DAEWOO LACETTI 2004  Service Repair Manual SECTION : 9P
DOORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical te

Page 2422 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 9P – 2IDOORS
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATION
ApplicationNSmLb–FtLb–In
Door Hinge–to–Body Bolts3627–
Door Hinge–to–Door Bolts2015–
Door Hold–Open

Page 2423 of 2643

DAEWOO LACETTI 2004  Service Repair Manual DOORS  9P – 3
DAEWOO V–121 BL4
SCHEMATIC AND ROUTING DIAGRAMS
POWER DOOR LOCKS CIRCUIT

Page 2424 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 9P – 4IDOORS
DAEWOO V–121 BL4
POWER WINDOWS CIRCUIT (FRONT ONLY)

Page 2425 of 2643

DAEWOO LACETTI 2004  Service Repair Manual DOORS  9P – 5
DAEWOO V–121 BL4
POWER WINDOWS CIRCUIT (FRONT AND REAR)

Page 2426 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 9P – 6IDOORS
DAEWOO V–121 BL4
DIAGNOSIS
POWER WINDOWS
System With Only Front Power Windows, One or Both Windows
are Inoperative
CAUTION : When powering the window motors directly from a battery wi

Page 2427 of 2643

DAEWOO LACETTI 2004  Service Repair Manual DOORS  9P – 7
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
11With the power window relay still removed,
use an ohmmeter to check the resistance be-
tween ground and terminal 86 of the power
window

Page 2428 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 9P – 8IDOORS
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
181.  Remove the trim panel from a door which
has an inoperative power window.
2.  Move a vehicle battery close enough to the
door so that

Page 2429 of 2643

DAEWOO LACETTI 2004  Service Repair Manual DOORS  9P – 9
DAEWOO V–121 BL4
System With Front and Rear Power Windows, One or Both Front
Windows are Inoperative
CAUTION : When powering the window motors directly from a battery with jumper wir

Page 2430 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 9P – 10IDOORS
DAEWOO V–121 BL4
StepNo Yes Value(s) Action
11With the power window relay still removed,
use an ohmmeter to check the resistance be-
tween ground and terminal 85 of the power
window
