GENERAL ENGINE INFORMATION 1A–3
DAEWOO M-150 BL2
COMPONENT LOCATOR
ENGINE COMPARTMENT (TYPICAL)
(Left–Hand Drive Shown, Right–Hand Drive Similar)
D102A401
1 Power Steering Oil Reservoir
2 Coolant Reservoir
3 Canister
4 Canister Solenoid
5 Manifold Absolute Pressure (MAP) Sensor
6 Intake Manifold
7 Ignition Coil
8 Idle Air Control (IAC) Valve
9 Throttle Position (TP) Sensor
10 Throttle Body
11 Brake Fluid Reservoir
12 Wiper Motor13 Battery
14 Fuse Box
15 Air Cleaner Housing
16 Resonator
17 PCV Hose
18 Distributor
19 Exhaust Manifold
20 Snorkel
21 Engine
22 Washer Fluid Reservoir
23 Oil Level Gauge
24 Oil Filler Cap

1A–4 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
ENGINE COMPARTMENT (EURO III)
(Left–Hand Drive Shown, Right–Hand Drive Similar)
MAA1A010
1 Power Steering Oil Reservoir
2 Coolant Reservoir
3 Canister Purge Solenoid
4 Manifold Absolute Pressure (MAP) Sensor
5 Intake Manifold
6 Throttle Position (TP) Sensor
7 Throttle Body
8 Idle Air Control (IAC) Valve
9 Brake Fluid Reservoir
10 Wiper Motor11 Battery
12 Fuse Box
13 Air Cleaner Housing
14 Resonator
15 Electronic Ignition System Ignition Coil
16 Exhaust Manifold
17 Snorkel
18 Engine
20 Washer Fluid Reservoir
19 Oil Level Gauge
21 Oil Filler Cap

1A–14 GENERAL ENGINE INFORMATION
DAEWOO M-150 BL2
SPECIFICATIONS
GENERAL SPECIFICATIONS
 Application Description
  Maximum Speed 144 km/h (90 mph)
 Vehicle Capacity Gradeability 0.420 tan θ

Vehicle Capacity
 Minimum Turning Radius 4.5 m (14.8 ft)
  Bore × Stroke 68.5 × 72.0 mm (2.70 × 2.83 inch)
  Displacement 796 cm3 (48.6 in3)
  Compression Ratio 9.3 : 1
  Maximum Power 37.5 KW (6,000 rpm)

Engine Information
 Maximum Torque 68.6 Nm (50.59 lb-ft) (at 4,600 rpm)
Ignition Timing (Ignition Sequence)5 BTDC (1–3–2) / 10 BTDC (1–3–2)
Air Conditioning System (ON)

1,000 ± 50 rpm  Idle Speed Air Conditioning System (OFF) 950 rpm  Engine Overhead Cam L–3


 Ignition Type

 Direct Ignition System (DIS) /
High Energy Ignition (HEI)
  Distributor Optical Sensor Type
  Starter SD 80
   Unleaded BPR5EY–11, RN9YC4, WR8DCX
  Spark–Plug Leaded BPR5EY, RN9YC, WR8DC
  Fuel Injection Type MPI
  Fuel Pump Electric Motor Pump
Engine Part TypeFuel FilterCartridge Engine Part Type
Lubricating Type

Forced Feed Type  Oil Pump Rotary Pump Type  Cooling Type Forced Water Circulation  Radiator Cross – Flow  Water Pump Centrifugal  Thermostat Pellet Type
  Air Cleaner Element Non Woven Fablic
  Muffler Catalytic Converter, Closed Circuit
  Battery MF
Engine PartEngine OilSJ Grade
SAE 5W30, SAE 10W30, SAE 15W40
CapacityRefrigerantFour Seasons
Engine Disassembly

3.0 L (3.17 qt)   Oil Change (Including filter) 2.7 L (2.85 qt)  Engine Oil Oil Change (Not including filter) 2.5 L (2.64 qt)   Oil Level Gauge 1 L (1.06 qt) (MIN to MAX)  Coolant 3.8 L (4.02 qt) Engine Information Battery 12V–35 AH, 246 CCA
 Engine Information

Generator

65 A
  Starter 0.8 kW
   Output Capacity 90 – 133 Lph
  Fuel Pump Output Pressure 380 kPa (55.1 Psi)
  Fuel Tank Capacity 35 L (9.2 gal), 38 L (10 gal)

SOHC ENGINE MECANICAL 1B–7
DAEWOO M-150 BL2
MANIFOLD & AIR FLOW SYSTEM
D21B0021
1 Intake Manifold
2 Exhaust Gas Recirculation (EGR) Pipe
3 Exhaust Gas Recirculation (EGR) Valve and
Solenoid
4 Throttle Body Assembly
5 Air Filter Assembly
6 Resonator7 Snorkel
8 Oxygen Sensor
9 Exhaust Manifold
10 Exhaust Manifold Heat Shield
11 Exhaust Manifold Heat Shield (Euro III)
12 Exhaust Manifold (Euro III)

