23
Accesses
READY TO SET OFF
2
HINGED REAR DOORS
When parked with the rear
doors open to 90°, the doors
mask the rear lights.
To signal your position to road
users travelling in the same
direction who may not have
noticed that you have stopped,
use a warning triangle or any
other device stipulated by the
legislation and regulations of
your country.
TAILGATE
From the outside
The two hinged doors open to 90°.
To open, pull the handle towards you then
pull the lever to open the left-hand door.
To close, start with the left-hand door then
close the right-hand door.
Opening to 180°
A retractable check strap system permits
extension of the opening from 90° to 180°.
Disengage the check strap towards you
when the door is partially open.
The check strap will re-attach automatically
on closing. From the outside
If fitted on your vehicle, locking/unlocking is
via the remote control.
To open, press the control then raise the
tailgate.
A strap is provided to secure the tailgate in
the upper position.
From inside
Emergency control
In the event of a central unlocking operating
fault, this permits unlocking of the tailgate
from the inside.
Fold the rear seats to gain access to the lock.
Insert a small screwdriver in this opening to
unlock the tailgate.
Page 131 of 194
131
Rear suspension
IN-CAR TECHNOLOGY
4
Metal suspension
This equipment adopts long movement limiters
which make it possible to guarantee stable
behaviour both when loaded and when empty.
No action on your part is required except to
ensure that maintenance is carried out and that
the authorised loads are complied with. irrespective of the weight of the load, within
the limit of the authorised values. On board,
the increasing or lightening of the load on
the vehicle's platform is detected by two
height sensors. When all of the doors are
closed, the sensors trigger the automatic
compensation and determine the optimum
height of the sill for the vehicle's driving
conditions.
Deactivation of the automatic correction
The control which permits deactivation of the
automatic control is located on the right-hand
side, at the rear of the vehicle.
REAR SUSPENSION
Two types of suspension are offered.
You must deactivate the automatic
correction manually in the following
situations:
- when working underneath the vehicle,
- when changing a wheel,
- when the vehicle is being transported by lorry, train, ferry, boat, ...
Rear suspension with pneumatic
compensation
If fitted on your vehicle, this type of
suspension regulates the variations in the
height of the rear platform of your vehicle Two functions
1. Automatic
correction
2. Manual
correction
1 - Automatic correction of the height of the rear sill
The pneumatic suspension automatically
regulates the variations in the height of the
rear platform of your vehicle.
The automatic compensation is temporarily
inactive:
- if a door/the tailgate is open,
- when braking or when stopped at a red light (brake pedal pressed). With the vehicle stationary:
- press and hold,
- release the control.
Deactivation is confirmed by
the diode which is lit. It remains lit for
approximately 30 seconds.
Return to automatic correction
With the vehicle stationary:
- press and hold,
- release the control.
Return to automatic correction is
confirmed by the diode which is switched off.
According to the configurations, a bleep may
be heard during these operations.
A red warning light on your
i n s t r u m e n t p a n e l fl a s h e s i f t h e
height is not at its optimum level and
requires correction, drive slowly until
this warning light is switched off.
Page 176 of 194
174
Changing a bulb
THIRD BRAKE LIGHT
Type A, W 5 W - 5 W
Type B, P 2 1 W - 2 1 W
NUMBER PLATE LIGHTS
Type A, W 5 W - 5 W
With tailgate
- M o v e a s i d e t h e p l a s t i c l e n s u s i n g a s c r e w d r i v e r , o n t h e p o i n t i n d i c a t e d b y
t h e a r r o w .
- C h a n g e t h e b u l b .
- R e p l a c e t h e p l a s t i c l e n s a n d p r e s s o n i t .
With hinged doors
- U n c l i p t h e i n t e r i o r t r i m .
- D i s c o n n e c t t h e c o n n e c t o r b y m o v i n g a s i d e i t s t a b .
- R e m o v e t h e p l a s t i c c o v e r .
- T u r n t h e b u l b h o l d e r a q u a r t e r t u r n a n t i c l o c k w i s e .
- C h a n g e t h e b u l b . Light located on the outside (hinged doors)
- U n s c r e w t h e t w o s c r e w s u s i n g a T o r x
TM
s c r e w d r i v e r w i t h 2 0 s o c k e t .
- R e m o v e t h e l i g h t .
- C h a n g e t h e b u l b . Light located on the inside (tailgate)
- U n s c r e w t h e t w o s c r e w s u s i n g a T o r x
TM
s c r e w d r i v e r w i t h 2 0 s o c k e t .
- R e m o v e t h e p l a s t i c c o v e r .
- R e m o v e t h e b u l b h o l d e r m o v i n g a s i d e t h e t w o t a b s .
- R e m o v e t h e f a u l t y b u l b b y p r e s s i n g i t l i g h t l y w h i l e t u r n i n g i t a n t i c l o c k w i s e .
- C h a n g e t h e b u l b .
