FUSES Ð TOTALLY INTEGRATED POWER
MODULE (TIPM)
The TIPM is located in the engine compartment near the
air cleaner assembly. This center contains cartridge fuses
and mini fuses. A label that identifies each component
may be printed on the inside of the cover. Refer to the
following chart for FUSES/TIPM location.
Cavity Car-
tridge
Fuse Mini
Fuse Description
1 40 Amp
Green ÐÐTIPM Fuse and Relay Center406 MAINTAINING YOUR VEHICLE

Cavity Car-
tridge
Fuse Mini
Fuse Description
14 Ð 10 Amp
Red Ignition Off Draw
(IOD) Ð Cabin Com-
partment Node
(CCN)/ Interior
Lighting
15 40 Amp
Green Ð Battery Feed Ð Ra-
diator Fan Relay
16 Ð 15 Amp
Lt. Blue IGN Run/ACC Ð
Cigar Lighter/PWR
Sunroof Mod
17 Ð 10 Amp
Red Ignition Off Draw
(IOD) Ð Wireless
Control Module
(WCM)/Clock/
Steering Control
Module (SCM) Cavity Car-
tridge
Fuse Mini
Fuse Description
18 40 Amp
Green Ð Battery Feed Ð Auto
Shutdown (ASD) Re-
lay
19 Ð 20 Amp
Yellow Ignition Off Draw
(IOD) Ð Power Amp
Feed2-if equipped
20 Ð 15 Amp
Lt. Blue Ignition Off Draw
(IOD) Ð Radio
21 Ð 10 Amp
Red Ð
22 Ð 10 Amp
Red Ignition Run Ð Cli-
mate Controls/Hot
Cupholder - if
equipped
23 Ð 15 Amp
Lt. Blue Auto Shutdown
(ASD) Relay Feed 3408 MAINTAINING YOUR VEHICLE

Cavity Car-
tridge
Fuse Mini
Fuse Description
24 Ð 25 Amp
Clear Battery Feed Ð PWR
Sunroof Feed
25 Ð 10 Amp
Red Ignition Run Ð
Heated Mirrors - If
Equipped
26 Ð 15 Amp
Lt. Blue Auto Shutdown
(ASD) Relay Feed 2
27 Ð 10 Amp
Red Ignition Run Ð Occu-
pant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC) Cavity Car-
tridge
Fuse Mini
Fuse Description
28 Ð 10 Amp
Red Ignition Run Ð Occu-
pant Classification
Module (OCM)/
Occupant Restraint
Controller (ORC)
29 Ð Ð Hot Car (No Fuse Re-
quired)
30 Ð 20 Amp
Yellow Ignition Run Ð
Heated Seats - If
Equipped
31 Ð 10 Amp
Red Ð
32 30 Amp
Pink Ð Auto Shutdown
(ASD) Relay Feed 1 MAINTAINING YOUR VEHICLE 409
