Page 1089 of 2627
C316 - (PASSENGER SEAT SIDE)
CAV CIRCUIT
1 P89 20LG/OR
2 P54 20OR/LG
3 A210 12OR/RD
4 Z939 14BK
5 P188 18LG/VT
6-
C319 - (CENTER CONSOLE SIDE)
CAV CIRCUIT
1 Z939 18BK
2 A405 18RD/DB
C319 - (SEAT JUMPER SIDE)
CAV CIRCUIT
1 A405 12RD/DB (EXCEPT HEATED SEAT)
1 Z939 14BK (HEATED SEAT)
2 Z939 14BK (EXCEPT HEATED SEAT)
2 A405 12RD/DB (HEATED SEAT)
C320 - (RIGHT REAR DOOR SIDE)
CAV CIRCUIT
1 Z72 20LG/BK
2 G76 20VT/GY
3 P392 18LG (POWER WINDOW/LOCKS)
4 G778 18TN/OR (POWER WINDOW/
LOCKS)
5 Q15 14TN/LG (POWER WINDOW/
LOCKS)
6 Q412 14OR/WT (POWER WINDOW/
LOCKS)
7 Q612 14OR/GY (POWER WINDOW/
LOCKS)
8 X296 18GY/DG
9 X206 18GY/LG
10 -
8W - 80 - 40 8W-80 CONNECTOR PIN-OUTSDR
Page 1106 of 2627
DRIVER DOOR MODULE C1 - BLUE 12 WAY
CAV CIRCUIT FUNCTION
1 Q612 14OR/DB RIGHT REAR WINDOW DRIVER (DOWN)
2 Q412 14OR/LB RIGHT REAR WINDOW DRIVER (UP)
3 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
6 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
7 G161 20VT/DG DRIVER DOOR LOCK SWITCH MUX
8 Z421 14BK/BR GROUND
9 F30 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
11 Z941 20BK GROUND
12 Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
DRIVER DOOR MODULE C2 - BLUE 8 WAY
CAV CIRCUIT FUNCTION
1 P71 18TN/DG LEFT MIRROR UP DRIVER
2 P195 18LG/YL LEFT MIRROR COMMON DRIVER (RIGHT/DOWN)
3 A930 18RD FUSED B(+)
4 P74 18TN/OR RIGHT MIRROR LEFT DRIVER
5 Z461 20BK/DG GROUND
6 P75 18TN/LG LEFT MIRROR LEFT DRIVER
7 P72 18TN/GY RIGHT MIRROR UP DRIVER
8 Q15 14OR/LB POWER WINDOW SWITCH FEED
EGR SOLENOID (4.7L/5.7L)-6WAY
CAV CIRCUIT FUNCTION
1 K34 18DB/LG EGR SENSOR SIGNAL
2 F856 20YL/PK 5 VOLT SUPPLY
3 K900 20DB/DG SENSOR GROUND
4 Z335 18BK/WT GROUND
5- -
6 K35 18DB/VT EGR SOLENOID CONTROL
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 57
Page 1119 of 2627
HORN-HIGH NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z299 18BK/OR GROUND
HORN-LOW NOTE-2WAY
CAV CIRCUIT FUNCTION
1 X2 18DG/OR HORN RELAY OUTPUT
2 Z298 18BK/DB GROUND
IDLE AIR CONTROL MOTOR (3.7L/4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K961 18BR/VT IAC RETURN
2 K61 18VT/GY IAC MOTOR CONTROL
IGNITION SWITCH - BLACK 14 WAY
CAV CIRCUIT FUNCTION
1 A970 10RD FUSED B(+)
2 F1 16PK/WT FUSED IGNITION SWITCH OUTPUT (OFF-RUN-START)
3 F951 16PK/LG FUSED IGNITION SWITCH OUTPUT (RUN-START)
4 A951 16RD FUSED B(+)
5 G15 20VT/TN KEY IN IGNITION SWITCH SENSE
6 Z943 20BK GROUND
7 A921 16RD FUSED B(+)
8 C7 10DB BLOWER MOTOR FEED
9 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10 F991 10PK/YL (POWER WINDOWS) FUSED IGNITION SWITCH OUTPUT (RUN-START)
11 A981 14RD FUSED B(+)
12 A991 10RD (POWER WINDOWS) FUSED B(+)
13 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
14 F922 16PK/YL FUSED IGNITION SWITCH OUTPUT (RUN)
8W - 80 - 70 8W-80 CONNECTOR PIN-OUTSDR
Page 1125 of 2627
INTEGRATED POWER MODULE C6 - BLACK 15 WAY
CAV CIRCUIT FUNCTION
1- -
2 A400 14TN/RD FUSED B(+)
3- -
4 K342 16BR/WT ASD RELAY OUTPUT
5- -
6- -
7- -
8- -
9- -
10 A961 14RD (DIESEL) FUEL HEATER RELAY OUTPUT
10 C123 16LB/WT (NGC) CONDENSER FAN RELAY OUTPUT
