DODGE CHALLENGER SRT 2016 3.G Owners Manual

selectable options. In the Custom Mode Set-Up screen the
individual current configuration will be displayed. Select
which mode suits your driving needs for a custom
driving experience.
Custom Mode Set-Up Info
Within the Custom Mode Set-Up screen, press the “info”
button on the touchscreen then use the left / right arrows
to scroll through all the available Drive Mode systems
giving you a description of their operation and current
configuration.Power — If Equipped With 6.2L Supercharged Engine
•
700+
Press the “700+” button on the touchscreen to modify the
output power of the engine to 700+.
Power — 6.2L Supercharged Engine Only
4
UNDERSTANDING YOUR INSTRUMENT PANEL 319

NOTE:This selection is only available with the RED RKE
Key Fob.
• 500
Press the “500” button on the touchscreen to modify the
output power of the engine to 500.
NOTE: This selection is available with the RED or
BLACK RKE Key Fob and will limit the transmission to
the “Street” setting but Eco and Valet modes are still
available. Transmission — If Equipped With 8 Speed
Transmission
Transmission
320 UNDERSTANDING YOUR INSTRUMENT PANEL

•Track
Press the “Track” button on the touchscreen to provide
the fastest shift speeds and will have the highest comfort
trade-off.
• Sport
Press the “Sport” button on the touchscreen to provide
faster shift speeds and will have a moderate comfort
trade-off.
• Street
Press the “Street” button on the touchscreen to provide a
balance of shift speed and comfort for typical daily
driving. Paddle Shifters
•
ON
Press the “ON” button on the touchscreen to enable
steering wheel paddle shifters.
Paddle Shifters
4
UNDERSTANDING YOUR INSTRUMENT PANEL 321

•OFF
Press the “OFF” button on the touchscreen to disable
steering wheel paddle shifters. Traction
•
Track
Press the “Track” button on the touchscreen to modify
traction control to optimize track performance with the
least stability control.
Traction
322 UNDERSTANDING YOUR INSTRUMENT PANEL

•Sport
Press the “Sport” button on the touchscreen to turn off
traction control and reduce stability control.
• Street
Press the “Street” button on the touchscreen to provide
full traction control and full stability control. Suspension
•
Track
Press the “Track” button on the touchscreen to provide
the firmest possible suspension stiffness with the highest
amount of comfort trade-off.
Suspension
4
UNDERSTANDING YOUR INSTRUMENT PANEL 323

•Sport
Press the “Sport” button on the touchscreen to provide a
firmer suspension stiffness with moderate comfort trade-
off.
• Street
Press the “Street” button on the touchscreen to provide a
balance of suspension stiffness and ride comfort for
typical daily driving. Steering — If Equipped With 6.4L Engine
•
Track
Press the “Track” button on the touchscreen to adjust the
steering effort to the highest level.
Steering
324 UNDERSTANDING YOUR INSTRUMENT PANEL

•Sport
Press the “Sport” button on the touchscreen to adjust the
steering effort to the higher level.
• Street
Press the “Street button on the touchscreen to adjust the
steering effort to the lowest level.RACE OPTIONS
Press the “Race Options” button on the touchscreen
while in the Drive Modes screen, to display the vehicle’s
Race Options
4
UNDERSTANDING YOUR INSTRUMENT PANEL 325

Launch Control screen. Within Race Options, you can
activate, deactivate, and adjust the RPM values for the
Launch Control and Shift Light features.
Launch Control
WARNING!
Launch Mode is intended for off-highway or off-road
use only and should not be used on any public
roadways. It is recommended that this feature be
used in a controlled environment, and within the
limits of the law. The capabilities of the vehicle as
measured by the performance pages must never be
exploited in a reckless or dangerous manner, which
can jeopardize the user ’s safety or the safety of
others. Only a safe, attentive, and skillful driver can
prevent accidents.Launch Control can be accessed by pushing the Launch
Control button on the instrument panel switch bank or
pushing the SRT button on the instrument panel switch
bank then selecting the “Race Options” button on the
touchscreen. Press the “Activate Launch Control” button
on the touchscreen to activate the feature. Press the
Activate Launch Control
326 UNDERSTANDING YOUR INSTRUMENT PANEL

“Launch RPM Set-Up” to set the holding RPM. Launch
Mode can be turned on or off by either pushing the
Launch Control button on the instrument panel switch
bank (if activated), or by pressing the “Cancel Launch
Mode” button on the touchscreen.
NOTE:Launch RPM Set-Up cannot be accessed unless
Launch Mode is deactivated.
To adjust the Launch RPM, drag the slider bar or press
the arrows on the touchscreen to adjust the holding RPM.
The launch RPM limits will vary between the automatic
transmissions (1500–3500 RPM) and manual transmis-
sions (2000–4500 RPM).
Launch RPM Set-Up — Manual Transmission
4
UNDERSTANDING YOUR INSTRUMENT PANEL 327

For further information refer to “Drive Modes” in “Start-
ing and Operating”.
Shift Light
Your vehicle is equipped with a shift light feature that
illuminates the back lighting of the tachometer (in red)within the Driver Information Display (DID). This fea-
ture is a visual cue to manually up-shift using the paddle
shifters.
To actuate the Shift Light feature, press the “Shift Light”
button on the touchscreen, then press the “Shift Light
On” button on the touchscreen. Activation is shown on
the DID. Pressing the “Shift Light RPM Set-Up” button
on the touchscreen will take you to the Shift Light RPM
Set-Up screen.
NOTE:
You must be in Paddle Shift Mode in order to
activate the shift light. Refer to “Paddle Shift Mode” in
“Starting And Operating” for further information.
Shift Light
328 UNDERSTANDING YOUR INSTRUMENT PANEL
