DAEWOO LACETTI 2004 Service Repair Manual

DOORS 9P – 21
DAEWOO V–121 BL4
Installation Procedure
1. Install the door seal trim.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the door trim panel. Refer to Section 9G,
Interior Trim.
DOOR LOCK STRIKER
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the screws and the door lock striker.
(Front door shown, rear door similar.)
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the screws and the door lock striker.
Tighten
Tighten the door lock striker screws to 24 NSm (18 lb–
ft).

9P – 22IDOORS
DAEWOO V–121 BL4
DOOR LOCK STRIKER ADJUSTMENT
(Front Door Shown, Rear Door Similar)
The door lock striker consists of a striker with two screws
that are threaded into a tapped, floating cage plate located
in the appropriate body pillar. This floating cage plate al-
lows the striker to be easily adjusted in and out or up and
down.
The door is secured in the closed position when the door
lock fork snaps over and engages the striker.
Notice : The door lock striker is an important attaching
part that can affect the performance of vital components
and systems. It can cause major repair expenses. If re-
placement becomes necessary, the door lock striker must
be replaced by one with the same part number or with an
equivalent. Do not use a replacement part of lesser quality
or of a substitute design. The specified torque values must
be used during reassembly to ensure the proper retention
of the part.
Up/Down or In/Out Adjustment
An adjustment of the striker in the up and down or in and
out directions may be necessary for a number of reasons:
S Vehicle frame damage as the result of a collision.
S Installation of new door weatherstripping.
S Customer complaints of excessive windnoise.
S Difficulty in opening or closing the door.
To adjust the door striker in an up and down or in and out
direction, perform the following procedure:
1. The door must be properly aligned.
2. Loosen the striker screws.
3. The floating cage plate can be moved slightly using
the ends of the striker screws. Move the floating
cage plate to the desired position.
4. If proper adjustment requires that the floating cage
plate be moved more than is possible, use an elec-
tric hand drill and a 3/8–inch rotary file bit with a flat
head to enlarge the body opening in the direction
required.
Notice : It is important to use a flat–tipped drill bit to pre-
vent damage to the tapped floating cage plate. The striker
screws and the tapped floating cage plate are important
attaching parts that could affect the performance of vital
components and systems.
5. Tighten the door lock striker screws to the correct
position.
Tighten
Tighten the door lock striker screws to 24 NSm (18 lb–
ft).

DOORS 9P – 23
DAEWOO V–121 BL4
FRONT DOOR LOCK
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the seal trim. Refer to ”Door Seal Trim” in
this section.
3. Remove the screws and the front door lock.
4. Disconnect the lock rods.
5. Disconnect the electrical connector.
Installation Procedure
1. Connect the electrical connector.
2. Connect the lock rods.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
3. Install the front door lock with the screws.
Tighten
Tighten the front door lock screws to 8 NSm (71 lb–in).
4. Install the seal trim. Refer to ”Door Seal Trim” in
this section.
5. Connect the negative battery cable.
CHILDPROOF REAR DOOR LOCK
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the door seal trim. Refer to ”Door Seal
Trim” in this section.
3. Remove the rear sash inside door.
4. Remove the door lock screws.
5. Disconnect the lock rods.
6. Remove the door lock.
7. Disconnect the electrical connector.
Installation Procedure
1. Connect the electrical connector.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the rear door lock with the screws.
Tighten
Tighten the rear door lock screws to 8 NSm (71 lb–in).
3. Install the lock rods.
4. Installation the rear sash inside door.
5. Install the door seal trim. Refer to ”Door Seal Trim”
in this section.
6. Connect the negative battery cable.

9P – 24IDOORS
DAEWOO V–121 BL4
INSIDE DOOR HANDLE
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the door trim. Refer to Section 9G, Interi-
or Trim.
2. Remove the tweeter speaker (if it is equiped) and
the screw.
3. Slide the door handle forward and remove it from
the door.
4. Disconnect the inside door handle and the lock
rods.
Installation Procedure
1. Connect the inside door handle and the lock rods.
2. Insert the inside door handle into the slots in the
door.
3. Slide the door handle rearward.
4. Install the inside door handle screw.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
5. Install the door seal trim. Refer to Section 9G, Inte-
rior Trim.
OUTSIDE DOOR HANDLE
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the door seal trim. Refer to ”Door Seal
Trim” in this section.
2. Disconnect the outside door handle and the lock
rods.
3. Remove the bolts and the door handle.
Installation Procedure
1. Connect the outside door handle and the lock rods.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. Install the door handle with the bolts.
Tighten
Tighten the outside door handle bolts to 4.5 NSm (40
lb–in).
3. Install the door seal trim. Refer to ”Door Seal Trim”
in this section.

DOORS 9P – 25
DAEWOO V–121 BL4
INSIDE LOCK ROD
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the door seal trim. Refer to ”Door Seal
Trim” in this section.
2. Remove the inside door handle. Refer to ”Inside
Door Handle” in this section.
3. Disconnect the inside lock rods from the lock.
Installation Procedure
1. Connect the inside lock rods to the lock.
2. Install the inside door handle. Refer to ”Inside Door
Handle” this section.
3. Install the door seal trim. Refer to ”Door Inside
Trim” in this section.
DOOR LOCK CYLINDER
(Front Door Shown)
Removal Procedure
1. Remove the door seal trim. Refer to ”Door Seal
Trim” in this section.
2. Disconnect the outside door handle lock rod.
3. Remove the bolt and the lock cylinder.
Installation Procedure
1. Install the lock cylinder with the bolt.
Tighten
Tighten the outside door handle bolt to 4.5 NSm (40
lb–in).
2. Connect the outside door handle lock rod.
3. Install the door seal trim. Refer to ”Door Seal Trim”
in this section.