11 A960 14RD (DIESEL) FUSED B(+)
11 A16 16RD/BR (NGC) FUSED B(+)
12 F982 14PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
13 - -
14 T16 18YL/OR TRANSMISSION CONTROL RELAY OUTPUT
15 - -
INTEGRATED POWER MODULE C7 - GRAY 26 WAY
CAV CIRCUIT FUNCTION
1 T750 14YL/GY STARTER MOTOR RELAY OUTPUT
2 W3 16BR/WT WIPER RELAY LOW SPEED OUTPUT
3 F983 20PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
4 A930 18RD FUSED B(+)
5- -
6 L43 18WT/DB LEFT LOW BEAM OUTPUT
7 L34 18WT/GY RIGHT HIGH BEAM OUTPUT
8- -
9 A109 16OR/RD (GAS) FUEL PUMP RELAY OUTPUT
10 - -
11 K51 20BR/WT (GAS) ASD RELAY CONTROL
13 - -
14 - -
15 L33 18WT/LG LEFT HIGH BEAM OUTPUT
16 - -
16 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT
17 - -
17 C15 16DB/WT REAR WINDOW DEFOGGER RELAY OUTPUT
18 - -
19 K31 20BR FUEL PUMP RELAY CONTROL
20 - -
20 L89 18WT/YL (FOG LAMPS) FOG LAMP RELAY OUTPUT
21 T751 16YL FUSED IGNITION SWITCH OUTPUT (START)
22 L44 18WT/TN RIGHT LOW BEAM OUTPUT
23 T41 20YL/DB (EXCEPT NGC) TRS T41 SENSE
23 T752 20DG/OR (NGC) STARTER RELAY CONTROL
24 A944 20RD FUSED B(+)
26 - -
8W - 80 - 76 8W-80 CONNECTOR PIN-OUTSDR
Page 1135 of 2627
POWER WINDOW CIRCUIT BREAKER-2WAY
CAV CIRCUIT FUNCTION
1 F991 10PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
2 F30 12PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
POWER WINDOW MOTOR-DRIVER-2WAY
CAV CIRCUIT FUNCTION
A Q21 14OR/WT LEFT FRONT WINDOW DRIVER (DOWN)
B Q11 14OR/LG LEFT FRONT WINDOW DRIVER (UP)
POWER WINDOW MOTOR-LEFT REAR-2WAY
CAV CIRCUIT FUNCTION
A Q211 14TN/LB DRIVER REAR WINDOW DRIVER (DOWN)
B Q111 14TN/YL DRIVER REAR WINDOW DRIVER (UP)
POWER WINDOW MOTOR-PASSENGER-2WAY
CAV CIRCUIT FUNCTION
A Q22 14OR/VT RIGHT FRONT WINDOW DRIVER (DOWN)
B Q12 14OR/BR RIGHT FRONT WINDOW DRIVER (UP)
8W - 80 - 86 8W-80 CONNECTOR PIN-OUTSDR
Page 1136 of 2627
POWER WINDOW MOTOR-RIGHT REAR-2WAY
CAV CIRCUIT FUNCTION
A Q212 14TN/LB PASSENGER REAR WINDOW DRIVER (DOWN)
B Q112 14TN/YL PASSENGER REAR WINDOW DRIVER (UP)
POWER WINDOW SWITCH-LEFT REAR - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q111 14TN/YL DRIVER REAR WINDOW DRIVER (UP)
2 Q611 14OR/GY LEFT REAR WINDOW DRIVER (DOWN)
3- -
4 Q411 14OR/WT LEFT REAR WINDOW DRIVER (UP)
5 Q211 14TN/LB DRIVER REAR WINDOW DRIVER (DOWN)
6 Q15 14OR/LB POWER WINDOW SWITCH FEED
POWER WINDOW SWITCH-PASSENGER - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q12 14OR/BR RIGHT FRONT WINDOW DRIVER (UP)
2 Q26 14OR/GY MASTER WINDOW SWITCH RIGHT FRONT (DOWN)
3- -
4 Q16 14OR/TN MASTER WINDOW SWITCH RIGHT FRONT (UP)
5 Q22 14OR/VT RIGHT FRONT WINDOW DRIVER (DOWN)
6 Q15 14OR/LB POWER WINDOW SWITCH FEED
POWER WINDOW SWITCH-RIGHT REAR - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Q112 14TN/YL PASSENGER REAR WINDOW DRIVER (UP)
2 Q612 14OR/GY RIGHT REAR WINDOW DRIVER (DOWN)
3- -
4 Q412 14OR/WT RIGHT REAR WINDOW DRIVER (UP)
5 Q212 14TN/LB PASSENGER REAR WINDOW DRIVER (DOWN)
6 Q15 14TN/LG POWER WINDOW SWITCH FEED
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 87
Page 1159 of 2627
CONNECTOR NAME/NUMBER COLOR LOCATION FIG.
