(2) Disconnect wire harness connector to power
mirror switch (Fig. 1).
(3) Using two jumper wires:
²Connect one to a 12 volt source
²Connect the other to a good body ground
²Refer to the Mirror Motor Test Chart for proper
wire connections at the switch connector
MIRROR MOTOR TEST CHART
12 VOLTS GROUND MIRROR REACTION
SWITCH CONNECTOR RIGHT LEFT
PIN 1 PIN 2 - UP
PIN 6 PIN 2 - LEFT
PIN 2 PIN 1 - DOWN
PIN 2 PIN 6 - RIGHT
PIN 7 PIN 2 UP -
PIN 4 PIN 2 LEFT -
PIN 2 PIN 7 DOWN -
PIN 2 PIN 4 RIGHT -
(4) If results shown in table are not obtained,
check for open or shorted circuit. Replace mirror
assembly as necessary.
AUTOMATIC DAY / NIGHT
MIRROR
DESCRIPTION
The automatic day/night mirror uses a thin layer
of electrochromic material between two pieces of con-
ductive glass to make up the face of the mirror.
When the mirror switch is in the On position, two
photocell sensors are used by the mirror circuitry to
monitor external light levels and adjust the reflec-
tance of the mirror.
OPERATION
The ambient photocell sensor is located on the for-
ward-facing (windshield side) of the rear view mirror
housing, and detects the ambient light levels outside
of the vehicle. The headlamp photocell sensor is
located inside the rear view mirror housing behind
the mirror glass and faces rearward, to detect the
level of the light being received at the rear window
side of the mirror. When the circuitry of the auto-
matic day/night mirror detects that the difference
between the two light levels is too great (the light
level received at the rear of the mirror is much
higher than that at the front of the mirror), it begins
to darken the mirror.
The automatic day/night mirror circuitry also mon-
itors the transmission using an input from the
backup lamp circuit. The mirror circuitry is pro-
grammed to automatically disable its self-dimming
feature whenever it senses that the transmission
backup lamp circuit is energized.
The automatic day/night mirror is a completely
self-contained unit and cannot be repaired. If faulty
or damaged, the entire mirror assembly must be
replaced.
DIAGNOSIS AND TESTING - AUTOMATIC DAY /
NIGHT MIRROR
For complete circuit diagrams, refer to the appro-
priate wiring information.
(1) Check the fuse in the Integrated Power Module
(IPM). If OK, go to Step 2. If not OK, repair the
shorted circuit or component as required and replace
the faulty fuse.
(2) Turn the ignition switch to the On position.
Check for battery voltage at the fuse in the IPM. If
OK, go to Step 3. If not OK, repair the open circuit to
the ignition switch as required.
(3) Turn the ignition switch to the Off position.
Disconnect and isolate the battery negative cable.
Unplug the wire harness connector from the auto-
matic day/night mirror (Fig. 2). Connect the battery
negative cable. Turn the ignition switch to the On
position. Check for battery voltage at the fused igni-
tion switch output (run/start) circuit cavity of the
automatic day/night mirror wire harness connector. If
OK, go to Step 4. If not OK, repair the open circuit to
the IPM as required.
(4) Turn the ignition switch to the Off position.
Disconnect and isolate the battery negative cable.
Check for continuity between the ground circuit cav-
ity of the automatic day/night mirror wire harness
connector and a good ground. There should be conti-
nuity. If OK, go to Step 5. If not OK, repair the cir-
cuit to ground as required.
Fig. 1 POWER MIRROR SWITCH CONNECTOR
DRPOWER MIRRORS 8N - 11
POWER MIRRORS (Continued)

POWER WINDOWS
TABLE OF CONTENTS
page page
POWER WINDOWS
DESCRIPTION.........................19
OPERATION...........................19
DIAGNOSIS AND TESTING - POWER
WINDOWS...........................19
WINDOW MOTOR
REMOVAL.............................20WINDOW SWITCH
DIAGNOSIS AND TESTING - WINDOW
SWITCH............................20
REMOVAL.............................20
INSTALLATION.........................21
POWER WINDOWS
DESCRIPTION
The power window system allows each of the door
windows to be raised and lowered electrically by
actuating a switch on each door panel. A master
switch on the drivers door allows the driver to raise
or lower each of the passenger door windows and to
lock out the individual switches on the passenger
doors from operation. The power window system
receives battery feed through a fuse in the Integrated
Power Module (IPM) and a circuit breaker located in
the instrument panel wiring harness near the park
brake pedal, only when the ignition switch is in the
RUN or ACCESSORY position.
