DODGE DURANGO 2011 3.G Owners Manual

•You can also turn the temperature control to maximum
heat, the mode control to floor and the blower control
to high. This allows the heater core to act as a
supplement to the radiator and aids in removing heat
from the engine cooling system.
CAUTION!
Driving with a hot cooling system could damage
your vehicle. If the temperature gauge reads HOT
(H), pull over and stop the vehicle. Idle the vehicle
with the air conditioner turned off until the pointer
drops back into the normal range. If the pointer
remains on HOT (H), and you hear continuous
chimes, turn the engine off immediately and call for
service.
WARNING!
You or others can be badly burned by hot engine
coolant (antifreeze) or steam from your radiator. If
you see or hear steam coming from under the hood,
do not open the hood until the radiator has had time
to cool. Never try to open a cooling system pressure
cap when the radiator or coolant bottle is hot.
JACKING AND TIRE CHANGING
WARNING!
•Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.(Continued)
6
WHAT TO DO IN EMERGENCIES 449

WARNING! (Continued)
•Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never put any part of your body
under a vehicle that is on a jack.
•Never start or run the engine while the vehicle is
on a jack. If you need to get under a raised vehicle,
take it to a service center where it can be raised on
a lift.
•The jack is designed to be used as a tool for
changing tires only. The jack should not be used to
lift the vehicle for service purposes. The vehicle
should be jacked on a firm level surface only.
Avoid ice or slippery areas.
Jack Location
The scissor-type jack and tire changing tools are located
in rear cargo area, below the load floor.
Rotate the thumb screw on the jack to loosen the assem-
bly and remove the jack from the bracket.
Jack Storage Location
450 WHAT TO DO IN EMERGENCIES

Spare Tire Stowage
The spare tire is stowed under the rear of the vehicle by
means of a cable winch mechanism. To remove or stow
the spare, use the jack handle/lug wrench connected to
the square socket extension to rotate the “spare tiredrive” nut. The nut is located under a plastic cover at the
center-rear of the cargo floor area, just inside the liftgate
opening.
Thumb Screw Location
Spare Tire Location
6
WHAT TO DO IN EMERGENCIES 451

CAUTION!
Do not use power tools to winch the tire up or down.
Impact type tools can damage the winch mechanism.
Spare Tire Removal
1. Remove the jack tools from the bag.
2. Raise the rubber mat and remove the plug from
storage compartment floor.
3. Fit the jack handle extension over the drive nut. Use
the lug wrench handle and extension to completely lower
the spare tire. Keep turning the handle until the winch
stops.
Lowering/Raising Spare Tire
452 WHAT TO DO IN EMERGENCIES

4. Slide the tire out from under the vehicle and rotate it
vertically behind the rear bumper.5. Spread the retaining tabs on the plastic plate and pull
the metal stamping toward you to release it from the
plastic plate.
Spare Tire
Tab Location
6
WHAT TO DO IN EMERGENCIES 453

6. Slide the metal stamping up the steel extension tube
and winch cable. Rotate the metal stamping and push it
through the hole in the plastic plate and wheel.7. Pinch the three short and two long tubes to remove the
protective plate from the steel spare wheel.
Sleeve And Cable
Releasing Protective Plate
454 WHAT TO DO IN EMERGENCIES

Preparations For Jacking
1. Park the vehicle on a firm level surface, away from
traffic.
WARNING!
Do not attempt to change a tire on the side of the
vehicle closest to moving traffic, pull far enough off
the road to avoid being hit when operating the jack
or changing the wheel.
2. Place the transmission in PARK, set the parking brake
and activate the Hazard Warning flashers. 3. Block the diagonally opposite
wheel.
NOTE: Passengers should not remain in the vehicle
when the vehicle is being jacked.
Jacking Instructions
WARNING!
Carefully follow these tire changing warnings to help
prevent personal injury or damage to your vehicle:
•Always park on a firm, level surface as far from
the edge of the roadway as possible before raising
the vehicle.
(Continued)
6
WHAT TO DO IN EMERGENCIES 455

WARNING! (Continued)
•Turn on the Hazard Warning flasher.
•Block the wheel diagonally opposite the wheel to
be raised.
•Set the parking brake firmly and set the automatic
transmission in PARK.
•Never start or run the engine with the vehicle on a
jack.
•Do not let anyone sit in the vehicle when it is on a
jack.
•Do not get under the vehicle when it is on a jack.
•Only use the jack in the positions indicated and
for lifting this vehicle during a tire change.
•If working on or near a roadway, be extremely
careful of motor traffic.
WARNING! (Continued)
•To assure that spare tires, flat or inflated, are
securely stowed, spares must be stowed with the
valve stem facing the ground.
CAUTION!
Do not attempt to raise the vehicle by jacking on
locations other than those indicated in the Jacking
Instructions for this vehicle.
Jack Warning Label
456 WHAT TO DO IN EMERGENCIES

1. Loosen the lug nuts on the road wheel one turn, but do
not remove.
2. Assemble the cover on top of the jack and attach the
lug wrench to the jack tool with the hook.3. For the front axle, place the jack and protective cap on
the body flange just behind the front tire as indicated by
the triangular lift point symbol on the sill molding.
Do
not raise the vehicle until you are sure the jack is fully
engaged.
Jack And Tool AssemblyLift Point Symbol On Sill Molding
6
WHAT TO DO IN EMERGENCIES 457

4. For a rear tire, place the jack and protective cap on the
flange rearward of the hoist/rear tie-down bracket, just
forward of the rear tire (as indicated by the triangular lift
point symbol on the sill molding).Do not raise the
vehicle until you are sure the jack is fully engaged.
Front Jacking LocationLift Point Symbol On Sill Molding
458 WHAT TO DO IN EMERGENCIES