Mode Door Actuator 2 BK Right Side of HVAC N/S
Multi-Function Switch BK On Steering Column 31
Natural Vacuum Leak Detection
AssemblyBK Rear of Transmission 18, 50
Output Speed Sensor DB Left Side of Transmission 11, 14, 15, 16
Overdrive Switch WT Center of Instrument Panel 35
Overhead Map/Reading Lamp
(Except Base)NAT Center of Headliner N/S
Oxygen Sensor 1/1 Upstream BK Left Front of Side of Transmission 15, 16, 17, 19
Oxygen Sensor 1/2 Downstream NAT Left Rear of Side of Transmission 15, 16, 17, 19
Oxygen Sensor 2/1 Upstream BK Right Front Side of Transmission 15, 17, 18
Oxygen Sensor 2/2 Downstream BK Right Rear Side of Transmission 15, 17, 18
Park Brake Switch At Park Brake 22, 24
Park/Turn Signal Lamp-Left Front BK At Lamp 23, 28, 29
Park/Turn Signal Lamp-Right Front BK At Lamp 1, 21, 26
Passenger Airbag On/Off Switch Right Side of Instrument Panel 33, 35, 39
Passenger Blend Door Actuator
(Dual Zone)BK Right Side of HVAC N/S
Passenger Lumbar Switch At Passenger Seat N/S
Power Mirror-Left BK At Mirror 41
Power Mirror-Right BK At Mirror 42
Power Outlet RD Center of Instrument Panel 35
Power Outlet-Console BK Center of Instrument Panel N/S
Power Seat Motor-Driver Front
VerticalRD At Driver Seat N/S
Power Seat Motor-Driver Horizontal BK At Driver Seat N/S
Power Seat Motor-Driver Rear
VerticalBK At Driver Seat N/S
Power Seat Switch-Driver BK At Driver Seat N/S
Power Seat Switch-Passenger BK At Passenger Seat N/S
Power Steering Pressure Switch BK Near Power Steering Pump 7
Power Window Circuit Breaker Under Instrument Panel 31, 35, 38
Power Window Motor-Driver BK In Driver Door at Motor 41
Power Window Motor-Left Rear BK In Door at Motor 43
Power Window Motor-Passenger BK In Passenger Door at Motor 42
Power Window Motor-Right Rear BK In Door at Motor 43
Power Window Switch-Left Rear BL In Door 43
Power Window Switch-Passenger Passenger Door 42
Power Window Switch-Right Rear BL In Door 43
Powertrain Control Module C1 BK Right Rear Engine Compartment 4, 8
Powertrain Control Module C2 WT Right Rear Engine Compartment 4, 8
Powertrain Control Module C3 GY Right Rear Engine Compartment 21
Powertrain Control Module C4 GN Right Rear Engine Compartment 4, 8
8W - 91 - 6 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
Page 2566 of 2627
OPERATION
OPERATION
The Powertrain Control Module (PCM) monitors
many different circuits in the fuel injection, ignition,
emission and engine systems. If the PCM senses a
problem with a monitored circuit often enough to
indicate an actual problem, it stores a Diagnostic
Trouble Code (DTC) in the PCM's memory. If the
problem is repaired or ceases to exist, the PCM can-
cels the code after 40 warm-up cycles. Diagnostic
trouble codes that affect vehicle emissions illuminate
the Malfunction Indicator Lamp (MIL). The MIL is
displayed as an engine icon (graphic) on the instru-
ment panel. Refer to Malfunction Indicator Lamp in
this section.
Certain criteria must be met before the PCM
stores a DTC in memory. The criteria may be a spe-
cific range of engine RPM, engine temperature,
and/or input voltage to the PCM.
The PCM might not store a DTC for a monitored
circuit even though a malfunction has occurred. This
may happen because one of the DTC criteria for the
circuit has not been met.For example,assume the
diagnostic trouble code criteria requires the PCM to
monitor the circuit only when the engine operates
between 750 and 2000 RPM. Suppose the sensor's
output circuit shorts to ground when engine operates
above 2400 RPM (resulting in 0 volt input to the
PCM). Because the condition happens at an engine
speed above the maximum threshold (2000 rpm), the
PCM will not store a DTC.
There are several operating conditions for which
the PCM monitors and sets DTC's. Refer to Moni-
tored Systems, Components, and Non-Monitored Cir-
cuits in this section.
Technicians must retrieve stored DTC's by connect-
ing the DRB scan tool (or an equivalent scan tool) to
the 16±way data link connector. The connector is
located on the bottom edge of the instrument panel
near the steering column (Fig. 1).
NOTE: Various diagnostic procedures may actually
cause a diagnostic monitor to set a DTC. For
instance, pulling a spark plug wire to perform a
spark test may set the misfire code. When a repair
is completed and verified, connect the DRB scan
tool to the 16±way data link connector to erase all
DTC's and extinguish the MIL.
OPERATION - TASK MANAGER
The Task Manager determines which tests happen
when and which functions occur when. Many of the
diagnostic steps required by OBD II must be per-
formed under specific operating conditions. The TaskManager software organizes and prioritizes the diag-
nostic procedures. The job of the Task Manager is to
determine if conditions are appropriate for tests to be
run, monitor the parameters for a trip for each test,
and record the results of the test. Following are the
responsibilities of the Task Manager software:
²Test Sequence
²MIL Illumination
²Diagnostic Trouble Codes (DTCs)
²Trip Indicator
²Freeze Frame Data Storage
²Similar Conditions Window
Test Sequence
In many instances, emissions systems must fail
diagnostic tests more than once before the PCM illu-
minates the MIL. These tests are know as 'two trip
monitors.' Other tests that turn the MIL lamp on
after a single failure are known as 'one trip moni-
tors.' A trip is defined as 'start the vehicle and oper-
ate it to meet the criteria necessary to run the given
monitor.'
