display DODGE DURANGO 2014 3.G Service Manual

The main display area will normally display the main
menu or the screens of a selected feature of the main
menu. The main display area also displays “pop up”
messages that consist of approximately 60 possible warn-
ing or information messages. These pop up messages fall
into several categories:
•Five Second Stored Messages
When the appropriate conditions occur, this type of
message takes control of the main display area for five
seconds and then returns to the previous screen. Most of
the messages of this type are then stored (as long as the
condition that activated it remains active) and can be
reviewed from the “Messages” main menu item. As long
as there is a stored message, an “i” will be displayed in
the EVIC’s compass/outside temp line. Examples of this
message type are “Right Front Turn Signal Lamp Out”
and “Low Tire Pressure”. •
Unstored Messages
This message type is displayed indefinitely or until the
condition that activated the message is cleared. Examples
of this message type are “Turn Signal On” (if a turn signal
is left on) and “Lights On” (if driver leaves the vehicle).
• Unstored Messages Until RUN
These messages deal primarily with the Remote Start
feature. This message type is displayed until the ignition
is in the RUN state. Examples of this message type are
“Remote Start Aborted - Door Ajar” and “Push Brake
Pedal and Push Button to Start”.
• Five Second Unstored Messages
When the appropriate conditions occur, this type of mes-
sage takes control of the main display area for five seconds
and then returns to the previous screen. An example of this
message type is “Automatic High Beams On”.
304 UNDERSTANDING YOUR INSTRUMENT PANEL

Battery Saver Mode/Battery Saver On Message —
If Equipped
When theBattery Saver Mode or “Battery Saver On
message is displayed, the vehicle will turn off certain
electrical functions to reduce battery energy consump-
tion. This will occur during periods when the battery is
not being adequately charged. During this time, the
following features (if equipped) may be turned off or will
operate at a reduced power level: heated seats and heated
steering wheel, heated or cooled cup-holder, rear de-
froster and heated mirrors, heating and air conditioning,
power inverter, audio and telematics system.
This condition is temporary and recoverable, this is for
driver information only.
Engine Oil Change Indicator System
Oil Change Required
Your vehicle is equipped with an engine oil change
indicator system. The “Oil Change Required” message
will display in the EVIC for five seconds after a single
chime has sounded, to indicate the next scheduled oil
change interval. The engine oil change indicator system
is duty cycle based, which means the engine oil change
interval may fluctuate, dependent upon your personal
driving style.
Unless reset, this message will continue to display each
time you turn the ignition switch to the ON/RUN
position or cycle the ignition to the ON/RUN position if
equipped with Keyless Enter-N-Go™. To turn off the
message temporarily, press and release the OK button. To
reset the oil change indicator system (after performing
the scheduled maintenance) refer to the following proce-
dure.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 305

MPH To km/h
Press and release the UP or DOWN arrow
button until the MPH to km/h icon is high-
lighted in the EVIC. Press and release the OK
button to change the display between MPH
or km/h
Vehicle Info (Customer Information Features)
Press and release the UP or DOWN arrow
button until the Vehicle Info icon is highlighted
in the EVIC. Press the RIGHT or LEFT arrow
button to scroll through the following informa-
tion sub-menus:
Tire Pressure
Press and release the RIGHT or LEFT arrow button until
“Tire Pressure” is displayed in the EVIC. If tire pressure is OK for all tires a vehicle ICON is
displayed with tire pressure values in each corner of the
ICON.
If one or more tires have low pressure, “Inflate Tire To
XX” is displayed with the vehicle ICON and the tire
pressure values in each corner of the ICON with the
pressure value of the low tire displayed in a different
color than the other tire pressure value.
If the Tire Pressure system requires service, “Service Tire
Pressure System” is displayed.
Tire PSI is an information only function and cannot be
reset.
Refer to “Tire Pressure Monitoring System (TPMS)”
under “Starting and Operating” for further information.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 313

