In addition to the front power outlet, there is also a power
outlet located in the storage area of the center console.If your vehicle is equipped with a rear full center console,
there is also a power outlet located in the lower storage
area of the rear full center console.
Front Center Console Outlet
Rear Full Center Console Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 259

The rear cargo power outlet is located in the right rear
cargo area.NOTE:
The rear cargo power outlet can be changed to
“battery” powered all the time by switching the power
outlet right rear quarter panel fuse in the fuse panel from
fuse location F90 to F91.
Rear Cargo Power Outlet
Rear Cargo Power Outlet Fuse
260 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
To avoid serious injury or death:
•Only devices designed for use in this type of outlet
should be inserted into any 12 Volt outlet.
• Do not touch with wet hands.
• Close the lid when not in use and while driving the
vehicle.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Outlet Fuse Locations
1 — F104 Fuse 20 A Yellow Power Outlet Console Bin
2 — F90–F91 Fuse 20 A Yellow Power Outlet Right Rear Quarter
Panel
3 — F93 Fuse 20 A Yellow Cigar Lighter Instrument Panel
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 261

CAUTION!
•Many accessories that can be plugged in draw power
from the vehicle’s battery, even when not in use (i.e.,
cellular phones, etc.). Eventually, if plugged in long
enough, the vehicle’s battery will discharge suffi-
ciently to degrade battery life and/or prevent the
engine from starting.
• Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the bat-
tery even more quickly. Only use these intermit-
tently and with greater caution.
• After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
POWER INVERTER — IF EQUIPPED
There is a 115 Volt, 150 Watt inverter outlet located on the
back of the center console to convert DC current to AC
current. This outlet can power cellular phones, electron-
ics and other low power devices requiring power up to
150 Watts. Certain high-end video game consoles will
exceed this power limit, as will most power tools.
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The power inverter is designed with built-in overload
protection. If the power rating of 150 Watts is exceeded,the power inverter will automatically shut down. Once
the electrical device has been removed from the outlet the
inverter should automatically reset. To avoid overloading
the circuit, check the power ratings on electrical devices
prior to using the inverter.
WARNING!
To avoid serious injury or death:
•
Do not insert any objects into the receptacles.
• Do not touch with wet hands.
• Close the lid when not in use.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Power Inverter
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263

CUPHOLDERS
Front Seat Cupholders
There are two cupholders for the front seat passengers
located in the center console.
Rear Cupholders
Rear Center Arm Rest Cupholders — If Equipped
There are two cupholders for the rear seat passengers
located in the fold-down center armrest.
Front Cupholder LocationRear Center Arm Rest Cupholders
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Full Console Cupholders — If Equipped
There are two cupholders for the rear seat passengers
located in the front of the rear full console.The rear full console cupholders are equipped with a
light ring that illuminates the cupholders for the rear
passengers. The light ring is controlled by the Dimmer
Control. Refer to “Lights” in “Understanding The Fea-
tures Of Your Vehicle” for further information.
Rear Full Console Cupholders
Light Ring In Rear Full Console Cupholders
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265

Rear Mini Console Cupholders — If Equipped
There are two cupholders for the rear seat passengers
located in the front of the rear mini console.STORAGE
Glove Compartment
The glove compartment is located on the right side of the
instrument panel.
Rear Mini Console Cupholders
Glove Compartment
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To open the glove compartment, pull outward on the
latch and lower the glove box door.
Door Storage
Large storage areas are built into the door panels for easy
access.
Front Center Console
The front center console contains both an upper and a
lower storage area.
To open the upper storage compartment, pull upward on
the small latch located on the lid.
Door Panel StorageStorage Compartment Latches
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267

Lift upward on the larger of the latches to access the
lower storage compartment.
Rear Full Center Console — If Equipped
The rear full center console contains both an upper and a
lower storage area.To open the upper storage compartment, pull upward on
the small latch located on the front of the lid.
Lift upward on the larger of the latches to access the
lower storage compartment.
Storage Compartment
Upper Storage Compartment