Many of the diagnostic tests must be performed
under certain operating conditions. However, there
are times when tests cannot be run because another
test is in progress (conflict), another test has failed
(pending) or the Task Manager has set a fault that
may cause a failure of the test (suspend).
²Pending
Under some situations the Task Manager will not
run a monitor if the MIL is illuminated and a fault is
stored from another monitor. In these situations, the
Task Manager postpones monitorspendingresolu-
tion of the original fault. The Task Manager does not
run the test until the problem is remedied.
Fig. 1 DATA LINK CONNECTOR LOCATION - TYPICAL
1 - 16-WAY DATA LINK CONNECTOR
DREMISSIONS CONTROL 25 - 5
EMISSIONS CONTROL (Continued)
Page 2607 of 2627
LUBRICATION - DIAGNOSIS AND
TESTING, ENGINE DIAGNOSIS.......9-187,9-7
LUBRICATION - OPERATION . . . 9-150,9-289,9-61
LUBRICATION - STANDARD PROCEDURE . . 19-34
LUBRICATION - STANDARD PROCEDURE,
BODY...............................23-3
LUMBAR CONTROL SWITCH -
DESCRIPTION.......................8N-17
LUMBAR CONTROL SWITCH -
OPERATION.........................8N-18
LUMBAR CONTROL SWITCH - REMOVAL . 8N-18
LUMBAR MOTOR - DESCRIPTION.......8N-18
LUMBAR MOTOR - DIAGNOSIS AND
TESTING...........................8N-18
LUMBAR MOTOR - OPERATION.........8N-18
LUMBAR SUPPORT HANDLE/BEZEL -
INSTALLATION.......................23-82
LUMBAR SUPPORT HANDLE/BEZEL -
REMOVAL..........................23-82
MAIN BEARING - FITTING - STANDARD
PROCEDURE, CRANKSHAFT.......9-134,9-207
MAIN BEARING CLEARANCE -
STANDARD PROCEDURE...............9-274
MAIN BEARING FITTING, STANDARD
PROCEDURE.........................9-44
MAIN BEARINGS - INSPECTION,
CRANKSHAFT..................9-135,9-208
MAINTENANCE SCHEDULES, 24-VALVE
CUMMINS TURBO DIESEL..............0-12
MALFUNCTION INDICATOR LAMP (MIL) -
DESCRIPTION.......................8J-31
MALFUNCTION INDICATOR LAMP (MIL) -
OPERATION.........................8J-31
MANAGER - DESCRIPTION, TASK.........25-1
MANAGER - OPERATION, TASK..........25-5
MANIFOLD - CLEANING, EXHAUST . 9-163,9-226,
9-298
MANIFOLD - CLEANING, INTAKE . . . 9-160,9-226,
9-297
MANIFOLD - DESCRIPTION, EXHAUST . . . 9-161,
9-226,9-74
MANIFOLD - DESCRIPTION, INTAKE.....9-159,
9-225,9-72
MANIFOLD - INSPECTION, EXHAUST.....9-163,
9-227,9-298
MANIFOLD - INSPECTION, INTAKE . 9-160,9-226,
9-297
MANIFOLD - INSTALLATION, EXHAUST . . . 9-164,
9-227,9-298,9-74
MANIFOLD - INSTALLATION, INTAKE.....9-160,
9-226,9-298,9-73
MANIFOLD - OPERATION, EXHAUST......9-226
MANIFOLD - REMOVAL, EXHAUST . . 9-161,9-226,
9-298,9-74
MANIFOLD - REMOVAL, INTAKE . . . 9-159,9-226,
9-297,9-73
MANIFOLD LEAKAGE - DIAGNOSIS AND
TESTING, INTAKE...............9-159,9-225
MANIFOLD LEAKS - DIAGNOSIS AND
TESTING, INTAKE.....................9-72
MANUAL - INSTALLATION, WINDOW
REGULATOR...................23-27,23-35
MANUAL - REMOVAL, WINDOW
REGULATOR...................23-26,23-35
MANUAL BLEEDING - STANDARD
PROCEDURE..........................5-5
MANUAL TRANSMISSION -
DESCRIPTION.........................0-4
MANUAL TRANSMISSION - NV3500 -
ASSEMBLY..........................21-17
MANUAL TRANSMISSION - NV3500 -
CLEANING..........................21-15
MANUAL TRANSMISSION - NV3500 -
DESCRIPTION........................21-1
MANUAL TRANSMISSION - NV3500 -
DIAGNOSIS AND TESTING..............21-3
MANUAL TRANSMISSION - NV3500 -
DISASSEMBLY........................21-4
MANUAL TRANSMISSION - NV3500 -
INSPECTION
........................21-16
MANUAL TRANSMISSION - NV3500 -
INSTALLATION
.......................21-39
MANUAL TRANSMISSION - NV3500 -
OPERATION
..........................21-1
MANUAL TRANSMISSION - NV3500 -
REMOVAL
...........................21-3
MANUAL TRANSMISSION - NV3500 -
SPECIAL TOOLS
.....................21-40MANUAL TRANSMISSION - NV3500 -
SPECIFICATIONS.....................21-40
MANUAL TRANSMISSION - NV4500 -
ASSEMBLY..........................21-63
MANUAL TRANSMISSION - NV4500 -