OPERATION
WINDOW SWITCH
The power window switches control the battery
and ground feeds to the power window motors. The
passenger door power window switches receive their
battery and ground feeds through the circuitry of the
drivers window switch. When the power window lock-
out switch is in the Lock position, the battery feed
for the passenger door window switches is inter-
rupted.
WINDOW MOTOR
Window motors use permanent type magnets. The
B+ and ground applied at the motor terminal pins
will cause the motor to rotate in one direction.
Reversing current through the motor terminals will
cause the motor to rotate in the opposite direction.
DIAGNOSIS AND TESTING - POWER
WINDOWS
WIRING VOLTAGE TEST
The following wiring test determines whether or
not voltage is continuous through the body harness
to the front switch.
(1) Remove the Driver Door Module (Refer to 8 -
ELECTRICAL/POWER LOCKS/DOOR MODULE -
REMOVAL).
(2) Disconnect wire connector from back of power
window switch.
(3) Switch ignition to the ON position.
(4) Connect the clip end of a 12 volt test light to
Pin 14 of the window switch harness connector.
Touch the test light probe to Pin 10.
²If the test light illuminates, the wiring circuit
between the battery and switch is OK.
²If the lamp does not illuminate, first check the
fuse in the Integrated Power Module (IPM). Check
the circuit breaker located near the park brake
pedal. If fuse and circuit breaker are OK, then check
for a broken wire.
Refer to the appropriate wiring information.
POWER WINDOW MOTOR TEST
If the power window motor is receiving proper cur-
rent and ground and does not operate, proceed with
motor test.
(1) Remove front door trim panel as necessary to
gain access to power window motor wire connector
(Refer to 23 - BODY/DOOR - FRONT/TRIM PANEL -
REMOVAL).
(2) Disconnect power window motor wire connector
from door harness.
(3) Using two jumper wires, connect one to a bat-
tery (+) source and the other to a good ground (-).
(4) Connect the Negative (-) jumper probe to one of
the motor connector terminals.
DRPOWER WINDOWS 8N - 19

(5) Momentarily touch the Positive (+) jumper
probe to the other motor connector terminal.
When positive probe is connected the motor should
rotate in one direction to either move window up or
down. If window is all the way up or down the motor
will grunt and the inner door panel will flex when
actuated in that one direction.
(6) Reverse jumper probes at the motor connector
terminals and window should now move in opposite
direction. If window does not move or grunt, replace
the motor.
If window moved completely up or down, reverse
the jumper probes and cycle window to the opposite
position to verify full operation.
If motor grunts and does not move, verify that reg-
ulator is not binding.
WINDOW MOTOR
REMOVAL
The window motor is serviced with the window
regulator (Refer to 23 - BODY/DOOR - FRONT/WIN-
DOW REGULATOR - REMOVAL) or (Refer to 23 -
BODY/DOORS - REAR/WINDOW REGULATOR -
REMOVAL).
WINDOW SWITCH
DIAGNOSIS AND TESTING - WINDOW SWITCH
The Light-Emitting Diode (LED) illumination
lamps for all of the power window and lock switch
and bezel unit switch paddles receive battery current
through the power window circuit breaker in the
junction block. If all of the LEDs are inoperative in
both the power window and lock switch units and the
power windows are inoperative, (Refer to 8 - ELEC-
TRICAL/POWER WINDOWS - DIAGNOSIS AND
TESTING). If the power windows operate, but any or
all of the LEDs are inoperative, the power window
and lock switch units with the inoperative LED(s) is
faulty and must be replaced. For complete circuit dia-
grams, refer to the appropriate wiring information.
(1) Check the fuse in the Integrated Power Module
(IPM) and the circuit breaker located near the park
brake pedal. If OK, go to Step 2. If not OK, replace
the faulty fuse or circuit breaker.
(2) Turn the ignition switch to the On position.
