FUEL INJECTOR NO. 6 (GAS)-2WAY
CAV CIRCUIT FUNCTION
1 K58 18BR/VT INJECTOR CONTROL NO. 6
2 K342 16BR/WT ASD RELAY OUTPUT
FUEL INJECTOR NO. 7 (GAS)-2WAY
CAV CIRCUIT FUNCTION
1 K26 18BR/YL INJECTOR CONTROL NO. 7
2 K342 16BR/WT ASD RELAY OUTPUT
FUEL INJECTOR NO. 8 (GAS)-2WAY
CAV CIRCUIT FUNCTION
1 K28 18BR/LB INJECTOR CONTROL NO. 8
2 K342 16BR/WT ASD RELAY OUTPUT
FUEL INJECTOR PACK NO. 1 (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K227 14BR/LG ENG - INJECTOR HIGH SIDE DRIVER - BANK 1
2 K12 14BR/DB INJECTOR CONTROL NO. 2
3 K227 14BR/LG ENG - INJECTOR HIGH SIDE DRIVER - BANK 1
4 K11 14BR/YL INJECTOR CONTROL NO. 1
4 K11 14WT/DB INJECTOR CONTROL NO. 1
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 65

FUEL INJECTOR PACK NO. 2 (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
1 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
2 K14 14BR/TN INJECTOR CONTROL NO. 4
3 K227 14BR/LG ENG - INJECTOR HIGH SIDE DRIVER - BANK 1
4 K13 14BR/LB INJECTOR CONTROL NO. 3
4 K13 14TN INJECTOR CONTROL NO. 3
FUEL INJECTOR PACK NO. 3 (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
1 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
1 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
2 K58 14BR/VT INJECTOR CONTROL NO. 6
3 K229 14TN/PK ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
3 K229 14BR/LB ENG - INJECTOR HIGH SIDE DRIVER - BANK 2
4 K38 14BR/OR INJECTOR CONTROL NO. 5
4 K38 14GY INJECTOR CONTROL NO. 5
FUEL PUMP MODULE - LT GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 Z201 12BK/OR GROUND
2 K900 18DB/DG SENSOR GROUND
3 N4 18DB/WT FUEL LEVEL SENSOR SIGNAL
4 A109 14OR/RD FUEL PUMP RELAY OUTPUT
FUEL PUMP MOTOR (DIESEL)-2WAY
CAV CIRCUIT FUNCTION
1 K31 18BR FUEL PUMP RELAY CONTROL
2 K65 18BR/LB FUEL PUMP RELAY RETURN
8W - 80 - 66 8W-80 CONNECTOR PIN-OUTSDR

HEADLAMP SWITCH - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 E19 20OR/BR PANEL LAMPS DIMMER SIGNAL
4 Z407 20BK/OR GROUND
5 L89 20WT/YL (FOG LAMPS) FOG LAMP RELAY OUTPUT
6 E2 20OR/BR PANEL LAMPS DIMMER SIGNAL
7 L115 20WT/YL HEADLAMP SWITCH RETURN
8 L116 20WT/LG HEADLAMP SWITCH SIGNAL
HEADLAMP-LEFT - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L43 18WT/DB LEFT LOW BEAM OUTPUT
B Z345 18BK/LB GROUND
C L33 18WT/LG LEFT HIGH BEAM OUTPUT
HEADLAMP-RIGHT - BLUE 3 WAY
CAV CIRCUIT FUNCTION
A L44 18WT/TN RIGHT LOW BEAM OUTPUT
B Z346 18BK/LG GROUND
C L34 18WT/GY RIGHT HIGH BEAM OUTPUT
HEATED SEAT CUSHION-DRIVER - BLUE 4 WAY
CAV CIRCUIT FUNCTION
1 P187 18LG/BR DRIVER SEAT TEMPERATURE SENSOR INPUT
2 Z939 20BK GROUND
3 P53 20LG/OR DRIVER SEAT TEMPERATURE 5 VOLT SUPPLY
4 P89 20LG/OR SEAT HEATER DRIVER
8W - 80 - 68 8W-80 CONNECTOR PIN-OUTSDR

HORN-HIGH NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z299 18BK/OR GROUND
HORN-LOW NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z298 18BK/DB GROUND
IDLE AIR CONTROL MOTOR (3.7L/4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K961 18BR/VT IAC RETURN
2 K61 18VT/GY IAC MOTOR CONTROL
IGNITION SWITCH - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 A970 10RD FUSED B(+)
2 F1 16PK/WT FUSED IGNITION SWITCH OUTPUT (OFF-RUN-START)
3 F951 16PK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
4 A951 16RD FUSED B(+)
5 G15 20VT/TN KEY IN IGNITION SWITCH SENSE
6 Z943 20BK GROUND
7 A921 16RD FUSED B(+)
8 C7 10DB BLOWER MOTOR FEED
9 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 F991 10PK/YL (POWER WINDOWS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 A981 14RD FUSED B(+)
12 A991 10RD (POWER WINDOWS) FUSED B(+)
13 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
14 F922 16PK/YL FUSED IGNITION SWITCH OUTPUT (RUN)
8W - 80 - 70 8W-80 CONNECTOR PIN-OUTSDR