CLEANING..........................21-62
MANUAL TRANSMISSION - NV4500 -
DESCRIPTION.......................21-43
MANUAL TRANSMISSION - NV4500 -
DIAGNOSIS AND TESTING.............21-44
MANUAL TRANSMISSION - NV4500 -
DISASSEMBLY.......................21-46
MANUAL TRANSMISSION - NV4500 -
INSPECTION........................21-62
MANUAL TRANSMISSION - NV4500 -
INSTALLATION.......................21-80
MANUAL TRANSMISSION - NV4500 -
OPERATION.........................21-43
MANUAL TRANSMISSION - NV4500 -
REMOVAL..........................21-44
MANUAL TRANSMISSION - NV4500 -
SPECIAL TOOLS.....................21-81
MANUAL TRANSMISSION - NV4500 -
SPECIFICATIONS.....................21-81
MANUAL TRANSMISSION - NV5600 -
ASSEMBLY.........................21-106
MANUAL TRANSMISSION - NV5600 -
DESCRIPTION.......................21-88
MANUAL TRANSMISSION - NV5600 -
DIAGNOSIS AND TESTING.............21-90
MANUAL TRANSMISSION - NV5600 -
DISASSEMBLY.......................21-91
MANUAL TRANSMISSION - NV5600 -
INSPECTION.........................21-106
MANUAL TRANSMISSION - NV5600 -
INSTALLATION......................21-121
MANUAL TRANSMISSION - NV5600 -
OPERATION.........................21-90
MANUAL TRANSMISSION - NV5600 -
REMOVAL..........................21-90
MANUAL TRANSMISSION - NV5600 -
SPECIAL TOOLS....................21-123
MAP SENSOR - DESCRIPTION.....14-32,14-83
MAP SENSOR - INSTALLATION..........14-34
MAP SENSOR - OPERATION............14-32
MAP SENSOR - REMOVAL.............14-33
MARKER LAMP - INSTALLATION,
FENDER............................8L-18
MARKER LAMP - INSTALLATION,
TAILGATE...........................8L-18
MARKER LAMP - REMOVAL, FENDER....8L-17
MARKER LAMP - REMOVAL, TAILGATE . . . 8L-18
MASTER CYLINDER - DESCRIPTION......5-24
MASTER CYLINDER - OPERATION........5-25
MASTER CYLINDER BLEEDING -
STANDARD PROCEDURE................5-26
MASTER CYLINDER/POWER BOOSTER -
DIAGNOSIS AND TESTING..............5-25
MATCH MOUNTING - STANDARD
PROCEDURE.........................22-3
MATCHING TIRE - DESCRIPTION, FULL
SIZE, SPARE WHEEL WITH.............22-15
MATS - INSTALLATION, CARPETS AND
FLOOR.............................23-65
MATS - REMOVAL, CARPETS AND
FLOOR.............................23-65
MEASUREMENT - 4WD (LD) -
STANDARD PROCEDURE, HEIGHT.........2-3
MEASURING TIMING CHAIN WEAR -
STANDARD PROCEDURE...............9-167
MEASURING TIMING CHAIN WEAR,
STANDARD PROCEDURE................9-77
MECHANICAL - DIAGNOSIS AND
TESTING, ENGINE DIAGNOSIS.....9-185,9-188,
9-233,9-6,9-92
MECHANISM - DESCRIPTION, SHIFT....21-252,
21-398
MECHANISM - INSTALLATION, SHIFT.....21-87
MECHANISM - OPERATION, SHIFT......21-252,
21-398
MECHANISM - REMOVAL, SHIFT
........21-86
METRIC SYSTEM - DESCRIPTION
......Intro.-8
MICRO 420 BATTERY TESTER -
STANDARD PROCEDURE, USING
........8F-12
MILE, SPECIFICATIONS - TIRE
REVOLUTIONS PER
...................22-10
MINI-TRIP COMPUTER - DIAGNOSIS
AND TESTING, COMPASS
..............8M-6MIRROR - DESCRIPTION, AUTOMATIC
DAY / NIGHT........................8N-11
MIRROR - DIAGNOSIS AND TESTING,
AUTOMATIC DAY / NIGHT..............8N-11
MIRROR - INSTALLATION, SIDE VIEW....23-42
MIRROR - OPERATION, AUTOMATIC DAY
/ NIGHT............................8N-11
MIRROR - REMOVAL, AUTOMATIC DAY /
NIGHT.............................8N-12
MIRROR - REMOVAL, REAR VIEW.......23-69
MIRROR - REMOVAL, SIDE VIEW........23-41
MIRROR - REMOVAL, SIDEVIEW........8N-12
MIRROR FLAG - INSTALLATION, SIDE
VIEW..............................23-27
MIRROR FLAG - REMOVAL, SIDE VIEW . . . 23-27
MIRROR GLASS - INSTALLATION, SIDE
VIEW..............................23-43
MIRROR GLASS - REMOVAL, SIDE VIEW . . 23-42
MIRROR SUPPORT BRACKET -
INSTALLATION, REAR VIEW............23-70
MIRROR SWITCH - DIAGNOSIS AND
TESTING, POWER....................8N-12
MIRROR SWITCH - REMOVAL, POWER . . . 8N-12
MIRRORS - DESCRIPTION, HEATED.......8G-6
MIRRORS - DESCRIPTION, POWER......8N-10
MIRRORS - DIAGNOSIS AND TESTING,
POWER............................8N-10