SOHC ENGINE MECANICAL 1B–9
DAEWOO M-150 BL2
DIAGNOSTIC INFORMATION AND PROCEDURE
COMPRESSION PRESSURE CHECK
Tools Required
09915–64510 Compression Pressure Gauge
Check the compression pressure in the following proce-
dures:
1. Warm up the engine to the normal operating tempera-
ture (Cooling temperature : 80–90C (176–194F)).
2. Stop the engine and then remove the high tension
cable and the spark plug.
3. Disconnect the distributor optical sensor connector.
4. Install the compression pressure gauge 09915–64510
(a) in the hole of spark plug.
D12B301A
5. Disengage the clutch in Neutral (to lighten starting
load on engine upon cranking), and depress the ac-
celerator all the way to make the throttle fully open.
6. Crank the engine with the starting motor, and read the
highest pressure on the compression pressure gauge.
The difference of measured value between cylinders
is 98.06kPa (14.22 psi) and less.
On checking, make the connection perfectly airtight
between the hole of spark plug and compression pres-
sure gauge.
Unit Standard Limit



Compression
Pressure
– 400 rpm
kPa(psi)1,225.75
(177.73)
1,176.72–
1,274.78
(170.62–
184.84)
7. After checking, remove the gauge and install the re-
moved parts.
OIL PRESSURE CHECK
Tools Required
09915–77310 Oil Pressure Gauge
Prior to check oil pressure, check the followings:
Check oil level and add if required.
Replace the discolored, deteriorated or diluted oil.
Check any oil leakage and repair the defective parts.
Check the compression pressure in the following proce-
dures:
1. Remove the oil pressure switch (b) from the cylinder
block.
2. Install the oil pressure gauge 09915–77310 (c) to the
mounting place of the oil pressure switch.
D12B302A
3. Start the engine and warm up to the normal operating
temperature.
4. Raise the engine speed up to 2,000rpm and then
read oil pressure.
Item Unit Standard
Oil Pressure – 2000rpmkPa
(psi)245.15–294.18
(35.55–42.66)
5. After checking, wrap the threads of oil pressure
switch with a seal tape and tighten it to the specified
torque 12–16 N
m (106–144 lb-in).
6. Start the engine and check oil pressure switch for oil
leakage.

DAEWOO M-150 BL2
SECTION 1D
ENGINE COOLING
CAUTION: Disconnect the negative battery cable before removing or installing any electrical unit or when a
tool or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable
will help prevent personal injury and damage to the vehicle. The ignition must also be in B unless otherwise
noted.
TABLE OF CONTENTS
Description and Operation 1D-2. . . . . . . . . . . . . . . . . .
General Description 1D-2. . . . . . . . . . . . . . . . . . . . . . .
Radiator 1D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank 1D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Pump 1D-3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 1D-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric Cooling Fan 1D-3. . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Sensor 1D-4. . . . . . . . .
Coolant Temperature Sensor 1D-4. . . . . . . . . . . . . . . .
Component Locator 1D-5. . . . . . . . . . . . . . . . . . . . . . . .
Coolant Hose and Components 1D-5. . . . . . . . . . . . .
Radiator/Fan 1D-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnostic Information and Procedure 1D-7. . . . . . .
Coolant Leaks Test 1D-7. . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank Cap Test 1D-7. . . . . . . . . . . . . . . . . . . . . . .
Thermostat Test 1D-7. . . . . . . . . . . . . . . . . . . . . . . . . . . Cooling System Diagnosis 1D-8. . . . . . . . . . . . . . . . . .
Repair Instructions 1D-9. . . . . . . . . . . . . . . . . . . . . . . . .
On-Vehicle Service 1D-9. . . . . . . . . . . . . . . . . . . . . . . . . .
Draining and Refilling the Cooling System 1D-9. . . .
Surge Tank 1D-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric Cooling Fan 1D-11. . . . . . . . . . . . . . . . . . . . . .
Radiator 1D-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat (Typical) 1D-12. . . . . . . . . . . . . . . . . . . . . .
Thermostat (Euro III) 1D-13. . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Sensor 1D-14. . . . . . . . . . . . . . .
Engine Coolant Temperature Sensor 1D-15. . . . . . . .
Coolant Pump 1D-15. . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 1D-17. . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 1D-17. . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specifications 1D-18. . . . . . . . . .

