Page 81 of 358
79Access
Deadlocking
Deadlocking renders the exterior and
interior door controls inoperative. It also deactivates the manual centralcontrol button. Therefore, never leave anyone inside the vehicle when it is deadlocked.
Using the remote control
) Press the closed padlock to lock
the vehicle completely.
Maintain pressure with
your
finger for more than twoseconds to close the windows. ) Press the closed padlock again within
five seconds to deadlock the vehicle.
With the electronic ke
y in the reader or the
Keyless Entry and Starting key inside the
vehicle, pressin
g the "STA R T/STOP" button,
with no action on the pedals, allows the ignition
to be switched on and so activate the ancillary
equipment.
Ignition on without starting
the engine
(accessory position)
)
Press the "STA R T/STOP" button,
the instrument panel comes on
but the engine does not star t. ) Press the button again to switch
off the ignition and so allow the
vehicle to be locked.
If you use the accessory position for too long, the system automatically goes intoeconomy mode to avoid the risk of a flat
battery.
With the Keyless Entry and
startin
g system
By the doors: )
With the electronic key in the defined
zone A , press a finger on the door handle (at the markings) to lock the vehicle.
)
Within five seconds, press the door handle
again to deadlock the vehicle.
Ensure that no one is preventing the correct closing of the windows. Be aware of children when operating
the windows.
Page 82 of 358
Emergency procedure
Emergency unlocking/locking
using the integral key
The integral key is used to lock and unlock the
vehicle when the electronic key cannot operate:
- cell battery flat, vehicle battery discharged
or disconnected, ...
- vehicle located in an area with stron
gelectromagnetic signals. )Maintain a pull on button 1
, to extract the integral key 2.
Complete unlocking
)
Tu r n t h e k ey towards the front of the vehicle
to unlock the vehicle.
Normal locking
)Turn the key towards the rear of the vehicle
to lock the vehicle completely.
Deadlocking
)Turn the key towards the rear in the driver's door lock to lock the vehicle completely. )Turn the key towards the rear again withinfive seconds to deadlock the vehicle.
Page 83 of 358
81Access
Do not throw the remote control batteries away, they contain metalswhich are harmful to the environment. Take them to an approved collectionpoint.
Changing the battery of the electronic key
Battery ref.: CR2032 / 3 volts.
This replacement battery is available from a
CITROËN dealer or a qualified workshop.
A message appears in the instrument panel
screen when replacement o
f the battery is needed. ) Unclip the cover using a small screwdriver at the cutout. )
Lift off the cover. )
Remove the flat battery from its location. )
Fit the new battery into its location
observing the original direction of fitment. ) Clip the cover onto the casing.
Remote control problem -
reinitialisation
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate your
v
ehicle.
)Place the mechanical key (integral with theremote control) in the lock to unlock your
vehicle. )Place the electronic key in the reader. )Switch on the ignition by pressing STA R T/STOP.
The electronic key is fully operational again.
If the problem persists, contact a CITROËN
dealer or a qualified workshop as soon as
possible.
Page 84 of 358
Lost electronic key
Visit a CITROËN dealer with the vehicle's registration document and your personal identification documents and if possible the key code label.
The CITROËN dealer will be able to retrieve the key code and the transponder code required to order a new key.
Electronic key
The electronic key is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.Do not repeatedly press the buttons of your electronic key out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would have to be reinitialised.The electronic key cannot operate as a remote control when it is in the reader or even when the ignition is switched on.
Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by the emergency services more difficult in an emergency.
As a safety precaution (with children on board), take the Keyless Entry and Starting electronic key when you leave the vehicle, even for a shorttime.
Electrical interference
The Keyless Entry and Starting electronic key may not operate if close to certain electronic devices: telephone, laptop computer, strongmagnetic fields, ...
Anti-theft protection
Do not make any modifications to the electronic engine immobiliser system; this could cause malfunctions. Don't forget to turn the steering to engage the steering lock.
When purchasing a second-hand vehicle
Have all of the keys in your possession paired by a CITROËN dealer, to ensure that only your keys allow your vehicle to be unlocked and star ted.
Page 85 of 358
83Access
Central locking control
Automatic central lockingof the doors
(anti-intrusion security)
The doors and boot can lock automatically while driving (speed above 6 mph (10 km/h)).
To activate or deactivate this function (activated
by default):
If the vehicle is deadlocked or locked from the outside, the button is not active. In this case, use the remote control to unlock the vehicle or pull an interior door handle to open a door.
If one of the doors is open, central locking from the inside does not take place.
Driving with the doors locked may make access to the passenger compar tment by the emergency ser vices more
difficult in an emergency.
)
Press the closed padlock tolocate your locked vehicle in a car park.
Locating your vehicle
)Operate the button.
This allows the doors and the boot to be locked or unlocked. This is indicated b
y lighting of the cour tesy
lamps and flashing of the direction indicatorsfor a few seconds.
) Operate this button until amessage appears in theinstrument panel screen.
Transporting long or voluminousobjects
If you want to drive with the boot open,press the central locking control button to lock the doors.