MIRRORS - OPERATION, HEATED........8G-6
MIRRORS - OPERATION, POWER........8N-10
MODE - DESCRIPTION, CIRCUIT
ACTUATION TEST.....................25-1
MODE - DESCRIPTION, STATE DISPLAY
TEST...............................25-1
MODE DOOR - INSTALLATION..........24-38
MODE DOOR - REMOVAL..............24-38
MODE DOOR ACTUATOR - DESCRIPTION . . 24-23
MODE DOOR ACTUATOR -
INSTALLATION.......................24-23
MODE DOOR ACTUATOR - OPERATION . . . 24-23
MODE DOOR ACTUATOR - REMOVAL.....24-23
MODE SENSOR - DESCRIPTION . . 21-509,21-538,
21-573
MODE SENSOR - OPERATION . . . 21-509,21-539,
21-573
MODES OF OPERATION - DESCRIPTION....8E-7
MODES, STANDARD PROCEDURE -
CONFIGURING A NEW MODULE /
SWITCH OPERATING...................8Q-3
MODULE - DESCRIPTION, AIRBAG
CONTROL..........................8O-11
MODULE - DESCRIPTION, DRIVER DOOR . . 8N-5
MODULE - DESCRIPTION, FRONT
CONTROL........................8W-97-5
MODULE - DESCRIPTION, FRONT
CONTROL...........................8E-5
MODULE - DESCRIPTION, FUEL PUMP....14-11
MODULE - DESCRIPTION, FUEL TANK....14-63
MODULE - DESCRIPTION, HEATED SEAT . . . 8E-6
MODULE - DESCRIPTION, HEATED SEAT . . 8G-13
MODULE - DESCRIPTION, INTEGRATED
POWER..........................8W-97-3
MODULE - DESCRIPTION, REMOTE
KEYLESS ENTRY......................8N-7
MODULE - DESCRIPTION, SENTRY KEY
IMMOBILIZER.......................8E-13
MODULE - DESCRIPTION, TRANSFER
CASE CONTROL......................8E-16
MODULE - DESCRIPTION,
TRANSMISSION CONTROL.............8E-20
MODULE - DESCRIPTION, WIPER.......8R-22
MODULE - DIAGNOSIS AND TESTING,
DRIVER DOOR.......................8N-6
MODULE - DIAGNOSIS AND TESTING,
FRONT CONTROL..................8W-97-5
MODULE - DIAGNOSIS AND TESTING,
FRONT CONTROL.....................8E-5
MODULE - DIAGNOSIS AND TESTING,
HEATED SEAT ........................8E-6
MODULE - DIAGNOSIS AND TESTING,
HEATED SEAT
.......................8G-14
MODULE - DIAGNOSIS AND TESTING,
REMOTE KEYLESS ENTRY
..............8N-7
MODULE - INSTALLATION, AIRBAG
CONTROL
..........................8O-13
MODULE - INSTALLATION, DRIVER
DOOR
..............................8N-7
MODULE - INSTALLATION, ENGINE
CONTROL
...........................8E-4
20 INDEXDR
Description Group-Page Description Group-Page Description Group-Page
Page 2608 of 2627
MODULE - INSTALLATION, FRONT
CONTROL........................8W-97-6
MODULE - INSTALLATION, FRONT
CONTROL...........................8E-5
MODULE - INSTALLATION, FUEL PUMP . . . 14-12
MODULE - INSTALLATION, FUEL TANK....14-64
MODULE - INSTALLATION, HANDS FREE . . . 8T-2
MODULE - INSTALLATION, HEATED SEAT . . . 8E-7
MODULE - INSTALLATION, HEATED SEAT . 8G-15
MODULE - INSTALLATION, INTEGRATED
POWER..........................8W-97-4
MODULE - INSTALLATION, REMOTE
KEYLESS ENTRY......................8N-8
MODULE - INSTALLATION, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - INSTALLATION, WIPER.......8R-23
MODULE - OPERATION, AIRBAG
CONTROL..........................8O-11
MODULE - OPERATION, DRIVER DOOR....8N-5
MODULE - OPERATION, FRONT
CONTROL........................8W-97-5
MODULE - OPERATION, FRONT
CONTROL...........................8E-5
MODULE - OPERATION, FUEL PUMP.....14-11
MODULE - OPERATION, FUEL TANK......14-63
MODULE - OPERATION, HEATED SEAT.....8E-6
MODULE - OPERATION, HEATED SEAT....8G-14
MODULE - OPERATION, INTEGRATED
POWER..........................8W-97-3
MODULE - OPERATION, REMOTE
KEYLESS ENTRY......................8N-7
MODULE - OPERATION, SENTRY KEY
IMMOBILIZER.......................8E-13
MODULE - OPERATION, TRANSFER CASE
CONTROL..........................8E-16
MODULE - OPERATION, TRANSMISSION
CONTROL..........................8E-20
MODULE - OPERATION, WIPER.........8R-23
MODULE - REMOVAL, AIRBAG CONTROL . 8O-12
MODULE - REMOVAL, DRIVER DOOR.....8N-7
MODULE - REMOVAL, ENGINE CONTROL . . . 8E-4
MODULE - REMOVAL, FRONT CONTROL . 8W-97-6
MODULE - REMOVAL, FRONT CONTROL . . . 8E-5
MODULE - REMOVAL, FUEL PUMP.......14-12