Check for battery voltage at the fuse in the Inte-
grated Power Module (IPM). If OK, turn the ignition
switch to the Off position and go to Step 3. If not OK,
check circuit breaker and repair the circuit to the
ignition switch as required.
(3) Disconnect and isolate the battery negative
cable. Remove the power window switch unit fromthe door trim panel (passenger doors). The drivers
door switch is included with the Driver Door Module
(Refer to 8 - ELECTRICAL/POWER LOCKS/DOOR
MODULE - DIAGNOSIS AND TESTING) for service
procedures. Unplug the wire harness connector from
the switch unit.
(4) Test the power window switch continuity. See
the Power Window Switch Continuity charts to deter-
mine if the continuity is correct in the Off, Up and
Down switch positions (Fig. 1). If OK, (Refer to 8 -
ELECTRICAL/POWER WINDOWS - DIAGNOSIS
AND TESTING). If not OK, replace the faulty switch.
POWER WINDOW SWITCH CONTINUITY
CHART
SWITCH POSITION CONTINUITY BETWEEN
NEUTRAL PIN 2 AND 5, PIN 4 AND
1
UP (FRONT
PASSENGER)PIN 6 AND 5
UP (REAR
PASSENGER)PIN 6 AND 1
DOWN (FRONT
PASSENGER)PIN 6 AND 1
DOWN (REAR
PASSENGER)PIN 6 AND 5
REMOVAL
FRONT PASSENGER
(1) Disconnect and isolate the battery negative
cable.
(2) Remove the door trim panel (Refer to 23 -
BODY/DOOR - FRONT/TRIM PANEL - REMOVAL).
(3) Remove the switch from the trim panel bezel.
Fig. 1 PASSENGER DOOR SWITCH
8N - 20 POWER WINDOWSDR
POWER WINDOWS (Continued)

Component Page
Manifold Absolute Pressure Sensor........ 8W-30
Mode Door Actuators................... 8W-42
Multi-Function Switch............ 8W-40, 52, 53
Natural Vacuum Leak Detection Assembly . . 8W-30
Output Speed Sensor................... 8W-31
Overhead Map/Reading Lamp......... 8W-44, 49
Oxygen Sensor Downstream Relay........ 8W-30
Oxygen Sensors....................... 8W-30
Park Brake Switch.................... 8W-40
Park Lamp Relay................... 8W-50, 52
Park/Turn Signal Lamps............. 8W-50, 52
Power Mirrors........................ 8W-62
Power Outlets........................ 8W-41
Power Seat Motors.................... 8W-63
Power Seat Switches................... 8W-63
Power Steering Pressure Switch.......... 8W-30
Power Window Circuit Breaker........... 8W-10
Power Window Motors.................. 8W-60
Power Window Switches................ 8W-60
Powertrain Control Module.............. 8W-30
PTCS............................... 8W-10
PTO Switch.......................... 8W-30
Radio............................... 8W-47
Rear Window Defogger Relay............ 8W-48
Recirculation Door Actuator............. 8W-42
Remote Radio Switches................. 8W-47
Seat Belt Pretensioners................. 8W-43
Seat Belt Switch-Driver................ 8W-40
Seat Belt Tensioner Reducer............. 8W-40
Seat Heater Interface Module............ 8W-63
Sentry Key Immobilizer Module.......... 8W-39
Side Impact Sensors................... 8W-43
Speakers............................ 8W-47Component Page
Speed Control Servo................... 8W-33
Speed Control Switches................. 8W-33
Splices.............................. 8W-70
Starter Motor........................ 8W-21
Starter Motor Relay................... 8W-21
Tail/Stop Lamp....................... 8W-52
Tail/Stop/Turn Signal Lamps.......... 8W-51, 52
Tail/Turn Lamp....................... 8W-52
Tailgate Lamp........................ 8W-51
Throttle Position Sensor................ 8W-30
Tow/Haul Overdrive Switch........... 8W-30, 31
Trailer Tow Connectors................. 8W-54
Trailer Tow Relays.................... 8W-54
Transfer Case Control Module............ 8W-31
