DODGE NITRO 2008 1.G Owners Manual

Right Front Turn Signal
1. Open the hood.
2. Reach behind the headlamp unit in the engine com-
partment to access the turn signal bulb.
3. Twist the bulb counter clockwise to remove.
4. Disconnect the electrical connector and replace the
bulb.
Front Side Marker
1. Open the hood.
2. Remove the grille assembly, as follows:
a. Remove eight fasteners.
b. Remove two screws from each headlamp.c. Remove two scrivets from the center of the grille.
d. Remove one push pin from the top of each fender.
e. Pull the grille assembly toward you to disconnect
the grille clips to the fender and the headlamp ball-
studs to the front end module.
3. Disconnect electrical connector.
4. Turn the bulb counterclockwise to remove.
Front Fog Light (Front Fascia Mounted)
1. Reach between the front fascia and wheel liner from
under the vehicle.
2. Turn the front fog light bulb 1/4 turn counter clock-
wise to remove from housing.
3. Disconnect the electrical connector and replace bulb.
MAINTAINING YOUR VEHICLE 391
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with any oily surface, clean the
bulb with rubbing alcohol.
Rear Tail, Stop, Turn Signal, and Back-Up Lights
1. Open the lift gate.
2. Remove the two push pins.
3. Pull lamp straight back and disconnect electrical con-
nection.
392 MAINTAINING YOUR VEHICLE

4. Remove the two screws attaching the backplate to the
lamp assembly.
5. Pull the backplate straight back from the lamp hous-
ing.
6. Disconnect the electrical connector.
7. Remove the bulb from the backplate.
Center High Mounted Stop Light (CHMSL)
1. Remove the two screws securing the CHMSL.
2. Disconnect the electrical connector and washer hose (if
equipped) from CHMSL.
3. Replace the CHMSL.
MAINTAINING YOUR VEHICLE 393
7

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)19.5 Gallons 73.8 Liters
Engine Oil with Filter
3.7 Liter Engine (SAE 5W-20, API Certified Engine Oil) 5 Qts 4.7 Liters
4.0 Liter Engine (SAE 10W-30, API Certified Engine Oil) 6 Qts 5.7 Liters
Cooling System *
3.7 Liter Engine (MopartAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)14 Qts 13 Liters
4.0 Liter Engine (MopartAntifreeze/Engine Coolant 5 Year/
100,000 Mile Formula)14 Qts 13 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
394 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
Engine Oil (3.7L Engine) Use API Certified SAE 5W-20 engine oil, meeting material standard MS-6395
or equivalent.
Engine Oil (4.0L Engine) Use API Certified SAE 10W-30 engine oil, refer to oil viscosity chart for cor-
rect SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter MopartEngine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs 3.7 Liter ZFR6F-11G (Gap 0.043º)
Spark Plugs 4.0 Liter ZFR5LP-13G (Gap 0.050º)
Fuel Selection (3.7L Engines) 87 Octane, (R+M)/2 Method
Fuel Selection (4.0L Engines) 87 Octane, (R+M)/2 Method Acceptable, 89 Octane, (R+M)/2 Method Pre-
ferred
MAINTAINING YOUR VEHICLE 395
7

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MopartATF+4, Automatic Transmission Fluid.
Manual Transmission MopartManual Transmission Lubricant or equivalent (meeting the re-
quirements of DaimlerChrysler Material Standard MS-9224)
Transfer Case MopartATF+4, Automatic Transmission Fluid.
Front Axle SAE 80W-90 Multipurpose Type, GL-5 Gear Lubricant or equivalent.
Rear Axle SAE 75W-140 Synthetic Gear Lubricant or equivalent.
Brake Master Cylinder/Manual
Transmission Clutch SystemMopartDOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE
J1703 brake fluid is not available, then DOT 4 is acceptable. Use only rec-
ommended brake fluids.
Power Steering Reservoir MopartATF+4, Automatic Transmission Fluid.
396 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS
mEmission Control System Maintenance........398
mMaintenance Schedule...................398NRequired Maintenance Intervals...........401
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The ªScheduledº maintenance services, listed inbold
typemust be done at the times or mileages specified to
assure the continued proper functioning of the emission
control system. These, and all other maintenance services
included in this manual, should be done to provide best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions such as dusty areas and very short trip
driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE:Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part, which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULE
The oil change indicator system will remind you that it is
time to take your vehicle in for scheduled maintenance.
On Electronic Vehicle Information Center (EVIC)
equipped vehicles ªOil Change Requiredº will be dis-
played in the EVIC and a single chime will sound,
indicating that an oil change is necessary.
On Non-EVIC equipped vehicles ªChange Oilº will flash
in the instrument cluster odometer and a single chime
will sound, indicating that an oil change is necessary.
Based on engine operation condition the oil change
indicator message will illuminate, this means that service
is required for your vehicle. Have your vehicle serviced
as soon as possible, within the next 500 miles (805 km).
398 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

NOTE:
²The oil change indicator message will not monitor the
time since the last oil change. Change your vehicles oil
if it has been 6 months since your last oil change even
if the oil change indicator message is NOT illumi-
nated.
²Change your engine oil more often if you drive your
vehicle off-road for an extended period of time.
²Under no circumstances should oil change intervals
exceed 6,000 miles (10,000 km) or 6 months, whichever
comes first.
Your dealer will reset the oil change indicator message
after completing the scheduled oil change. If this sched-
uled oil change is performed by someone other than yourdealer the message can be reset by referring to the steps
described under ªOil Change Requiredº in ªUse Factory
Settingsº of the EVIC section in this manual or under
ªOdometer/Trip Odometerº in the ªInstrument Cluster
Descriptions section of this manual.
At Each Stop for Fuel
²Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
²Check the windshield washer solvent and add if
required.
MAINTENANCE SCHEDULES 399
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Once a Month
²Check tire pressure and look for unusual wear or
damage.
²Inspect the battery and clean and tighten the terminals
as required.
²Check the fluid levels of coolant reservoir, brake
master cylinder, power steering and transmission and
add as needed.
²Check all lights and other electrical items for correct
operation.At Each Oil Change
²Change the engine oil filter.
²Inspect the brake hoses and lines.
²Check the manual transmission fluid level.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
