Fuse, Relay, and Diode Assignments – Optional Equipment
Freightliner-all.book Pag e 231 Monday, December 1, 2003 2:54 PM

232 MAINTAINING YOUR VEHICLENOTE: The arrangement of the fuses (1) depends on
the optional equipment installed on the vehicle. The
assignments are shown on the inside of the cover of the
fuse box.
Diodes:No. Circuit
1. Not in use
2. Not in use
3. Not in use
4. Not in use
Fuses:No. Rated Circuit
5. 10A Immobilizer
6. 7.5A Anti-lock brake system (ABS)
7. 25A Anti-lock brake system (ABS)
8. 40A Not in use
9. 40A Anti-lock brake system (ABS)
10. Not in useRelays:No. Circuit
11. Not in use
12. Starter relay
13. Not in use
Freightliner-all.book Pag e 232 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 233
7
BULB REPLA CEMENTSwitch the lights off to prevent short circuits.
Only touch new bulbs with a clean, lint-free cloth. Do
not touch bulbs with wet or greasy fingers.
Only fit 12 volt bulbs of the same type as before and
with the correct wattage rating.
Front Lamp UnitBulbs are changed from inside the engine
compartment.
Move the retainer bar to the side and remove the
housing cover.
WARNING!
Bulbs and bulb holders can become very hot. Al-
low the lamp to cool down before changing the
bulb.
Keep bulbs out of reach of children.
Do not use bulbs which have been dropped or
which show signs of scratches on the glass. They
could explode.
Changing an H7 bulb:
The bulb is pressurized. Always wear eye and
hand protection.
Freightliner-all.book Pag e 233 Monday, December 1, 2003 2:54 PM

234 MAINTAINING YOUR VEHICLE1. Turn signal lamp and sidemarker lamp,
3457 NA – 12V 28 / 7.5W, yellow glass
2. Low beam headlamp, H7 – 12V 55W
3. Fog lamp, H1 – 12V 55W
4. Side and parking lamps, W5W – 12V 5W
5. High beam headlamps, H1 – 12V 55Turn Signal Lamps and Side-Marker Lamps
1. Turn bulb holder, together with bulb,
counterclockwise and remove.
2. Remove the bulb from the bulb holder.
3. Insert a new bulb in the bulb holder.
4. Insert the bulb holder together with the bulb and
turn clockwise to the stop.Freightliner-all.book Pag e 234 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 235
7
Low Beam Headlamps
1. Unplug the cable connector from the bulb.
2. Unclip in the retaining springs. Press the retaining
springs towards the headlamps and down
(direction of arrow).3. Remove the bulb.
4. Insert the new bulb so that the retaining lugs are
fed into the recesses in the reflector section of the
bulb holder.
5. Clip in the retaining springs.
6. Press on the cable connector.
7. Secure the housing cap.Freightliner-all.book Pag e 235 Monday, December 1, 2003 2:54 PM

236 MAINTAINING YOUR VEHICLEFog Lamp (Optional)
1. Remove the cable connector from the bulb holder.
2. Press both retaining springs in the direction of the
headlamps and then outward (in the direction of
the arrow).3. Remove the bulb.
4. Put in the new bulb so that the retaining lugs on the
bulb holder are inserted into the recesses in the
bulb holder reflector section.
5. Secure both retaining springs.
6. Press on the cable connector.
7. Secure the housing cap.Freightliner-all.book Pag e 236 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 237
7
Side and Parking Lamps
1. Pull out the bulb holder with the bulb.
2. Replace the bulb.
3. Insert the bulb holder.
4. Secure the housing cap.High Beam Headlamp
1. Unplug the cable connector from the bulb.
2. Press the retaining spring towards the headlamps
and outwards (direction of arrow).
3. Remove the bulb.
4. Insert the new bulb so that the retaining lugs are fed into
the recesses in the reflector section of the bulb holder.5. Clip in the retaining springs.
6. Press on the cable connector.
7. Secure the housing cap.
Freightliner-all.book Pag e 237 Monday, December 1, 2003 2:54 PM

238 MAINTAINING YOUR VEHICLETaillampsCargo/Passenger Van
1. Locked
2. Unlocked
Bulbs are changed from inside the cargo area.
The rear lamp cluster bulb holder is located behind the
interior paneling. Remove the paneling.Brake lamp, taillamp, standing lamp,
P21/5W – 12V 21/5W
Backup lamp, P21W – 12V 21W
Turn signal lamp, P21W – 12V 21W
Side-marker lamp, R5W – 12V 5W
1. Unclip and remove the bulb socket.
2. To change a bulb, press the bulb into the bulb
socket, turn it counterclockwise and remove.
3. Insert the new bulb.
4. Clip the bulb socket into place.Freightliner-all.book Pag e 238 Monday, December 1, 2003 2:54 PM

MAINTAININ G YOUR VEHICLE 239
7
Chassis
Retaining screws
Clearance lamp, R5W - 12V 5W
Turn signal lamp, P21W - 12V 21W
Stop lamp, P21W - 12V 21W
Taillamp, R5W - 12V 5W
Backup lamp, P21W - 12V 21W
License plate lamp (driver‘s side only),
R5W - 12V 5W1. Loosen retaining screw a and remove lamp
housing.
2. To change a bulb, press the bulb into the bulb
socket, turn it counterclockwise and remove.
3. Insert the new bulb.
4. Install lamp housing.Freightliner-all.book Pag e 239 Monday, December 1, 2003 2:54 PM

240 MAINTAINING YOUR VEHICLELicense Plate Lamps
(Cargo/Passenger Vans Only)1. Press the bulb socket to the left, against the force of
the spring, and remove.
2. Replace the bulb, C5W – 12V 5W.
3. Install the cover.
4. Re-install the bulb socket.
A dditional Brake Lamp
(Cargo/Passenger Vans Only)Retaining screws
1. Take out the retaining screws (1) and remove the
lamp housing.
2. To change a bulb, P21W – 12V 21W
Press the bulb into the bulb socket, turn it
counterclockwise and remove.
3. Insert the new bulb.
4. Install the lamp housing.
Freightliner-all.book Pag e 240 Monday, December 1, 2003 2:54 PM