Transfer Case Mode Sensor.............. 8W-31
Transfer Case Selector Switch............ 8W-31
Transfer Case Shift Motor............... 8W-31
Transmission Control Relay............. 8W-31
Transmission Range Sensor.............. 8W-31
Transmission Solenoid Assembly.......... 8W-31
Transmission Solenoid/TRS Assembly...... 8W-31
Underhood Lamp...................... 8W-44
Vacuum Pump........................ 8W-30
Vistronic Fan Drive................. 8W-30, 70
Washer Fluid Level Switch.............. 8W-53
Washer Pump Motor-Front.............. 8W-53
Water In Fuel Sensor.................. 8W-30
Wheel Speed Sensors................... 8W-35
Wiper High/Low Relay................. 8W-53
Wiper Motor-Front.................... 8W-53
Wiper On/Off Relay.................... 8W-53
8W - 02 - 2 8W-02 COMPONENT INDEXDR

8W-10 POWER DISTRIBUTION
Component Page
A/C Compressor Clutch....................8W-10-17, 40
A/C Compressor Clutch Relay.................8W-10-17, 40
A/C-Heater Control....................8W-10-42, 43, 49
Adjustable Pedal Relay....................8W-10-15, 32
Adjustable Pedal Switch..................8W-10-15, 32, 42
Airbag Control Module.....................8W-10-42, 44
Airbag-Passenger On/Off Switch.................8W-10-42
Ambient Temperature Sensor.................8W-10-48, 50
Amplifier Audio..........................8W-10-31
Ashtray Lamp...........................8W-10-35
Auto Shut Down Relay....................8W-10-12, 19
Automatic Day/Night Mirror.................8W-10-41, 48
Auxiliary Battery.........................8W-10-12
Backup Lamp Switch.....................8W-10-44, 49
Battery.............................8W-10-12, 19
Blower Motor............................8W-10-52
Brake Lamp Switch....................8W-10-14, 30, 40
Capacitor..............................8W-10-22
Cigar Lighter Outlet........................8W-10-46
Circuit Breaker...........................8W-10-52
Clearance Lamp No. 1.......................8W-10-35
Clearance Lamp No. 2.......................8W-10-35
Clearance Lamp No. 3.......................8W-10-35
Clearance Lamp No. 4.......................8W-10-35
Clearance Lamp No. 5.......................8W-10-35
Clutch Interlock Brake Switch..................8W-10-37
Coil On Plug No. 1.......................8W-10-20, 23
Coil On Plug No. 2.......................8W-10-21, 22
Coil On Plug No. 3.......................8W-10-20, 23
Coil On Plug No. 4.......................8W-10-21, 22
Coil On Plug No. 5.......................8W-10-20, 23
Coil On Plug No. 6.......................8W-10-21, 22
Coil On Plug No. 7.......................8W-10-20, 23
Coil On Plug No. 8.......................8W-10-21, 22
Compass/Mini-Trip Computer...............8W-10-31, 39, 41
Condenser Fan.........................8W-10-18, 45
Condenser Fan Relay.....................8W-10-18, 45
Controller Antilock Brake.................8W-10-14, 28, 44
Data Link Connector......................8W-10-30, 50
Door Lock Switch-Passenger....................8W-10-41
Driver Door Module....................8W-10-15, 32, 52
Electric Backlight.........................8W-10-49
Electric Brake Provision....................8W-10-12, 19
Engine Control Module................8W-10-12, 26, 38, 40
Fender Lamp-Front Left......................8W-10-35
Fender Lamp-Front Right.....................8W-10-35
Fender Lamp-Rear Left......................8W-10-35
Fender Lamp-Rear Right.....................8W-10-35
Fog Lamp Relay........................8W-10-16, 36
Fog Lamp-Left...........................8W-10-36
Fog Lamp-Right..........................8W-10-36
