DODGE VIPER 2004 ZB / 2.G Owners Manual

WHAT TO DO IN EMERGENCIES
CONTENTS
mHazard Warning Flasher..................132
mIf Your Engine Overheats.................132
mJump-Starting Procedures.................134
mDriving On Slippery Surfaces..............137NTraction............................137
mFreeing A Stuck Vehicle..................138
mTowing A Disabled Vehicle................139
6

HAZARD WARNING FLASHER
The flasher switch is on the top of the steering
column, just behind the steering wheel. Depress
the flasher button and all front and rear directional
signals will flash. Depress the flasher button again to turn
the flashers off.Do not use this emergency warning system when the
vehicle is in motion. Use it when your vehicle is disabled
and is creating a safety hazard for other motorists.
If it is necessary to leave the vehicle to go for service, the
flasher system will continue to operate with the ignition
key removed.
NOTE:With extended use, the flasher may run down
your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
²On the highways ÐSlow down and use the highest
gear possible.
²In city traffic ÐWhile stopped, put the transmission
in neutral, but do not increase engine idle speed.
132 WHAT TO DO IN EMERGENCIES

²In city trafficÐWhile moving, shift into the highest
gear possible to reduce engine RPM.
NOTE:There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the cooling system and turning off the A/C removes this
heat. You can also turn the Temperature control to
maximum heat, the Mode control to floor, and the fan
control to High. This allows the heater core to act as a
supplement to the radiator and aids in removing heat
from the cooling system.WARNING!
A hot cooling system is dangerous. You or others
could be badly burned by steam or boiling coolant.
If your temperature gauge pointer is in the red area,
turn off the engine immediately. You may want to
call a service center for service. If you decide to look
under the hood yourself, see Section 7 of this
manual. Follow the warnings under the Radiator
Cap paragraph.
WHAT TO DO IN EMERGENCIES 133
6

JUMP-STARTING PROCEDURES
WARNING!
²Do not attempt to push or tow your vehicle to get
it started. Unburned fuel could enter the catalytic
converter and once the engine has started, ignite
and damage the converter and vehicle. If the
vehicle has a discharged battery, booster cables
may be used to obtain a start from a booster
battery or the battery in another vehicle. This type
of start can be dangerous if done improperly, so
follow this procedure carefully.
²Take care to avoid the radiator cooling fan and
accessory drive whenever the hood is raised. You
can be hurt by the moving components.
WARNING!
²Battery fluid is a corrosive acid solution; do not
allow battery fluid to contact eyes, skin or cloth-
ing. Don't lean over battery when attaching
clamps or allow the clamps to touch each other. If
acid splashes in eyes or on skin, flush contami-
nated area immediately with large quantities of
water.
²A battery generates hydrogen gas that is flam-
mable and explosive. Keep flame or spark away
from the top of the battery. Do not use a booster
battery or any other booster source with an output
that exceeds 12 volts.
134 WHAT TO DO IN EMERGENCIES

The battery is located under the battery access panel
inside the trunk on the left side. Remote battery terminals
are located in the engine compartment for jump starting.1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
inadvertent electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach but
WHAT TO DO IN EMERGENCIES 135
6

without letting the vehicles touch. Set the parking brake,
place the transmission in neutral and turn the ignition
OFF for both vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. If you are jump starting your Viper, connect one end of
a jumper cable to the positive terminal of the booster
battery. Connect the other end of the same cable to the
remote battery positive terminal after removing the plas-
tic cover.
5. If you are jump starting another vehicle, connect one
end of a jumper cable to the remote battery positive
terminal post on the Power Distribution Center. Connect
the other end of the same cable to the positive terminal of
the discharged battery after removing the plastic cover.6. Connect the other cable, first to the negative terminal
of the booster battery and then to the ground (on the ear
of the Thermostat Housing) of your Viper as shown.
Make sure you have a good contact.
7. If you are jump starting another vehicle, connect one
end of a jumper cable to the ground (on the ear of the
Thermostat Housing shown in illustration) of your Viper
136 WHAT TO DO IN EMERGENCIES

and the other end to the engine of the other vehicle. Make
sure that you have a good contact on the engines.
NOTE:When using another vehicle as the power
source, turn off all accessories.
8. Turn off the Theft Security System.
NOTE:If system is not turned off, the Theft System
electronics will prevent the engine from starting.
9. Allow battery to charge to at least 12.4 volts before
attempting to start engine.
10. Start the engine in the booster vehicle and let the
engine idle for a few minutes. Then start the Viper
engine. If engine does not start in 15 seconds, stop
cranking engine and allow starter to cool down before
cranking again.
11. When removing the booster cables, reverse the above
sequence exactly.DRIVING ON SLIPPERY SURFACES
WARNING!
Rapid acceleration on slippery surfaces is danger-
ous. You could lose control of the vehicle and possi-
bly have an accident. Accelerate slowly and carefully
whenever there is likely to be poor traction (ice,
snow, wet, mud, loose sand, etc.).
Traction
When driving on wet or slushy roads, it is possible for a
wedge of water to build up between the tire and road
surface. This is hydroplaning and may cause partial or
complete loss of vehicle control and stopping ability. To
reduce this possibility, the following precautions should
be observed:
WHAT TO DO IN EMERGENCIES 137
6

²Slow down during rainstorms or when roads are
slushy.
²Slow down if road has standing water or puddles.
CAUTION!
Driving your Viper through deep puddles at speeds
over 5 mph, may cause water to be ingested into the
engine. This can cause severe engine damage.
²Replace tires when tread wear indicators first become
visible.
²Keep tires properly inflated.
²Maintain enough distance between your vehicle and
the vehicle in front to avoid a collision in a sudden
stop.
FREEING A STUCK VEHICLE
If your vehicle becomes stuck in mud, sand or snow, it
can often be moved by a rocking motion. Turn your
steering wheel right and left to clear the area around the
front wheels. Then shift back and forth between Reverse
and First gear. Usually the least accelerator pedal pres-
sure to maintain the rocking motion without spinning the
wheels is most effective.
CAUTION!
Racing the engine or spinning the wheels too fast
may lead to transmission/axle overheating and fail-
ure. It can also damage the tires. Do not spin the
wheels above 30 mph (48 km/h).
138 WHAT TO DO IN EMERGENCIES

TOWING A DISABLED VEHICLE
Do not tow with sling type equipment. Only use flat bed
equipment. Always comply with applicable state or local
towing ordinances.
CAUTION!
Towing with equipment other than flat bed types
may damage your vehicle.
WHAT TO DO IN EMERGENCIES 139
6
