DODGE STRATUS COUPE 2005 2.G Owners Manual

SPECIFICATIONS
CONTENTS
mVehicle labeling........................372
N1 - Vehicle emission control information label . . 372
N2 - Vehicle identification number plate.......372
N3 - Vehicle information code plate..........372
N4 - Air conditioner label.................372
N5 - Engine serial number.................373
N6 - Tire and loading information placard.....374N7 - Certification label...................374
mBattery..............................374
mGeneral vehicle data....................375
mTires and wheels.......................375
mVehicle weights........................375
mEngine specifications....................377
mCapacities............................378
10

VEHICLE LABELING
Keep a record of the vehicle identification number as
such information will assist the police if your vehicle is
stolen.
1 -Vehicle emission control information label
The vehicle emission control information label is affixed
on the underside panel of the engine hood.
2 -Vehicle identification number plate
This is stamped on the number plate riveted to the left
front corner of the instrument panel pad. It is visible from
outside of the vehicle through the windshield.
3 - Vehicle information code plate
The vehicle information code plate is located on the
bulkhead inside the engine compartment.
4 - Air conditioner label
The air conditioner label is affixed on the inside panel of
the engine hood.
B02D0350
372 SPECIFICATIONS

5 - Engine serial number
The engine serial number is stamped on the cylinder
block as shown in the illustrations.
B02B05404 CylinderB02B05506 Cylinder
SPECIFICATIONS 373
10

6 - Tire and loading information placard
The tire inflation pressure label is located on the inside
sill of the driver 's door.
7 - Certification label
The certification label is located on the inside sill of the
driver's door.
BATTERY
BCI Group NO.86
Battery is 12 volts.
NOTE: There are various size of the batteries in the BCI
Group No.86.
When you replace a battery, check the size of the battery
to prevent interfering with other parts in the engine
compartment.
B02E0180
B02F0060X
6
7
374 SPECIFICATIONS

GENERAL VEHICLE DATA
Overall length 190.9in (4,850mm)
Overall width 70.3in (1,785mm)
Overall height 53.9in (1,370mm)
Wheel base 103.7in (2,635mm)
TIRES AND WHEELS
Item 2.4 liter3.0 liter
SE R/T
Ti reType Radial, tubeless
Size P205/60R16 91HP215/50R17
90H
Spare tire T125/70D16
WheelType Steel/Aluminum* Aluminum
Size 16x6JJ 17x6 1/2JJ
PCD 4.5 in. (114.3 mm)
Offset 1.81 in. (46 mm)
Spare wheel 16x4T
PCD: Pitch Circle Diameter (installation holes)
*: optionalNOTE:These tires satisfy vehicle loading conditions
described in the owner 's manual.
VEHICLE WEIGHTS
Item 2.4 liter 3.0 liter
Gross vehicle
weight rating4,061lb (1,842 kg) 4,227lb (1,917 kg)
Gross axle
weight
ratingFront
2,171lb (985 kg) 2,322lb (1,053 kg)
Rear
1,894lb (859 kg) 1,905lb (864 kg)
Seating capacity 5 persons
NOTE:For combined weight of occupants and cargo,
refer to the tire and loading information Placard located
on the driver 's door sill.
GVWR: maximum total weight(load) limit speci-
fied for the vehicle
GAWR: maximum weight(load) limit specified for
the front or rear axle.
Seating capacity: the number of maximum occu-
pants
SPECIFICATIONS 375
10

Cargo loads capacity: 150 lbs (68kg) time the des-
ignated seating capacity,
subtract from the vehicle
capacity weight.CAUTION!
Do not use the gross vehicle weight rating data
provided in the chart or on the safety certification
label for determining vehicle passenger and/or cargo
load capacity.
Use the values provided on the tire and loading
information placard (Refer to the section ªVehicle
labelingº).
376 SPECIFICATIONS