Front Control Module . 8W-10-13, 26, 29, 30, 32, 33, 34, 36, 47, 48, 50, 51
Fuel Heater............................8W-10-53
Fuel Heater Relay.....................8W-10-18, 40, 53
Fuel Injector No. 1.......................8W-10-23, 24
Fuel Injector No. 2.......................8W-10-21, 22
Fuel Injector No. 3.......................8W-10-23, 24
Fuel Injector No. 4.......................8W-10-21, 22
Fuel Injector No. 5.......................8W-10-23, 24
Fuel Injector No. 6.......................8W-10-21, 22
Fuel Injector No. 7.......................8W-10-23, 24
Fuel Injector No. 8.......................8W-10-21, 22
Fuel Pump Module.......................8W-10-17, 39
Fuel Pump Relay......................8W-10-17, 39, 40
Fuse 1.............................8W-10-12, 19
Fuse 2...........................8W-10-12, 13, 19
Fuse 3.............................8W-10-13, 25
Fuse 4.............................8W-10-13, 25
Fuse 5.......................8W-10-12, 13, 14, 26, 27
Fuse 6...........................8W-10-13, 14, 28
Fuse 7.............................8W-10-14, 28
Fuse 8.............................8W-10-15, 29
Fuse 9.............................8W-10-13, 25
Fuse 10.............................8W-10-13, 25
Fuse 11...........................8W-10-13, 14, 30
Fuse 12...........................8W-10-18, 45, 53
Fuse 13.............................8W-10-13, 30
Fuse 14.............................8W-10-15, 37
Fuse 15...........................8W-10-16, 17, 34
Fuse 16.............................8W-10-17, 40
Fuse 17...........................8W-10-17, 18, 39
Fuse 18.............................8W-10-14, 30
Fuse 19.............................8W-10-14, 31
Fuse 20.............................8W-10-13, 25
Fuse 21.............................8W-10-14, 31
Fuse 22.............................8W-10-14, 31
Fuse 23.............................8W-10-14, 31
Fuse 24.............................8W-10-14, 30Component Page
Fuse 25.............................8W-10-14, 31
Fuse 26...............................8W-10-49
Fuse 27...........................8W-10-17, 18, 43
Fuse 28.............................8W-10-40, 41
Fuse 29...............................8W-10-46
Fuse 32.............................8W-10-17, 34
Fuse 33.............................8W-10-17, 34
Fuse 34.............................8W-10-17, 34
Fuse 35...............................8W-10-44
Fuse 36...............................8W-10-43
Fuse 37...............................8W-10-44
Fuse 38.............................8W-10-43, 44
Fuse 40...........................8W-10-15, 16, 32
Fuse 41.............................8W-10-16, 36
Fuse 42.............................8W-10-14, 32
Fuse 43.............................8W-10-14, 32
Fuse 45...........................8W-10-16, 17, 36
Fuse 46...........................8W-10-15, 16, 33
Fuse 47.............................8W-10-16, 33
Fuse 48.............................8W-10-15, 32
Fuse 49.............................8W-10-12, 19
Fuse 50.............................8W-10-26, 40
Fuse 51...........................8W-10-14, 15, 30
Fuse 52.............................8W-10-43, 44
Fuse 53...............................8W-10-41
Fusible Link............................8W-10-12
G104........................8W-10-27, 29, 47, 48, 53
G201................................8W-10-25
Generator..............................8W-10-12
Headlamp Switch.........................8W-10-36
Headlamp-Left...........................8W-10-51
Headlamp-Right..........................8W-10-51
Heated Mirror Relay......................8W-10-18, 43
Horn Relay...........................8W-10-16, 36
