119Comfort

004
Driving

It is recommended that you do notapply the parking brake in very coldconditions (ice) and during towing (recovery...). To do this, release the parking brake manually, select position A
or R
, then press the STA R T/STOP switch to stopthe engine.
The electric parking brake combines
2 operating modes:- Automatic Application/ReleaseApplication is automatic when the engine
stops, release is automatic on use of the
accelerator (this mode is activated by
default), -Manual Application/ReleaseManual application of the parking brake is done by pulling control lever A.Manual release is done by pullingthenreleasing the control lever, while pressing
the brake pedal.
When the driver's door is opened, there is an
audible signal and a message is displayed if the
brake is not applied.

Programming the automatic
mode

Depending on the country of sale of the vehicle,
the automatic application when the engine isswitched off and the automatic release when
you press the accelerator can be deactivated.
You can contact a CITROËN dealer or a qualified workshop to have it activated.

In this case, programming is done via
the configuration menu.








Electric parking brake
If deactivated, the parking brake must
be applied and released manually.
If this warning lamp comes on in
the instrument panel, the automaticmode is deactivated.

Never leave the vehicle without checking that the parking brake is on.
This warning lamp comes onfixed (not flashing).


Label on door panel

123Driving
With the ignition on or the hybrid system active,
to release the parking brake, press the brakepedal, pullthen release control lever A.The full release of the parking brake isconfirmed by:
Manual release
- the braking warning lamp and
the Pwarning lamp in the control lever A
going off,
- the display of a message.
I
f you pull the control lever A
without pressing
the brake pedal, the parking brake will not
be released and a message appears in the
instrument panel.
If necessar
y, you can make a maximum application
of the parking brake. It is obtained
by means of a long pull on control lever A ,
until you see a message and an audible signalis heard.
Maximum application is essential:

- in the case of a vehicle towing a trailer,
if the automatic functions are activated
but you are applying the parking brakemanually,

- when the slope you are parked on mayvary (e.g. on a ferry, on a lorry, duringtowing).


Maximum application


In the case of towing, a loaded vehicle or parking on a gradient, make amaximum application of the parkingbrake then turn the front wheels towardsthe pavement and engage a gear whenyou park.
After a maximum application, the release time will be longer.



Before leaving the vehicle, check that parking brake warning lamps in the instrument panel and the control lever Aare on fixed, not flashing. With the vehicle stationar
y, to apply the parkingbrake whether the hybrid system is active or not, pull
control lever A .


Manual application

The application of the parking brake is confirmed by:


- illumination of the brakin
g warning
lamp and of the P warning lamp in
the control lever A ,
- the display of a message.
When the driver
’s door is opened with the hybrid system active, there is an audible signal
and a message is displayed if the parking brakehas not been applied.

Before leaving the vehicle, check thatparking brake warning lamps in the instrument panel and in the control lever Aare on fixed (not flashing). Never leave a child alone inside thevehicle with the ignition on, as theycould release the parking brake.

Automatic application,
engine off
- illumination of the braking warning lamp and of the Pwarning lamp in
the control lever A,- the display of a message. With the vehicle stationar
y, the parking brake is automatically applied when the engine is
switched off.The application of the parking brake is confirmed by:

Automatic release
Full release of the parking brake is confirmed by:
- the braking warning lamp and
the P warning lamp in the controllever A
going off,
- the display of a message.
When stationary, with the hybrid system activated, do not press the accelerator pedal unnecessarily, as you may release the parking brake.




Before leaving the vehicle, check that parking brake warning lamps in the instrument panel and the control lever Aare on fixed, not flashing.

Immobilising the vehicle,
hybrid system active
With the hybrid system active and the vehiclestationary, in order to immobilise the vehicle
it is essential to manuallyapply the parking
brake by pulling control lever A
.
The application of the parking brake is confirmed by:


- illumination of the brakin
g warninglamp and of the P
warning lamp in
the control lever A,
- the display of a message.
When the driver’s door is opened, a loud beep
is heard and a messa
ge is displayed if the parking brake has not been applied. The electric parkin
g brake releases
automatically and progressively as thevehicle moves off, select position fA , M or Rand then press the accelerator.

