Citroen DS5 HYBRID4 2013 1.G Owner's Manual

Range varies according to the ambient climatic conditions, the driving style and conditions, the use of vehicle systems and ageing of the battery.











Electric motor and battery
Electric motor-

Te c h n o l ogy
Synchronous with permanent magnets.
Max. power: EU standard
(kW) *
27

Max. power speed (rpm)

2 500

Max. torque: EU standard (Nm)

200

Max. torque speed (rpm) 1 250

E
fficiency (%) 80 to 90
High voltage batteryNi-MH(Nickel Metal Hydride)

Volt a
ge (V~)

200

Energy capacity (kWh / Ah)

1.1 / 5.5
Ran
ge (miles (km)) 1. 2 (2) (approximately)

*

The maximum power corresponds to the value type approved on an engine test bed, under conditions defined by European legislation
(directive 1999/99/EC).

251Technical data













Engine and gearbox
Diesel engineHDi160 PEF
Gearbox

Electronic gearbox system(6-speed)

Model code

RHC

Cubic capacit
y (cc)

1 997
Bore x stroke
(mm) 85 x 88

Max power: EU standard (kW) *

120
Max power en
gine speed (rpm) 3 850

Max torque: EU standard
(Nm)
300

Max torque en
gine speed (rpm) 1 750

Fuel

Diesel

Catalytic converter
yes

P
article emission filter
yes

Oil capacities
(in litres)
Engine (with filter replacement) -

*

The maximum power corresponds to the type approved value on a test bed, under conditions defined by European legislation (directive 1999/99/EC).

Diesel engineHDi160PEF
Gearbox
Electronic gearbox system(6-speed)
Model code

RHC



- Unladen weight-


- Kerb weight
*



1 735


- Gross vehicle wei
ght (GV W)
2 265


- Gross train wei
ght (GT W)
on a 12% gradient
2 765



- Braked trailer (within GTW limit) on a 10% or 12% gradient 500



- Braked trailer
**
(with load transfer with the GTW limit)
800



- Unbraked trailer
500



- Recommended nose wei
ght 75

















Weights and towed loads (in kg)
*

The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
To make use of the 300 kg load transfer, the driver must be alone in the vehicle with no luggage in the vehicle.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced b
y 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Technical data





Dimensions (in mm)

Identifi cation markings
A.Vehicle Identification Number (VIN) under the bonnet.This number is engraved on the bodyworknear the damper support.

The tyre pressures must be checked when the tyres are cold, at least oncea month.
The rear quarter light cannot be etchedas it is made of polycarbonate material.


If the tyre pressures are too low, thisincreases fuel consumption.

B.Vehicle identification Number (VIN) on
the windscreen lower cross member.This number is indicated on a self-adhesive label which is visible through the windscreen.
C.Manufacturer's label. The VIN is indicated on a self-destroyinglabel affixed to the door aper ture, on the
passenger's side.
D.Tyre/paint label. This label is affixed to the centre pillar, on
the driver's side. It bears the followin
g information:


- the tyre inflation pressures with and without
load,

- the tyre sizes,

- the brands of tyre recommended by the manufacturer,

- the inflation pressure of the spare wheel,

- the paint colour code.
