Page 61 of 322
Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid, trans-
mission fluid or brake fluid leaks are suspected, the cause
should be located and corrected immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61
2
Page 62 of 322
Page 63 of 322
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mMirrors..............................66
NInside Day/Night Mirror Ð If Equipped......66
NOutside MirrorÐDriver's Side.............66
NOutside MirrorÐPassenger's Side...........67
NElectric Remote-Control Mirrors............67
NVanity Mirrors Ð If Equipped.............69
NSun Visor Sliding Feature................69
mSeats................................69
NFront Seat Adjustment...................69
NManual Seat Height Adjustment Ð
If Equipped..........................70
NManual LumbarÐ If Equipped.............71NDriver's Seat Back Recline................71
NAdjustable Head Restraints...............72
NHeated Seats Ð If Equipped..............72
NFolding Rear Seat......................74
NReclining And Folding Rear Seat Ð
If Equipped..........................75
mTo Open And Close The Hood.............76
mLights...............................77
NMap/Reading Lights....................77
NMulti-Function Control Lever..............77
NHeadlights, Parking Lights, Instrument Panel
Lights..............................78
3
Page 64 of 322
NDaytime Running Lights (DRL) Ð If Equipped..78
NLights-On Reminder....................79
NFog Lights Ð If Equipped................79
NTurn Signals..........................79
NHighbeam/Lowbeam Select Switch..........80
NPassing Light.........................80
mWindshield Wipers And Washers...........80
NWindshield Washers....................80
NMist Feature..........................81
NWindshield Wiper Operation..............82
NIntermittent Wiper System................82
NAdding Washer Fluid...................82
mTilt Steering Column.....................82
mElectronic Speed Control Ð If Equipped......83
NTo Activate...........................84
NTo Set At A Desired Speed................84NTo Deactivate.........................84
NTo Resume Speed......................84
NTo Vary The Speed Setting................84
NManual Transaxle......................85
NTo Accelerate For Passing................85
mAnti-Lock Brake System (ABS) ± If Equipped..86
mElectronic Brake Control System -
ABS/TCS/BAS/ESP Ð If Equipped
.........87
NTraction Control System (TCS) Ð If Equipped . .87
NBrake Assist System (BAS) Ð If Equipped.....87
NESP (Electronic Stability Program) Ð
If Equipped..........................88
mPower Sunroof Ð If Equipped.............91
NOpening Sunroof ± Manual...............92
NOpening Sunroof ± Express Mode...........92
NClosing Sunroof ± Manual................92
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 65 of 322
NClosing Sunroof ± Express Mode...........92
NPinch Protect Feature....................92
NPinch Protect Override..................92
NVenting Sunroof ± Express................93
NSunshade Operation....................93
NWind Buffeting........................93
NSunroof Maintenance....................93
NIgnition Off Operation...................93
mElectrical Power Outlets..................93
NElectrical Outlet Use With Engine Off........95
mConsole Features.......................96
mCargo Area Features.....................96NCargo Light/Removable Self- Recharging
Flashlight ± If Equipped.................96
NTonneau Cover Ð If Equipped.............98
NRemovable Load Floor...................99
NCargo Tie-Down Loops..................99
NFold Down Speakers ± If Equipped.........100
mRear Window Features..................101
NRear Window Wiper/Washer.............101
NRear Window Defroster.................102
mRoof Luggage Rack Ð If Equipped.........102
mCooled Beverage Storage Bin/Glove
Compartment Ð If Equipped
.............103
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
3
Page 66 of 322
MIRRORS
Inside Day/Night Mirror Ð If Equipped
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustment.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Outside MirrorÐDriver's Side
Adjust the Flat (Drivers Side) Outside Mirror so you can
just see the side of your vehicle in the part of the mirror
closest to vehicle with your head close to the door glass.
Adjusting Rear View Mirror
Mirror Directions
66 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 67 of 322
Outside MirrorÐPassenger's Side
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side mirror could cause you to collide
with another vehicle or other object. Use your inside
mirror when judging the size or distance of a vehicle
seen in this convex mirror.
Electric Remote-Control Mirrors
The controls for the power mirrors are located on the
driver's door trim panel.
Remote Control Mirrors Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 67
3
Page 68 of 322
To adjust a mirror, turn the control wand toward the left
or right mirror positions indicated. Tilt the control wand
in the direction you want the mirror to move. When
finished adjusting the mirror, turn the control to the
center position to prevent accidentally moving a mirror.
WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in the
right side mirror.
Mirror Directions
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 69 of 322
Vanity Mirrors Ð If Equipped
To use the mirror, rotate the sun visor down and swing
the mirror cover upward.
Sun Visor Sliding Feature
The sun visors may be pulled out to provide extended
coverage of the side glass.
SEATS
Front Seat Adjustment
The adjusting bar is at the front of the seats, near the
floor. Pull the bar up to move the seat to the desired
position.
Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
Vanity Mirror
Front Seat Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 69
3
Page 70 of 322
WARNING!
²Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt
might not be properly adjusted and you could be
injured. Adjust the seat only while the vehicle is
parked.
²Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your
chest. In a collision you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
Manual Seat Height Adjustment Ð If Equipped
The driver's seat height can be raised or lowered by using
the ratcheting handle on the outboard side of the seat to
adjust the driving position.
Seat Height Adjustment
70 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
