DODGE SPRINTER 2004 1.G Owners Manual

WHAT TO DO IN EMERGENCIES 201
6
If the Engine is DamagedFor towing distances up to 30 miles (about 50 km)
 Shift selector lever to "N" position.
 Do not exceed a towing speed of 30 mph (50 km / h).
For towing distances greater than 30 miles (about
50 km)
 Remove the propeller shafts leading to the drive
axles.
The vehicle can be towed without restriction.If the Transmission is Damaged Remove the propeller shafts leading to the drive
axles.
WARNING!
Do not tow the vehicle if the key cannot be turned
in the ignition lock.
If the key cannot be turned, the ignition lock re-
mains locked and the vehicle cannot be steered.
With the engine not running there is no power
assistance for the braking and steering systems.
In this case, it is important to keep in mind that a
considerably higher degree of effort is necessary
to brake and steer the vehicle.
The vehicle must not be towed with the front axle
raised and the key in position 2 in the ignition
lock as the drive wheels could then lock due to the
acceleration skid control (ASR) or the optional
Electronic Stability Program (ESP).
Freightliner-all.book Pag e 201 Monday, December 1, 2003 2:54 PM

202 WHAT TO DO IN EMERGENCIESIf the Front Axle is DamagedRaise the front axle.
 Observe the same towing restrictions as for engine
damage.
If the Rear Axle is Damaged  Raise the rear axle.
NOTE: Comply with local legal regulations regarding
towing vehicles.
Freightliner-all.book Pag e 202 Monday, December 1, 2003 2:54 PM

MAINTAINING YOUR VEHICLE
7
CONTENTS
Engine Compartment . . . . . . . . . . . . . . . . . . . . . . . 205

Sprinter Original Parts . . . . . . . . . . . . . . . . . . . . . . 207

Service Products . . . . . . . . . . . . . . . . . . . . . . . . . . . 207Disposal of Service Products . . . . . . . . . . . . . . 208

Emission Related Component Warranty
Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Regular Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208Windshield Washer System Fluid Reservoir . 209Air Filter Restriction Indicator (Optional) . . . 209Engine Oils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . 210Ribbed V-Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . 211Hydraulic Brake System, Clutch Mechanism
Fluid Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212Engine Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Checking Coolant Level . . . . . . . . . . . . . . . . . . 213

Winter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 215

Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216Disconnecting the Battery . . . . . . . . . . . . . . . . . 216Reconnecting the Battery . . . . . . . . . . . . . . . . . . 217Charging the Battery . . . . . . . . . . . . . . . . . . . . . 217

Replacing Wiper Blades . . . . . . . . . . . . . . . . . . . . . 218Appearance Car and Corrosion Protection . . 219Power Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . 220Automatic Car Wash . . . . . . . . . . . . . . . . . . . . . 221Tar Stains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221Paintwork, Painted Body Components . . . . . . 221Engine Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . 221Vehicle Washing . . . . . . . . . . . . . . . . . . . . . . . . . 222Ornamental Moldings . . . . . . . . . . . . . . . . . . . . 222Headlamps, Taillamps, Turn Signal Lenses . . 222Window Cleaning . . . . . . . . . . . . . . . . . . . . . . . 223
Freightliner-all.book Pag e 203 Monday, December 1, 2003 2:54 PM

204 MAINTAINING YOUR VEHICLE
Wiper Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223Light Alloy Wheels . . . . . . . . . . . . . . . . . . . . . . 224Instrument Cluster . . . . . . . . . . . . . . . . . . . . . . . 224Steering Wheel and Gear Selector Lever . . . . 224Cup Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224Headliner and Shelf Below Rear Window . . . 224Upholstery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224Hard Plastic Trim Items . . . . . . . . . . . . . . . . . . 225Plastic and Rubber Parts . . . . . . . . . . . . . . . . . . 225

Electrical Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225Standard Fuse and Relay Equipment . . . . . . . 226Relay Assignment, Standard Equipment . . . . 230Fuse and Relay Optional Equipment . . . . . . . 230

Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 233Front Lamp Unit . . . . . . . . . . . . . . . . . . . . . . . . . 233Taillamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
License Plate Lamps
(Cargo/Passenger Vans Only) . . . . . . . . . . . . . 240Additional Brake Lamp
(Cargo/Passenger Vans Only) . . . . . . . . . . . . . 240Side-Mounted Turn Signals . . . . . . . . . . . . . . . 241Side-Marker Lamps,
Standing Lamps (Optional) . . . . . . . . . . . . . . . . 241Interior Lighting in Passenger Compartment
and Load Compartment . . . . . . . . . . . . . . . . . . 242Interior Lighting with Reading Lamp . . . . . . . 242Interior Lighting with Interior Sensor
Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243Exit Lamps (Optional) . . . . . . . . . . . . . . . . . . . . 243

Capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244Recommended Fluids and Lubricants . . . . . . 245
Freightliner-all.book Pag e 204 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 205
7
ENGINE COMPA RTMENTFreightliner-all.book Pag e 205 Monday, December 1, 2003 2:54 PM