Horn-High Note..........................8W-10-36
Horn-Low Note...........................8W-10-36
Ignition Switch...............8W-10-13, 25, 37, 41, 44, 46, 52
Instrument Cluster............8W-10-14, 25, 30, 31, 41, 46, 52
Integrated Power Module . . 8W-10-3, 4, 12, 13, 14, 15, 16, 17, 18, 19, 25,
26, 27, 28, 29, 30, 31, 32, 33, 34, 36, 37, 39, 40, 41, 42, 43, 44, 45, 46,
47, 48, 49, 50, 51, 53
License Lamp-Left.........................8W-10-34
License Lamp-Right........................8W-10-34
Oxygen Sensor Downstream Relay..............8W-10-12, 19
Park Lamp Relay.......................8W-10-17, 34
Park/Turn Signal Lamp-Left Front..............8W-10-34, 47
Park/Turn Signal Lamp-Right Front.............8W-10-34, 47
Passenger Lumbar Switch.....................8W-10-28
Power Mirror-Left.........................8W-10-43
Power Mirror-Right........................8W-10-43
Power Outlet..........................8W-10-14, 31
Power Outlet-Console.....................8W-10-14, 32
Power Seat Switch-Driver.....................8W-10-28
Power Seat Switch-Passenger...................8W-10-28
Power Window Circuit Breaker..................8W-10-52
Powertrain Control Module . . 8W-10-18, 19, 22, 27, 31, 37, 39, 40, 45, 52
PTCNo.1 .........................8W-10-39, 40, 41
PTCNo.2 .............................8W-10-46
PTCNo.5 .............................8W-10-33
Radio..............................8W-10-30, 46
Rear Window Defogger Relay...................8W-10-49
Seat Belt Tensioner Reducer....................8W-10-46
Seat Heater Interface Module...................8W-10-32
Sentry Key Immobilizer Module..............8W-10-31, 39, 40
Starter Motor..........................8W-10-15, 37
Starter Motor Relay......................8W-10-15, 37
Tail/Stop/Turn Signal Lamp-Left...........8W-10-34, 47, 48, 50
Tail/Stop/Turn Signal Lamp-Right..........8W-10-35, 47, 48, 50
Tailgate Lamp...........................8W-10-34
Trailer Tow Connector.................8W-10-16, 17, 33, 34
Trailer Tow Connector-Add On..........8W-10-14, 31, 33, 34, 48
Trailer Tow Left Turn Relay..................8W-10-16, 33
Trailer Tow Right Turn Relay.................8W-10-16, 33
Transfer Case Control Module...............8W-10-14, 32, 37
Transfer Case Selector Switch...................8W-10-41
Transmission Control Relay................8W-10-13, 26, 27
Transmission Range Sensor................8W-10-38, 44, 49
Transmission Solenoid Assembly.................8W-10-26
Transmission Solenoid/TRS Assembly...........8W-10-27, 44, 49
Underhood Lamp..........................8W-10-30
Vistronic Fan Drive........................8W-10-43
Washer Fluid Level Switch....................8W-10-48
Washer Pump Motor-Front....................8W-10-48
Wiper High/Low Relay.....................8W-10-15, 29
Wiper Motor-Front.......................8W-10-29, 48
Wiper On/Off Relay......................8W-10-15, 29
DR8W-10 POWER DISTRIBUTION 8W - 10 - 1

8W-60 POWER WINDOWS
Component Page
Circuit Breaker................... 8W-60-2, 4
Driver Door Module........ 8W-60-2, 3, 4, 5, 6, 7
G302............................ 8W-60-2, 4
Ignition Switch...................... 8W-60-2
Power Window Circuit Breaker....... 8W-60-2, 4
Power Window Motor-Driver......... 8W-60-2, 4Component Page
Power Window Motor-Left Rear......... 8W-60-7
Power Window Motor-Passenger....... 8W-60-3, 5
Power Window Motor-Right Rear........ 8W-60-6
Power Window Switch-Left Rear...... 8W-60-4, 7
Power Window Switch-Passenger.... 8W-60-3, 4, 5
Power Window Switch-Right Rear..... 8W-60-4, 6
DR8W-60 POWER WINDOWS 8W - 60 - 1

Component Page
Fuel Pump Module.................. 8W-80-66