Transmission Temperature (Automatic Transmission
Only)
Press and release the RIGHT or LEFT arrow button until
“Transmission Temperature” is displayed in the EVIC. It
shows transmission temperature value with bargraph.
Oil Temperature
Press and release the RIGHT or LEFT arrow button until
“Oil Temperature” is highlighted in the EVIC. Press and
release the RIGHT arrow button and the oil temperature
will be displayed.
Battery Voltage
Press and release the RIGHT or LEFT arrow button until
“Battery Voltage” is highlighted in the EVIC. Press and
release the RIGHT arrow button and the battery voltage
will be displayed.Oil Life
Press and release the RIGHT or LEFT arrow button until
“Oil Life” is highlighted in the EVIC. Press and release
the RIGHT arrow button and the current oil life will be
displayed.
Oil Pressure
Press and release the RIGHT or LEFT arrow button until
“Oil Pressure” is highlighted in the EVIC. Press and
release the RIGHT arrow button and the current oil
pressure will be displayed.
Driver Assist
Press and release the UP or DOWN arrow
button until the Driver Assist display icon is
highlighted in the EVIC. For further informa-
tion, refer to “Adaptive Cruise Control (ACC)
— If Equipped” in “Understanding The Features Of Your
Vehicle”.
314 UNDERSTANDING YOUR INSTRUMENT PANEL

Fuel Economy
Press and release the UP or DOWN arrow
button until the Fuel Economy icon is
highlighted.
• Average Fuel Economy/Miles Per Gallon (MPG or
L/100 km with Bargraph)
• Range To Empty (RTE)
• Current Fuel Economy (MPG or L/100 km)
Trip A
Press and release the UP or DOWN arrow
button until the Trip A icon is highlighted in
the EVIC (Toggle left or right to select Trip A or
Trip B). The Trip A information will display the
following: •
Distance
• Average Fuel Economy
• Elapsed Time
Hold the OK button to reset all the information.
Trip B
From the Trip A menu press and release the
Left or Right arrow button until the Trip B icon
is highlighted in the EVIC (Toggle left or right
to select Trip A or Trip B). The Trip B informa-
tion will display the following:
• Distance
• Average Fuel Economy
• Elapsed Time
Hold the OK button to reset all the information.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 315

Audio
Press and release the UP or DOWN arrow button until
the Audio Menu item is highlighted in the EVIC.
Stored Messages
Press and release the UP or DOWN arrow
button until the Messages display icon is high-
lighted in the EVIC. This feature shows the
number of stored warning messages. Pressing
the RIGHT arrow button will allow you to see what the
stored messages are.
Screen Setup
Press and release the UP or DOWN arrow button until
the Screen Setup Menu item is highlighted in the EVIC.
Press and release the OK button to enter the sub-menus
and follow the prompts on the screen as needed. The Screen Setup feature allows you to change what informa-
tion is displayed in the instrument cluster as well as the
location that information is displayed.
Speed Warning — If Equipped
Once Speed Warning is entered, use the UP or DOWN
arrow buttons to adjust the Speed Warning. The Speed
Warning can be set in increments of 5 MPH and range
from 30-120 MPH. Once the desired speed is displayed,
press the OK button to set the speed. Press the LEFT
arrow button to exit to the main menu.
Screen Setup Driver Selectable Items
Current Gear
•
On
• Off
316 UNDERSTANDING YOUR INSTRUMENT PANEL

Upper Left
•None
• Gear Display
• Compass
• Outside Temp (default setting)
• Time
• Range To Empty (RTE)
• Fuel Economy Average
• Fuel Economy Current
• Trip A
• Trip B
Upper Right
• None •
Compass (default setting)
• Outside Temp
• Time
• Range To Empty (RTE)
• Fuel Economy Average
• Fuel Economy Current
• Trip A
• Trip B
Restore To Defaults (Restores All Settings To Default
Settings)
• Cancel
• Okay
4
UNDERSTANDING YOUR INSTRUMENT PANEL 317