1D–4 ENGINE COOLING
DAEWOO M-150 BL2
The main fan size is 320 mm (12.6 in.) in diameter with
seven blades(k) to aid the air flow through the radiator
and the condenser. An electric motor(l) attached to the
radiator support drives the fan.
A/C OFF or Non-A/C Model
The cooling fan is actuated by the electronic control
module (ECM) using a low speed cooling fan relay
and a high speed cooling fan relay. On A/C equipped
vehicles, a series/parallel cooling fan relay is also
used.
The ECM will turn the cooling fan on at low speed
when the coolant temperature reaches 93
C (199
F)
and high speed at 100
C (212
F).
The ECM will change the cooling fan from high speed
to low speed at 97
C (207
F) and turn the cooling
fans off at 90
C (194
F).
A/C ON
The ECM will only turn the cooling fan on at high
speed when the A/C system is on regardless of any
condition.
ENGINE COOLANT TEMPERATURE
SENSOR
The engine coolant temperature (ECT) sensor (n) uses
a thermistor to control the signal voltage to the engine
control module (ECM).
D102D004
COOLANT TEMPERATURE SENSOR
The coolant temperature sensor(m) controls the instru-
ment panel temperature indicator. The coolant tempera-
ture sensor is located on the distributor case with the
ECT sensor on an SOHC engine.

ENGINE COOLING 1D–5
DAEWOO M-150 BL2
COMPONENT LOCATOR
COOLANT HOSE AND COMPONENTS
D12D4011
1 Radiator Coolant Return Hose
2 Upper Radiator Hose
3 Not Used
4 Radiator Assembly
5 Lower Radiator Hose
6 Throttle Body Assembly
7 Surge Tank hose
8 Surge Tank
9 Coolant Temperature Sensor
10 Engine Coolant Temperature Sensor11 Surge Tank Return Hose
12 Water Inlet Cap
13 Heater Outlet Hose
14 Heater Inlet Hose
15 Distributor Case
16 Thermostat
17 Thermostat Housing
18 Throttle Body Inlet Hose
19 Throttle Body Outlet Hose
20 Hose Bracket

1D–14 ENGINE COOLING
DAEWOO M-150 BL2
MAA1D020
4. Remove the thermostat.
Remove the bolts.
Remove the thermostat housing.
Remove the thermostat with the gasket.
5. Check the gasket for crack or other damage.
6. Inspect the valve seat for foreign matter that could
prevent the valve from seating properly.
7. Inspect the thermostat for proper operation. Refer to
“Thermostat Test” in this section.
MAA1D011
Installation Procedure
1. Install the thermostat with the bolts and the thermo-
stat housing.
Tighten
Tighten the mounting bolts to 8–15 Nm (71–130
lb-in).
2. Secure the upper radiator hose to the thermostat
housing with a hose clamp.
3. Refill the engine cooling system. Refer to “Draining
and Refilling the Cooling System” in this section.
4. Install the air filter assembly. Refer to Section 1B,
SOHC Engine Mechanical.
D102D515
COOLANT TEMPERATURE SENSOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the lower radiator hose and drain the
coolant. Refer to “Draining and Refilling the Cooling
System” in this section.
3. Remove the coolant temperature sensor.
Disconnect the electrical connector (1).
Remove the coolant temperature sensor (2).
D12D516A
10 Nm
Installation Procedure
1. Install the coolant temperature sensor into the
threaded hole in the intake manifold.
Tighten
Tighten the coolant temperature sensor to 10 Nm
(89 lb-in).
Connect the electrical connector to the coolant
temperature sensor (1).
2. Connect the lower radiator hose and refill the coolant.
Refer to “Draining and refilling the cooling system” in
this section.
3. Connect the negative battery cable.

ENGINE COOLING 1D–15
DAEWOO M-150 BL2
D102D517
ENGINE COOLANT TEMPERATURE
SENSOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the lower radiator hose and drain the
coolant “Draining and Refilling the Cooling System” in
this section.
3. Remove the engine coolant temperature (ECT) sen-
sor.
Disconnect the electrical connector (1).
Remove the ECT sensor (2).
D12D518A
20 Nm
Installation Procedure
1. Install the ECT sensor.
Tighten
Tighten the ECT sensor to 20 Nm (15 lb-ft).
Connect the electrical connector to the ECT sen-
sor (1).
2. Connect the lower radiator hose and refill the coolant.
Refer to “Draining and Refilling the Cooling System”
in this section.
3. Connect the negative battery cable.
D102B533
COOLANT PUMP
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the lower radiator hose and drain the
coolant. Refer to “Draining and Refilling the Cooling
System” in this section.
3. Remove the timing belt. Refer to Section 1B, Engine
Mechanical.
4. Remove the rear timing belt cover.
Remove the bolts (1).
Remove the rear timing belt cover (2).
D102D519
5. Remove the coolant pump.
Remove the nuts (1).
Remove the bolts (2).
Remove the coolant pump (3).
Remove the gasket.
Notice: Remove the coolant pump as shown figure (a).