Fuel Pump Motor (Diesel)............ 8W-80-66
Generator......................... 8W-80-67
Glove Box Lamp And Switch.......... 8W-80-67
Hands Free Module (Telematics)....... 8W-80-67
Headlamp Switch................... 8W-80-68
Headlamp-Left..................... 8W-80-68
Headlamp-Right.................... 8W-80-68
Heated Seat Cushion-Driver........... 8W-80-68
Heated Seat Cushion-Passenger........ 8W-80-69
Heated Seat Switch-Driver............ 8W-80-69
Heated Seat Switch-Passenger......... 8W-80-69
Horn Switch....................... 8W-80-69
Horn-High Note.................... 8W-80-70
Horn-Low Note..................... 8W-80-70
Idle Air Control Motor (3.7L/4.7L)...... 8W-80-70
Ignition Switch..................... 8W-80-70
Inlet Air Temperature Sensor.......... 8W-80-71
Input Speed Sensor (45RFE).......... 8W-80-71
Instrument Cluster C1............... 8W-80-71
Instrument Cluster C2............... 8W-80-72
Instrument Cluster C3............... 8W-80-72
Intake Air Temperature Sensor (Gas).... 8W-80-73
Intake Air Temperature/Manifold Absolute
Pressure Sensor (Diesel)............ 8W-80-73
Integrated Power Module C1.......... 8W-80-73
Integrated Power Module C2.......... 8W-80-74
Integrated Power Module C3.......... 8W-80-74
Integrated Power Module C4.......... 8W-80-75
Integrated Power Module C5.......... 8W-80-75
Integrated Power Module C6.......... 8W-80-76
Integrated Power Module C7.......... 8W-80-76
Knock Sensor (3.7L)................. 8W-80-77
Knock Sensor-Left (5.7L)............. 8W-80-77
Knock Sensor-Right (5.7L)............ 8W-80-77
License Lamp-Left.................. 8W-80-77
License Lamp-Right................. 8W-80-77
Lift Pump Motor (Diesel)............. 8W-80-78
Line Pressure Sensor (NGC)........... 8W-80-78
Lumbar Motor-Driver................ 8W-80-78
Lumbar Motor-Passenger............. 8W-80-78
Manifold Absolute Pressure Sensor
(NGC).......................... 8W-80-79
Mode Door Actuator 1 (Panel To Floor) . . . 8W-80-79
Mode Door Actuator 2 (Defrost To Floor) . 8W-80-79
Multi-Function Switch............... 8W-80-79
Natural Vacuum Leak Detection Assembly
(NGC).......................... 8W-80-80
Output Speed Sensor (45RFE)......... 8W-80-80
Output Speed Sensor (47RE).......... 8W-80-80
Overhead Map/reading Lamp (Except
Base).......................... 8W-80-80
Oxygen Sensor 1/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 1/2 Downstream (NGC) . . 8W-80-81Component Page
Oxygen Sensor 2/1 Upstream (NGC).... 8W-80-81
Oxygen Sensor 2/2 Downstream (NGC) . . 8W-80-81
Park/Turn Signal Lamp-Left Front...... 8W-80-82
Park/Turn Signal Lamp-Right Front.... 8W-80-82
Passenger Blend Door Actuator (Dual-
Zone).......................... 8W-80-82
Passenger Lumbar Switch............ 8W-80-82
Power Mirror-Left................... 8W-80-82
Power Mirror-Right................. 8W-80-83
Power Outlet...................... 8W-80-83
Power Outlet-Console (Except Base)..... 8W-80-83
Power Seat Motor-Driver Front Vertical . . 8W-80-83
Power Seat Motor-Driver Horizontal.... 8W-80-84
Power Seat Motor-Driver Rear Vertical . . 8W-80-84
Power Seat Motor-Passenger Front
Vertical......................... 8W-80-84
Power Seat Motor-Passenger Horizontal . 8W-80-84
Power Seat Motor-Passenger Rear
Vertical......................... 8W-80-84
Power Seat Switch-Driver............ 8W-80-85
Power Seat Switch-Passenger.......... 8W-80-85
Power Steering Pressure Switch (NGC) . . 8W-80-85
Power Window Circuit Breaker........ 8W-80-86
Power Window Motor-Driver.......... 8W-80-86
Power Window Motor-Left Rear........ 8W-80-86
Power Window Motor-Passenger........ 8W-80-86
