DACIA DUSTER 2016 1.G Owners Manual

JauneNoir Noir texte
5.43
ENG_UD32194_1
Prééquipement radio (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
Location for front speaker 2
or rear speaker 3
Unclip the cover using a flat-blade
screwdriver or similar.
FITTED AUDIO EQUIPMENT
Radio location 1
If your vehicle is not fitted with an audio
system, one can be fitted and locations
have been provided for:
– the radio 1;
– front speakers 2;
– rear speakers 3.
To install any equipment, please con-
sult an approved dealer.
Unclip and remove storage compart-
ment 1.
– In all cases, it is very important to follow the manufacturer’s instructions care-
fully.
– The specifications of the brackets and wires (available from our network)
vary depending on the equipment level of your vehicle and the type of radio.
Consult an authorised dealer to find out the correct part number.
– No work may be carried out on the vehicle’s electrical or radio circuits, except
by approved Dealers: an incorrectly connected system may result in damage
being caused to the electrical equipment and/or the components connected to
it.
1
2
3

JauneNoir Noir texte
5.44
ENG_UD32195_1
Accessoires VT (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
ACCESSORIES
Electrical and electronic accessoriesBefore installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, posi-
tion of the aerial, etc.), make sure it is compatible with your vehicle. Consult an authorised dealer. Connect accessories
with a maximum power of 120 Watts only. Fire hazard.
No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected
system may result in damage being caused to the electrical equipment and/or the components connected to it. In the case of
subsequent fitting of electrical equipment, ensure that it is properly protected by a fuse. Establish the rating and position of
this fuse.
Use of transmission/receiving devices (telephones, CB equipment etc.).Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the
vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform
to the legislation in force concerning the use of such equipment.
Fitting after-market accessoriesIf you wish to install accessories on the vehicle: please contact an authorised dealer. Furthermore, to ensure the correct opera-
tion of your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for
your vehicle, which are the only accessories for which the manufacturer will provide a warranty. If you are using an anti-theft
device, only attach it to the brake pedal.
Obstructions to the driverOn the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regu-
larly. Do not lay one mat on top of another. There is a risk of wedging the pedals.
Special features of LPG versionsCertain LPG versions are not compatible with towbars. Please contact an authorised dealer before attempting any installation.
Furthermore, to ensure the correct operation of your vehicle, and to avoid any risk to your safety, we recommend that you use
only accessories specifically designed for your vehicle, which are the only accessories for which the manufacturer will provide
a warranty. Any work on or modification to the LPG system which is not authorised by the car manufacturer is strictly forbidden,
and if this is necessary it must be carried out by qualified personnel from an authorised dealer.

JauneNoir Noir texte
5.45
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (1/5)
The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact
an approved dealer as soon as possible.
The starter is activated POSSIBLE CAUSES WHAT TO DO
Warning lights dim or fail to come on;
the starter does not run.Battery terminals disconnected,
oxidised or incorrectly secured.Retighten them, reconnect them or clean
them if they are oxidised.
Battery discharged or worn.Connect another battery to the faulty bat-
tery. Refer to the information on “Battery:
troubleshooting” in Section 5 or replace the
battery if necessary.
Do not push the vehicle if the steering
column is locked.
The engine will not start. Starting conditions are not fulfilled.Refer to the information on “Starting/stop-
ping the engine in Section 2.
The steering column remains locked. Steering wheel locked. To unlock, gently move the key and the
steering wheel (refer to the information on
the “Ignition switch” in Section 2).

JauneNoir Noir texte
5.46
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (2/5)
On the road POSSIBLE CAUSES WHAT TO DO
Vibrations. Tyres not inflated to correct pres-
sures, incorrectly balanced or
damaged.Check the tyre pressures; if this is not the cause, have
their condition checked by an approved dealer.
Coolant boiling in the coolant
reservoir.Mechanical fault: cylinder head
gasket damaged, faulty coolant
pump.Stop the engine.
Contact an approved dealer.
Engine cooling fan not working. Contact an approved dealer.
Smoke under the bonnet.Short circuit or cooling system
leak.Stop, switch off the ignition, move away from the vehi-
cle and contact an approved dealer.
The oil pressure warning light
comes on:
on a bend or under braking The engine oil level is too low. Top up the engine oil level (refer to the information on
“Engine oil level: topping up/filling” in Section 4).
at idle speed Low oil pressure. Go to your nearest approved dealer.
The oil pressure warning
light takes a long time to
go out or remains lit during
acceleration.Loss of oil pressure. Stop the vehicle: contact an approved dealer.

