8B–74 SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO M-150 BL2
D110B010
AIRBAG MODULE DEPLOYMENT
(IN VEHICLE)
(Left–Hand Drive Shown, Right–Hand
Drive Similar)
Deploy the airbags before disposing of them. This in-
cludes those in a whole vehicle being scrapped.
If the vehicle is still within the warranty period, contact
the Daewoo regional service manager for approval or
special instructions before deploying the airbag mod-
ules.
Caution: Before deploying the airbags, remove all
loose objects from the airbags expansion area.
Caution: Deploy the airbags with the vehicle doors
closed and the side windows open.
Caution: Deploy the airbags only in an evacuated
area. Service personnel who must be present dur-
ing the deployment should be at least 10 meters
(33 feet) in front of the vehicle.
Caution: Do not connect the voltage source until af-
ter having completed all other preparations for the
deployment of the airbags.
Caution: Allow a deployed airbag module to cool
for at least 30 minutes before handling.
Caution: Wear the gloves and the eye protectors
during the disposal process.
Caution: If the deployment fails, disconnect the volt-
age source and wait 5 minutes before approaching
the vehicle.
Deployment Procedure
1. Disconnect both battery cables and place the battery
at least 10 meters (32.8 feet) from the vehicle.
Caution: Wait 1 minute after disconnecting both
battery cables to allow the capacitor inside the
sensing and diagnostic module (SDM) to discharge
before taking any other action. The capacitor sup-
plies the reserve power to deploy the airbags, even
if the battery is disconnected. Unintentional deploy-
ment of the airbags can cause injury.
2. Remove the lower cover from the steering column.
3. At the lower steering column, cut the two wires lead-
ing from the supplemental inflatable restraint (SIR)
harness to the clock spring.
4. Strip 13 mm (0.5 inch) of insulation from the ends of
the wires leading to the clock spring.
5. Use two additional wires, each at least 10 meters
(33 feet) long, to reach from the deployment battery
to the airbag module.
6. Strip 13 mm (0.5 inch) of insulation from the ends of
these two additional wires.
7. Twist the two wires together at one end.

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B–75
DAEWOO M-150 BL2
D110B011A
8. Place the twisted ends of the two wires near the de-
ployment battery. Do not connect the wires to the
battery at this time.
9. Using the free ends of the 10 meters (33 feet) wires
leading to the clock spring, make two splices, one at
each wire from the airbag module.
10. Wrap the splices with insulating tape.
11. Now that the free ends of the 10 meters (33 feet)
wires are spliced to the airbag module wires, and the
ends that are twisted together are near the deploy-
ment battery, clear the area.
12. Untwist the wires that are near the deployment
battery.
13. Touch one wire to the positive battery terminal and
touch the other wire to the negative battery terminal.
The airbag will deploy.
14. Repeat the procedure for the passenger airbag,
cutting the wires to the passenger airbag module
instead of the wires leading to the clock spring.
15. Strip 13 mm (0.5 inch) of insulation from the ends of
the wires leading to the passenger airbag module.
16. Use two additional wires, each at least 10 meters
(33 feet) long, to reach from the deployment battery
to the passenger airbag module.
17. Strip 13 mm (0.5 inch) of insulation from the ends of
these two additional wires.
18. Twist the two wires together at one end.
19. Place the twisted ends of the two wires near the de-
ployment battery. Do not connect the wires to the
battery at this time.
20. Using the free ends of the 10 meter (33 feet) wires to
the passenger airbag module, make two splices,
one at each wire from the airbag module.
21. Wrap the splices with insulating tape.
22. Now that the free ends of the 10 meters (33 feet)
wires are spliced to the passenger airbag module
wires, and the ends that are twisted together are
near the deployment battery, clear the area.
23. Untwist the wires that are near the deployment
battery.
24. Touch one wire to the positive battery terminal and
touch the other wire to the negative battery terminal.
The passenger airbag will deploy.
25. Using the proper precautions, dispose of the
deployed airbag. Refer to “Deployed Airbag Module
Disposal Procedure” in this section.

8B–76 SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO M-150 BL2
AIRBAG MODULE DEPLOYMENT
(OUTSIDE OF VEHICLE)
Deploy all intact airbag modules that have been

Removed from a scrapped vehicle.

Found to be defective.

Found to have been damaged during transit, storage,
or service.
Caution: Deploy the airbags only in an evacuated
area. Service personnel who must be present dur-
ing the deployment should be at least 10 meters
(33 feet) in front of the vehicle.
Caution: Do not connect the voltage source until
completing all other preparations for the deploy-
ment of the airbags.
Caution: Allow a deployed airbag module to cool
for at least 30 minutes before removing it from the
vehicle.
Caution: Wear gloves and eye protection during the
disposal process.
Caution: If the deployment fails, disconnect the volt-
age source and wait 5 minutes before approaching
the vehicle.
1. Position the airbag module face up, on flat ground
outdoors, at least 10 meters (33 feet) from any ob-
stacles or people.
2. Place a vehicle battery at least 10 meters (33 feet)
away from the airbag module.
3. Deploy the airbag module using the deployment tool.
4. Using the proper precautions, dispose of the
deployed airbag. Refer to “Deployed Airbag Module
Disposal Procedure” in this section.
DEPLOYED AIRBAG MODULE
DISPOSAL PROCEDURE
Caution: After an airbag module has been
deployed, the surface of the airbag may contain a
powdery residue. The powder lubricates the airbag
as it inflates. The dust that is produced as a by-
product of the deployment is unlikely to be harmful,
but use the gloves and the safety glasses in order to
prevent any possible irritation of the skin and the
eyes.
Caution: After deployment, the metal surfaces of
the airbag module will be hot. In order to avoid the
risk of an injury or a fire, do not place the deployed
airbag modules near any flammable objects, and al-
low the airbag modules to cool for 30 minutes be-
fore handling them.
Deploy an airbag before disposing of it. This includes
those in a whole vehicle being scrapped.