Power Window Motor-Right Rear....... 8W-80-87
Power Window Switch-Left Rear....... 8W-80-87
Power Window Switch-Passenger....... 8W-80-87
Power Window Switch-Right Rear...... 8W-80-87
Powertrain Control Module C1 (NGC) . . . 8W-80-88
Powertrain Control Module C2 (NGC) . . . 8W-80-89
Powertrain Control Module C3 (NGC) . . . 8W-80-90
Powertrain Control Module C4 (NGC) . . . 8W-80-91
Radio C1 (Except Infinity)............ 8W-80-92
Radio C1 (Infinity).................. 8W-80-92
Radio C2.......................... 8W-80-93
Recirculation Door Actuator........... 8W-80-93
Remote Radio Switch-Left............ 8W-80-93
Remote Radio Switch-Right........... 8W-80-93
Seat Belt Switch-Driver.............. 8W-80-94
Seat Belt Tensioner Reducer (Standard
Cab)........................... 8W-80-94
Seat Belt Tensioner-Driver............ 8W-80-94
Seat Belt Tensioner-Passenger......... 8W-80-94
Seat Heater Interface Module.......... 8W-80-94
Sentry Key Immobilizer Module (SKIM) . . 8W-80-95
Side Impact Sensor-Left.............. 8W-80-95
Side Impact Sensor-Right............. 8W-80-95
Speaker-Center Instrument Panel...... 8W-80-95
Speaker-Left Front Door.............. 8W-80-95
Speaker-Left Instrument Panel........ 8W-80-96
Speaker-Left Rear.................. 8W-80-96
Speaker-Right Front Door............ 8W-80-96
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

C301 - (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 P195 18LG/YL (POWER WINDOWS/
LOCKS)
3 P72 18TN/GY (POWER WINDOWS/
LOCKS)
4 X154 18GY/YL
5 X156 18GY/LB
6 P74 18TN/OR (POWER WINDOWS/
LOCKS)
7 Q15 14OR/LB (POWER WINDOWS/
LOCKS)
8-
9-
10 Z74 20BK/WT (EXCEPT POWER WIN-
DOWS/LOCKS)
10 Z461 20BK/DG (POWER WINDOWS/
LOCKS)
C302 (SLT) - (BODY SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9 G162 20VT/LB
10 P392 18LG/DB
11 Z216 18BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 33

C302 - BLACK (PASSENGER DOOR SIDE)
CAV CIRCUIT
1 F21 20PK/DG
2-
3-
4 G778 18VT/LB
5-
6 G160 20VT/LG
7 Q16 14OR/TN
8 Q26 14OR/GY
9-
10 P392 18LG/DB
11 Z216 20BK/DB
12 -
13 C16 18DB/GY
14 -
15 -
16 -
C304 - (BODY SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (SLT)
3 P72 18TN/GY (SLT)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (SLT)
7 F30 12PK/YL (SLT)
8 Q15 12OR/LB (SLT)
9 A930 18RD (SLT)
10 Z75 20BK/VT
C304 - (DRIVER DOOR SIDE)
CAV CIRCUIT
1 G75 20VT
2 P195 18LG/YL (POWER WINDOW/
LOCKS)
3 P72 20TN/GY (POWER WINDOW/
LOCKS EXCEPT SECURITY)
3 P72 18 TN/GY (SECURITY)
4 X153 18DG/YL
5 X155 18DG/LB
6 P74 18TN/OR (POWER WINDOW/
LOCKS)
7 F30 14PK/YL (POWER WINDOW/
LOCKS)
8 Q15 14OR/LB (POWER WINDOW/
LOCKS)
9 A930 18RD (POWER WINDOW/LOCKS)
10 Z75 20BK/VT (EXCEPT SECURITY)
10 Z463 20BK/LB (SECURITY)
8W - 80 - 34 8W-80 CONNECTOR PIN-OUTSDR

C306 - (REAR DOOR SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/GY
3 P393 18LG (POWER WINDOW/LOCKS)
4 P5 18TN/OR (POWER WINDOW/LOCKS)
5 Q15 14OR/LB (POWER WINDOW/
LOCKS)
6 Q411 14OR/WT (POWER WINDOW/
LOCKS)
7 Q611 14OR/GY (POWER WINDOW/
LOCKS)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C306 - NATURAL (BODY SIDE)
CAV CIRCUIT
1 Z79 20LG/BK
2 G77 20VT/OR
3 P393 18LG (SLT)
4 P5 18TN/OR (SLT)
5 Q15 14OR/LB (SLT)
6 Q411 14OR/WT (SLT)
7 Q611 14OR/GY (SLT)
8 X295 18GY/DG
9 X205 18GY/LG
10 -
C308 - (BODY SIDE)
CAV CIRCUIT
1 G74 20VT/WT
2 G162 20VT/LB (SLT)
3 D25 20WT/VT
4 X154 18GY/YL
5 G160 20VT/LG (SLT)
6 G76 20TN/YL
7 F201 18PK/OR
8 P392 18LG/DB (SLT)
9 G778 18VT/LB (SLT)
10 F21 20PK/DG (SLT)
11 -
12 -
13 -
14 X206 18DG/LG
15 X296 18DG/GY
16 -
17 -
18 Z105 18BK
19 X156 18GY/LB
8W - 80 - 36 8W-80 CONNECTOR PIN-OUTSDR