MODULE - REMOVAL, FUEL TANK.......14-63
MODULE - REMOVAL, HANDS FREE.......8T-2
MODULE - REMOVAL, HEATED SEAT......8E-7
MODULE - REMOVAL, HEATED SEAT.....8G-15
MODULE - REMOVAL, INTEGRATED
POWER..........................8W-97-3
MODULE - REMOVAL, REMOTE KEYLESS
ENTRY..............................8N-7
MODULE - REMOVAL, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - REMOVAL, WIPER...........8R-23
MODULE / SWITCH OPERATING MODES,
STANDARD PROCEDURE -
CONFIGURING A NEW.................8Q-3
MODULE LAMP REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE LENS REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE (SKIM) - DESCRIPTION,
SENTRY KEY IMMOBILIZER.............8Q-1
MODULE (SKIM) - OPERATION, SENTRY
KEY IMMOBILIZER
....................8Q-2
MOLDING - INSTALLATION, FRONT
DOOR INNER BELT
...................23-93
MOLDING - INSTALLATION, FRONT
DOOR OUTER BELT
...................23-93
MOLDING - INSTALLATION, REAR DOOR
INNER BELT
.........................23-94
MOLDING - INSTALLATION, REAR DOOR
OUTER BELT
........................23-94
MOLDING - REMOVAL, FRONT DOOR
INNER BELT
.........................23-93
MOLDING - REMOVAL, FRONT DOOR
OUTER BELT
........................23-92
MOLDING - REMOVAL, REAR DOOR
INNER BELT
.........................23-94
MOLDING - REMOVAL, REAR DOOR
OUTER BELT
........................23-93
MOLDINGS - INSTALLATION, BODY SIDE
. . 23-36
MOLDINGS - REMOVAL, BODY SIDE
.....23-36
MONITORED SYSTEMS - DESCRIPTION
....25-2
MONITORS - DESCRIPTION,
COMPONENT
.........................25-4MOTOR - DESCRIPTION, ADJUSTABLE
PEDAL...............................5-6
MOTOR - DESCRIPTION, BLOWER.......24-28
MOTOR - DESCRIPTION, DOOR LOCK.....8N-4
MOTOR - DESCRIPTION, IDLE AIR
CONTROL..........................14-28
MOTOR - DESCRIPTION, LUMBAR.......8N-18
MOTOR - DESCRIPTION, SHIFT . . 21-511,21-541,
21-575
MOTOR - DIAGNOSIS AND TESTING,
BLOWER...........................24-28
MOTOR - DIAGNOSIS AND TESTING,
DOOR LOCK.........................8N-4
MOTOR - DIAGNOSIS AND TESTING,
LUMBAR...........................8N-18
MOTOR - DIAGNOSIS AND TESTING,
STARTER ...........................8F-32
MOTOR - INSTALLATION, ADJUSTABLE
PEDAL...............................5-7
MOTOR - INSTALLATION, BLOWER......24-31
MOTOR - INSTALLATION, IDLE AIR
CONTROL..........................14-29
MOTOR - INSTALLATION, SHIFT . 21-511,21-541,
21-575
MOTOR - INSTALLATION, STARTER......8F-34
MOTOR - OPERATION, BLOWER.........24-28
MOTOR - OPERATION, DOOR LOCK.......8N-4
MOTOR - OPERATION, IDLE AIR
CONTROL..........................14-28
MOTOR - OPERATION, LUMBAR........8N-18
MOTOR - OPERATION, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, ADJUSTABLE
PEDAL...............................5-7
MOTOR - REMOVAL, BLOWER..........24-31
MOTOR - REMOVAL, IDLE AIR CONTROL . . 14-29
MOTOR - REMOVAL, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, STARTER..........8F-33
MOTOR - REMOVAL, WINDOW..........8N-20
MOTOR RELAY - DESCRIPTION,
STARTER ...........................8F-35
MOTOR RELAY - INSTALLATION,
STARTER ...........................8F-37
MOTOR RELAY - OPERATION, STARTER . . . 8F-36
MOTOR RELAY - REMOVAL, STARTER....8F-37
MOTOR RESISTOR BLOCK -
DESCRIPTION, BLOWER...............24-18
MOTOR RESISTOR BLOCK - DIAGNOSIS
AND TESTING, BLOWER...............24-19
MOTOR RESISTOR BLOCK -
INSTALLATION, BLOWER..............24-19
MOTOR RESISTOR BLOCK - OPERATION,
BLOWER...........................24-18
MOTOR RESISTOR BLOCK - REMOVAL,
BLOWER...........................24-19
MOTOR SWITCH - DESCRIPTION,
BLOWER...........................24-20
MOTOR SWITCH - DIAGNOSIS AND
TESTING, BLOWER...................24-20
MOTOR SWITCH - OPERATION, BLOWER . . 24-20
MOUNT - INSTALLATION, DISC BRAKE
CALIPER ADAPTER....................5-22
MOUNT - INSTALLATION, FRONT . . . 9-147,9-218,
9-287,9-59
MOUNT - INSTALLATION, REAR
....9-149,9-220,
9-288,9-61
MOUNT - REMOVAL, FRONT
. 9-146,9-217,9-286,
9-58