206 MAINTAINING YOUR VEHICLELegend For Engine Compartment
1. Windshield washer system fluid reservoir.
2. Maintenance indicator for air cleaner element
(Optional).
3. Oil dipstick.
4. Oil filler neck.
5. Ribbed V-belt.
Auxiliary drive (Optional) refer to “Auxiliary
drive“.6. Fuel filter with water separator.
7. Hydraulic brake fluid reservoir.
8. Coolant reservoir.
9. Battery
The auxiliary battery is located underneath the
front passenger seat (optional equipment).
10. Fuse box
(These special fuses should only be replaced at by
an authorized Sprinter Dealer).Freightliner-all.book Pag e 206 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 207
7
SPRINTER ORIGINAL PARTSEvery authorized Sprinter Dealer maintains a stock of
Sprinter original parts for maintenance and repair
work.
Sprinter original parts are subjected to the most
stringent quality inspections and will ensure that the
vehicle is maintained at a high level of operating
efficiency and safety, and that it maintains its value.
Each part has been specifically designed and
manufactured or selected and approved for use in
Sprinter vehicles.
It is therefore best to use only Sprinter original parts.
For cost-effective repairs in accordance with sound
recycling principles, the use of non-genuine parts and
accessories not authorized by the manufacturer could
damage the vehicle or compromise its durability or
safety.
When ordering original parts, always provide the
vehicle identification number and the engine number.
SERVICE PRODUCTSMechanical elements and the lubricants used for them
must be carefully matched.
For this reason, only brands tested and approved by
the manufacturer should be used. Please contact your
Sprinter Dealer to obtain the necessary information.
No lubricant additives should be used.
The use of such additives could affect your warranty
rights. Information is available from any authorized
Sprinter Dealer.
For specifications of engine oils, coolant and brake
fluid, contact your
authorized
Sprinter
Dealer.
WARNING!
If handled incorrectly, service products can consti-
tute a health risk for people and an environmental
hazard.
Always observe relevant guidelines for handling,
storing and disposing of service products.
Freightliner-all.book Pag e 207 Monday, December 1, 2003 2:54 PM

208 MAINTAINING YOUR VEHICLEDisposal of Service ProductsDispose of service products and of parts which come
into contact with them (e.g. filters) in an
environmentally responsible manner. Comply with
applicable bars and regulations.EMISSION RELA TED COMPONENT WA RRA NTY
STATEMENTThe Manufacturer warrants to the original and each
subsequent owner of a MERCEDES-BENZ heavy-duty
on highway diesel engine that:
(1) the engine was designed, built and equipped so as
to conform at the time of sale with the applicable
regulations adopted by the Federal Environmental
Protection Agency
(2) the emission control system of such engine is free
from defects in materials and workmanship which
would cause it not to conform with those regulations
for a period of use of five years or 100 000 miles or
3 000 hours of engine operation, whichever occurs
first.
REGULA R CHECKSThe following checks should be performed at regular
intervals (for example once a week or each time the
vehicle is refueled):
 Windshield cleaner system – fluid reservoir.
 Air strainer, in vehicles with an air strainer element
maintenance indicator (optional equipment).
 Engine oil level.
 Checking ribbed V-belt.
 Hydraulic brake system, clutch mechanism fluid
level.
 Coolant level.
 Tire and spare wheel condition and pressures of the
same. For more information, refer to "Wheels and
Tires".
 Vehicle lighting.
Freightliner-all.book Pag e 208 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 209
7
Windshield Washer System Fluid Reservoir1. Washer system fluid reservoir
When topping off, add windshield washer fluid ("S"
for summer or "W" for winter) to the water.
Capacity of fluid reservoir (1): about 7.4 US qt (7 liters).
A ir Filter Restriction Indicator (Optional)The indicator on the air filter housing in the engine
compartment shows the degree of contamination in the
air filter element. If the red field reaches the 100 %
range, the air filter element should be replaced as soon
as possible.Engine OilsUse engine oils approved to MB 228.3 or MB 228.5 that
are also licensed to API CI-4.
Freightliner-all.book Pag e 209 Monday, December 1, 2003 2:54 PM

210 MAINTAINING YOUR VEHICLEEngine Oil Level 1. Oil dipstick
2. Oil filler neckCheck the engine oil level at regular intervals with the
vehicle standing on a level surface.
 Check engine oil level about 5 minutes after
stopping the engine, which should have reached its
regular operating temperature. The normal
operating temperature should have been reached
and maintained for some time.
 Wipe the dipstick clean with a lint-free cloth before
checking.
The engine oil level must be between the
lower (MIN) and upper (MAX) marks on
the dipstick.
Add engine oil only up to the MAX mark.
Excess oil must be drained or siphoned off.
 For approved engine oils, contact your Sprinter
Dealer.Freightliner-all.book Pag e 210 Monday, December 1, 2003 2:54 PM