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B–77
DAEWOO M-150 BL2
D110B012
If the vehicle is still within the warranty period, contact
the Daewoo regional service manager for approval or
special instructions before deploying an airbag module.
Deployed airbag modules should be disposed of in the
same manner as any other scrap parts, with the addition
of the following steps:
1. Place the deployed airbag in a sturdy plastic bag.
2. Seal the plastic bag securely.
3. Wash your hands and rinse them with water after
handling a deployed airbag.

8B–78 SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO M-150 BL2
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application Nm Lb-Ft Lb-In Clock Spring Mounting Screws 3 – 27
Driver Airbag Module Mounting Bolts

15

11

–
Passenger Airbag Module Mounting Nuts

10

–

89
Passenger Airbag Module Mounting Bolts 15 11 –
Sensing and Diagnostic Module Mounting Bolts 15 11 –
SPECIAL TOOLS AND EQUIPMENT
SPECIAL TOOLS TABLE
D102F101
Scan Tool
D110B101
DS 401
Torx Bolt Wrench

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B–79
DAEWOO M-150 BL2
SCHEMATIC AND ROUTING DIAGRAMS
SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
ELECTRICAL SCHEMATIC
D1AB201B

DAEWOO M-150 BL2
SECTION 9A
BODY WIRING SYSTEM
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in B unless otherwise
noted.
TABLE OF CONTENTS
Description and Operation 9A-2. . . . . . . . . . . . . . . . . .
How to Read Electrical Wiring Diagram 9A-2. . . . . . .
How to Check Terminal Number of Connector 9A-4.
Special Tools and Equipment 9A-5. . . . . . . . . . . . . . .
Special Tools Table 9A-5. . . . . . . . . . . . . . . . . . . . . . . .
Schematic and Routing Diagrams 9A-6. . . . . . . . . . .
Wire Color Chart 9A-6. . . . . . . . . . . . . . . . . . . . . . . . . .
Power Distribution Schematic 9A-7. . . . . . . . . . . . . . .
Relay & Fuse Box Locator (Engine Room) 9A-8. . . .
Fuse Box Locator
(Passenger Compartment) 9A-9. . . . . . . . . . . . . . . . Fuse Chart 9A-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Harness Routing 9A-11. . . . . . . . . . . . . . . . . . . .
Engine Harness Routing 9A-12. . . . . . . . . . . . . . . . . . .
Instrument Harness Routing 9A-14. . . . . . . . . . . . . . .
Airbag Harness Routing 9A-16. . . . . . . . . . . . . . . . . . .
Body Harness Routing 9A-17. . . . . . . . . . . . . . . . . . . .
Front Door Harness Routing 9A-19. . . . . . . . . . . . . . .
Rear Door Harness Routing 9A-20. . . . . . . . . . . . . . . .
Tailgate Harness Routing 9A-21. . . . . . . . . . . . . . . . . .

9A – 2 BODY WIRING SYSTEM
DAEWOO M-150 BL2
DESCRIPTION AND OPERATION
HOW TO READ ELECTRICAL WIRING DIAGRAM
D111001A

BODY WIRING SYSTEM 9A–3
DAEWOO M-150 BL2
Contents of Electrical Wiring Diagram
PositionExplanation
A
–The box above the fuse box: Power supply lines
–Power supply lines: 30, 15, 15A, Ka, 58, 50
–Refer to “Circuit Identification Symbol” in this section for more details.
B
–Ef10 or F3: Fuse Number

Ef10: Fuse No 10 in the engine room fuse box

F3: Fuse No 3 in the passenger room fuse box
–40A: Fuse Capacity
–Refer to “Relay Box Locator” and “Fuse Box Locator” in this section.
C
–Connector
–Connector No C202, terminal No 10
–Refer to “How to Check Terminal Number of Connect” in this section
D–Internal circuit of component (Relay)
(Component Name, Terminal Number)
E–Internal circuit of component (Switch)
(Terminal Number)
F–Wiring Harness Color
–Refer to “Wire Color Chart” in this section
G
–Ground line.
–G402: Ground Position
–In case of the ground numberless, this means the body ground.
Circuit Identification Symbol
Identification SymbolMeaning
CConnector
EfFuse in engine room fuse box
FFuse in passenger compartment fuse box
GGround

9A–4 BODY WIRING SYSTEM
DAEWOO M-150 BL2
HOW TO CHECK TERMINAL NUMBER OF CONNECTOR
Terminal number is given based on female terminal connector.
Example: Terminal number 4 of 6 pin connection.
D111002A