ENGINE SPECIFICATIONS
Item Specifications
Engine model 4 Cylinder 6 Cylinder
Engine displacement 2,351dm
3(143.4 CID) 2,972dm3(181.3 CID)
No. of cylinders and cylinder arrangement 4 in-line 6 - V60 É
Bore 86.5 mm (3.41 in) 91.1 mm (3.58 in)
Stroke 100 mm (3.94 in) 76.0 mm (2.99 in)
Compression ratio 9.0 9.0
Controlled by-pass thermostat 88 ÉC (190 ÉF) 88 ÉC (190 ÉF)
Spark plugs NGK BKR5E-11 FR5E1
DENSO K16PR-U11 Ð
CHAMPION RC10YC4 Ð
Spark plug gap 1.0 to 1.1 mm
(.039 to .043 in)0.7 to 0.8 mm
(.028 to .031 in)
Firing order 1-3-4-2 1-2-3-4-5-6
Ignition timing idle speed and mixture Refer to the ªVehicle emission control informationº label
under the engine hood.
NOTE
1. Your engine is equipped with intake and exhaust valve auto-lash adjusters that require no adjustment.
2. Your vehicle has one of the listed spark plugs. Use any one of the listed spark plugs for replacement.
SPECIFICATIONS 377
10

CAPACITIES
Item Capacity Recommended Lubricants
Fuel (approximate) 62dm3(16.3 gal) Ð
Engine oil Oil pan 4dm3(4.2 qt) Engine oils displaying
ILSAC certification symbol
or conforming to the API
classification SL, SL/CF Oil filter 0.3dm
3(0.32 qt)
Power steering 1.2dm
3(1.3 qt) Diamond ATF
Automatic transaxle 4 Cyl.: 7.7dm3(8.2 qt)
6 Cyl.: 8.4dm3(8.9 qt)Diamond ATF SPIII
Manual transaxle 4 Cyl.: 2.2dm3(2.3 qt)
6 Cyl.: 2.8dm3(3.0 qt)Gear oil API classification
GL-4 SAE 75W-85W or
75W-90
Brakes and clutch As required Conforming to Brake fluid
DOT3 or DOT4
Transaxle linkage, Parking brake cable mechanism, hood
lock and hook, door latches, seat adjustersAs required Multipurpose grease NLGI
Grade 2
Engine coolant 4 Cyl.-M/T: *8.0L (8.5 qt)
-A/T: *7.9L (8.3 qt)
6 Cyl.-M/T: *9.2L (9.7 qt)
-A/T: *9.1L (9.6 qt)Long Life Antifreeze Coolant
or an equivalent
Refrigerant (air conditioning) 425g (15 oz) HFC-134a
Windshield washers 4 L (4.2 qt) Ð
*: Include 0.65 L (.69 qt.) in reserve tank.
378 SPECIFICATIONS

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
mSuggestions For Obtaining Service
For Your Vehicle
.......................380
NPrepare For The Appointment............380
NPrepare A List........................380
NBe Reasonable With Requests.............380
mIf You Need Assistance..................380
mWarranty Information...................382
mMopar Parts..........................383
mCustomer Arbitration Board..............383
mReporting Safety Defects.................383
NIn Canada..........................383
mPublication Order Forms.................385
mDepartment Of Transportation Uniform
Tire Quality Grades
....................387
NTreadwear..........................387
NTraction AA, A, B, C...................387
NTemperature A, B, C...................388
11

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you're having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle's
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle's problems or the
specific work you want done. If you've had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE......
DaimlerChrysler Motors Corporation and its dealers are
vitally interested in your satisfaction. We want you to be
happy with our products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. DaimlerChrysler
Motors Corporation dealers have the facilities, factory-
trained technicians, special tools, and the latest informa-
tion to assure your vehicle is fixed correctly and in a
timely manner. DaimlerChrysler Motors Corporation has
empowered its dealers to make warranty and repair
decisions that ensure you are not inconvenienced. There
is no need for you to wait for a decision from the
DaimlerChrysler Motors Corporation. If a special circum-
stance occurs that requires information from
DaimlerChrysler Motors Corporation, we have asked the
dealer's service management to make the contact on your
behalf.
This is why you should always talk to your dealer's
service manager first. Most matters can be resolved with
this process.
