
than one finger is not recognised.
The screen can be used when wearing
gloves. This technology allows use at
all temperatures.

In very hot conditions, the volume may
be limited to protect the system. The
return to normal takes place when
the temperature in the passenger
compartment drops.
To clean the screen, use a soft
non-abrasive cloth (spectacles cloth)
without any additional product.
Do not use pointed objects on the
screen.
Do not touch the screen with wet
hands.