125
Driving

Emergency braking


In the event of a failure of the main servicebrake or in an exceptional situation (e.g. driver
taken ill, under instruction, etc) a continuouspull on the control lever A will stop the vehicle.
The Dynamic Stability Control system provides stability during emergency braking.
If the emer
gency braking malfunctions,
a message is displayed.
Emergency release
) Take the vehicle blocks and the release
device, located under the boot carpet.
) On sloping ground, secure the vehicle byplacing chocks in front or behind the front
wheels, on the falling side of the slope. In the event of the electric parkin
g brake
malfunctioning or the battery running flat, an
emergency manual device can release theparking brake. ) Immobilise the vehicle and with the hybridsystem active, place the gear selector inposition M
or R.)
Switch off the engine then switch the
ignition back on (press the STA R T/STOP switch twice). If it is impossible to
immobilise the vehicle, do not operate the
control and contact a CITROËN dealer or a qualified workshop urgently.
The emergency braking must only be used in exceptional circumstances.
If a failure of the DSC system is
signalled by the illumination of this warning lamp, then braking stability isnot guaranteed.
In this event, stability must be assured by the
driver by repeating alternate "pull-release" actions on the control lever A.

For safety reasons, you must contact a
CITROËN dealer as soon as possible to replace the protective cover. Ta k e care not to allow moisture or dust in the proximity of the protective cover.
Following an emergency unlocking, immobilisation of the vehicle is no longer guaranteed once the manualemergency release has been deployed and the manual control does not allow the re-application of your parking brake. Take no action, either on the controllever A, or stopping or star ting the engine while the release device is engaged.
To r e - e ngage the electric parking brake(after correction of the fault or battery problem), make a long pull on the control lever A
until the parking brake warning lamp in the instrument panel flashes then make a second long pulluntil this warning lamp comes on fixed. Front left seat moved back full
y.
)Slide the front left-hand seat back as far aspossible. )Raise the pre-cut zone B in the carpetunder the seat.)Pierce the protective cover Con the tube Dwith the release device (located in the boot). )Place the release device in the tube D.)Turn the release device clockwisemaking several dozen turnsFor safety reasons, it is essential
tocontinue turning the device as far as it will
go. The parking brake is released.
)
Remove the release device and stow it. )
The operation of the parking brake
reinitialises after the ignition is switched off
then on again. If the reinitialisation of the
parking brake proves impossible, contact a
CITROËN dealer or a qualified workshop.) The (subsequent) time required for
application may be longer than during
normal operation.

127Driving
Operating faults
If the electric parking brake fault warning lamp comes on together with one or more of the warning lamps presented in these tables, place the vehicle in
a safe condition (on level ground, gear engaged) and contact a CITROËN dealer or a qualified workshop without delay.
SituationsConsequences
Display of the message "Parking brake fault" and of the following warning lamps:

- The automatic functions are deactivated.

- Hill start assist is not available.

- The electric parking brake can only be used manually.
Displa
y of the message "Parking brake fault" and of the following warning lamps:

- Manual release of the electric parking brake is only possible bypressing the accelerator pedal and pulling the control lever.

- Hill start assist is not available.

- The automatic functions and the manual application are still available.
Displa
y of the message "Parking brake fault" and of the following warning lamps:

- The automatic functions are deactivated.

- Hill start assist is not available.

SituationsConsequences
To a p p l
y the electric parking brake:) immobilise the vehicle and switch off the ignition. )
pull the control for at least 5 seconds or until application is complete.)
switch on the ignition and check that the electric parking brake
warning lamps come on.
The application is slower than during normal operation.
To release the electric parking brake:) switch on the ignition.)
pull the control lever and hold it for approximately 3 seconds then
release it.
If the braking warning lamp is flashing or if the warning lamps do not come on with the ignition on, these procedures will not work. Place the
vehicle on level ground and have it checked by a CITROËN dealer or a qualified workshop. and possibl
y



flashing

Display of the message "Parking brake fault" and of the following
warning lamps:

- Only the automatic application on switching off the engine and automatic release on acceleration functions are available.

- The manual application/release of the electric parking brake and theemergency braking are not available.


an
d possibly



flashing



Display of the message "Batter y charge fault".

- You must stop as soon as it is safe to do so. Switch off and
immobilise your vehicle (if necessary, place the a chock under
a wheel).

- Apply the electric parking brake before switching off the engine.
