Setting the date and time
With CITROËN Connect
Radio
F Select the Settings menu.
F Sel ect "System configuration ".
F

Sel
ect "Date " or "Time ".
F

C
hoose the display formats.
F

C
hange the date and/or the time using the
numeric keypad.
F

P
ress this button to confirm.
With CITROËN Connect Nav
The date and time settings are only available
if the synchronisation with the GPS is
deactivated.
F
Sel
ect the Settings menu.
F

P
ress the " OPTIONS " button to go to the
secondary page.
F

Sel
ect the " Date" or "Time " tab.
F

S
et the time or the date using the numeric
keypad.
F

P
ress this button to confirm.Additional settings
You can choose to:
- c hange the date and time display format
(12hr / 24hr),
-

c
hange the time zone,
-

a
ctivate or deactivate the synchronisation
with the GPS (UTC).
The system does not automatically
manage the change between winter and
summer time (depending on country).
The change between winter and
summer time is done by changing the
time zone.
F

Sel

ect " Date and time ".
F

Sel

ect " Setting the time- date ".
Instruments

53
Electronic key - remote control
System which permits remote locking or unlocking
of the vehicle as well as opening the boot and,
depending on version, operation of the alarm.
It also allows the location and starting of the
vehicle as well as providing protection against
theft.Unlocking the vehicle
F Press this button.
Unlocking the vehicle and
opening the boot
The direction indicators flash for a few
seconds. The door mirror spot lamps
come on. Depending on version, the
door mirrors unfold, the welcome
lighting comes on and the alarm is
deactivated.F

M
ake a long press on this
button to unlock the vehicle
and, depending on version,
release the tailgate or open the
motorised tailgate.
F

T

o unlock the other doors and the boot,
press this button again.
The setting of selective unlocking is done in the
Driving menu.
Select " Unlock driver's door ".
Complete unlocking is activated by default.
Complete unlocking
F To unlock only the driver's door, press this button once.
Selective unlockingSettings for the motorised tailgate can be
adjusted in the Driving menu.
Motorised operation is activated by default.
A.
U

nlocking the vehicle.
B.
C

entral locking the vehicle.
C.
U

nlocking the vehicle and, depending on
version, release of the tailgate or opening
of the motorised tailgate.
The electronic key includes an integral back-up
emergency key.
2
Access

55
System that allows the unlocking, locking
and starting of the vehicle while keeping the
electronic key on your person.For reasons of safety and theft protection,
do not leave your electronic key in the
vehicle, even when you are close to it.
It is recommended that you keep it on
your person.The electronic key can also be used as
a remote control.
For more information on the Electronic
key - remote control
, refer to the
corresponding section.
Keyless Entry and Starting
Unlocking the vehicle
Complete unlocking
F With the electronic key on your person and in the recognition zone A , pass your hand
behind the door handle of one of the front
doors to unlock the vehicle or press the
tailgate opening control (located centrally).
Selective unlocking
F To unlock only the driver's door, with the electronic key on your person, pass your
hand behind the driver's door handle.
F

T
o unlock the complete vehicle, pass your
hand behind the front passenger door
handle with the electronic key close to
the passenger door, or press the tailgate
opening control with the electronic key
close to the rear of the vehicle.
Activation or deactivation of selective unlocking
is done in the Driving menu.
Select " Unlock driver's door ".
By default, complete unlocking is activated.
The direction indicators flash for a
few
seconds.
Depending on version, the door mirrors
unfold, the alarm is deactivated and the
welcome lighting comes on.
2
Access

56
Ensure that nothing could prevent the
correct operation of the windows.
Be aware of children when operating
the windows.
Locking the vehicle
F With the electronic key in the recognition zone A , press with a finger or thumb
on one of the front door handles (at the
markings) to lock the vehicle or press the
locking button on the right of the tailgate.
Maintaining pressure allows the windows to be
raised to the desired position.
It is not possible to lock the vehicle if one of the
keys is left inside the vehicle. The direction indicators come on for a
few seconds.
Depending on your version, the door
mirrors fold and the alarm is activated.
Normal locking
Deadlocking
By the doors or tailgate:
F W ith the electronic key in the recognition
zone A , press a finger or thumb on one of
the front door handles (at the markings) or
the locking control located on the right of
the tailgate to lock the vehicle.
F

