DAEWOO MATIZ 2003 Service Repair Manual

IMMOBILIZER ANTI-THEFT SYSTEM 9T–29
DAEWOO M–150 BL2
D29T004
Installation Procedure
After replacing the immobilizer control unit, the keys
must be re-authorized using the key coding procedure.
Refer to “Key Coding Procedure” in this section. Also,
the electronic control module (ECM) identification (ID)
code must be reset. Refer to “Identification (ID) Code
Reprogramming” in this section.
1. Connect the electrical connectors to the immobilizer
control unit.
2. Slide the immobilizer control unit onto its mounting
bracket.
D105A505
3. Install the steering column covers. Refer to Section
6E, Steering Wheel and Column.
4. Connect the negative battery cable.

9T–30 IMMOBILIZER ANTI-THEFT SYSTEM
DAEWOO M–150 BL2
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS

Application

Nm

Lb-Ft

Lb-In
Immobilizer Control Unit Mounting Bolts4–35

IMMOBILIZER ANTI-THEFT SYSTEM 9T–31
DAEWOO M–150 BL2
SCHEMATIC AND ROUTING DIAGRAMS
D19T001B
IMMOBILIZER ANTI-THEFT SYSTEM

9T–32 IMMOBILIZER ANTI-THEFT SYSTEM
DAEWOO M–150 BL2
SCHEMATIC AND ROUTING DIAGRAMS
D209T001
REMOTE KEYLESS ENTRY AND IMMOBILIZER ANTI-THEFT SYSTEM