INTAKE AIR TEMPERATURE SENSOR (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG SENSOR GROUND
2 K21 18DB/LG IAT SIGNAL
INTAKE AIR TEMPERATURE/MANIFOLD ABSOLUTE PRESSURE SENSOR (DIESEL)-4WAY
CAV CIRCUIT FUNCTION
A K916 18BR/OR SENSOR GROUND
B K21 18DB/LG INTAKE AIR TEMPERATURE SENSOR SIGNAL
C F855 18PK/YL 5 VOLT SUPPLY
D K37 18LB (A/T) BOOST PRESSURE SENSOR SIGNAL
D K37 18BR/OR (M/T) BOOST PRESSURE SENSOR SIGNAL
INTEGRATED POWER MODULE C1 - 26 WAY
CAV CIRCUIT FUNCTION
1 A960 14RD (DIESEL) FUSED B(+)
1 A16 16RD/BR (NGC) FUSED B(+)
2 F21 20PK/DG FUSED IGNITION SWITCH OUTPUT (RUN-START)
3- -
4 F500 20DG/PK FUSED IGNITION SWITCH OUTPUT (RUN)
5 L673 18YL TRAILER TOW LEFT TURN RELAY OUTPUT
6- -
7 L674 18LG TRAILER TOW RIGHT TURN RELAY OUTPUT
8 A981 14RD FUSED B(+)
9 A114 18GY/RD FUSED B(+)
10 L70 18WT/GY FUSED PARK LAMP RELAY OUTPUT
11 F951 16PK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
12 A941 18RD FUSED B(+)
13 A919 20RD FUSED B(+)
14 X2 18DG/OR HORN RELAY OUTPUT
15 - -
16 A103 18GY/RD FUSED B(+)
17 L678 18BR PARK LAMP RELAY OUTPUT
18 - -
19 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
20 - -
21 - -
22 - -
23 - -
24 - -
25 - -
26 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 73

INTEGRATED POWER MODULE C4 - 10 WAY
CAV CIRCUIT FUNCTION
1 Z116 18BK/VT GROUND
2 L54 18WT/LG RIGHT STOP LAMP FEED
3 W1 20BR/TN WASHER FLUID SWITCH SENSE
4- -
5- -
6 F941 20PK/LG (DIESEL) FUSED IGNITION SWITCH OUTPUT (RUN-START)
7 W7 20BR/GY WIPER PARK SWITCH SENSE
8- -
9- -
10 F202 20PK/GY FUSED IGNITION SWITCH OUTPUT (RUN-START)
INTEGRATED POWER MODULE C5 - 26 WAY
CAV CIRCUIT FUNCTION
1 F922 16PK/YL FUSED IGNITION SWITCH OUTPUT (RUN)
2 F941 20PK/LG (DIESEL) FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 Z912 20BK (GAS) GROUND
3- -
4 L10 18WT/GY FUSED IGNITION SWITCH OUTPUT (RUN)
5- -
6- -
7- -
8 Z920 12BK GROUND
9 C110 20DB/LB DEFOGGER RELAY CONTROL
10 - -
11 C13 20LB/OR A/C CLUTCH RELAY CONTROL
12 - -
13 - -
14 Z114 20BK/LG (DIESEL) GROUND
14 K173 18BR/VT (NGC) CONDENSER FAN RELAY CONTROL
15 F202 20PK/GY (DIESEL) FUSED IGNITION SWITCH OUTPUT (RUN-START)
15 A16 16RD/BR (NGC) FUSED B(+)
16 T515 20YL/DB TRANSMISSION CONTROL RELAY CONTROL
17 C16 16DB/GY HEATED MIRROR RELAY OUTPUT
18 C3 20DB/YL A/C CLUTCH RELAY OUTPUT
19 - -
20 - -
21 C110 20DB/LB DEFOGGER RELAY CONTROL
22 W4 16BR/OR WIPER RELAY HIGH SPEED OUTPUT
23 F100 18PK/VT FUSED IGNITION SWITCH OUTPUT (RUN)
24 F201 18PK/OR FUSED IGNITION SWITCH OUTPUT (RUN)
25 - -
26 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 75