9P – 26IDOORS
DAEWOO V–121 BL4
POWER WINDOW REGULATOR
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the door glass. Refer to Section 9L, Glass
and Mirrors.
3. Disconnect the electrical connector.
4. Remove the nuts and the window regulator.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the window regulator with the nuts.
Tighten
Tighten the window regulator nuts to 8 NSm (71 lb–in).
2. Connect the electrical connector.
3. Install the door glass. Refer to Section 9L, Glass
and Mirrors.
4. Connect the negative battery cable.
DOOR ASSEMBLY
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the bolt and the door hold–open link from
the body.
3. With the aid of another technician, remove the door
hinge bolts and the front door. (Front door shown,
rear door similar.)
4. Disconnect the body–to–door rubber grommet and
the electrical connector.

DOORS 9P – 27
DAEWOO V–121 BL4
Installation Procedure
1. Connect the electrical connector and the body–to-
door rubber grommet.
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
2. With the aid of another technician, lightly secure the
front door with the door hinge bolts. (Front door
shown, rear door similar.)
3. Adjust the door for proper fit.
Tighten
Tighten the door hinge–to–body bolts to 20 NSm (15
lb–ft).
4. Install the door hold–open link to the body with the
Tighten
Tighten the door hold–open link–to–body bolt to 25
N·m (18 lb–ft).
5. Connect the negative battery cable.
6. Perform the waterleak test. Refer to Section 9I,
Waterleaks.
7. Check for windnoise. Refer to Section 9J, Wind-
noise.
DOOR HINGE
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. With the aid of another technician, remove the bolts
and the hinge from the door and the body.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. With the aid of another technician, install the hinge
to the door and the body with the bolts.
Tighten
Tighten the door hinge–to–body bolts to 20 NSm (15
lb–ft)
Tighten the door hinge–to–door bolts to 20 NSm (15
lb–ft).

9P – 28IDOORS
DAEWOO V–121 BL4
DOOR HOLD–OPEN LINK
(Front Door Shown, Rear Door Similar)
Removal Procedure
1. Remove the door seal trim. Refer to ”Door Seal
Trim” in this section.
2. Remove the bolts on the door and on the body.
3. Remove the door hold–open link.
Installation Procedure
Notice : Dissimilar metals in direct contact with each other
may corrode rapidly. Make sure to use the correct fasten-
ers to prevent premature corrosion.
1. Install the door hold–open link to the door and the
body with the bolts.
Tighten
Tighten the door hold–open link–to–body bolt to 25
NSm (18 lb–ft).
Tighten the door hold–open link–to–door bolts to 9
NSm (80 lb–in).
2. Install the door seal trim. Refer to ”Door Seal Trim”
in this section.

DOORS 9P – 29
DAEWOO V–121 BL4
GENERAL DESCRIPTION
AND SYSTEM OPERATION
DOOR LOCK STRIKER
The front and the rear door lock strikers each consist of a
striker with two screws threaded into a floating cage plate
in the B–pillars and the C–pillars. The door is secured in
the closed position when the door lock fork snaps over and
engages the striker.
CHILDPROOF REAR DOOR LOCK
The childproof rear door locks help prevent passengers,
especially children, from opening the rear doors of the ve-
hicle from the inside.
To activate the locks, move the levers of both rear doors
to the lock position. Then, close both doors. The rear pas-
sengers will be unable to open the doors from inside of the
vehicle.
To deactivate the locks, unlock the door from the inside of
the vehicle and open the door from the outside. Move the
lever to the unlock position. The rear door will now work
normally.
POWER DOOR LOCKS
The power door locks use a solenoid that is contained in
each door lock assembly. The door locks are activated by
the actuator on the inside door handle or by the lock cylin-
der on the driver’s side door only. When the driver’s side
door is locked or unlocked by the actuator or the lock cylin-
der, all doors are locked or unlocked accordingly.
POWER WINDOWS
The power windows are controlled by electrical switches
on the door panels and are operated by a motor at each
window regulator. Each door has a switch to control its
window, and the driver’s side door has four switches to
control all door windows on the vehicle. The windows are
lowered by pressing the switch and raised by pulling up on
the switch. The window will stop movement when the
switch is released or when the window is completely open
or closed.
The driver’s side window opens automatically. By pressing
and releasing the switch, the driver ’s side window will low-
er and will stop only when the switch is activated again, or
when the window is completely open.
The driver’s side door control also contains a window lock
button that will prevent the operation of the front passen-
ger door or the rear door windows when pressed.

SECTION : 9Q
ROOF
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9Q–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 9Q–2. . . . . . . . . . .
SPECIAL TOOLS9Q–2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools Table 9Q–2. . . . . . . . . . . . . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9Q–3 . . . . .
Power Sunroof System 9Q–3. . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS9Q–4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sunroof 9Q–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9Q–6 . . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9Q–6. . . . . . . . . . . . . . . . . . . . .
Power Sunroof 9Q–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun Shade 9Q–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sunroof Glass 9Q–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Formed Headliner 9Q–8. . . . . . . . . . . . . . . . . . . . . . . . .
Sun Visors with Vanity Mirror 9Q–10. . . . . . . . . . . . . . .
Passenger Assist Handles 9Q–10. . . . . . . . . . . . . . . . .
Power Sunroof Control Switch 9Q–11. . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9Q–12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Roof 9Q–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Sunroof/Sunroof Control Switch 9Q–12. . . . . .
Sun Visors with Vanity Mirror 9Q–12. . . . . . . . . . . . . . .
Passenger Assist Handles 9Q–12. . . . . . . . . . . . . . . . .
Coat Hooks 9Q–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
