Page 1941 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (6) Install assembled puller plate and bolt (Fig.
184). Insert bolt through cam, case and adapter tool.
Be sure plate is seated squarely on cam.
(7) Hold puller plate and bolt in place and install
pul

Page 1942 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (14) Position overdrive piston retainer on trans-
mission case and align bolt holes in retainer, gasket
and case (Fig. 187). Then install and tighten retainer
bolts to 17 N´m (13 ft. lbs.) torque.
(1

Page 1943 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual PRESSURE ON A CONFINED FLUID
Pressure is exerted on a confined fluid (Fig. 189)
by applying a force to some given area in contact
with the fluid. A good example of this is a cylinder
filled with fluid

Page 1944 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual PISTON TRAVEL
The relationship between hydraulic lever and a
mechanical lever is the same. With a mechanical
lever its a weight-to-distance output rather than a
pressure-to-area output. Using the sam

Page 1945 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual DISASSEMBLY
(1) Remove planetary snap-ring from intermediate
shaft (Fig. 193). Discard snap-ring as it is not reus-
able.
(2) Remove front planetary gear and front annulus
gear as assembly (Fig. 194).

Page 1946 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (5) Remove sun gear and driving shell as assembly
(Fig. 197).
(6) Remove tabbed thrust washer from rear plane-
tary gear (Fig. 198). Note washer position on gear for
assembly reference.
(7) Remove rea

Page 1947 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual thrust plate if worn, or severely scored. Replace the
driving shell if distorted, cracked, or damaged in any
way.
Replace all snap-rings during geartrain assembly.
Reusing snap-rings is not recommende

Page 1948 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (6) Install tabbed thrust washer on front face of
rear planetary gear (Fig. 205). Seat washer tabs in
matching slots in face of gear carrier. Use extra
petroleum jelly to hold washer in place if desir

Page 1949 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (12) Install front annulus gear over and onto front
planetary gear (Fig. 209). Be sure gears are fully
meshed and seated.
(13) Install front planetary and annulus gear
assembly (Fig. 210). Hold gears

Page 1950 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (17) Check planetary geartrain end play with
feeler gauge (Fig. 212). Insert gauge between rear
annulus gear and shoulder on intermediate shaft as
shown. End play should be 0.15 to 1.22 mm (0.006 to
0