Soft-Keys
Soft-Keys are accessible on the Uconnect® display.
Customer Programmable Features — Uconnect®
5.0 Settings
Press the SETTINGS hard-key to display the menu set-
ting screen. In this mode the Uconnect® system allows
you to access programmable features that may be
equipped such as Display, Clock, Safety/Assistance,
Lights, Doors & Locks, Auto-On Comfort & Remote Start,
Engine Off Operation, Compass Settings, Audio, Phone/
Bluetooth® and SiriusXM Setup.
NOTE:Only one touchscreen area may be selected at a
time.
When making a selection, press the soft-key to enter the
desired mode. Once in the desired mode, press and
release the preferred setting until a check-mark appears next to the setting, showing that setting has been se-
lected. Once the setting is complete, either press the Back
Arrow soft-key or the Back hard-key to return to the
previous menu or press the X soft-key to close out of the
settings screen. Pressing the Up or Down Arrow soft-keys
on the right side of the screen will allow you to toggle up
or down through the available settings.
NOTE:
Depending on the vehicles options, feature set-
tings may vary.
Display
After pressing the Display soft-key the following settings
will be available:
• Display Mode
When in this display you may select the Auto or Manual
display settings. To change Mode status, touch and
release the “Auto” or “Manual” soft-key. Then touch the
back arrow soft-key.
320 UNDERSTANDING YOUR INSTRUMENT PANEL

•Display Brightness With Headlights ON
When in this display, you may select the overall screen
brightness with the headlights on. Adjust the brightness
with the + and – setting soft-keys or by selecting any
point on the scale between the “+” and “–” soft-keys.
Then touch the back arrow soft-key.
• Display Brightness With Headlights OFF
When in this display, you may select the overall screen
brightness with the headlights off. Adjust the brightness
with the + and – setting soft-keys or by selecting any
point on the scale between the “+” and “–” soft-keys.
Then touch the back arrow soft-key.
• Set Language
When in this display, you may select one of multiple
languages (English / Français / Español) for all display
nomenclature, including the trip functions and the navi-
gation system (if equipped). Touch the “Set Language” soft-key, then touch the desired language soft-key until a
check-mark appears next to the language, showing that
setting has been selected. Touch the back arrow soft-key
to return to the previous menu.
•
Units
When in this display, you may select to have the EVIC,
odometer, and navigation system (if equipped) changed
between US and Metric units of measure. Touch “US” or
“Metric” until a check-mark appears next to the setting,
showing that setting has been selected. Touch the back
arrow soft-key to return to the previous menu.
• Voice Response Length
When in this display, you may change the Voice Re-
sponse Length settings. To change the Voice Response
Length, touch the “Brief” or “Detailed” soft-key until a
check-mark appears next to the setting, showing that
setting has been selected. Touch the back arrow soft-key
to return to the previous menu.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 321

•Show Command List
When in this display, you may choose to Never, With
Help or Always display the Teleprompter with possible
options while in a voice session. To change the Show
Command List, touch the “Never,” “With Help” or
“Always” soft-key until a check-mark appears next to the
setting, showing that setting has been selected. Touch the
back arrow soft-key to return to the previous menu.
• Touchscreen Beep
When in this display, you may turn on or shut off the
sound heard when a touchscreen button (soft-key) is
pressed. Touch the “Touchscreen Beep” soft-key until a
check-mark appears next to the setting, showing that
setting has been selected. Touch the back arrow soft-key
to return to the previous menu.
• Navigation Turn-By-Turn In Cluster — If Equipped
When this feature is selected, the turn-by-turn directions
will appear in the display as the vehicle approaches a designated turn within a programmed route. To make
your selection, touch the “Navigation Turn-By-Turn In
Cluster” soft-key, until a check-mark appears next to the
setting, showing that setting has been selected. Touch the
back arrow soft-key to return to the previous menu.
Clock
After pressing the “Clock” soft-key the following settings
will be available:
•
Time and Format
When in this display, you may set the time and choose
the format to display the time. Touch the “12h,” “24h,”
“AM” or “PM” soft-key until a check-mark appears next
to the setting, showing that setting has been selected.
Touch the back arrow soft-key to return to the previous
menu. If 24h is selected, AM/PM soft-keys will be greyed
out (unavailable).
322 UNDERSTANDING YOUR INSTRUMENT PANEL