MOUNT - REMOVAL, REAR
. . 9-149,9-220,9-288,
9-61
MOUNTED STOP LAMP - INSTALLATION,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP - REMOVAL,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP UNIT -
INSTALLATION, CENTER HIGH
..........8L-11
MOUNTED STOP LAMP UNIT -
REMOVAL, CENTER HIGH
..............8L-11
MOUNTING - STANDARD PROCEDURE,
MATCH
.............................22-3
MUFFLER - 5.9L DIESEL - INSTALLATION
. 11-10
MUFFLER - 5.9L DIESEL - REMOVAL
.....11-10
MUFFLER - INSTALLATION
..............11-9
MUFFLER - REMOVAL
..................11-9
MULTI-FUNCTION SWITCH - DIAGNOSIS
AND TESTING
.......................8L-18MULTI-FUNCTION SWITCH -
INSTALLATION.......................8L-19
MULTI-FUNCTION SWITCH - REMOVAL . . . 8L-19
NAME PLATES - INSTALLATION,
EXTERIOR..........................23-38
NAME PLATES - REMOVAL, EXTERIOR....23-38
NATURAL VAC LEAK DETECTION ASSY -
DESCRIPTION.......................25-23
NATURAL VAC LEAK DETECTION ASSY -
INSTALLATION.......................25-25
NATURAL VAC LEAK DETECTION ASSY -
OPERATION.........................25-23
NATURAL VAC LEAK DETECTION ASSY -
REMOVAL..........................25-24
NAVIGATION - INSTALLATION, ANTENNA . . . 8A-6
NAVIGATION - REMOVAL, ANTENNA......8A-6
NAVIGATION/TELECOMMUNICATION -
DESCRIPTION........................8T-1
NAVIGATION/TELECOMMUNICATION -
OPERATION..........................8T-1
NECK SEAL - DIAGNOSIS AND TESTING,
RADIATOR CAP-TO-FILLER..............7-58
NEW MODULE / SWITCH OPERATING
MODES, STANDARD PROCEDURE -
CONFIGURING A......................8Q-3
NIGHT MIRROR - DESCRIPTION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - DIAGNOSIS AND
TESTING, AUTOMATIC DAY.............8N-11
NIGHT MIRROR - OPERATION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - REMOVAL,
AUTOMATIC DAY......................8N-12
NOISE - DIAGNOSIS AND TESTING,
WIND...............................23-2
NOISE OR VIBRATION - DIAGNOSIS AND
TESTING, TIRE.......................22-7
NOISE SUPPRESSION GROUND STRAP -
DESCRIPTION, RADIO..................8A-9
NOISE SUPPRESSION GROUND STRAP -
INSTALLATION, RADIO................8A-10
NOISE SUPPRESSION GROUND STRAP -
OPERATION, RADIO...................8A-9
NOISE SUPPRESSION GROUND STRAP -
REMOVAL, RADIO.....................8A-9
NON-DEPLOYED SUPPLEMENTAL
RESTRAINTS - STANDARD
PROCEDURE, HANDLING...............8O-6
NON-MONITORED CIRCUITS -
OPERATION..........................25-8
NOZZLE - DESCRIPTION, WASHER......8R-11
NOZZLE - INSTALLATION, WASHER......8R-12
NOZZLE - OPERATION, WASHER........8R-12
NOZZLE - REMOVAL, WASHER..........8R-12
NUMBER - DESCRIPTION, VEHICLE
IDENTIFICATION....................Intro.-1
NV241 GENII - ASSEMBLY, TRANSFER
CASE.............................21-428
NV241 GENII - CLEANING, TRANSFER
CASE.............................21-426
NV241 GENII - DESCRIPTION, TRANSFER
CASE.............................21-415
NV241 GENII - DIAGNOSIS AND
TESTING, TRANSFER CASE............21-416
NV241 GENII - DISASSEMBLY,
TRANSFER CASE....................21-417
NV241 GENII - INSPECTION, TRANSFER
CASE.............................21-426
NV241 GENII - INSTALLATION,
TRANSFER CASE....................21-438
NV241 GENII - OPERATION, TRANSFER
CASE.............................21-415
NV241 GENII - REMOVAL, TRANSFER
CASE.............................21-417
NV241 GENII - TRANSFER CASE........21-438
NV241/NV243 - TRANSFER CASE.......21-439
NV243 - ASSEMBLY, TRANSFER CASE . . . 21-496
NV243 - CLEANING, TRANSFER CASE . . . 21-493
NV243 - DESCRIPTION, TRANSFER CASE . 21-482
NV243 - DIAGNOSIS AND TESTING,
TRANSFER CASE....................21-483
NV243 - DISASSEMBLY, TRANSFER
CASE
.............................21-484
NV243 - INSPECTION, TRANSFER CASE
. . 21-493
NV243 - INSTALLATION, TRANSFER
CASE
.............................21-505
NV243 - OPERATION, TRANSFER CASE
. . 21-483
NV243 - REMOVAL, TRANSFER CASE
....21-484
DRINDEX 21
Description Group-Page Description Group-Page Description Group-Page