JauneNoir Noir texte
5.47
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (3/5)
On the road POSSIBLE CAUSES WHAT TO DO
Abnormal white smoke from the ex-
haustMechanical fault: damaged cylinder
head gasket.
orStop the engine.
Contact an approved dealer.
This is not necessarily a fault.
Smoke may be caused by
regeneration of the particle filter.Please refer to the information on “Special
features of diesel versions” in Section 2.
The power-assisted steering be-
comes heavy.Belt broken. Have the belt replaced.
No power-assisted steering oil For maintenance operations on the power-
assisted steering, contact an authorised
dealer.
The “2WD” mode and electronic fault
warning lights come on.Fault in the 4-wheel drive system.Drive as soon as possible at a moderate
speed to an approved dealer. The problem
may be resolved by replacing the wheels.
The system will not switch to “2WD”
or “4WD Lock” mode. “AUTO” mode
remains active.Fault in the 4-wheel drive system.Contact an approved dealer as soon as
possible.

JauneNoir Noir texte
5.48
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (4/5)
Radiator: If there is a significant lack of coolant, remember that it must never be topped up using cold coolant while
the engine is very warm. After any procedure on the vehicle which has involved even partial draining of the cooling
system, it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved
by the Technical Department may be used for this purpose.
On the road POSSIBLE CAUSES WHAT TO DO
Whistling Roof aerial poorly positioned. Position the aerial.
The engine overheats. The coolant
temperature indicator light comes
on.Engine cooling fan not working. Stop the vehicle, switch off the engine and
contact an approved dealer.
Coolant leaks. Stop the vehicle, switch off the engine and
check the coolant reservoir: it should con-
tain fluid. If there is no coolant, consult an
approved dealer as soon as possible.
The oil change warning light remains
lit after an oil change.Warning not reset after oil change.Reset the warning after changing the oil;
refer to the information in the paragraph on
the “On-board computer” in Section 1.

JauneNoir Noir texte
5.49
ENG_UD32196_1
Anomalies de fonctionnement (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5
OPERATING FAULTS (5/5)
Electrical equipment POSSIBLE CAUSES WHAT TO DO
The wipers do not work. Wiper blades stuck. Free the blades before using the wipers.
Faulty electrical circuit. Consult an approved dealer.
The wiper does not stop. Faulty electrical controls. Consult an approved dealer.
Direction indicators flashing more
quickly.Blown bulb. Replace the bulb.
The direction indicators do not work. Faulty electrical circuit. Consult an approved dealer.
The headlights do not switch on or off. Faulty electrical circuit or control. Consult an approved dealer
Traces of condensation in the lights. This is not a fault. Traces of condensa-
tion are a natural phenomenon caused
by variations in temperature.
The traces will disappear slowly once the
lights are switched on.

JauneNoir Noir texte
5.50
ENG_UD35403_1
Filler NU (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_5

JauneNoir Noir texte
6.1
ENG_UD39332_8
Sommaire 6 (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_6
Section 6: Technical specifications
Vehicle identification plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2
Engine identification plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.3
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.5
Engine specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.6
Weights/Towing weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.7
Replacement parts and repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.8
Service sheets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.9
Anticorrosion check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.15

JauneNoir Noir texte
6.2
ENG_UD34151_2
Plaques d’identification véhicule (H79 - H79 Ph2 - H79 Nissan - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_6
Quote the details given on identifica-
tion plate A on all letters or orders.
VEHICLE IDENTIFICATION PLATE
Vehicle identification plate A
The presence and location of the infor-
mation depends on the vehicle.
1 Manufacturer name.
2 EC design number or approval
number.
3 Identification number.
4 MAM (Maximum Authorised
Mass). 5 GTW (Gross train weight: vehicle
fully loaded, with trailer).
6 MPAW (Maximim Permissible
Weight) for front axle.
7 MPAW on rear axle.
8 Reserved for related or additional
entries.
9 Diesel exhaust emissions.
10 Paint reference (colour code).
A
1
2
3
4
5
6
7
8
9
10
A