INTEGRATED POWER MODULE C6 - BLACK 15 WAY
CAV CIRCUIT FUNCTION
1- -
2 A400 14TN/RD FUSED B(+)
3- -
4 K342 16BR/WT ASD RELAY OUTPUT
5- -
6- -
7- -
8- -
9- -
10 A961 14RD (DIESEL) FUEL HEATER RELAY OUTPUT
10 C123 16LB/WT (NGC) CONDENSER FAN RELAY OUTPUT
11 A960 14RD (DIESEL) FUSED B(+)
11 A16 16RD/BR (NGC) FUSED B(+)
12 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 - -
14 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
15 - -
INTEGRATED POWER MODULE C7 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 T750 14YL/GY STARTER MOTOR RELAY OUTPUT
2 W3 16BR/WT WIPER RELAY LOW SPEED OUTPUT
3 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 A930 18RD FUSED B(+)
5- -
6 L43 18WT/DB LEFT LOW BEAM OUTPUT
7 L34 18WT/GY RIGHT HIGH BEAM OUTPUT
8- -
9 A109 16OR/RD (GAS) FUEL PUMP RELAY OUTPUT
10 - -
11 K51 20BR/WT (GAS) ASD RELAY CONTROL
13 - -
14 - -
15 L33 18WT/LG LEFT HIGH BEAM OUTPUT
16 - -
16 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT
17 - -
17 C15 16DB/WT REAR WINDOW DEFOGGER RELAY OUTPUT
18 - -
19 K31 20BR FUEL PUMP RELAY CONTROL
20 - -
20 L89 18WT/YL (FOG LAMPS) FOG LAMP RELAY OUTPUT
21 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
22 L44 18WT/TN RIGHT LOW BEAM OUTPUT
23 T41 20YL/DB (EXCEPT NGC) TRS T41 SENSE
23 T752 20DG/OR (NGC) STARTER RELAY CONTROL
24 A944 20RD FUSED B(+)
26 - -
8W - 80 - 76 8W-80 CONNECTOR PIN-OUTSDR

KNOCK SENSOR (3.7L) - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 K42 18DB/YL KNOCK SENSOR NO. 1 SIGNAL
2 K942 18BR/LG KNOCK SENSOR NO. 1 RETURN
3 K242 18BR/WT KNOCK SENSOR NO. 2 SIGNAL
4 K924 18WT/BR KNOCK SENSOR NO. 2 RETURN
KNOCK SENSOR-LEFT (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K42 18DB/YL KNOCK SENSOR NO. 1 SIGNAL
2 K942 18BR/LG KNOCK SENSOR NO. 1 RETURN
KNOCK SENSOR-RIGHT (5.7L)-2WAY
CAV CIRCUIT FUNCTION
1 K242 18BR/WT KNOCK SENSOR NO. 2 SIGNAL
2 K924 18WT/BR KNOCK SENSOR NO. 2 RETURN
LICENSE LAMP-LEFT-2WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2 Z367 18BK/BR GROUND
LICENSE LAMP-RIGHT-2WAY
CAV CIRCUIT FUNCTION
1 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
2 Z367 18BK/BR GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 77

PARK/TURN SIGNAL LAMP-LEFT FRONT - BROWN 3 WAY
CAV CIRCUIT FUNCTION
1 L61 18WT/LG LEFT FRONT TURN LAMP DRIVER
2 L7 18WT/YL FUSED PARK LAMP RELAY OUTPUT
3 Z377 18BK/BR GROUND
PARK/TURN SIGNAL LAMP-RIGHT FRONT - BROWN 3 WAY
CAV CIRCUIT FUNCTION
1 L60 18WT/TN RIGHT FRONT TURN LAMP DRIVER
2 L70 18WT/GY FUSED PARK LAMP RELAY OUTPUT
3 Z378 18BK/TN GROUND
PASSENGER BLEND DOOR ACTUATOR (DUAL-ZONE)-2WAY
CAV CIRCUIT FUNCTION
1 C34 20DB/LB COMMON DOOR DRIVER
2 C33 20LB/BR PASSENGER BLEND DOOR DRIVER
PASSENGER LUMBAR SWITCH-5WAY
CAV CIRCUIT FUNCTION
1 Z939 14BK GROUND
2 P106 12LG/WT RIGHT SEAT REAR UP
3 A210 12OR/RD FUSED B(+)
4 P104 12LG LUMBAR MOTOR FORWARD
5 Z939 14BK GROUND
POWER MIRROR-LEFT - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 C16 18DB/GY HEATED MIRROR RELAY OUTPUT
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 P75 18TN/LG LEFT MIRROR LEFT DRIVER
4 P71 18TN/DG LEFT MIRROR UP DRIVER
5 Z461 20BK/DG GROUND
6- -
7- -
8- -
8W - 80 - 82 8W-80 CONNECTOR PIN-OUTSDR

POWER MIRROR-RIGHT - BLACK 8 WAY
CAV CIRCUIT FUNCTION
1 C16 18DB/GY HEATED MIRROR RELAY OUTPUT
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
4 P72 18TN/GY RIGHT MIRROR UP DRIVER
5 Z216 20BK/DB GROUND
6- -
7- -
8- -
POWER OUTLET - RED 3 WAY
CAV CIRCUIT FUNCTION
1 A205 18RD/OR FUSED B(+)
2- -
3 Z737 18BK/LB GROUND
POWER OUTLET-CONSOLE (EXCEPT BASE)-3WAY
CAV CIRCUIT FUNCTION
1 A405 18RD/DB FUSED B(+)
2- -
3 Z939 18BK GROUND
POWER SEAT MOTOR-DRIVER FRONT VERTICAL - RED 2 WAY
CAV CIRCUIT FUNCTION
1 P21 12LG/TN LEFT SEAT FRONT DOWN
2 P19 12LG/LB LEFT SEAT FRONT UP
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 83