W
ithin five seconds, press the door handle
or the locking control located on the right of
the tailgate again to deadlock the vehicle. Deadlocking renders the interior door
controls inoperative.
It also deactivates the manual central
control button.
Therefore, never leave anyone inside
the vehicle when it is deadlocked.
Access

57
As a safety measure (children on
board), never leave the vehicle without
taking the electronic key for the Keyless
Entry and Starting system with you,
even for a short period.
Be aware of the risk of theft when the
electronic key for the Keyless Entry and
Starting system is in one of the defined
zones with the vehicle unlocked.
If one of the doors or the boot is still
open or if the electronic key for the
Keyless Entry and Starting system has
been left inside the vehicle, the central
locking does not take place.
However, the alarm (if fitted) will be fully
activated after about 45 seconds.
In order to preserve the battery in the
electronic key and the vehicle's battery,
the "hands-free" functions are put into
long-term standby after 21 days without
use. To restore these functions, press
one of the remote control buttons or
start the engine with the electronic key
in the reader.
For more information on starting with
Keyless Entr y and Star ting, refer to
the corresponding section.
If the vehicle is unlocked by mistake
and with no action on the doors or boot,
the vehicle will lock again automatically
after about 30 seconds.
If fitted to your vehicle, the alarm will
also be reactivated automatically.
The automatic folding and unfolding
of the door mirrors can be deactivated
by a CITROËN dealer or a qualified
workshop. Accumulations (water, dust, grime,
salt...) on the inner sur face of the door
handle may affect detection.
If cleaning the inner sur face of the door
handle using a cloth does not restore
detection, contact a CITROËN dealer or
a qualified workshop.
A sudden splash of water (stream of
water, high pressure jet washer,
…)
may be identified by the system as the
desire to open the vehicle.
2
Access

58
F Turn the key towards the rear of the vehicle to lock the vehicle completely.
Deadlocking
F Turn the key towards the rear in the driver's door lock to lock the vehicle completely.
F

T
urn the key towards the rear again within
five seconds to deadlock the vehicle.
Depending on version, the direction
indicators flash for a few seconds, the
door mirrors fold.
For versions with alarm: it is not deactivated / activated when unlocking / locking the vehicle
with the integral key.
The siren will sound on opening the door with the key (integral with the remote control). It
stops when the ignition is switched on.
Emergency procedure
The integral key is used to lock and unlock the
vehicle when the electronic key cannot operate
and in the event of a fault with the Keyless
Entry and Starting system:
-

c
ell battery flat, vehicle battery discharged
or disconnected,
...
-

v
ehicle located in an area with strong
electromagnetic signals.
F

T
o extract the emergency mechanical key
from the electronic key, press button 1 and
guide the key 2 out.
The integral key is also used to deactivate/
reactivate the passenger's airbag.
It provides a backup means of locking the
passenger doors.
It also allows locking of the vehicle without
activation of the alarm.
Emergency unlocking/locking using the integral key
F Turn the key towards the front of the vehicle to unlock the vehicle.
Depending on version, the direction
indicators flash for a few seconds, the
door mirrors unfold and the welcome
lighting comes on.
For versions with alarm: the siren will
sound on opening the door with the key
(in the remote control). It stops when
the ignition is switched on.
Unlocking Normal locking
Access

59
Remote control problem -
reinitialisationChanging the battery
Following disconnection of the vehicle battery,
replacement of the remote control battery or
in the event of a remote control malfunction,
you can no longer unlock, lock or locate
your
vehicle.
F

P
lace the mechanical key (integral with
the remote control) in the lock to unlock
your
vehicle.
F

P
lace the electronic key in the reader.
F

S
witch on the ignition by pressing START/
S T O P.
The electronic key is fully operational again.
If the problem persists, contact a CITROËN
dealer or a qualified workshop as soon as
possible. Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.
Battery ref.: CR2032 / 3 volts.
Battery replacement is signalled by the display
of a message.
F

U
nclip the cover using a small screwdriver
at the cut-out.
F

L
ift off the cover.
F

R
emove the flat battery from its location.
F

F
it the new battery into its location
observing the original direction of fitment.
F

C
lip the cover onto the casing.
2
Access
